INSTRUCTION MANUAL
IT-30DSP
PROGRAMMABLE FSK TONE TRANSMITTER
Fig.
1. IT-30DSP
DESCRIPTION: The IT-30DSP
is aprogrammable frequency shift keyed (FSK) tone transmitter
intended for the use
on the transmitting end of acommunication channel in supervisory control,
telemetry and data transmission applications. Atransmitter/receiver combination may
be used over
voice grade circuits including carrier, wire line, fiber optics, and microwave.
Each transmitter module
is field programmable for aspecific center frequency and frequency shift
(bandwidth/baud rate) via DIP switches. Operational modes inciude two frequency (2F) or three
frequency (3F) keying, carrier on/off (Request-To-Send, RTS) and when communicating with a
similarly equipped receiver, inverted keying and flasher (keying of both mark and space
simultaneously).
Utilizing state of the art design and crystal controlled Digital Signal Processing (DSP) techniques
provides for improved performance, flexibility, and reliability.

FEATURES:
•Voltage keying inputs provided
on, each unit (optical keying optionai).
•Front paneilevei adjustment.
•DIP switch programmable -no need tor external equipment to change trequency, bandwidth or
mode ot operation.
•Cost saving design while maintaining reliability and quality.
•
12 Year Warranty.
SPECIFICATIONS:
Output Level: Front panel adjustable to
+5 dBm.
Output Impedance:
15 KQ minimum.
Keying inputs: Mark and Space, High impedence 3-30 Vdc.
Keying methods: CMOS, TTL, RS232, Dry contact, Opto isolation, Voltage (various inputloutput
interfaces available).
Operating Frequency Range: 200-3800
Hz. (See programming charts)
Operating Bandwidths:
50, 60, 85, 120, 170, 240, 300, or 600 Hz. Standard.
Indicators: Front panel mounted tor mark, space,
RTS (Request-To-Send), and CD/carrier on
CTS (Clear-To-Send).
Spectral Purity: Harmonic content: 70dB below carrier level. Spurious signals
at adjacent
channels: 70dB below carrier.
Bias distortion: Less than 7% with channel
keyed in accordance to programmed bandwidth,
back to back Transmitter/Receiver.
Environmental Requirements: Temperature Range: -30 to +70 C(-22 to +158
F) Relative
Humidity: 95% maximum, non-condensing at
40 C(104 F).
Power Requirements: +12 Vdc ±35% (7.8 to 16.2 Vdc), 130 ma @ 12 V

SAFETY:
Standard safety precautions must be followed at all times when installing, operating,
servicing, and repairing this.)equipment. INIVEN/CONOLOG
CORP. assumes no liability
for failure to observe standard or specifically noted safety requirements or to use this
equipment for purposes other than intended.
GROUNDING: Asuitable ground
is required to reduce the hazard of shock. Refer to the
enclosed module, chassis, and/or cabinet 'wiring diagram for ground connection locations.
ENVIRONMENT: Operation of any electrical equipment
in any area containing gases, fumes,
wet, or damp
is apotential safety hazard. Necessary precautions should be taken.
MANUAL: Operators and maintenance personnel should read this manual before installing
the equipment and placing it
in service. Only properly trained personnel with proper tools and
equipment should operate, maintain, repair, or service this equipment.
SHOCK: Potentially dangerous electrical shock can occur whenever working
on this product.
Protective measures and safety procedures should
be observed at ali times.
THEORY
OF OPERATION:
GENERAL: The unit generates
an audio tone which changes frequency when the input is
keyed. The keying inputs are referred to as mark and space. In the two frequency mode,
the audio tone output
is at afrequency plus or minus the shift (programmable) of the
programmed center frequency. Upon keying (applying avoltage), the transmitter changes
state to the opposite frequency.
In atwo frequency system, the center frequency is not
produced.
In athree frequency unit the center frequency is normally generated when neither a
mark or space output
is present. When the transmitter is keyed to the space frequency the
receiver space output
is activated and when the transmitter is keyed to the mark frequency
the receiver mark output
is activated. Only one keying input should be on at agiven time
unless the IT-30DSP and receiver are set to operate
in flasher mode. The Flasher option on
the IT-30DSP allows the unit to shift between mark and space frequencies rapidly when both
inputs are keyed simultaneously.
Athird keying input
is available which allows the audio tone output to be turned on/off.
The
RTS (carrier on/off) input permits the transmitter to be used in systems requiring aquiet
line until communications
is need such as apolling or data system.
PROGRAMMING: Upon applying power to the unit, the Digital Signal Processor (DSP) (U5)
reviews the program information
of octal inverting buffers (U 12 &U 13) which have been set
by switches
SW1 and SW2.

INPUT: Standard inputs are via 02, 03, OS and associated circuitry. The input information is fed
to (U4) octal bus driver along with the mode of operation settings of SW3. (US) Stores the
information in memory (RAM).
DSP(Digital Signal Processing): The microprocessor
(US) operating parameters are determined
by the two EPROM's (2K x8-bit) U6 & U7. Ali sine wave generation and keying input information
is then processed in (US)."',
WATCH DOG TIMER: (U9) is awatch dog timer which recycles the microprocessor should its
software sequence fail to perform
as required. The timer effectively restarts the program to eliminate
having to re-initiate power up of the module.
OUTPUT: The digital signal
is processed through (U14) digital to analog converter and then passes
through alow pass filter consisting of L
1, L2 and associated capacitors (C10 -C14) Iimiting the
signals to 4kHz. Variable resistor (R24) adjust the signal level which
is amplified by operational
amplifier (U16). The signal is coupled to the line via transformer T1.
SW2
DS4
DSl--
DS2
DS3
SW4
Fig. 2. Controls &Indicators
Table 1. Controls and Indicators
SWl
SW3
DS1 Indicator, Mark, lights when mark is keyed on
DS2 Indicator, Space, lights when space is keyed on.
DS3 Indicator, (CTS), Clear to send, lights when carrier (mark, space or center)
is
present at the output.
DS4 Indicator, (RTS), Request to send, lights when
RTS is keyed.
R24 Variable resistor, audio tone level adjustment.
SW1 Switch, Programs center frequency (see chart).
SW2 Switch, Programs frequency shift (see chart).
SW3 Switch, Programs modes
of operation (see listing).
SW4 Switch, Front Panel, Keys
RTS when SW3 position 4 is on (see SW3 settings)

@@
} SPACE KEYING
}.MARK KEYING
+12VDC INPUT
l----f- COMMON
>---+-} PHONE LINE OUTPUT
>---+-} RTS/CARRIER KEYING
11
@{,:;\
®
W
\SJ@
@
@@
IT-30DSP
Fig. 3. Terminai Block (TB1)
INSTALLATION:
UNPACKING: This equipment may be supplied loose, mounted in an individual chassis 'stacked
interconnected chassis, or as part of arack or cabinet. Follow the procedure for the type of system
supplied.
Loose and/or equipment mounted
in an individual chassis will be packed in its own shipping carton.
Inspect the carton for possible damage
in transit. Open each carton carefully and remove the
contents. Inspect the equipment for possible damage. Verify
ali items of value have been removed
prior to discarding any packing materia!.
NOTE: It is suggested the carton be retained for possible onward shipment.
Interconnected chassis or equipment supplied
in racks or cabinets will be supplied in special boxes,
wood crates, or if shipped via air-ride
van without any case. Inspect the crate or other packing for
possible damage
in transit. Carefully remove the equipment from the container and inspect it for
possible damage. Verify
ali items of value have been removed from the crate prior to discarding
any packing material and refer to the note above.
Should transit damage
be found please notify INIVEN immediately.
MOUNTING: After unpacking follow the appropriate mounting procedure.
Loose module: (The following
is for new installations -replacement of an existing module will have
the termi nai block already mounted. Each new unit is shipped with the terminai block plugged into
the rear of the unit. There are also four 6-32 screws shipped with
it to mount the terminai block to
the chassis. Locate the desired position within the chassis for which the module is to be placed.
Viewing the chassis from the front, the recommended arrangement
is apower supply on the extreme
left then followed
by transmit and or receive modules working towards the right of the chassis.

Interconnected Chassis or equipment mounted on shipping rails is to be mounted similar to an
individual chassis. When shipping rails are provided the equipment is to be placed near the desired
location. Remove the screws holding the shipping rails and then remove the rails. Slide the equipment
into the rack or cabinet and secure it with proper screws for the mating hardware being used.
Tighten ali screws.
Systems provided
in arack or cabinet from the factory must be secured to the floor or wall as
required. Mounting hardware is not sqpplied due to the various surfaces and mounting methods.
CAUTION: EQUIPMENT MOUNTED IN SWING RACK TYPE CABINETS MUST BE SECURED
TO THE MOUNTING SURFACE PRIOR TO OPENING THE SWING RACK TO PREVENT THE
CABINET FROM FALLlNG.
VENTILATION: Proper ventilation is required for most electronic equipment. Enclosed cabinets or
rooms where this equipment
is mounted should be kept at temperatures within the limits of the
equipment. Operation above these limits may affect reliability.
ELECTRICAL CONNECTIONS: User connections are made via the terminai blocks
on the rear of
the chassis. Each unit in the Gen 1SERIES of equipment will contain these connections in the
instruction manual for the specific individual module.
On equipment supplied wired from the factory
or
on wired chassis and cabinets an "as supplied" drawing will be included with the equipment.
External wiring should
be in accordance with the "as supplied" drawing when supplied.
For safety reasons power on the leads to be connected to the unit are to be de-energized
during installation.
Methods of making the wiring connections to the terminai blocks vary and based on local practice.
It is suggested number 20 AWG size insulated wire, stripped portion tinned, be used. Approximately
1/4" of the insulation
is to be removed and inserted in the terminai block.
Module power and tone lines may
be daisychained should the application require.
Tighten all connections and insure exposed wires do not touch each other or the chassis.
INITIAL STARTUP &LEVEL CHECKS:
FREQUENCY SELECTION: With the module removed from the chassis. Select the desired
bandwidth and center frequency from the enclosed charts. Refer to figure 2for switch location.
EXAMPLE: For an 85 baud channel at 1615 Hz center frequency, set SW2 position 3to "ON"
(only asingle position within SW2
is to be "ON" at any one time). Set SW1 positions 1, 4, &7
to "ON" (be sure
all other positions on SW1 are "OFF").
MODE OF OPERATION: Set SW3 to the desired mode of operation
as detailed below. Refer to
figure 2for switch location.

SWITCH SW3 SETTINGS:
Ali Positions "OFF": 3F Operation. Keying the Mark input produces aMark frequency out,
keying the Space input provides aSpace frequency
outo The center frequency will be output
when the input is idle.
Position 1"ON" only: 3F Operation, Inverted Output. Keying the Mark input produces aSpace
frequency out, keying the Space input produces aMark frequency
outo The center frequency
will
be output when the input is idle.
Position 2"ON" only: 2F Operation. Keying the Mark input produces the Mark frequency when
keyed. The Space frequency
is output when the input is idle. The keying leads should be on
the Mark input. 00 not use this option with position 3 in the "ON" position.
Position 3"ON" only: 3F Operation, FLASHER. The transmitter will shift at 20msec intervals
between Mark and Space when the Mark and Space inputs are keyed at the same time. (This
operation will not function if the position 2
is in the "ON" position).
Position 4"ON" only: (RTS). When position 4
is on, the front panel switch is activated. When
position 4
is in the off position, the front panel switch will not be able to turn off the output(s).
RTS can also be keyed from the RTS input on the rear terminai block when the front panel
switch (SW4) is in the "OFF" position. This option may be used in all modes.
Positions 1&2"ON": 2F operation, Inverted Output. Keying the Mark input produces aSpace
frequency output. The Mark frequency
is output when the input is idle. The keying leads should
be on the Mark input. 00 not use this option with position 3 in the "ON" position.
ADJUSTMENTS: The transmitter contains afront panel LEVEL adjustment (R24) (see figure 2for
location). Each transmitter
is shipped from the factory with the level adjustment set at -6 dBm,
which
is adequate for most applications.
The following equipment
is recommended to perform the initial startup and level checks at:
1. Digital multimeter with dB readout function; Fluke 8060A or equivalent.
2. Flatblade screw driver with 1/8 inch wide tip or potentiometer adjustment too!.
3. Optionai -Card Extender.
WARNING: 00 NOT INSERT THE UNIT INTO ARACK WITH THE POWER ON.
INITIAL SETTINGS: With the power (+12Vdc) and phone line wired to the terminai blocks on the
rear of the chassis, connect the test leads of the multimeter (dB mode) across the "tone out"
on
the terminai block. Turn on the power and note the reading on the multimeter (the tone output
on the terminai block should be connected to the line or if this is not possible, terminated in a
600 ohm resistor). Adjust R24(LVL ADJ) with ascrewdriver or adjustment tool to the desired level.
Only one transmitter should be
on the line during this adjustment or acomposite level will be
read, which is not atrue reading of the transmitter output level. The "as set" level should be
recorded for future reference.

When two or more transmitters are connected on one communications line, each individual
transmitter level should be adjusted at areduced level
in order for the combined (composite)
signals not to exceed the desired output level. Refer to the chart below for recommended levels
referenced to 0dBm. The recommended dBm levels may also
be used as reference for any
desired level setting
in dB.
-,
"MULTIPLE TONE
OUTPUT LEVELS
Number af dB RMS V
Channels -Level 600 n
1 0 0.7746
2-3 0.5484
3-4.8 0.4457
4
-6 0.3882
5
-7
0.3460
6-7.8 0.3156
7-8.5 0.2911
8
-9 0.2748
9-9.5 0.2595
10 -10 0.2449
11
-10.4 0.2339
12 -10.8 0.2234
13 -11.1 0.2158
14 -11.5 0.2061
15 -11.8 0.1991
16 -12 0.1946
17 -12.3 0.1880
18 -12.5 0.1837
19 -12.8 0.1774
20 -13 0.1734
21 -13.2 0.1695
22 -13.4 0.1656
23 -13.6 0.1618
24 -13.8 0.1582
EXAMPLE: For two transmitters with adesired composite level of -6 dBm, reduce the desired
level of each transmitter by 3dB (from the chart below) and set each to
-9 dBm.
ALL SAFETY PROCEDURES ARE TO BE STRICTLY ADHERED TO AND ONLY QUALlFIED
MAINTENANCE, OPERATORS, OR SERVICE PERSONNEL ARE TO PERFORM
WORK ON THIS
EQUIPMENT.
L1FE THREATENING VOLTAGES AND CURRENTS ARE PRESENT WITHIN THIS
EQUIPMENT. OBTAIN
ALL REQUIRED APPROVALS PRIOR TO PLACING IN OR OUT OF
SERVICE. ANY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT
WILL VOID THE
WARRANTY.
NOTE:
In the event areplacement module is being installed check all switch settings prior to
installation. Comparison with the removed module is one convenient method.

FOR 50 BAUD OPERATLON
SET POSITION 1OF SW2 "ON"
To Obtain Center Set Listed Positions
Freq.
Hz
of SW1 to "ON"
365 4
465 1,4
565 2,4
665 1,2,4
765 3,4
865 1,3,4
965 2,3,4
1075 1,2,3,4
1175 5
1275 1,5
1375 2,5
1475 1,2,5
1575 3,5
1675 1,3,5
1775 2,3,5
1875 1,2,3,5
2000 4,5
2100 1,4,5
2200 2,4,5
2300 1,2,4,5
2400 3,4,5
2500 1,3,4,5
2600 2,3,4,5
2700 1,2,3,4,5
2800 6
2900 1,6
3000 2,6
3100 1,2,6
3200 3,6
3300 1,3,6
3400 2,3,6
3500 1,2,3,6
FOR 60 BAUD OPERATION
SET POSITION 2OF SW2 "ON"
To Obtain Center Set Listed Positions
Freq.
Hz of SW1 to "ON"
420 4,6
540 1,4,6
660 2,4,6
780 1,2,4,6
900 3,4,6
1020
1346
1140 2,3,4,6
1260 1,2,3,4,6
1380 5,6
1500 1,5,6
1620 2,5,6
1740 1,2,5,6
1860 3,5,6
1980 1,3,5,6
2100 2,3,5,6
2220 1,2,3,5,6
2340 4,5,6
2460 1,4,5,6
2580
2456
2700 1,2,4,5,6
2820
3456
2940 1 3456
3060
23456
3180
123456
3300 7
3420 1,7

FOR 85 BAUD OPERATION
SET POSITION 3OF SW2 "ON"
Ta Obtain Center Set Listed Pasitians
Freq. Hz af
SW1 ta"'mN"
425
27
595 1 2 7
765 3,7
935 1,3,7
1105 2,3,7
1275 1,2,3,7
1445 4,7
1615 1,4,7
1785 2,4,7
1955 1,2,4,7
2125 3,4,7
2295 1,3,4,7
2465 2,3,4,7
2635 1,2,3,4,7
2805 5,7
2975 1,5,7
3145 2,5,7
3315 1,2,5,7
3485 3,5,7
FOR 120 BAUD OPERATION
SET POSITION 4OF SW2
"ON"
Ta Obtain Center Set Listed Pasitians
Freq. Hz af
SW1 ta "ON"
480 13,5,7
720 2,3,5,7
960 1,2,3,5,7
1200 4,5,7
1440 1,4,5,6
1680 2,4,5,7
1920 1,2,4,5,7
2160 3,4,5,7
2400 1,3,4,5,7
2640 2,3,4,5,7
2880 1,2,3,4,5,7
3120 6,7
3360 1,6,7
FOR 170 BAUD OPERATION
SET POSITION 5OF SW2 "ON"
Ta Obtain Center Set Listed Pasitians
Freq. Hz af
SW1 ta "ON"
850 267
1190 1 267
1530 367
1870 1,3,6,7
2210 2,3,6,7
2550 1,2,3,6,7
2890 4,6,7
3230 1,4,6,7
FOR 240 BAUD OPERATION
SET POSITION 6OF SW2
"ON"
Ta Obtain Center Set
listed Pasitians
Freq. Hz af
SW1 ta "ON"
600
2467
1080 1
2467
1560
3467
2040 1,3,4,6,7
2520 2,3,4,6,7
3000 1,2,3,4,6,7
FOR 300 BAUD OPERATION
SET POSITION 7OF SW2
"ON"
Ta Obtain Center Set listed Pasitians
Freq. Hz af
SW1 ta "ON"
1020 5,6,7
1700 1,5,6,7
2380 2,5,6,7
3060 1,2,5,6,7
FOR 600 BAUD OPERATION
SET POSITION 8OF SW2
"ON"
Ta Obtain Center Set Listed Pasitians
Freq. Hz af
SW1 ta "ON"
1360 3,5,6,7
2720 1,3,5,6,7

Circuit
Symbol
C14,6
C5, 18-35
C7-9
C10
C11
C12
C13
C14
C16
C17
C36, 37
R1
R2, 3
R4, 7
R5, 8
R6, 9
R10-13, 32
R14-17, 28
R18, 19, 23
R20
R21
R22
R24
R26
R27
R29
R30
R31
R34-36
R37
01, 2, 4, 5
03
06
DS14
01-5
U1
U2
U3
U4
U6, 7
U5
U10, 11
U8
U9
U12, 13
U15
U14
U16
U17
U18
Table 1. Replaceable parts IT-30DSP
Description
CAPACITORS:
Capacitor, tantalum dipped, 1
uF, 20V, +/-10%
Capacitor;.ceramic,
.1 u F, 50V, +/-20%
Capacitor, ceramic,
18pF, 100V, +/-5%
Capacitor, metalized polycarbonate,
.01 uF, 100V, +/--3%
Capacitor, metalized polycarbonate, .0082uF,
100V, +/-2%
Capacitor, metalized polycarbonate, .027uF, 100V, +/-3%
Capacitor, metalized poJycarbonate, .0022uF,
100V, +/-3%
Capacitor, metalized polycarbonate, .022uF,
100V, +/-3%
Capacitor, ceramic,
100pF, 50V, +/-5%
Capacitor, tantalum,
4.7uF, 35V, +/-10%
Capacitor, ceramic,
330pF, 100V, +/-5%
RESISTORS:
Resistor, carbon, 6.2K, 1/4 watt, +/-5%
Resistor, carbon, 5.6K, 1/4 watt, +/-5%
Resistor, carbon, 50K, 1/4 watt, +/-5%
Resistor, carbon, 20K, 1/4 watt, +/-5%
Resistor, carbon, 1.0K, 1/4 watt, +/-5%
Resistor, carbon, 100K, 1/4 watt, +/-5%
Resistor, carbon, 10K, 1/4 watt, +/-5%
Resistor, carbon, 680(, 1/4 watt, +/-5%
Resistor, carbon, 4.7K, 1/4 watt, +/-5%
Resistor, carbon, 3.9K, 1/4 watt, +/-5%
Resistor, carbon, 2.4K, 1/4 watt, +/-5%
Resistor, variable, 50K, 3/4 watt, 10 turn
Resistor, metal film, 1.18K, 1/4 watt,
+/-1 %
Resistor, metal film, 10K, 1/4 watt,
+/-1 %
Resistor, carbon, 33K, 1/4 watt, +/-5%
Resistor, carbon, 27K, 1/4 watt, +/-5%
Resistor, carbon, 220K, 1/4 watt, +/-5%
Resistor, metal film, 100K, 1/4 watt,
+/-1 %
Resistor, metal film, 105K, 1/4 watt, +/-1%
SEMICONDUCTORS:
Diode, avalanche,
400V, 1A
Diode, zener, 5.6V
Diode, general purpose
LEO, red
Transistor, NPN
NOT USED
IN STANDARD APPLlCATIONS
Negative voltage regulator, 5Vdc
Dual phototransistor
Octel/bus driver, non-inverting
EPROM, 2K x8bit
Digital signal processor (DSP)
Counter, binary resettable SYNC/ASYNC
3line to 8line decoder/demultiplexer
Watchdog timer
Octal inverting buffer, 3state
Ouad 2input nand schmidt trigger
14bit DAC
Dual operational amplifier
Dual amplifier
Hex inverter
INIVEN Part
Number
DT20V105K
CM-Z5U-D-104-M
CM-NPO-E-180-J
MPC32E103H
MPC32E822G
MPC32E273H
MPC32E222H
MPC32E223H
CM-NPO-D-101-J
DT35V475K
CM-NPO-D-331-J
RCF07J622
RCF07J562
RCF07J503
RCF07J203
RCF07J102
RCF07J104
RCF07J103
RCF07J681
RCF07J472
RCF07J392
RCF07J214
3008P-1-503
RN55D1181 F
RN55D1002F
RCF07J333
RCF07J273
RCF07J224
RN55D1003F
RN55D1053F
1N4004
1N752A
1N914
550-1106-RED
2N4401
MC79M05CT
MCT6
MM74HC244N
CY7C291-50WC
TMS320C10NL
MM74HC161N
MM74HC138N
DS1232
MM74HC240N
MM74HC132N
AD7840JN
TL0821P
TL081CT
MM74HC04N

Circuit
Symbol
T1
SW1,2
SW3
SW4
Y1
Description
MISCELLANEOUS COMPONENTS:
Transformer, INIVEN
Switch, DIP 8position
Switch, push
b1:.l,tton
Switch, toggle '
Crystal, quartz,20 MHz.
INIVEN Part
Number
CC1992-00
ADF-08
ADF-04
7101SYZB
SE200-AS
Table 1. Replaceable Parts, Voltage Converter board:
Circuit
Symbol
C4
C1
C2
C3
R3
R1
R2
01
Ui
Description
CAPACITORS:
Capacitor, ceramic, 0.1 uF, 50V, +/-20%
Capacitor, tantalum,
10uF, 35V, +/-20%
Capacitor, ceramic, 0.047uF,
50V, +/-10%
Capacitor, electrolytic,
100uF, 35V, +/-10%
RESISTORS:
Resistor, carbon, 2.2K, 1/4 watt, +/-5%
Resistor, carbon, 20K, 1/4 watt, +/-5%
Resistor, carbon, 200K, 1/4 watt, +/-5%
SEMICONDUCTORS:
Transistor, NPN
Switched capacitor voltage converter
INIVEN Part
Number
CM-Z5U-D-104M
DT35VI06M
CM-X7R-D-473K
ER35V107
RCF07J222
RCF07J203
RCF07J204
2N4401
LT1054CN8

NOTES

WARRANTY AGREEMENT
We hereby certify that the INIVEN product line carries awarranty for any part whicll
fails during normal operation or service for
12 Years. Adefective part should be returned
to the factory, shipping charges prepaid, for repair f.o.b. Somerville, New Jersey.
In case
INIVEN cannot promptly return the unit
to you, it will endeavor to provide aloaner until
the repair or replacement
is returned to you. Any unauthorized repairs or modifications
will void the warranty. This warranty
is contingent upon the commercial availability of parts
as purchased
by INIVEN. However, in the event that failure is less than two years from
the date of delivery of the product, INIVEN will accept full responsibility.
INIVEN 5Columbia
Rd. Somerville, NJ 08876
PRINTED
IN U.S.A.
INIVEN TM 5Columbia Rd. Somerville, NJ 08876
908-722-3770
FAX [phone]
