OPERATOR’S MANUAL 637354
INCLUDING: OPERATION, INSTALLATION & MAINTENANCE.
RELEASED: 2-6-01
REVISED: 1-23-08
(REV. C)
8” AIR MOTOR
6” Stroke
Also covers 637357 service kits.
READ THIS MANUAL CAREFULLY BEFORE INSTALLING,
OPERATING OR SERVICING THIS EQUIPMENT.
It is the responsibility of the employer to place this information in the hands of the operator. Keep for future reference.
INGERSOLL RAND COMPANY LTD
1872 ENTERPRISE DRIVE yROCHESTER HILLS, MICH. 48309
[phone] yFAX [phone] © 2008 CCN 99909624
SERVICE KITS
Use only genuine Ingersoll Rand replacement parts to assure
compatible pressure rating and longest service life.
66614 for general repair of 637354 air motor.
90350 installation tool is recommended for repair of 637354 air
motor.
DISASSEMBLY
NOTE: All threads are right hand.
Force the (43) piston assembly up by pushing toward the top
of the air motor (see gure 4).
Remove six (1) screws, releasing the (31) cap and (32) gasket.
Loosen the eight (45) screws, which hold the (33) valve plate
and pin assembly, (30) valve guide, two (4) valve guides and
the (5) valve plate, until the (30) valve guide and the two (4)
valve guides can be removed by pulling upward (see gures 1
and 2).
(Use an Allen wrench to push out screws and washers as shown.)
Figure 1
Allen Wrench
46 Washer (8)
45 Screw (8)
(The remaining four
washers and screws are
on the opposite side.)
4. Remove the eight (45) screws and the eight (46) washers from
the 8” air motor by pressure outward with a small Allen wrench
(see gure 1).
5. Using a screwdriver, unhook the (28) insert spring assembly
from the bottom of the (33) valve plate and pin assembly (see
gure 2).
6. Remove the (28) insert spring assembly from the pins in the
top of the (33) valve plate and pin assembly.
7. Pull the (2) valve piston upward until the (7) upper gland has
pulled out of its chamber.
8. Remove the (7) upper gland.
9. Remove the (39) seal, (38) “O” ring and the (13) “O” ring from
the (7) upper gland (see gure 7).
10. Disassemble the (2) valve piston from the (10) piston adapter
(see gure 3).
11. Remove (2) valve piston.
12. Pull the (10) piston adapter upward and grasp the (11) exten-
sion rod below the (10) adapter. Push the (10) piston adapter
down on the (11) extension rod. Remove the (37) washer and
(11) extension rod.
y
y
y
1.
2.
3.
13. Remove the (8) upper washer and the (9) “U” cup packing from
the (10) piston adapter.
14. Remove the six (22) nuts and (23) bolts.
Figure 3
210
15. Remove the (35) head assembly and place on the workbench,
with the end that the tube ts in, up.
16. Remove the (16)“O” ring from the (35) head assembly.
17. Remove the four (40) screws, releasing the (41) lower gland.
18. Remove the (12) lower washer and (13 and 42) “O” rings from
the (41) lower gland.
19. Remove (44) tube.
20. Remove the“O” ring from the (44) tube.
21. Pull upward on the (18) air cylinder until the (43) piston as-
sembly separates from the (26) air motor base assembly. If the
(43) piston assembly is not pulled from the (26) air motor base
assembly, remove it after removing the (18) air cylinder.
22. Remove the (16) “O” ring from the (26) air motor base and
bearing assembly.
24536 30 29 4534
4628334645
47
48
7
Figure 2

Page 2 of 4 637354 (en)
23. Now remove the (21) retaining ring, (24) guide washer and
(25) “U” cup packing from the (26) air motor base and bearing
assembly.
24. (43) piston assembly is factory assembled and should not be
disassembled.
25. Remove the (17) “O” ring from the (43) piston assembly. CAU-
TION: Do not mar the nish on the piston rod.
26. Disassemble the (43) piston assembly from the (14) screw.
27. Unscrew the (19) valve rod from the (11) extension rod by
holding (19) valve rod with adjustable-type pliers and placing
a wrench on the ats provided at the top of the (11) extension
rod.
ASSEMBLY
NOTE: All threads are right hand. Inspect and replace old parts with
new parts as necessary. Look for deep scratches on metallic sur-
faces. Replace all “O” rings upon reassembly. Lubricate all “O” rings
and “U” cups with Darina® EP 2 grease upon reassembly.
Place (17) “O” ring onto the (43) piston.
Place the (14) screw onto the (19) valve rod. The threaded end
of the screw should be down, away from the threaded end of
the valve rod.
While holding the (19) rod assembly below the threads with
locking type pliers, clean threads with solvent and apply Loc-
tite® 271™ to the threads and attach the (11) extension rod.
Place the (19) valve rod into the hole in the end of the (43)
piston assembly and screw the (14) screw into the (43) piston
assembly.
Thoroughly grease and install the (16) “O” ring in the (26) air
motor base and bearing assembly.
Place the (25) “U” cup packing, (24) guide washer and (21) re-
taining ring in the (26) air motor base and bearing assembly.
1.
2.
3.
4.
5.
6.
Grease and install (13) “O”ring on the (41) lower gland.
Grease the bore in the (35) head assembly and insert (41)
lower gland into the bore of the (35) head assembly with a
twisting motion.
Align the bolt holes in the (41) lower gland and (35) head as-
sembly and secure with four (40) screws.
Push the (43) piston assembly through the (25) “U” cup pack-
ing in the (26) air motor base and bearing assembly, being
careful not to damage the“U”cup packing.
Thoroughly grease the inside of the (18) cylinder.
Apply grease to (17) “O” ring, then insert into the bottom of
the (18) cylinder (see gure 5).
Push the (43) piston assembly to the top of the cylinder.
Thoroughly grease and install the (42 and 16) “O” rings in the
(35) head assembly.
Thoroughly grease the two (36) “O” rings and install one on
each end of the (44) tube.
Press the (44) tube into the counterbored hole in the (26) air
motor base and bearing assembly.
Push the (11) extension rod through the (42) “O” ring in the
base of the (35) head assembly.
Align and press the (35) head assembly down until the (18)
cylinder and (44) tube are seated in the head assembly.
Insert the six (23) bolts down through the holes in the anges
of the (35) head assembly and the air motor base and bearing
assembly.
Screw the six (22) nuts on the six (23) bolts. Alternately and
evenly tighten the nuts.
Thoroughly grease and install the (9) “U” cup packing in the
(10) adapter, with the lips of the packing down toward the
thick ange of the (10) piston adapter.
Thoroughly grease and install the (38 and 13) “O” rings in the
(7) upper gland.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
PARTS LIST / 637354
Item Description (size) (Qty) Part No. Item Description (size) (Qty) Part No.
1 Screw (#10 - 24 x 1/2”) (6) 95956827
92 Valve Piston (1) 92395
93 Pilot Insert (1) 90487
4 Valve Guide (2) 90481
5 Valve Plate (1) 90480
96 Valve Plate Gasket (1) 90482
7 Upper Gland (1) 91006
98 Washer (1) 91344
99 “U” Cup (3/16” x 1-3/8” o.d.) (1) Y186-51
910 Piston Adapter (1) 92393
11 Extension Rod (1) 90080
912 Washer (1) 91345
913 “O” Ring (1/16” x 1-3/8” o.d.) (2) Y325-26
14 Screw (1) 92218
916 “O” Ring (1/8” x 8” o.d.) (2) Y325-265
917 “O” Ring (1/4” x 8” o.d.) (1) Y325-443
18 Air Cylinder (1) 99398
19 Valve Rod (1) 90107-1
21 Retaining Ring (2.630” o.d.) (1) Y147-237
22 Nut (1/2” - 20) (6) Y11-8-C
23 Bolt (1/2”- 20 x 10-1/4”) (6) 94046-1
24 Guide Washer (1) 92216
925 “U” Cup (1/4” x 1-3/4” o.d.) (1) Y186-24
26 Air Motor Base Assembly (1) 66525-1
28 Insert Spring Assembly (1) 65807
929 Valve Insert (1) 99202
30 Valve Guide (1) 90488
31 Air Motor Cap (1) 90078
932 Gasket (1) 90083-1
33 Valve Plate and Pin Assembly (1) 65756
934 Valve Plate Gasket (1) 90479
35 Head Assembly (1) 66524-1
936 “O” Ring (3/32” x 7/8” o.d.) (2) Y325-115
937 Washer (1) 90105
938 “O” Ring (0.103” x 1.255” o.d.) (1) 91207
939 Seal (1) 91007
940 Machine Screw (#8 - 32 x 3/8”) (4) Y136-85-S
41 Lower Gland (1) 90114
942 “O” Ring (1/16” x 7/16” o.d.) (1) Y325-11
43 Piston Assembly (1) 62109-B
44 Tube (1) 92215
9 45 Machine Screw (#8 - 32 x 3/4”) (8) Y19-89-S
946 Washer (8) 90084
47 Machine Screw (1/4” - 28 x 3/4”) (2) Y119-49-C
48 Lock Washer (1/4”) (2) Y14-416
49 Ground Lug (1) 93006
9Darina EP 2 Grease Pack (2) 94833
9Items included in Service Kit 637357
(continued on page 4)
“Smart Parts”, keep these items on hand in addition to the service kits for fast repair and reduction of downtime.
yDarina® is a registered trademark of the Shell Oil Company y
yLoctite® is a registered trademark of Henkel Loctite Corporation y271™ is a trademark of Henkel Loctite Corporation y

637354 (en) Page 3 of 4
PARTS LIST / 637354
37
7
39
13
38
8
9
28
33
34
11
13
36
36
40
42
44
21
24
26
35
4
10
12
41
16
17
14
43
19
18
23
16
22
25
49
29 30253632131
47, 484645
Figure 4
Apply Loctite 271 to threads.

Page 4 of 4 637354 (en)
PN 97999-968
Bend the (39) seal in a heart shape and install in the (7) upper
gland inside the (38) “O” ring (see gure 6).
Figure 6
Seal Free Form Seal Collapsed Form
Push sides in, as shown, then slide into bore and position seal in groove.
24. Grease and carefully push the (2) piston into the (7) upper
gland to size the (39) seal and remove (see gure 7).
Figure 7
13 “O” Ring
38 “O” Ring
39 Seal
Direction for sizing
2 Valve Piston
7 Upper Gland
25. Place the (12) lower washer over the (11) extension rod.
26. Pull the (11) extension rod up and grasp with two ngers, (see
gure 8).
Figure 8
11 Extension Rod
37 Washer
35 Head Assembly
23.
27. Place the 90350 installation tool over the (11) extension rod,
with the turned diameter down and the chamfer up.
28. Fit the turned diameter of the 90350 installation tool into the
bore in the bottom of the (35) head assembly.
29. Place the (10) adapter down over the (11) extension rod, with
the threads upward.
30. Insert the (37) washer into the groove in the top of the (11)
extension rod.
31. Pull the (10) adapter up and around the (37) washer.
32. Place the (8) upper washer over the (11) extension rod and
onto the (10) adapter.
33. Clean the threads with solvent and put Loctite 271 on the
threads of the (2) piston. Screw the (2) piston into the (10)
adapter and tighten (see gure 3).
34. Push the assembled (10) adapter and (2) piston down through
the 90350 installation tool until they bottom.
35. Remove the 90350 installation tool.
36. Install the (7) upper gland over the (2) piston and push down,
being careful to retain the (39) seal in the “O” ring groove.
37. Align the two bolt holes and secure the (7) upper gland to the
(35) head assembly with the two (47) screws and two (48) lock
washers (see gure 2).
38. Insert the (28) spring in the (35) head assembly, with the hooks
down and the nylon roller toward the (2) piston (see gure 2).
39. Thoroughly grease and insert the (3) pilot insert, two (4) valve
guides, (5) valve plate and (6) gasket into the (35) head assem-
bly (see gure 2).
40. Thoroughly grease and insert the (29) valve insert into the (35)
head assembly (see gure 2).
41. Thoroughly grease and insert the (34) valve plate gasket and
the (33) valve plate and pin assembly between the insert and
the (35) head assembly, with the two pins in the (33) valve
plate up (see gure 2).
42. Hook the round coils in the (28) insert spring assembly over
the pins in the (33) valve plate and pin assembly (see gure 2).
43. Hook the bottoms of the (28) insert spring assembly into the
holes on the side of the (33) valve plate and pin assembly (see
gure 2).
44. Insert the (30) valve guide against the face of the (33) valve
plate and pin assembly. The legs of the (30) valve guide should
be down, with the leg having the threaded hole the farthest
from the bottom toward the air inlet in the (35) head assem-
bly.
45. Insert and tighten across corners the eight (45) screws and
eight (46) washers (see gure 1).
46. Thoroughly grease and install the (32) gasket in the (31) cap.
47. Place the (31) cap on the (35) head assembly and secure with
six (1) screws (see gure 4).
43 Piston
17 “O” Ring (apply
grease around “O”
ring)
18 Cylinder (apply
grease throughout
inside)
Figure 5
