MDrive17 Speed Control Datasheet REV121704 1
DESCRIPTION
The MDrive17 Speed Control offers
the system designer low cost, intelli-
gent velocity control integrated with a
NEMA 17 high torque stepping motor
and a +12 to +48 volt microstepping
driver.
The MDrive17 Speed Control fea-
tures a digital oscillator for accu-
rate velocity control with an output
frequency of up to 100 kilohertz.
Output frequency will vary with the
signal applied to the speed control
input. Speed can be adjusted by 15-
25kHz PWM, 0-20mA, 4-20mA or
0 to +5 volts.
There are two basic modes of opera-
tion: bidirectional and unidirectional.
By moving the center point, both
speed and direction are controlled
by the IMS Analog Speed Control GUI.
By setting the center point to zero or
the lower end of the potentiometer,
only velocity is controlled by the speed
control input; direction is controlled
by a separate digital input.
The MDrive17 Speed Control has 12
setup parameters, configured using
the supplied IMS Analog Speed Con-
trol GUI. The setup parameters en-
able the user to configure all MDrive
operational parameters which are
stored in nonvolatile memory.
The versatile, compact MDrive17
Speed Control is available in multiple
configurations to fit various system
needs. These options include a single
shaft rotary motor, a dual shaft rotary
motor available with optical encoder
or control knob, a planetary gear-
box, or a long life Acme screw linear
actuator. The rotary MDrive17 is
available in single, double and triple
stack sizes: 13, 15 & 19. Interface
connections are accomplished us-
ing either a 7 position pluggable
terminal strip or 12.0” (30.5cm)
flying leads.
CONFIGURING
The IMS Analog Speed Control is
a required software GUI for quick
and easy parameter setup of the
MDrive17 Speed Control from a
computer parallel/SPI port. GUI
access is via the IMS SPI Inter-
face included on the CD shipped
with the product, or download at
www.imshome.com. An optional
Parameter Setup Cable is available
for ease of connecting and configur-
ing the MDrive.
IMS Analog Speed Control features:
•Easy installation.
•Automatic detection of MDrive
version and communication
configuration.
•Will not set out-of-range values.
•Tool-tips display valid range
setting for each option.
•Single screen interface
(below) .
Configuring the MDrive Speed Control
is simplified with the IMS Analog Speed
Control's single screen interface.
FEATURES
•Integrated Variable Speed
Controller, Microstepping Driver
and NEMA 17 High Torque 1.8°
Stepping Motor
•+12 to +48 VDC Input Voltage
•Digital Oscillator for Accurate
Speed Control
•Low Cost
•Extremely Compact
•Available Configurations:
- Single Shaft*
- Long Life Linear Actuator
- Optical Encoder*
- Control Knob for Manual
Positioning*
- Integrated Planetary Gearbox*
•Three Stack Sizes Available*
•Electronically Configurable
(Eliminates Potentiometers):
- Motor Run/Hold Current
- Acceleration/Deceleration
- Initial and Max Velocity
- Speed Control Input Source
- Microstep Resolution to
256 Microsteps/Full Step
•2 Modes of Operation:
Bidirectional or Unidirectional
•15-25kHz PWM, 0-20mA,
4-20mA or 0 to +5 VDC
Speed Control Input with
Programmable Center Point
•Single Supply
•Interface Uses Pluggable
Terminal Strip or 12.0"
(30.5cm) Flying Leads
•Graphical User Interface (GUI)
for Quick and Easy Parameter
Setup
* Rotary Motor Only
Patent Pending
TM
SPEED CONTROL

MDrive17 Speed Control Datasheet REV121704 2
MDRIVE17 SPEED CONTROL SPECIFICATIONS
GENERAL SPECIFICATIONS
Speed Control Input ................................... 15 to 25kHz PWM, 0 to 20mA, 4 to 20mA or 0 to +5 VDC
A/D Resolution.................................................................................................................... 10 bit
Speed Control Potentiometer Resistance.................................................................................. 10 kΩ
Input Voltage (+V) Range*........................................................................................+12 to +48 VDC
Stop/Start, Direction (Low Level Input) ........................................................................ 0 to +1.5 VDC
Stop/Start, Direction (High Level Input) ...................................................................+3.0 to +5.0 VDC
Input Pull-up Resistance (to +5 VDC) Stop/Start, Direction ...................................................... 4.99 kΩ
Heat Sink Temperature (Max) ..................................................................................................85° C
Motor Temperature (Max).....................................................................................................100° C
SETUP PARAMETERS
NAME FUNCTION RANGE UNITS DEFAULT
ACCL Accel/Decel 2000 to 65000 steps/sec22000
C Joystick Center 0 to 1022 counts 0
DB Deadband 0 to 255 counts 1
DCLT Decel Type Decel at ACCL Rate/No Decel -- Decel
A1 Input Mode Volts/4-20mA/0-20mA -- Volts
FS Full Scale 1 to 1023 counts 1023
MHC Motor Hold Current 0 to 100 percent 5
MRC Motor Run Current 1 to 100 percent 25
MSEL Microstep Resolution 2, 4, 5, 8, 10, 16, 25, 32, 50, 64, 125, 128, 250, 256 µsteps per step 256
RANGE VI/VM Range 1 to 8 -- 3
VI Initial Velocity 1 to 100000 steps/sec 400
VM Maximum Velocity 1 to 100000 steps/sec 20000
PARAMETERS
All parameters are set using the supplied IMS Analog Speed Control GUI.
An optional Parameter Setup Cable is recommended with first orders.
PIN/WIRE ASSIGNMENTS
ENCODER PIN ASSIGNMENTS
ENCODER – Single-End ENCODER – Differential
PIN FUNCTION PIN FUNCTION PIN FUNCTION
1 GROUND 1 NO CONNECT 6 CHANNEL A +
2 INDEX 2 +5 VDC INPUT 7 CHANNEL B –
3 CHANNEL A 3 GROUND 8 CHANNEL B +
4 +5 VDC INPUT 4 NO CONNECT 9 INDEX –
5 CHANNEL B 5 CHANNEL A – 10 INDEX +
Optional Encoder Cables available.
CONNECTOR P1 – Pluggable Terminal Strip or Flying Leads
PIN FLYING LEADS FUNCTION
1 Violet STOP / START INPUT
2 Blue DIRECTION INPUT
3 Green SPEED CONTROL INPUT (0-5V (10K POT)/PWM/4-20mA/0-20mA)
4 Yellow +5 VDC OUTPUT (10K POT)
5 Gray LOGIC GROUND (10K POT)
6 Black POWER GROUND
7 Red
+V (+12 TO +48 VDC)
CONNECTOR P2 (SPI) – 10 Pin Pin-Header
PIN FUNCTION
4 CHIP SELECT
5 GROUND
6 +5 VDC OUTPUT
7 MASTER OUT - SLAVE IN
8 CLOCK
10 MASTER IN - SLAVE OUT
Omitted numbers are NO CONNECT
*Power supply current requirements = 2A (maximum) per MDrive17. Actual power supply current will depend on voltage and load.
NOTE: For recommended mating connector information, refer to the product's Quick Reference at www.imshome.com/quick.html

MDrive17 Speed Control Datasheet REV121704 3
Torque in Oz-In
Torque in N-cm
Speed in Full Steps per Second
500 1000 2000 3000 4000 5000 6000 7000
25
20
15
10
5
0
24 VDC
45 VDC 18
14
11
7
4
45
40
35
30
25
20
15
10
5
0500 1000 2000 3000 4000 5000 6000 7000
S
p
eed in Full Ste
p
s
p
er Second
Torque in Oz-In
Torque in N-cm
24 VDC
45 VDC 28
25
21
18
14
11
7
4
60
50
40
30
20
10
0500 1000 2000 3000 4000 5000 6000 7000
S
p
eed in Full Ste
p
s
p
er Second
Torque in Oz-In
Torque in N-cm
42
35
28
21
14
7
24 VDC
45 VDC
MDRIVE17 MOTOR SPECIFICATIONS
MD1713 Single Stack
Holding Torque ...................32 oz-in / 22.6 N-cm
Detent Torque.................1.66 oz-in / 1.17 N-cm
Rotor Inertia ....0.00053 oz-in-sec2 / 0.038 kg-cm2
Weight (Motor+Driver).............. 9.8 oz / 277.8 g
MD1715 Double Stack
Holding Torque ................60.0 oz-in / 42.4 N-cm
Detent Torque.................2.08 oz-in / 1.47 N-cm
Rotor Inertia ....0.00080 oz-in-sec2 / 0.057 kg-cm2
Weight (Motor+Driver)............ 10.5 oz / 297.7 g
MD1719 Triple Stack
Holding Torque ................74.9 oz-in / 52.9 N-cm
Detent Torque.................3.47 oz-in / 2.45 N-cm
Rotor Inertia ....0.00116 oz-in-sec2 / 0.082 kg-cm2
Weight (Motor+Driver)............ 15.1 oz / 428.1 g
MD1713 Linear Actuator
Maximum Thrust ........................50 lbs / 222 N
Maximum Screw Deflection .......................... ± 1°
Backlash ......................... 0.005 in / 0.127 mm
Weight (without screw)........... 10.4 oz / 294.8 g
TORQUE-SPEED CURVES
Rotary Motor
MD1713 Single Stack
MD1715 Double Stack
MD1719 Triple Stack
FORCE-SPEED CURVES
Linear Actuator
24 VDC
45 VDC
50
45
40
35
30
25
20
15
10
5
001000 2000 3000 4000 5000 6000 7000
22
44
66
88
111
133
177
200
222
155
Force in N
S
p
eed in Full Ste
p
s
p
er Second
Force in lbs
Screw D
Screw C
Screw B
Screw A
Load Limit 50lbs / 222N
50
45
40
35
30
25
20
15
10
5
001000 2000 3000 4000 5000 6000 7000
22
44
66
88
111
133
177
200
222
155
Force in N
S
p
eed in Full Ste
p
s
p
er Second
Force in lbs
Screw D
Screw C
Screw B
Screw A
Load Limit 50lbs / 222N

MDrive17 Speed Control Datasheet REV121704 4
The MDrive17 is available with a Planetary Gearbox
option developed to increase torque at lower speeds,
enable better inertia matching and produce finer
positional resolutions. These efficient, low mainte-
nance Planetary Gearbox come fully assembled with
the MDrive and are offered in a large number of
MDRIVE17 WITH PLANETARY GEARBOX
PLANETARY GEARBOX MECHANICAL SPECIFICATIONS
Dimensions in Inches (mm)
Planetary Gearbox for MDrive17
reduction ratios in 1-, 2- and 3-stage configurations.
An optional NEMA Flange allows mounting the Plan-
etary Gearbox to the load using a standard NEMA
bolt circle. Planetary Gearbox may be combined with
other MDrive17 options, however are unavailable on
Linear Actuator versions.
Planetary Gearbox with Optional NEMA Output Flange
Parameters 1-Stage 2-Stage 3-Stage
Permitted Output Torque (oz-in/Nm)...........................425/3.0 .............1062/7.5 ........2124/15.0
Gearbox Efficiency.......................................................0.80 ....................0.75 ................. 0.70
Maximum Backlash (degree)........................................ 0.80°...................0.85°.................0.90°
Ouput Side with Ball Bearing
Maximum Load, Radial (lb-force/N)............................ 36/160...............52/230........... 67.5/300
Maximum Load, Axial (lb-force/N)............................... 11/50.................18/80..............25/110
Weight - Gearbox Only (oz/g)....................................14.3/406 ............17.9/508 .........21.5/609
Weight - Gearbox & NEMA Flange (oz/g) ...................14.8/420 ............18.5/525 .........22.2/630
M3 x 0.276 (7.0) Deep
1.22
(31.0)
1.22
(31.0)
1.657 SQ.
(42.1 SQ.)
Key DIN 6885-A-3x3x16mm
Ctrg. DIN 332 - D M3
0.08
(2.0)
Ø 0.315 +0/-0.0004 (Ø 8.0 +0/-0.009)
Ø 0.866 +0/-0.002 (Ø 22.0 +0/-0.052)
0.846
(21.5) k2 ±0.02 (±0.5)
Ø 1.654 (Ø 42.0)
1.20
(30.5)
MDRIVE17
Key DIN 6885-A-3x3x16mm
Ctrg. DIN 332 - D M3
M4 x 0.394 (10.0) Deep
M3 x 0.394 (10.0) Deep
0.08
(2.0)
Ø 0.315 +0/-0.0004 (Ø 8.0 +0/-0.009)
Ø 0.984 +0/-0.002 (Ø 25.0 +0/-0.052)
0.984
(25.0) k1 ±0.02 (±0.5)
Ø 1.654 (Ø 42.0)
Ø 1.26
(Ø 32.0)
Ø 1.417
(Ø 36.0)
1.657 SQ.
(42.1 SQ.)
MDRIVE17
1-Stage 2-Stage 3-Stage
3.70:1 13.73:1 50.89:1
5.18:1 15.88:1 58.85:1
6.75:1 18.36:1 68.06:1
19.20:1 71.16:1
22.20:1 78.71:1
25.01:1 92.70:1
26.85:1 95.17:1
28.93:1 99.50:1
34.97:1 107.20:1
45.56:1 115.07:1
123.97:1
129.62:1
139.13:1
149.90:1
168.84:1
181.24:1
195.26:1
236.09:1
307.54:1
Gearbox Ratios (Rounded)
Gearbox Lengths
Inches (mm)
1-Stage 2-Stage 3-Stage
k1 Gearbox 2.736
(69.5)3.248 (82.5)3.76 (95.5)
k2 Gearbox w/
NEMA Flange 2.858 (72.6) 3.37 (85.6) 3.882 (98.6)

MDrive17 Speed Control Datasheet REV121704 5
LMAX LMAX2
SINGLE SHAFT
VERSION CONTROL KNOB or
ENCODER VERSION
Stack Size
1713 2.20 (55.9) 2.92 (74.2)
1715 2.43 (61.7) 3.15 (80.0)
1719 2.75 (69.8) 3.47 (88.1)
Linear Actuator MDrive17
MDRIVE17 SPEED CONTROL – MECHANICAL SPECIFICATIONS
Dimensions in Inches (mm)
Rotary MDrive17: Single Shaft, Control Knob & Encoder Versions
6.00
(152.4)
0.250
(6.35)
0.08
(2.0)
0.25
(6.4)
#8-32 UNC-2A
Thread to within
0.03 (0.76) of Shoulder
2.19
(55.6)
1.66 SQ.
(42.2 SQ.)
Ø 0.866
(Ø 22.00)
+0.000
-0.002
(-0.051)
2.16
(54.9)
P2
P1
1.33
(33.8)
Interface
Option
1.22 ±0.004 SQ.
(31.0 ±0.1 SQ.)
4X M3x0.5 THREAD
x 0.15 MIN DEEP
1.22 ±0.004 SQ.
(31.0 ±0.1 SQ.)
0.177 ±0.002
(4.5 ±0.05)
Interface
Option
0.59 ±0.02
(15.0 ±0.5)
0.08
(2.0)
Ø 0.1968
(Ø 5.0)
+0.000
-0.0005
(-0.012)
4X M3x0.5 THREAD
x 0.15 MIN DEEP
LMAX
LMAX2
P2
P1
1.33
(33.8) 0.94 ±0.02
(24.0 ±0.5)
2.16
(54.9)
1.67 SQ.
(42.4 SQ.)
Ø 0.866
(Ø 22.00)
+0.000
-0.002
(-0.051)
MDrive Lengths Inches (mm)
1.20
(30.4)
1.42
(36.1)
1.90
(48.3
)
Differential
Adapter
.
Ø 0.97
(Ø 24.6)
Control Knob 100 - 1000 Line Encoders
LMAX2 Options
Interface Options
Pluggable Clamp
Type Terminal Strip
0.44
(11.2)
Flying Leads
12.00
+1.0/-0.0
(304.8)
(+25.4/-0.0)

ORDER INFORMATION
Control Knob
The MDrive17 is available with a factory-mounted rear
control knob for manual shaft positioning.
Planetary Gearbox
Efficient, low maintenance Planetary Gearbox are of-
fered assembled with the MDrive17. Details inside.
Encoder
The MDrive17 is available with a factory-mounted
optical encoder. Available line counts are 100, 200,
250, 400, 500 or 1000. All encoders, except
1000 line, have an index mark. Encoders are avail-
able in both single-end and differential configurations.
Order optional Encoder Cables separately:
Single-end Cable (12"/30.5cm) ..... ES-CABLE-2
Differential Cable (36"/91.5cm).....ED-CABLE-2
Linear Actuator
The MDrive17 with long life Acme Screw Linear Actua-
MDRIVE17 SPEED CONTROL – OPTIONS
tor is available with the following travel/full step:
Screw A .............. 0.00125”/full step
Screw B ..............0.000625”/full step
Screw C ..............0.0003125”/full step
Screw D ..............0.00015625”/full step
Standard screw length is 6.0” (152.4mm) plus the
mounting end thread. Custom lengths from 2.0” to
24.0” are available without mounting end thread.
Linear Actuators are Non-Captive style. Contact the
factory regarding Captive Shaft or External styles.
Parameter Setup Cable
A low cost accessory which eliminates the need for
users to wire communications. This 6' (1.8m) cable
includes built-in logic level shifting circuitry to accom-
modate the 3.3v ports on some PCs and plugs in
easily to connect a standard DB-25 PC parallel/SPI
port to the MDrive's 10 pin pin-header (P2). Order
Cable Part No. MD-CC100-000.
†Linear Actuator Available ONLY in Stack Size 13. (MDOX1713LX)
MDO 17
Stack Sizes
13 = Single Stack & Linear Actuator
15 = Double Stack
19 = Triple Stack
†
MDRIVE17 SPEED CONTROL
Example #1: Part Number MDOP1719 is an MDrive17 Speed
COntrol with Pluggable Interface, NEMA 17 motor, stack size 19.
OPTION
Interface Options
F = 12” Flying Leads
P = Pluggable Clamp
Type Terminal Strip
C = 0.0003125”
B = 0.000625”
A = 0.00125”
D = 0.00015625”
N
S = Single End
D = Differential
Line Counts: 100, 200,
250, 400, 500, 1000
L
E
Screw Type (Travel/Full Step)
Encoder
Control
Knob
Linear
Actuator
†
OPTIONS
Example #4: MDOP1719ED500
Adds a 500 line count Differential Encoder
to the part shown in example #1.
Example #2: MDOP1719N
Adds a Control Knob
to the part shown in example #1.
Example #5: MDOP1713LC10.5
MDrive17 Speed Control Linear Actuator
with a 0.0003125”/Full Step Acme
Screw custom cut to 10.5”.
MAY NOT be combined with other options.
Note: MDrive17 Linear Actuator
Available ONLY in Stack Size 13
Custom Screw Length
Range 2.0” to 24.0”
Format XX.X
eg. 08.5 for an 8.5” Screw
(6.0” Screw Length Standard)
G
Planetary
Gearbox
Example #3: MDOP1719G5
Rounding ratio to the nearest whole number,
the above adds a Planetary Gearbox with
5.18:1 ratio to the part shown in example #1.
Add -F if optional NEMA Flange is desired.
Gearbox Ratio
Rounded to Nearest Whole Number
© 2002, 2004 Intelligent Motion Systems, Inc. All Rights Reserved. REV111104
P.O. Box 457, 370 N. Main Street
Marlborough, CT 06447 U.S.A.
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Home Page: www.imshome.com
TECHNICAL SUPPORT
Eastern U.S.
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Western U.S.
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
IMS MOTORS DIVISION
105 Copperwood Way, Suite H
Oceanside, CA 92054
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
IMS EUROPE GmbH
Hahnstrasse 10, VS-Schwenningen
Germany D-78054
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
European Sales Management
4 Quai Des Etroits
69005 Lyon, France
Phone: [phone]
Fax: [phone]
E-mail: bmar[email protected]
German Sales/Technical Support
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Product information covered by IMS Product Disclaimer available at www.imshome.com.
Visit the IMS web site for the most up-to-date product information.
Distributed By:
