Infinova V1700N-NE2 Series User manual

V1700N-NE2 Series
IP PTZ Dome Operation Manual
This manual mainly addresses the operation and programming of Infinova V1700N-NE2 series IP domes.
Based on network technology, V1700N-NE2 series IP domes could easily realize network digital video
transmission and network control function, and provide professional remote video services. They provide
high-reliable, cost-effective solutions to various applications.

Notice
Copyright Statement
This manual may not be reproduced in any form or by any means to create any derivative such as translation, transformation, or adaptation
without the prior written permission of Infinova.
Infinova reserves the right to change this manual and the specifications without prior notice. The most recent product specifications and
user documentation for all Infinova products are available on our web site www.infinova.com..
Trademarks
Infinova
®is a trademark of Infinova.
Copyright © 1993-2013 Infinova. All rights reserved.
All other trademarks that may appear belong to their respective proprietors.
FCC Warning
The V1700N-NE2 series IP Domes comply with the FCC rules.
Operation is subject to the following two conditions:
zThis device will not cause harmful interference.
zThis device must accept any interference received, including interference that may cause undesired operations.
The V1700N-NE2 series IP Domes have been tested and found to comply with the limits for a Class A digital device, pursuant to the FCC
rules. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. There is no guarantee that interference will not occur in a particular
installation.

Read this manual carefully before installation. This manual should be saved for future use.
Important Safety Instructions and Warnings:
zElectronic devices must be kept away from water, fire or high magnetic radiation.
zClean with a dry cloth.
zProvide adequate ventilation.
zUnplug the power supply when the device is not to be used for an extended period of time.
zOnly use components and parts recommended by manufacturer.
zPosition power source and related wires to assure to be kept away from ground and entrance.
zRefer to qualified personnel for all service matters.
zSave product packaging to ensure availability of proper shipping containers for future transportation.
Indicates that the un-insulated components within the product may carry a voltage harmful to humans.
Indicates operations that should be conducted in strict compliance with instructions and guidelines contained in this manual.
Warning: To avoid risk of fire and electric shock, keep the indoor product away from rain and
moisture!

Table of Contents
Chapter I System Introduction..................................................... 1
1.1 Product Description .............................................................. 1
1.2 Product Features ................................................................... 1
1.3 Product Model....................................................................... 1
1.4 Product Specifications .......................................................... 1
1.5 Notice.................................................................................... 2
Chapter II IE Browser Setting...................................................... 3
2.1 Software Installation ............................................................. 3
2.2 Set IE Browser ...................................................................... 3
2.3 Installation Viewer Software................................................. 3
Chapter III Basic Function Operation......................................... 4
3.1 Login..................................................................................... 4
3.2 System Information............................................................... 5
3.3 Account Settings ................................................................... 6
3.4 Network Settings................................................................... 7
3.4.1 IPv4 Settings ................................................................. 7
3.4.2 Network Link ................................................................ 7
3.4.3 FTP Settings .................................................................. 7
3.4.4 SMTP Settings............................................................... 8
3.4.5 SNMP Settings .............................................................. 8
3.5 Time Settings ........................................................................ 8
3.6 Alarm Settings....................................................................... 8
3.7 PTZ Settings ......................................................................... 9
3.8 System Log ........................................................................... 9
3.9 Deinterlaced Settings ............................................................ 9
3.10 Record Management ......................................................... 10
3.11 Security ............................................................................. 11
3.12 Advanced Settings............................................................. 11
3.12.1 Software Update........................................................ 11
3.12.2 Factory Settings......................................................... 12
3.12.3 Online Reboot ........................................................... 12
Chapter IV H.264 Video and Parameter Settings ..................... 13
4.1 Video Size ........................................................................... 13
4.2 Player.................................................................................. 13
4.3 Stream Type ........................................................................ 13
4.4 Motion Detection ................................................................ 13
4.5 Privacy mask....................................................................... 14
4.6 Color Setting....................................................................... 14
4.7 Video Quality...................................................................... 14
4.8 OSD Settings ...................................................................... 14
4.9 Qos Setting ......................................................................... 15
4.10 Resolution Setting............................................................. 15
4.11 I/P Rate ............................................................................. 15
4.12 Frame Rate........................................................................ 15
4.13 Bit Rate............................................................................. 15
4.14 Audio ................................................................................ 16
4.15 Snapshot............................................................................ 16
Chapter V M-JPEG Video Setting ............................................. 17
5.1 Resolution........................................................................... 17
5.2 Image Quality ..................................................................... 17
5.3 Frame Rate.......................................................................... 17
5.4 Snapshot.............................................................................. 17
Chapter VI Menu Settings .......................................................... 18
Chapter VII Camera Control ..................................................... 20
7.1 Lens Direction Control ....................................................... 20
7.2 Lens Function Setting ......................................................... 20
7.3 Camera Control Function.................................................... 20
7.3.1 Speed Adjustment........................................................ 21
7.3.2 Setting Preset and Calling up Preset............................ 21
7.3.3 Setting Pattern and Calling up Pattern......................... 21
7.3.4 Setting Autopan and Calling up Autopan .................... 21
7.3.5 Calling up Autoscan .................................................... 21
7.3.6 Lens Flip 180°............................................................. 21
Appendix I Magnetic Ring Filter Instruction ........................... 22
Appendix II Questions & Solutions............................................ 23

1
Chapter I System Introduction
1.1 Product Description
This manual addresses the operation and programming procedures
of Infinova V1700N-NE2 series IP domes.
V1700N-NE2 series IP PTZ dome camera is the newly developed
video surveillance product. Based on the network technology, the
network dome cameras can easily realize digital video transmission
which can provide professional services for the security filed.
The special network video module for the network dome supports
H.264/M-JPEG compression formats, providing high quality
real-time images by 30 frames per second. Three simultaneous
video streams transmission supported, the dome can select the
transmission on major stream or minor stream as per different
applications. The dome features motion detection function, and can
perform intelligent surveillance schedule and storage strategy via
the management platform.
Infinova's V1700N-NE2 series IP PTZ dome camera also support
multi-user access simultaneously. The built-in web server support
dome control by IE 6.0 or later. Two-way audio, OSD, and dynamic
adjustment of the encoding parameters are also supported.
The domes are available with the zoom lenses of 18X, 23X, 28X,
30X, 35X and 36X optical zoom and 12X digital zoom. Users can
control the domes with the speed from 0.08°/s to 400°/s. The
precise motor ensures the fast response, smooth running and low
noise of the domes. The domes also support functions like Preset,
Autoscan, Pattern, high speed Autopan etc.
1.2 Product Features
•Available with Sony and Hitachi etc. camera modules
•18X, 23X, 28X, 30X, 35X, and 36X optical zoom selectable
•H.264 / M-JPEG dual stream compression and three
simultaneous video streams
•Motion detection
•Two-way audio (optional)
•Alarm function (optional)
•Multiple handling ways of the alarm, e.g. Email sending, FTP
unloading, audible warning, relay output
•Remote PTZ control
•Dynamic I-P rate
•Dynamic adjustment of quality and compression rate
•Image snapshot
•Remote upgrade
•SD card storage (for PoE domes)
•Support TCP/IP, HTTP, HTTPS, ICMP, IGMP, UDP, SMTP,
RTP, RTSP, SNMP, 802.1X protocols
•Support multi-user access and parameters configuration
simultaneously via Web server
•Qos service, providing high quality video transmission
•Available with 254 presets, with the maximum speed up to
400°/S and precise locating
•Home return function, linkaged with preset, pattern and
autoscan
•Auto iris, auto focus, backlight compensation, auto gain
control
•Pattern, high speed autopan, auto flip
•Password protection, preventing from illegal alteration of the
dome menu
•Privacy mask function effectively shade the unwanted areas
•Indoor/outdoor mounts, high adaptability
•IP66 environmental rating, built-in heater and air cycle system,
anti-freeze design
•Modularization design for fast and precise installation
•Practical anti-dropping design
•Power supply of 12VDC and 24VAC
•Optional PoE power supply
1.3 Product Model
V17 X X N -N X XX X X E 2 X
Indoor --- 2
18X ---5
23X ---7
28X ---8
6 --- 24VAC
C--- Ceiling
C2 --Clear
S2 -- Smoked
C3 --Vandal-resistant clear
S3 Vandal-resistant smoked
35X ---9
--
Outdoor --- 4
B--- Bracket
5 --- 12VDC
30X --- 4
---NH.264/M-JPEG
36X --- 3
NTSC/EIA--- 0
PAL/CCIR--- 1
W--- With alarm/audio/RS485
Null ---Without alarm/audio/RS485
0---PoE
Bubble
1.4 Product Specifications
Operation Specifications
Programmable Presets: 254
Programmable Patterns: 4
Programmable Autopans: 4
Programmable Areas: 16
Video Blanking Sector: 16
Spherical Privacy Zone: 4 (23X/30X/35X), 24 (18X/28X/36X)
Tour: 6
Home Return: Yes
Autoscan: Yes
Image Mirror: Yes
WDR: Yes (for 23X/30X/35X/36X)
FNR: Yes
Image Stabilize: Yes (for 28X/30X/35X/36X)
Zoom Window: Yes (for PELCO-D protocol)
Communication Protocols: INFINOVA, PELCO-P/D
(self-adaptable)
Number of Addresses: 1~254
Baud Rate 2400/4800/9600bps optional

2
Video
Video Compression: H.264/M-JPEG
Max Resolution: 4CIF @ H.264/M-JPEG
Optional Resolution:
Major Stream:
NTSC: 4CIF (704 × 480) / 2CIF (704 × 240) /
CIF (352 × 240) / QCIF (176 × 120);
PAL: 4CIF (704 × 576) / 2CIF (704 × 288) /
CIF (352 × 288) / QCIF (176 × 144)
Minor Stream:
NTSC: CIF (352 × 240) / QCIF (176 × 120);
PAL: CIF (352 × 288) / QCIF (176 × 144)
Max Frame Rate: 25fps (PAL); 30fps (NTSC)
Audio (optional)
Audio Compress: G.711
Audio Interface: 1 input / 1 output
Network
Protocol: TCP/IP, HTTP, HTTPS, ICMP, IGMP,
UDP, SMTP, RTP, RTSP, SNMP,
ARP, 802.1x
Output Bit Rate: Variable bit rate;
Constant bit rate: 256 Kbps~3 Mbps
Alarm (optional): 2 alarm inputs, 2 relay outputs
Motion Detection: 4 motion detection areas
Electrical
Input Voltage: 12VDC, 24VAC or PoE
Power Surge Protection: Yes
Power Consumption
Indoor: 12VDC: 21W
24VAC: 28W
PoE:30W
Outdoor: 12VDC: 27W (with heater)
24VAC: 43W (with heater)
PoE:44W(withheater)
Note: PoE supply consumption includes PSE module power
consumption and Ethernet wire consumption.
Mechanical
Manual Speed: Pan: 0.08°~200°/s
Tilt: 0.2°~100°/s
Preset Speed: 400°/s at the most
Pan Travel: 360° continuous
Tilt Travel: 0°~90°
Preset Accuracy: ±0.1°
Motor: Stepping motor
Product Dimension:
Indoor:
Height 313mm × Ф218mm/ Height 12.3" × Ф8.6" (Bracket)
Height 240mm × Ф214mm / Height 9.4" × Ф8.4" (Ceiling)
Outdoor:
Height 313mm × Ф240mm / Height 12.3" × Ф9.4" (Bracket);
Height 300mm × Ф218mm / Height 11.8" × Ф8.6" (Ceiling)
Shipping Dimension (Length× Width× Height):
19.1" × 10.65" × 11.8" (485mm × 270mm × 300mm)
Environmental
Operating Temperature: 14°F~140°F (-10°C~+60°C) (indoor)
-40°F~140°F (-40°C~+60°C)(outdoor)
Operating Humidity: 0~90%RH (non-condensing)
1.5 Notice
1. Re-power the IP dome 10 seconds after it powers off.
2. Refer to the descriptions under the interfaces of the super users
for interface control when logging in as a common user.
3. Firstly perform Network Settings after login. Gateway address
should be set as the one that connected to the super domes.
4. IP address is not allowed to conflict with other devices’ IP
address; otherwise the images couldn’t be viewed.
5. No need to restart the system after performing network settings.

3
Chapter II IE Browser Setting
To view the video images, users shall configure the IE browser
settings for monitors or other viewing devices, and set system
functions according to the system prompts. The following points
shall be noted when setting the IE browser:
zSupport IE browser version: Internet Explorer 6.0 or later;
zBefore attempting to view the image, make sure the system have
installed InfiH264.cab controls and supports Directx 9.0c image
view software.
zInstall Quicktime control.
2.1 Software Installation
The V1700N-NE2 Series domes can be connected to computer or to
the network directly.
Note: Check if the connection is tight before power-on.
2.2 Set IE Browser
Users can view the images and relative interfaces that caught by
camera over IE browser or V2216 etc. software. To view images
over IE browser, ActiveX control shall be installed beforehand,
otherwise, the view can not be performed normally. To install the
controls, the security property of the IE shall be set.
(1) As shown in the following figure, click “Tool” in the menu
bar, and then click “Internet Options” on the pop-up menu.
Figure 2-1
(2) Select “Security” tab in the interface as shown below:
Figure 2-2
(3) Click “Custom Level” to pop up the following interface in the
figure below:
Figure 2-3
(4) Enable or prompt the option of “Download unsigned ActiveX
controls”.
(5) Select “low” in the “Reset custom settings”.
2.3 Installation View Software
The installation procedures of V1700N-NE2 IP dome image view
software are listed as follows:
(1) Download OCX
First, user has to log in with the Infinova super ID and password
(For more information, please refer to Chapter 3.1 Login). After
successfully logging in, you will be informed that the browsing

4
OCX is needed, which is shown as below:
Figure 2-4 OCX Installation
(2) Install OCX
According to the installation information, click “OK” button, then
the system will automatically install OCX. Real-time video is
displayed on the screen as follows after installation.
Figure 2-5 Download OCX
If the installation above fails, move forward according to the
following steps to continue:
(3) Install DirectX End-User Runtime (Directx 9.0c) version 9.0c
or above, which can be downloaded at
http://www.microsoft.com/downloads/details.aspx?FamilyId=0A9B
6820-BFBB-4799-9908-D418CDEAC197&displaylang=en
(4) Install Microsoft NET Framework Version 1.1 Redistributable
Package, which can be downloaded at
http://www.microsoft.com/downloads/details.aspx?FamilyID=262d
25e3-f589-4842-8157-034d1e7cf3a3&displaylang=en
The software above is in English and free of charge.
Note:
1. The steps mentioned above are not in sequence. Please try
step 1 and 2 first, and if it fails, you can proceed to step 3 or
4.
2. If the adopted operating system is Microsoft Windows 2003,
and the images can not be viewed after the control installed,
then please enable the acceleration function of the computer
hardware.
The preparation of IE image browsing comes to an end.
Chapter III Basic Function Operation
This chapter mainly introduces the settings and operation of
V1700N-NE2 IP domes.
3.1 Login
Please open IE browser after it powers on for about 50 seconds and
enter http://192.168.1.100/ (the default IP address) in the IP address
for example.
The login dialog box displays as below:
Figure 3-1. User Login
If this is the first time to run the software, you should enter the
default super username and password. There is one default ID:
admin (password: admin). Click “OK” button to log on.
In the logging in process, to re-input the username and password,
please click “Cancel”.
(1) If login as the super user, the following interface will display:
Figure 3-2. Super User Interface after Login
(2) If login as the common user, the following interface will
display:

5
Figure 3-3. Common User Interface after Login
The dome supports H.264/M-JPEG dual compression formats. The
system default is H.264 compression format after login successfully,
and you can click “M-JPEG” button to enter real-time video
interface under M-JPEG format as shown in figure 3-4.
Figure 3-4. M-JPEG interface
In the live view interface, users can configure parameters about
video, audio, privacy mask, motion detection, and stream type etc,
so as to obtain the desired surveillance performance. The Manual
will introduce the parameter configure under different format of
H.264 and M-JPEG in Chapter IV and Chapter V.
Users can enter system setting interface by clicking the button
“Settings” in the live view interface.
System setting interfaces of super and common user are shown as
follows:
Figure 3-5. Setting Interface for Super User
Figure 3-6. Setting Interface for Common User
Via the navigation menu on the left part of the interface, super user
can perform the following functions: view system information, user
management (add/delete user, change password), PTZ settings,
Network settings (including IPv4 network settings, Network link
settings, SMTP settings, FTP settings, SNMP settings), time
settings, alarm settings, Record settings, Security settings, and other
advanced setting (including remote update, factory restore and
system reboot).
Common users only can view system information, change his own
password, and view system log.
Note: The following descriptions are used for the super
user.
3.2 System Information
The initial interface of the system is the “System Settings” interface,
which displays related system information, like: basic information
of system, network settings, NTP settings, video parameter settings,
alarm settings, H.264 and M-JPEG video settings etc.

6
3.3 Account Settings
There is one default super user: admin (password: admin). The
super user can add or delete common users and alter the password
of common users. The system supports at most 7 common users.
The following part will introduce how to add and delete users by
super user.
After logging in as a super user, click the button.
The Account Settings interface will display all of the user
information. And the item of “Num” will display the total number
of the users; in the “Property” item, stands for super user,
while stands for common user; and in the “Operation” item,
click to delete, and click to edit user information.
Figure 3-7. Account Setting
1. Add Users
(1) Click , enter the interface of “Add a User”.
Figure 3-8. Add User
(2) Enter the desired User Name and Password (Special
characters are not allowed to appear in User Name or
Password, and number of password characters can be between
8-20 characters, the length of the user name is not more than
30 characters).
(3) Click “OK” button. If the setting is successful, the new user
name will appear in the following account list. E.g. adding
“USER1” as the new user.
Figure 3-9 Add User
(4) If the user exists, the following interface will display:
Figure 3-10
Click “OK” button, the image will be back to Figure 3-9.
If the 9th user is to be added, the following box will pop up:
Figure 3-11
2. Delete Users
Click button behind the common user to be deleted in the
account list, then the following figure will display:
Figure 3-12
Click “OK” button, the selected user will be deleted and the
account list will be automatically updated.
3. Change User Password
Click button in the account list, the dialog box of Edit User
Information will pop up:
Figure 3-13
Input the old password, enter your desired new password for twice
and then click “OK” button, the following figure will appear:
Figure 3-14

7
Important notes:
1) Super user’s password can only be edited.
2) Common user’s password can be edited by both super user and
himself.
3.4 Network Settings
Click button in the navigation bar, the following
interface concerning network parameters will display:
Figure 3-15
The MAC address in the interface is the MAC address of the device,
which can not be changed. Other items like IPv4, Network link,
FTP, SMTP and SNMP in the interface are settable.
3.4.1 IPv4 Settings
Figure 3-16
Users can set Address type, Unit IP address, Subnet mask and
Gateway IP address.
Address Type: display the way of IP address distribution: manually
configured. “Manually configured” means that the following items
can be set in the interface.
Unit IP address: used to set the IP address of the domes.
Subnet mask: used to set subnet mask of the domes.
Gateway IP address: used to set the gateway address of the domes.
When all settings are finished, click “Set” button. The following
interface will appear:
Figure 3-17
Click “OK” button, the system will skip to login interface
automatically.
3.4.2 Network Link
Figure 3-18
In this interface，users can choose the Network Link modes. There
are five modes available:
1. 10M-half
2. 10M-full
3. 100M-half
4. 100M-full
5. Auto
Click “Set” to finish the setting.
Note:
1. When select the options of 10M-half and 10M-full, the network
link indicator will not indicator.
2. Only the super user can set this option.
3.4.3 FTP Settings
Figure 3-19
V1700N-NE2 series dome has the function of alarm associated with
FTP uploading.
Configure server IP, user name and password in the FTP setting
interface and enable FTP alarm function in alarm settings, then FTP

8
image uploading for alarm triggered can be achieved.
3.4.4 SMTP Settings
V1700N-NE2 series IP domes support signal switch alarm and
motion detection alarm, triggering Email sending. To realize the
functions, the mail server and receiver information shall be set in
the SMTP setting interface.
In the Navigation bar, click Network to enter the following SMTP
interface.
Figure 3-20
zServer IP: set mail server address.
zFrom: set sender’s mail address.
zTo: mail address of recipient.
zCC: mail address of the person copy to.
zAuthentication: enable or disable authentication function. This
function should be set according to authentication requirements
of mail server.
zUser name: sender’s name, it can be set according user’s needs.
zPassword: set sender’s password.
Note: There is no limit for Sender’s name and password settings.
After setting completes, click “Set” button to take effect.
If user selects “mail” in “Alarm Settings” interface, system will
send mail according to SMTP settings.
3.4.5 SNMP Settings
Figure 3-21
V1700N-NE2 series dome supports heartbeat function.
In SNMP settings interface, enable the Heartbeat function and then
set heartbeat sever IP address and heartbeat interval, the heartbeat
package will be sent to the server or client at the designated
intervals, which greatly facilitates the server or client to know about
the camera’s network status.
3.5 Time Settings
Click button in the navigation bar to display the
following Time Zone Settings interface:
Figure 3-22
3.5.1 Time Zone Setting
Select time zone in the drop-down list and click “Set” to finish the
setting.
There are 33 time zones available: GMT-12:00 ~ GMT ~
GMT+13:00, and the default setting is GMT Greenwich Mean
Time.
For Daylight Saving Time enable region, please check
“Automatically adjust clock for daylight saving changes”.
3.5.2 Time Mode Setting
Synchronize with computer time: used to check the time of
system with the local PC time. Click “Set” to adjust.
Synchronize with NTP server: whether to select NTP server or not.
Select “NTP” to enable NTP server, or otherwise disable NTP
server.
If NTP server is selected, you can input NTP server address in the
IP bar. Click “Set” to finish. If so, the system will adjust time with
NTP server automatically.
3.6 Alarm Settings
Click button in the navigation bar to display the
following Alarm Settings interface:
Figure 3-23-1 Alarm settings (for 12VDC and 24VAC domes)

9
Figure 3-23-2 Alarm settings (for PoE domes)
V1700N-NE2 series IP domes support 2 switch value alarm inputs,
and users can select the state of the alarm inputs.
Note:
For PoE domes, the alarm is triggered by the High-low electrical
level. When supply the direct-current voltage of 5~15V between the
ports Alarm_In1 or 2 and Alarm_In_Com, the high level will be
triggered; and when the voltage is lower than 2V or the circuit is
open, then the low level will be triggered.
For non-PoE domes, the alarm is triggered when the circuit is
grounding or open.
Alarmout contact: used to set alarm output triggering method:
local contact and net contact optional.
Local contact: I/O out is triggered by I/O in or motion detection
alarm source. The default is local contact.
Net contact: I/O out is triggered by the monitoring management
software.
Note: This function needs to be supported by digital video
surveillance management software like V2216. If Net Contact is
selected, users have to set Alarm Server IP the same as the IP
address of V2216-CMS server. When the setting is finished, users
can remotely control the relay via V2216 software. For detailed
information, please refer to V2216 manual.
Alarm Server IP: used to set the IP address of alarm server when
NET contact is selected. If alarm occurs, it will inform the alarm
server.
Users can set alarm handling ways for switch value alarm input (2
inputs optional) or motion detection (4 areas optional) alarm, like
sending mail, FTP uploading, audible alarm, and relay output. After
setting completes, click “Set” button to take effect.
3.7 PTZ Settings
Click button in the navigation bar to display the
PTZ Setting box:
Figure 3-24 PTZ Interface
Camera address: set the distributed address of V1700N-NE2 IP
domes. The address shall be the consistent with the address set by
the DIP switch.
Baud rate: set the communication baud rate of control and camera
modules, the default value is 2400 bps. The options include 1200
bps，2400 bps，4800 bps，9600 bps，19200 bps，38400 bps，57600
bps.
Protocol: select the corresponding protocol of camera. The built-in
service software in this IP dome supports Pelco-P, Pelco-D and
Infinova.
3.8 System Log
Click button on the navigation bar to enter the
system log interface shown as below:
Figure 3-25
It can display 30 logs on one page. Users can turn over the page by
clicking the below arrows or skip to the designated page by clicking
“Goto”. Click “Delete logs”, a prompt will come out. Then, click
“Yes” to clear logs.
3.9 Deinterlaced Settings
Click button, and then comes out the deinterlaced
settings interface:

10
Figure 3-26
It is recommended to enable the Deinterlaced function of the
system when there are much of dynamic scenes, and to disable the
function when the major scenes are static.
Select “On” or “Off” and then click “Set” to finish the setting.
3.10 Record Management
3.10.1 Recording Control
There are 2 tab pages in the Record Management interface:
recording control and replay.
Click “Record Management” in the navigation bar, and select
“Recording Control” to display the interface below:
Figure 3-27 Recording Control
Recording storage mode: “Circle Mode” and “Stop Mode”
optional. In “Circle Mode”, when the SD card is full, the new
recorded files will cover the odd ones; and in “Stop Mode”, the
system will stop recording when the SD card is full.
Manual recording control: start or stop the manual recording.
Alarm recording: enable or disable the alarm recording function.
Automatic recording when network anomaly: enable or disable
the automatic recording function when the network anomaly.
Note: The system only support recording control of the minor
streams. If the resolution of the minor stream is set as “OFF”, then
the recording can not be performed.
Non-PoE domes do not support SD card storage.
Users can check full space and free space of the SD card and format
the card.
Place click “Uninstall SD card” if you want to unplug the SD card
in working.
3.10.2 Replay
Click “Record Management” in the navigation bar, and then
select "Replay" to display the interface below:
Figure 3-28 Replay
Click the option tab “Replay” and set up the InfiReplayAX control
as per the prompts.
If no prompts pop up and the video replay interface doesn’t display
normally, please modify the security settings of the IE browser.
1. Select “Tool” in the menu bar, and then select “Internet Options”
from the drop-down menu;
2. Select “Security” from the popup interface;
3. Select the Internet icon and click the option “Custom Level”;
4. Change all the “Disable” options to “Enable” or “Prompt” for
ActiveX control;
5. Select the option tab “Privacy” in the interface of “Internet
Options” and uncheck the box of “Pop-up Windows Blocked”.
After setup finished, brush the webpage and the replay interface can
display normally.
Video Search: set the start and end time, and then click the search
button. All videos recorded during this period of time will display in
the list.
Figure 3-29 Video Searching

11
Replay: to replay a video, double click a file in the list with the
mouse or select a file and then press the “Play” button . During
playing, click or to pause or stop playing.
Download: You can download the videos stored in the SD card to
your PC. Select the file from the video list (also you can select
multiple files simultaneously using the key “Ctrl” or “Shift”), and
then click the button “Download” to enter the downloading
interface.
Figure 3-30 Downloading Videos
Local download path: Set the path to save the downloaded files. If
resetting required, click the button “Browse”.
Click the button “Start Download”, and then the files in the list will
be downloaded in order.
The downloading progress can also be displayed. It shows 100%
after downloading is finished.
3.11 Security
Figure 3-31 Security
V1700N-NE2 Series IP domes support https and 802.1x protocols.
In the Security interface, the relevant settings about https and
802.1x can be done.
3.12 Advanced Settings
V1700N-NE2 series provides a series of advanced functions, such
as Software Update, Factory Settings and Online Reboot.
Click button to enter the interface shown below:
Figure 3-32
3.12.1 Software Update
Free software update is provided for V1700N-NE2 series IP domes,
and this update service can reduce system maintenance budget. You
can download the latest software from the Internet.
Follow the steps below to update software:
Figure 3-33
Click “Browse” button above, then select program update in the
pop-up dialog box. After that, click “Upload” button, the system
begins to update.
If update successfully, the following information will appear on the
current interface:
Figure 3-34
If the type of updating file is wrong, the following information will
come out:

12
Figure 3-35
At this time, re-check the updating file and camera system, or
otherwise choose other program to update.
Note: After update successfully, it needs to restart the system.
3.12.2 Factory Settings
Figure 3-36
Click “Set” button, the following hint would display:
Figure 3-37
Click “OK”, system starts to reset to the factory default. It takes
about 15 seconds to undertake this process, when finishing, the
figure below would appear:
Figure 3-38
Click “OK” button to close the webpage.
Note:
1. When factory setting is finished, IP address resumes to
192.168.1.100, while subnet code resumes to 255.255.255.0.
2. Only super users can set this option.
3.12.3 Online Reboot
Figure 3-39
Click “Reboot”, the system will be automatically re-started. And
after 80 seconds the webpage closes.
Note: only the super users can set this option.

13
Chapter IV H.264 Video and Parameter
Settings
When login successfully, the interface will be “H.264” (as shown in
figure 3-2 or 3-3). It can switch to full-screen mode by double
clicking the video window, and exit full-screen mode by double
clicking again. A serial buttons on the left help you to set
concerning parameters such as video setting, motion detection,
Privacy masks, OSD, audio, stream type, player and so on.
The system supports dual encoding stream, and it can set video
parameters under Major stream and Minor stream separately. Below,
take the video settings under Major stream as an example.
Common user is just able to set the four items: video size, stream
type, audio and player.
4.1 Video Size
Click the “Video Size” button in the navigation bar to display the
following interface:
Figure 4-1
Enter the desired value in the Width and Height field, and click
“Set” to confirm.
A 704*576 picture indicates 704 pixels in width, and 576 pixels in
height. Other settings are alike in signification.
Recommended settings:
704*480 (NTSC format) or 704*576 (PAL format)
The selectable video image sizes include:
NTSC: 704*480, 704*240, 352*240;
PAL: 704*576, 704*288, 352*288, 176*144.
4.2 Player
Click “Player” button, and Player setting interface will be shown as
follows:
Figure 4-2
Users can select player to play video:
Infinova Player: select Infinova player to play video.
Quick Time: select Quicktime Player to play video.
Note: When “Quick Time” is selected, system will prompt you to
input username and password to conduct confirmation, and the
username and password are the codes you used in logging in.
4.3 Stream Type
Click “Stream Type” button, and Stream Type interface will be
shown as below:
Figure 4-3
There are 2 options: Major stream and Minor stream. You can set
the separate settings under different stream types, and the different
video parameter settings under the steams are independent.
4.4 Motion Detection
Click 【Motion Detection 】button to display the following
interface regarding motion detection sensitivity:
Figure 4-4
Sensitivity: set the sensitivity, the value is between 1 and 30.
The recommended setting: 15. The smaller the value is, the higher
the sensitivity is.
Motion detection area 1-4: Two coordinates determine an area.
The line between those two points is the diagonal of detection area.
Each point extends along 2 lines perpendicular to the X-axis and
Y-axis, and the rectangle formed by those 4 crossed lines is the
motion detection area. The selectable value on X-axis can be any of
whole numbers from 0 to 44, while Y-axis can be any of whole
numbers from 0 to 36.
Note:
The zero point of the coordinates is the left upper corner of the
view.
The X/Y values of the second point shall be larger than that of the
first point in the coordinates.

14
If there is any motion detection alarm in the preset area, the alarm
icon on the webpage will turn red . If it’s normal, the icon is
grey .
Note: If the motion detection alarm is on, you need to wait about 5
seconds for motion detection alarm checking.
4.5 Privacy mask
Figure 4-5
V1700N-NE2 series domes support privacy mask function. If there
is certain location within the surveillance area where operators are
not allowed to see, and thus, PRIVACY MASK can be applied.
System covers and shields the sensitive area via Privacy MASK
setting, to avoid operators observing certain sensitive locations on
monitor.
Area: Two coordinates determine an area. The line between those
two points is the diagonal of detection area. Each point extends
along 2 lines perpendicular to the X-axis and Y-axis, and the
rectangle formed by those 4 crossed lines is the motion detection
area. The selectable value on X-axis can be any of whole numbers
from 0 to 44, while Y-axis can be any of whole numbers from 0 to
36.
Note: The horizontal ordinate and vertical ordinate of the second
point should be greater than that of the first point. Plus, the area of
Privacy Mask shouldn’t over 396. User can use formula:
(X2-X1)*(Y2-Y1) to calculate the area.
Tick “Enable” means Privacy mask function is enabled. After
finishing the setting, click “Set” to make it effect.
4.6 Color Setting
Click “Color Setting” button, and then comes out the color
saturation option:
Figure 4-6
The parameters adjusted here include: brightness, hue, contrast and
saturation.
Brightness: Natural (default)
Hue: 0 (default)
Contrast: 128 (default)
Saturation: Average (default)
4.7 Video Quality
If the bit rate set as “Variable bit rate” (vbr), in the left navigation
bar, you will see “Video quality” button under the “Color setting”
button, click “Video quality” to display the interface. The higher the
level is, and the clear the image is. After the desired option is
selected, click “set” button to finish the setting.
4.8 OSD Settings
Click “OSD” button in the navigation bar to display the following
interface:
Figure 4-7
OSD settings include: Text OSD, Date OSD and Time OSD.
Text OSD:
It is used to set the contents of text, its position where to display
and display status.
zText: the contents of the title. Display no more than 30
characters.
zX-axis &Y-axis: the title Axis location. Both X-axis and Y-axis
can be any of a whole number from 0 to 99.
Click “Display” to enable text display. And click “Set” button to
take the setting into effect. To disable the display function, cancel
the option click.
Date OSD: to set the date format, the display position; to enable or
disable the date OSD.
Time OSD: to set the time display position; to enable or disable the
time OSD.
After all settings finished, click “Set” button. If display enabled,
then the setting will appear on the screen at designated location.
