Insight Vision Digital Xpress D2 User manual

1 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company

2 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
TABLE OF CONTENTS
Warranty……………………………….page 3
Command Module……………………page 6
Remote…………………………………page 10
Base Frame…………………………….page 11
Camera…………………….…………...page 13

3 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
1 YEAR WARRANTY
Alliance Technology, LLC warrants to the first purchaser that should any of its products prove to be
defective in material or workmanship in normal use, within one (1) year from the date of delivery,
Alliance Technology, LLC will, at its exclusive option, repair, replace or exchange the product or any
of its parts. THIS WARRANTY IS SUBJECT TO THE FOLLOWING LIMITATIONS:
1. This warranty does not apply to any product which has been subject to accident, negligence,
alteration, abuse, misuse, overload, repair by anyone other than Alliance Technology, LLC or its
authorized representatives, or not maintained in accordance with the manufacturer's suggested
maintenance schedule.
2. This warranty applies only to components manufactured by Alliance Technology, LLC. The
appropriate manufacturer's warranty, if any, shall apply to components not manufactured by the
company.
3. This warranty does not apply to flex-link connectors, rod, LED light rings, cable, rollers, o-rings,
and skids, or other parts, which are considered consumable. The replacement of these items is
part of normal product maintenance.
4. This warranty shall not apply if the products are used or operated in any manner not consistent
with their intended purpose.
5. This warranty is limited to repair or replacement of defective products and parts during the
warranty period, and shall be the exclusive remedy. Alliance Technology, LLC shall in no event
have any other obligation or liability of any nature arising from the breakdown, malfunction, defect
or other failure of the product, including, without limitation, any liability for service, maintenance,
repairs, personal injury, property damage, loss of profits, loss of use or other consequential
damages.
6. Any action for any claimed breach of this warranty shall be brought within one (1) year from the
date of delivery of the product.
7. The purchaser must return the defective product, part or component to the Alliance Technology,
LLC factory in Saukville, WI 53080 at the purchaser's expense, properly and adequately
packaged, with insurance and transportation pre-paid. Alliance Technology, LLC will either repair
or replace the defective product, part or component, at its option, and will return it to the
purchaser at the customer's expense. In no event shall Alliance Technology, LLC be liable for
delay in repair or replacement and return under this warranty. Alliance Technology, LLC will
endeavour to effect appropriate repairs in the shortest time practical, with respect to the customer
having beneficial use of their equipment.
8. Alliance Technology, LLC neither assumes nor authorizes any person to assume any other
liability or make any other warranty in connection with the products.
9. THIS WARRANTY IS EXPRESSLY GIVEN IN LIEU OF ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED. ALLIANCE TECHNOLOGY, LLC EXPRESSLY DISCLAIMS ANY
OTHER WARRANTY, INCLUDING, WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

4 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
SYSTEM MAINTENANCE REQUIREMENTS
The following maintenance procedures are recommended for all Insight-Vision Digital
Xpress Systems. Standard warranty policy dictates that components and accessories subject
to wear and tear are not covered under the One (1) year warranty. Therefore we are
strongly recommending that all systems be maintained according to the following
procedures. Please be advised that Insight-Vision will not allow warranty coverage for these
items if these procedures are not followed.
Xpress D2 Command Module:
The D2 CM incorporates a USB port and LAN Network port for recording options. These
ports have no moving parts or recording heads so they do not require a cleaning device.
However, if water, dirt or dust become present in these connectors due to extreme conditions
in the field, owners/operators will be responsible for the cleaning of these connector/port
areas using a Q-tip or other non-abrasive cleaning tool to remove the debris before inserting a
memory stick or network connector.
FAILURE TO FOLLOW THIS PROCEDURE INVALIDATES ANY WARRANTY
CLAIM AGAINST INSIGHT VISION FOR THE FUNCTIONALITY OF THE
RECORDING DEVICE AND WARRANTY COVERAGE WILL NOT BE GRANTED.
O-Rings: O-rings are critical to insure the watertight integrity of the camera and connection
areas. O-rings are subject to wear and tear and can also suffer failure due to age and other
factors. They should be inspected regularly and replaced whenever needed.
When O-rings are working properly, a small amount of water and sometimes fine particles of
grit will build up behind them. Any time the camera or sonde connection is taken apart and
exposed, there exists the risk of grit wearing down or possibly even tearing the o-ring. It is
also possible for water to then enter the connection area once exposed. All connections, once
opened or exposed, MUST be thoroughly cleaned and dried before re-connecting. We
recommend using an old toothbrush or other soft bristled brush to clean the o-ring areas and
remove the grit or fine debris. Then, completely dry the area around male and female
connector and the o-ring before re-connecting.
Camera Head: All Insight Vision camera heads (CV, CVSL and CVmicro) are covered for
one (1) year under the standard warranty against all defects in workmanship. These cameras
are all sealed and pressurized with nitrogen to prevent water ingress. Warranty coverage will
apply for any and all internal failures to the camera head unless external damage is evident.

5 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
This would include a broken sapphire lens window and any deformation to the stainless steel
metal housing of the camera head.
Insight-Vision has provided a small and large protective skid that MUST be used at all times.
These skids are designed to aid in the centering of the camera head and have the added
benefit of helping to protect the camera head from extreme wear. Failure to use the provided
skids will result in direct wear to the front metal work area of the camera, resulting in the
eventual wearing down of the metal work. This wear will result in a possible breach that will
allow water to ingress into the camera head. This type of wear will not be covered under
warranty.
Push Rod: Insight Vision push rod terminations are covered for one (1) year under warranty.
This warranty policy covers workmanship on the termination connection ONLY and does not
cover push rod breakage or kinks in other parts of the rod.

6 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company

7 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
MAIN SYSTEM CONTROLS
1. Brightness Up - Increase Camera Head
LED brightness - recommended to keep
this at full brightness.
2. Brightness Down - Decrease Camera Head
LED brightness.
3. System Power ON/OFF button. Red LED
indicates system is ON.
4. On-Screen Distance Counter Position.
Button will toggle distance counter to 6
positions on display.
5. On-Screen Distance Counter Reset.
Button will reset distance counter to zero.
6. LED System Indicators
a. Green “Charging On” LED
- ON Green - Full Charge
- BLINKING Green - Charging
- OFF Green - Not Charging
b. Yellow “Power Low” LED
- OFF Yellow - Normal
- 1/2 sec ON, 1/2 sec OFF - Power Low
- 1 sec ON, 1 sec OFF - System Fault
c. Blue “Mic On” LED
- ON Blue - Microphone ON
- OFF Blue - Microphone Off
7. Built-In Microphone and IR remote window
8. Microphone ON/OFF button. Blue “MIC”
LED and on-screen “MIC” appear when ON.

8 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
9. On-Demand Recording ON/OFF Button. Red
blinking LED indicates recorder is turning ON
and will be ready for use shortly. Green LED
indicates recorder is ON and is ready for use.
10. Speaker ON/OFF button. Sound playback
is available during video playback. Button
will toggle volume from lowest to highest.
11. Built-In Speaker
12. Menu Button - Menu button brings up
the on-screen configuration menu.
Please call Insight Vision customer support
for assistance. Also doubles as a “soft”
key for on-screen display.
13. Menu Button - This button is used as a
“soft” key for on-screen display
14. Menu Button - This button is used as a
“soft” key for on-screen display. Also
doubles as a textwriter selection screen
15. Text-Writer Page Selector - 4 pages
a. Pg 1 - No text. Distance counter only
b. Pg 2 - Contractor Form Page
c. Pg 3 - Client Form Page
d. Pg 4 - Free Form Page
16. USB Thumbdrive Port - Used to connect the an
USB Thumbdrive for recording video.
17. USB to PC Port - Used to connect the Optional
Internal Hard Drive to a P.C. Move files
efficiently to an external computer.
18. Video Out Jack

9 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
19. Audio Out Jack
20. Camera Test Port - Camera Diagnostic Port.
21. Main System Connection - Connect provided
Interconnect Cable (8) to this receptacle.
22. Main System Power Connection - Connect the
main power cable. This connection will power
your D2 Camera System AND recharge the
internal battery. Note: Advanced functionality
recharges internal battery even when system is off.
23. Auxilliary System Power - Same as number 2
above but WITHOUT internal charging of battery

10 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
REMOTE CONTROL LAYOUT
Select “Camera View” from Main Menu to
view live video
Use GUIDE key to switch from “Camera View”
to “Main Menu”
1. One-Touch Recording Button - When in
Camera View, hit button to start recording.
2. Display - Show additional information during
playback and recording
3. Zoom - Zoom into video during playback. Use
arrow buttons for additional functionality.
4. Select - Select file names when performing
copy/paste/delete file functions on optional internal
Hard Drive and external USB Thumbdrive.
5. Option - Use for additional file name functionality
including file rename.
6. GOTO - Additional functionality during playback
7. GUIDE - Return to main Menu System from
Camera View.
8. OK Selection Button and Arrow Buttons - Used
to Select highlighted items and navigate menu
9. Return - Return to previous menu item.
10. Stop - Used to Stop Recording or Playback.
Play - Used to Play recorded videos.
Fast Rewind/Fast Forward Button - Used
during playback
Previous/Next Button - Used during playback to
go to previous or next recording
Slow - Used during playback
Pause/Step - Used during playback to pause video

11 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
Xpress Large Base Frame Reel
The large base frame is a ruggedized aluminum reel
designed to house 200’ or 300’ of the rigid (A) type
rod or semi-rigid (B) type rod.
This base frame comes with an integral digital
footage counter.
The design of this frame brings the push rod out from
the front to allow for easy operation.
When camera is not in use please store in basket.
This frame has been designed with a pull out luggage
style handle and wheels for easy transport. All anti-
slide supports are made with a non-marring material
safe for all floor surfaces.
The top part of the base frame includes a mounting
bracket for any of the Xpress command modules.
Stiff Rod (A)
The letter A following the rod length indicator designates the Insight Vision rigid
push rod. Example: 200A = 200’ of stiff rod.
This push rod is .475” in diameter and has been specifically designed for longer
pushing distances in 2”-12” pipe.
Attempts should not be made to push this rod type through 2” 90 degree bends as rod
breakage may occur. This rod type is only available in 200’ and 300’ lengths on the
large horizontal base frame.
Semi-rigid Rod (B)
The letter B following the rod length indicator designates the Insight Vision semi-
rigid push rod. Example: 150B = 150’ of semi-rigid rod.
This push rod is .365“ in diameter and has been specifically designed for pushing
normal distances in 2” through 4” pipe and achieving multiple 90-degree bends.
This rod type is available in the standard 100’, 150’ length. 200’ lengths are by
special order only.

12 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
Debris Bag
This optional item comes in two sizes, one for each size of base frame reels.
It is intended to minimize drippings while working indoors.
It is easily removable for cleaning.

13 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
ClearView Camera
This camera has a self-leveling feature that will position the camera so that the top of
the pipe will appear on the top of the display. (If ordered)
This is a color camera with LED’s for illumination of the pipe being inspected.
The camera module has an integrated auto iris feature, which will automatically
adjust for varied light levels.
The Sonde is not built into the camera.
This camera is intended for operation in pipes 2-12” I.D.
This camera will function with any of our Xpress command modules as well as our
Silver Bullet or Universal Jetcam systems.
Diameter is 1.30”
Sonde/Spring Assembly
The removable sonde is located inside the spring assembly
It continually transmits a signal at 512Hz and can be located with any locator capable
of picking up a 512Hz signal.
Skid Set
The skids are intended to protect the camera from damage due to debris in the pipe
being inspected.
The standard skids come in two sizes.
The small skid is for use in 3-4” diameter pipes.
The large skid is for use in 4-6” diameter pipes.

14 of 14
An Alliance Technology Company
600 Dekora Woods Blvd. Saukville, WI 53080
Toll Free: 800-488-8177 Local: 262-268-9330 Fax: [phone]
An Alliance Technology Company
Installation and removal of skids.
The skid is a two-piece device that must be unscrewed for installation.
Slide the rear half over the pushrod and slid forward to the rear of the camera.
Slide the front half over the camera to meet the rear half.
Screw the two pieces together to hold the skid in place.
Removal is the reverse of the installation steps.
