InFocus LP335 DRAGONFLY User manual

in
in
Present!
LP 335 Quick Start
™
Adjust the image position.
Power
The fans start. The Lamp LED on
the keypad lights orange then green
when the software has initialized.
Elevator
Zoom
Focus
Signal from computer
S-video from video player
Power
cord
LP335 connector panel
Power cord
lamp on/off
Laptop power
cord
If necessary, press the activation
keys on your laptop to see the
image on the screen.*
* Your computer may use a different key combination. Check your computer’s user’s guide for more information.
Lens cap
or
Fn
F5
LCD/CRT
F7
3
6
5
4
1
2
M1-DA analog
computer cable
USB
mouse
S
Sound from computer or video player
Composite video from video player
in
in
009-0494-00

Still need help?
Remember, your LP335 User’s Guide includes comprehensive instructions on setting
up and operating your LP335.
1Nothing appears on the screen.
Make sure you have plugged in the power cable, removed the lens cap, and
pressed the Lamp On/Off button on the keypad.
2All I see is the InFocus screen.
Make sure the computer cable is connected between the computer and the LP335.
Try pressing the laptop activation keys once more. Sometimes you need to press
them twice to make the image appear on the screen. If you also have a video
player plugged into the LP335, try pressing the Source button on the keypad or
the Computer button on the remote.
3There’s no computer image on the screen, just the message, Perfecting the
Image, in the lower right corner.
The projector may be having a hard time synchronizing with the computer signal.
Try pressing the Menu button on the projector keypad or remote. On the Image
menu, turn Auto Image to Off. See the LP335 User’s Guide for help with the menus.
4The computer image fills the screen, but the text is fuzzy and hard to read.
Try setting your laptop resolution to 1,024 x 768 (Start/Settings/Control Panel/
Display/Settings tab). If your laptop only goes up to 800 x 600 or 640 x 480, turn
off Auto Resize on the Image menu in the LP335. The image will be smaller, but it
should be sharp. See the LP335 User’s Guide for help with the menus.
5I can only see part of the computer image on the screen.
Try setting your laptop resolution to 1,024 x 768. With some laptop computers, it’s
necessary to disable the laptop display to do this. You use the activation keys to
show the image only on the screen.
6How do I play a video through the LP335?
Need to talk to someone?
Contact InFocus Technical Support.
⇒In North America, call InFocus at [phone] between 6 a.m. and 6 p.m.
PST, Monday-Friday.
-Or-
Call [phone] after hours or weekends
(a fee-per-instance charge may apply).
⇒In Europe, call InFocus in The Netherlands at [phone].
⇒In Asia, call InFocus in Singapore at [phone].
⇒Elsewhere, call [phone].
⇒Go to our Web site at www.infocus.com/service for information and an E-mail
form for Technical Support.
SAFETY INSTRUCTIONS
Please read and follow all safety instructions provided in this quick start and your User’s Guide BEFORE
using your projector. Failure to comply with safety instructions may result in fire, electrical shock, or per-
sonal injury and may damage or impair protection provided by equipment. Please save all safety instruc-
tions.
Safety Definitions
•Warning:Statements identify conditions or practices that could result in permanent personal injury.
•Caution:Statements identify conditions or practices that could result in damage to your equipment.
Safety Symbols
Attention:For information about usage of a feature, please refer to the User’s Guide.
Warning: Hot surface. Do not touch.
An arrow pointing to lamp door of the projector.
Safety Terms:
•Warning:Don’t look directly into the lens when the projector is turned on.
•Warning : To replace the lamp, unplug the power cord. To avoid burns, wait 30 minutes
before opening the lamp door. Follow all instructions provided in the User’s Guide.
•Warning : Please use the power cord provided. Connect the power cord to a receptacle
with a protective safety (earth) ground terminal.
•Warning: Refer all service to qualified service personnel. Servicing your own projector will void the
warranty.
•Caution:Don’t block ventilation openings.
•Caution: Don’t set liquids on the projector. Spilled liquids may damage your projector.
•Caution: Don’t place the projector on a hot surface or in direct sunlight.
•Caution: Do not drop the projector. Transport the projector in an InFocus-approved case; see the
User’s Guide for a list of cases.
in
in
Video
Audio Out
LR
Audio cable
Video cable
audio
adapter
