InFocus LP 730 User manual

i
TABLE OF CONTENTS
Safety Summary iii
Introduction 1
Image Resolution 1
Compatibility 2
Unpacking the Projector 2
Usage Guidelines 5
If You Need Assistance 5
Warranty 5
Setting up the Projector 7
Connecting the CableWizard™ to the Projector 8
Selecting Connectors on the CableWizard 8
Preparing to Connect Your Equipment to the Projector 10
Connecting an IBM-Compatible Laptop Computer 11
Connecting an IBM-Compatible Desktop Computer 13
Connecting an Apple PowerBook Computer 15
Connecting a Macintosh Desktop Computer 17
Connecting a Video Player 19
Connecting an External Speaker 21
Powering up the Projector and Adjusting the Image 21
Turning Off the Projector 22
Using the Projector 23
Basic Image Adjustment 23
Using the Remote Control 23
Adjusting the Projector 25
Using the Keypad Buttons 27
Using the On-Screen Menus 29
Display Menu Functions 31
Audio Menu Functions 33
Image Menu Functions 35
Controls Menu Functions 37

ii
Table of Contents
Maintenance & Troubleshooting 39
Cleaning the Lens 39
Cleaning the Fan Intake Filter 39
Replacing the Projection Lamp 41
Replacing the Batteries in the Remote Control 43
Using the Kensington Lock 43
Troubleshooting 44
Solutions to Common Problems 45
Appendix 49
Specifications 49
Accessories 51
Portable and Laptop Activation Chart 53
Using Video Mirroring with a PowerBook Computer 57
Projected Image Size 58
Index 61

iii
SAFETY SUMMARY
Please read these instructions carefully before using your projec-
tor. Failure to comply with them could result in fire, electrical
shock, personal injury or damage to equipment.
These graphics are used throughout this manual to draw your
attention to important information about the projectors.
NOTE: Additional useful details or tips.
CAUTION: Steps to take to avoid damage to your equipment.
WARNING: Steps to take to avoid personal injury.
These graphics are used on the projector’s labels.
Attention - Refer to this User’s Guide for important
safety information.
CAUTION- Hot Surfaces - Avoid touching hot surfaces.
Do not touch until the projector has cooled.
Do Not Look Into The Lens!
Be extremely careful not to look into the projection lens when the
projector is turned on. The bright light may harm your eyes. Be
especially careful to keep children from looking into the lens.
Power Source
Use only a three-wire grounding type power source. The power
source should not exceed 250 volts rms between the supply con-
ductors or between either conductor and the ground.
Power Cord
Use only the power cord that was shipped with the projector.
Although other power cords might be similar in appearance, they
have not been safety-tested with the projector. Do not use a
power cord if it has become damaged or frayed. Contact your In
Focus dealer or call In Focus if you need to replace your power
cord.

iv
Safety Summary
Grounding
The projector is grounded through the grounding conductor on
the power cord. To avoid electric shock, plug the power cord into
a properly wired receptacle. Do not defeat the purpose of the
grounding-type plug.
Lamp
To avoid overheating and unacceptable image quality, replace the
projection lamp with a lamp of the specified type. Refer to
page 49 for lamp specifications and to page 41 for instructions on
replacing the lamp.
Lamp Compartment
To avoid burns, do not open the lamp module door until the pro-
jector is turned off and the lamp has cooled for at least 2 minutes.
Follow the instructions in this manual for lamp replacement care-
fully.
Hot Surfaces
Allow the projector to cool at least 2 minutes before replacing a
lamp. When you open the lamp housing, be very careful not to
touch the hot surfaces inside.
Ventilation and Overheating
Openings in the projector case provide ventilation to protect it
from overheating. Keep loose papers and other objects well away
from the grills. Do not place the projector on top of or close to a
computer or other heat-producing equipment.
Liquid Spills
Do not set drinks on top of the projector. Spilled liquids can flow
inside and cause damage.
NOTE: If you open the projector
case, you will void the warranty.
Do Not Disassemble
All projector service must be performed by an authorized In
Focus service center. The only user-serviceable part in the projec-
tor is the projection lamp, which you can replace by opening the
lamp cover on the bottom of the projector (see page 41). Do not
open any other part of the projector. If your projector needs
repair, call In Focus Technical Support as described on page 5.
Before you call Technical Support, you may want to refer to
“Troubleshooting” on page 44 to see if you can resolve the prob-
lem yourself.

1
INTRODUCTION
The In Focus®LP™ 725 and 730 lightweight multimedia projec-
tors combine powerful and sophisticated features with easy-to-
use, intuitive controls. Built-in multimedia features include
audio, a palette of 16.7 million colors and active matrix liquid
crystal display (LCD) technology. The 700 series projectors are
ideal for high-performance business, training and imaging appli-
cations that demand exceptional color quality. The 725 has SVGA
800x600 graphics, the 730 has XGA 1024x768 graphics. The user
interfaces of the two products are identical; information in this
User’s Guide applies to both products.
NOTE: The 725 automatically
expands 640x480 images to
800x600. You can display these
images at 640x480 by turning off
the Auto Resize feature. See “Auto
Resize” on page 35 for more infor-
mation.
Image Resolution
LP 725
The SVGA resolution of the 725’s projected image is 800x600.
Screen resolutions between 800x600 and 1024x768 are com-
pressed to 800x600. The 725 cannot compress screen resolutions
above 1024x768. If your computer’s screen resolution is higher
than 1024x768, reset it to a lower resolution before you connect
the 725.
LP 730
NOTE: The 730 automatically
expands 640x480 and 800x600
images to 1024x768. You can dis-
play these images at their original
resolutions by turning off the Auto
Resize feature. See “Auto Resize”
on page 35 for more information.
The XGA resolution of the 730’s projected image is 1024x768.
Screen resolutions between 1024x768 and 1280x1024 are com-
pressed to 1024x768. The 730 cannot compress screen resolutions
above 1280x1024. If your computer’s screen resolution is higher
than 1280x1024, reset it to a lower resolution before you connect
the 730.

2
Introduction
Compatibility
The projector is compatible with a wide variety of computers and
video devices, including:
NOTE: Selected workstations are
also supported. Contact your In
Focus dealer for details.
•IBM-compatible computers, including laptops, up to 1024x768
resolution (LP 725) or 1280x1024 resolution (LP 730) at 75 Hz.
•Apple Macintosh and PowerBook computers up to 1024x768
resolution (LP 725) or 1280x1024 resolution (LP 730).
•Most standard VCRs, camcorders and laser disc players.
Unpacking the Projector
The projector comes with the items shown in Figure 1. Check to
make sure all are included. Contact your In Focus dealer immedi-
ately if anything is missing.
If you are experienced in setting up presentation systems, use the
LP 725/730 Quick Start card that was included in the shipping
box. For complete details on connecting and operating the projec-
tor, refer to this User’s Guide. User’s Guides are also available for
download from our website at www.infocus.com.
NOTE: The contents of your
shipping box may vary depending
on the configuration you’ve
ordered.

3
FIGURE 1
Shipping box contents
1. LP 725 or 730 projector 6. CableWizard
2. LP 725/730 User’s Guide 7. CableWizard computer cable
3. power cord 8. CableWizard mouse cable
4. remote and batteries 9. CableWizard audio cable
5. RCA audio/video (A/V) cable
Not shown: Quick Start card, online user guide CD-ROM, lens cap
1
2
3
4
5
6
7
8
9

4
Introduction
F
IGURE 2
Side view of projector
FIGURE 3
Front view of projector
connector panel
elevator button
speaker
power
switch power
cord
connector focus ring zoom ring
remote control
receiver

5
Usage Guidelines
•Do not look directly into the projection lens when the projector
is turned on. The bright light may harm your eyes.
NOTE: If the projector overheats
and turns off, you must wait about
30 seconds before you attempt to
turn it back on.
•Do not block the grills on the projector. Restricting the air flow
can cause it to overheat and turn off.
•Handle the projector as you would any product with glass
components. Be especially careful not to drop it.
•Avoid leaving the projector in direct sunlight or extreme cold
for extended periods of time. If this happens, allow it to reach
room temperature before use.
•This projector is not intended for use in a mainframe computer
room as defined in the Standard for the Protection of Electronic
Computer/Data Processing Equipment, ANSI/NFPA 75.
•Transport the projector in a vendor-approved hard or soft case.
Part numbers for these cases are listed on page 52. Call your In
Focus dealer to order.
If You Need Assistance
The first place to look for help is in this manual. Be sure to check
the guidelines in “Troubleshooting” on page 44.
If this manual doesn’t answer your question, call your In Focus
dealer. You can also call In Focus Customer Service directly at
1-800-799-9911. Customer Service is free between 5 a.m. and
5 p.m. PST, Monday through Friday. Service is available in North
America after hours and on weekends for a fee.
In Europe, call In Focus in The Netherlands at
(31) 23-5540310. In Singapore, call (65) 740-6435. Or, send us an
e-mail at [e-mail]
Our World Wide Web address is http://www.infocus.com.
Warranty
This product is backed by a limited one-year warranty. The
details of the warranty are printed at the back of this manual.
Longer term warranties can be purchased from your In Focus
dealer. Refer to page 52 for part numbers.

7
SETTING UP THE PROJECTOR
1Place the projector on a flat surface.
•The projector must be within 10 feet (3 m) of your power
source and within 10 feet of your computer.
NOTE: An optional extension
cable, sold separately, lets you
increase the distance between the
projector and your computer to
70 feet (21 m). See “Optional
Accessories” on page 52.
•If you want to project from behind a translucent screen, set
up the projector behind your screen. See “Rear Projection”
on page 38 to reverse the image.
•If you are installing the projector on the ceiling, refer to the
LP 700 Series Ceiling Mount Installation Guide that comes
with the Ceiling Mount Kit for more information. To turn
the image upside down, see “Ceiling” on page 38. The Ceil-
ing Mount Kit is sold separately; see page 52.
2Position the projector the desired distance from the screen.
•The distance from the lens of the projector to the screen
determines the size of the projected image. Figure 4 shows
three projected image sizes using the lens at minimum
focusing distance. For more information about image size,
see “Projected Image Size” on page 58.
3Make sure the projector and your computer are turned off.
FIGURE 4
Projected image size (minimum focusing distance)
2.5ft.
25ft.
5ft.
3.3 ft.6.5 ft. 32.5 ft.

8
Setting up the Projector
Connecting the CableWizard™ to the Projector
CAUTION: Turn off the
computer, monitor and projector
whenever you connect or
disconnect cables.
The CableWizard simplifies the connection process by providing
a central hub for all the connections between the projector and
your computer. The connectors on the CableWizard are labeled
with icons.
Connect the end of the CableWizard cable to the
connector on the projector’s connector panel (Figure 5).
NOTE: The projectors are
optimized for use with
CableWizard II. If you have
CableWizards from other models
of In Focus projectors, we do not
recommend using them. Image
quality is reduced by using a
CableWizard other than Cable
Wizard II. The label on the bottom
reads CableWizard or
CableWizard II.
FIGURE 5
Connecting the CableWizard to the projector
Selecting Connectors on the CableWizard
Turn the selector on the top of the CableWizard to reveal the
correct connectors for your computer.
NOTE: You must disconnect all
cables before turning the selector
on the CableWizard.
FIGURE 6
Selecting connectors on the CableWizard

9
•If you’re connecting an IBM-compatible desktop or laptop com-
puter, turn the selector until the window displays “PC.”
NOTE: The serial connector is
provided for use with a command
center for a fixed installation.
FIGURE 7
Selecting the IBM-compatible connectors on the CableWizard
•If you’re connecting a Macintosh desktop or an Apple PowerBook
computer, turn the selector until the window displays “Mac™.”
FIGURE 8
Selecting the Macintosh connectors on the CableWizard
computer
mouse
monitor
audio
serial
mouse
monitor computer
audio

10
Setting up the Projector
Preparing to Connect Your Equipment to the Projector
NOTE: Before you continue,
make sure the projector and your
equipment are turned off. If you’re
connecting a computer, make sure
the distance between it and the
projector is 10 feet or less and
you’ve selected the appropriate
connectors on the CableWizard.
Now you’re ready to connect your equipment. Computers are
connected to the CableWizard. Video players and other equip-
ment, such as external speakers, are connected directly to the pro-
jector.
Steps for connecting the different types of equipment are given
on the pages listed below.
NOTE: In some older computers,
the monitor connector does not
have a hole for Pin 9. If you have
trouble connecting the
CableWizard computer cable to
your computer, contact In Focus
Technical Support.
FIGURE 9
Connector panel
Equipment you want to connect Page
IBM-compatible laptop computer page 11
IBM-compatible desktop computer page 13
Apple PowerBook page 15
Macintosh desktop computer page 17
Video player page 19
External speaker page 21
CableWizard
wired remote
external
speaker s-video composite
video
L/R audio in
(optional
accessory)

11
Connecting an IBM-Compatible Laptop Computer
1Plug the end of the CableWizard computer cable into the
video connector on your computer.
NOTE: Many laptop computers
do not automatically turn on their
external video port when a sec-
ondary display device such as a
projector is connected. Refer to
your computer manual for the
command that activates the exter-
nal video port. Activation com-
mands for some laptop computers
are listed in the Appendix of this
manual on page 53.
2Plug the end of the CableWizard computer cable into the
connector on the CableWizard.
FIGURE 10
Connecting the CableWizard computer cable to an IBM-compatible laptop computer
NOTE: If you don’t want audio or
mouse control, you can use the
CableWizard Lite with your IBM-
compatible computer. CableWiz-
ard Lite is ordered separately. See
“Optional Accessories” on
page 52.
Do you want to play your computer’s audio on the projector?
1Plug either end of the CableWizard audio cable into the audio
connector on your computer.
2Plug the other end of the audio cable into the connector
on the CableWizard.
computer cable

12
Setting up the Projector
Do you want to control the computer’s mouse from the projector’s
remote or keypad?
1Locate the mouse cable and unplug it from your computer.
NOTE: Most laptop computers
do not allow you to use the
computer’s pointing device and the
projector’s remote at the same
time.
2Plug the end of the CableWizard mouse cable into the
mouse connector on your computer.
3Plug the end of the CableWizard mouse cable into the
connector on the CableWizard.
FIGURE 11
Connecting the CableWizard audio and mouse cables to an IBM-compatible laptop
computer
Now you’re ready to power up the projector and your laptop.
Skip to “Powering up the Projector and Adjusting the Image” on
page 21.
computer cable
audio cable
mouse cable

13
Connecting an IBM-Compatible Desktop Computer
1Locate the cable that connects your monitor to your computer.
Unplug it from the computer.
2Plug the end of the CableWizard computer cable into the
monitor connector on your computer.
3Plug the end of the computer cable into the connector
on the CableWizard.
FIGURE 12
Connecting the CableWizard computer cable to an IBM-compatible desktop computer
Do you want to display the image on your computer’s monitor as
well as on the projection screen?
1Plug your monitor’s cable into the connector on the
CableWizard.
Do you want to play your computer’s audio on the projector?
1Unplug the audio cable, if present, from your computer.
2Plug either end of the CableWizard audio cable into the audio
connector on your computer.
3Plug the other end of the audio cable into the connector
on the CableWizard.
computer cable

14
Setting up the Projector
Do you want to control your computer’s mouse from the projector’s
remote or keypad?
1Unplug the mouse cable from your computer.
NOTE: You cannot use your
computer’s mouse and the
projector’s remote at the same
time.
2Plug the end of the CableWizard mouse cable into the
mouse connector on your computer.
3Plug the end of the CableWizard mouse cable into the
connector on the CableWizard.
FIGURE 13
Connecting the CableWizard monitor, audio and mouse cables to an IBM-compatible
desktop computer
Now you’re ready to power up the projector and your computer.
Skip to “Powering up the Projector and Adjusting the Image” on
page 21.
audio cable
computer cable mouse cable
monitor cable

15
Connecting an Apple PowerBook Computer
1Plug the end of the CableWizard computer cable into the
video connector on your PowerBook.
NOTE: Some PowerBooks require
the Apple-supplied video-out cable
for external video. Connect it
between the PowerBook and the
CableWizard computer cable as
shown in Figure 14.
2Plug the end of the CableWizard computer cable into the
connector on the CableWizard.
3If you want the projector display to be the same as the Power-
Book’s screen display, turn on video mirroring. (See “Using
Video Mirroring with a PowerBook Computer” on page 57 for
additional information.)
FIGURE 14
Connecting the CableWizard computer cable to an Apple PowerBook
Do you want to play your computer’s audio on the projector?
1Plug either end of the CableWizard audio cable into the audio
connector on your PowerBook.
2Plug the other end of the audio cable into the connector
on the CableWizard.
computer cable PowerBook
video-out cable

16
Setting up the Projector
Do you want to control the computer’s mouse from the projector’s
remote or keypad?
1Locate the mouse cable and unplug it from your PowerBook.
NOTE: Most laptop computers
do not allow you to use the
computer’s pointing device and the
projector’s remote at the same
time.
2Plug the end of the CableWizard mouse cable into the
(ADB) connector on your PowerBook.
3Plug the end of the CableWizard mouse cable into the
connector on the CableWizard.
FIGURE 15
Connecting the CableWizard audio and mouse cables to a PowerBook
Now you’re ready to power up the projector and your Power-
Book. Skip to “Powering up the Projector and Adjusting the
Image” on page 21.
computer cable
PowerBook
video-out cable
mouse cable
audio cable

17
Connecting a Macintosh Desktop Computer
1Locate the cable that connects the monitor to your computer.
Unplug it from the computer.
2Plug the end of the CableWizard computer cable into the
monitor connector on your computer.
3Plug the end of the CableWizard computer cable into the
connector on the CableWizard.
FIGURE 16
Connecting the CableWizard computer cable to a Macintosh desktop computer
Do you want to display the image on your computer’s monitor as
well as on the projection screen?
1Plug the monitor’s cable into the connector on the
CableWizard.
Do you want to play your computer’s audio on the projector?
1Unplug the audio cable, if present, from your computer.
2Plug either end of the CableWizard audio cable into the audio
connector on your Macintosh.
3Plug the other end of the audio cable into the connector
on the CableWizard.
computer cable
