Infinite Peripherals LINEA PRO 6 User manual

ABOUT YOUR LINEA PRO 6 CHARGING CUP
GETTING STARTED
QUICK START GUIDE
PRODUCT SPECIFICATIONS
Removal
Installation
Mechanical
Compatibility Linea Pro 6 Standard with
iPhone 6
Linea Pro 6 Rugged Case with
iPhone 6
Weight 56 g (1.98 oz.) 58 g (2.05 oz.)
Dimensions 82.4 mm x 57.9 mm x 29.9 mm
(3.24” x 2.28” x 1.18”)
89 mm x 64.7 mm x 35.7 mm
(3.50” x 2.55” x 1.41”)
Cable Length 3’
Electrical
Connector USB A
Input 5.2V 2.4A DC
Environmental
Operating Temperature 32°F to 95°F (0°C to 35°C)
Storage Temperature -4°F to 113°F (-20°C to 45°C)
Linea Pro®6
Charging Cup
INSTALLATION
1. Ensure environmental conditions
are within appropriate operating
specifications for the charger, as well as
for the Linea Pro 6 and iOS device.
2. Clip the charging cup onto the bottom of
Linea Pro 6 device and check that cup is
properly aligned and fully seated on the
bottom of the Linea Pro 6 device.
3. Plug USB connector end of Linea Pro 6
Charging Cup into appropriate power
supply (5.2V 2.4A, not included).
4. Confirm that the Linea Pro 6 LED
indicator turns green to indicate
charging is active.
Note: Refer to Installation Diagram above.
REMOVAL
1. Grip the bottom of the cup with palm of
hand.
2. Pull down on the rear tab with fingertips
to unlock cup from device.
3. Separate the charging cup from the
device.
Note: Refer to Removal Diagram above.
The following table describes Linea Pro 6 Charging Cup specifications.

Please visit our website at ipcmobile.com,
or contact your Infinite Peripherals account
representative, for additional information
about our current and future product
accessory oerings.
Note: iOS device and other additional items
shown on cover page may not be included.
ACCESSORIES
Mobility Sales/Technical Center
Innite Peripherals, Inc.
17681 Mitchell N
Irvine, CA 92614
Toll-Free: [phone]
Oce: [phone]
Headquarters/Main Warehouse
Innite Peripherals, Inc.
2312 Touhy Ave.
Elk Grove Village, IL 60004
Toll-Free: [phone]
Oce: [phone]
Fax: [phone]
Specications subject to change without notice. Innite Peripherals,
Mobilize Your Enterprise, Linea Pro, Innea, Innea Tab and Innea Omni
are trademarks of Innite Peripherals, Inc. All other trademarks are the
property of their respective owners.
Technical Support
Innite Peripherals, Inc.
17681 Mitchell N
Irvine, CA 92614
Toll-Free: [phone]
Oce: [phone]
Email
[email protected]
Website
ipcmobile.com
•
Note: Box contents and part numbers may vary
based on order configuration.
Infinite Peripherals does not warrant, and is
not responsible for, any damage to the Linea
Pro 6 Charging Cup (“Product”) as a result
of liquid or solid particle intrusion into the
Product or damage caused by dropping the
Product. If a material or workmanship defect
arises with regard to any Infinite Peripherals
product, and a valid claim is received within the
Warranty Period, Infinite Peripherals (at its sole
discretion) will (1) repair the Product using new
or refurbished parts, or (2) replace the Product
with a new or refurbished Product. For purposes
of this limited warranty, “refurbished” means
a product or part that has been substantially
returned to its original specifications. In the event
of a defect, these are your exclusive remedies.
QSG-10025 Rev. B
WARNINGS & CAUTIONS
Please observe the following precautions:
•Keep the charger away from liquids. Do not
immerse the charger in water.
•The charger is intended for Indoor use only.
When not in use, place the charger in a cool,
dry place.
•Do not place the charger near a heat source.
Keep both the power supply and charger
away from direct sunlight and/or heat.
•Device should only be repaired by IPC or an
authorized service facility.
•Do not use any USB connector other than
the one provided with this charger. The use
of any other USB connector may damage the
charger and will void the warranty.
WARRANTY
TROUBLESHOOTING
PRODUCT RETURNS
Use the link provided to create an account
and gain access to our Knowledge Base and
online support services. Through our online
support center, you’ll be able to download
files, open a Support Ticket, manage your
RMAs, view your account Profile and
subscribe to Alerts.
To request a RMA:
1. Create a user account in the RMA
Support Portal at https://ipcmobile.
com/support/rma/
2. Login to your user account and click on
Create RMA Request.
3. Read the instructions provided and
complete the online request form.
4. Note the assigned RMA number and
write it clearly on your shipping carton.
5. Ship your equipment back to us at the
address provided.
ADDITIONAL INFORMATION
Please contact your Infinite Peripherals sales
representative for technical specifications and
additional product documentation.
CONTACT US
No LED illuminated on Linea Pro 6.
• The USB connector is not properly
connected.
• The Linea Pro 6 is not seated properly in
the charging cup.
The LED is illuminated on the Linea Pro 6 upon
installation but then turns o.
• Faulty charging cup.
• Faulty device.
