13 14
2Drawing and measuring commands:
12345678910 11 12 13 14 15 16 17
18 19 20 21 22 23 24 25 26 27
3. Save file: save present work.
4. Output as “ Word” : If “ Microsoft office” is installed in your
computer, program will open “Word” and output selected drawing
data(on the data-tree) to form a “Word” file.
5. Output as Excel: If Microsoft office is installed in your computer,
program will open Excel and output selected drawing data(on the
data-tree) to form a Excel file.
6. Output as DXF: Output present drawing as DXF file.
7. Metric / Inch switch: switch data unit between metric and Inch.
8. Cancel delete: back to recall deleted drawing objects.
9. Reticle line color: Change reticle line color in the image area.
10. Focusing instruction: click the icon to open focusing
indication dialogue box.
11. Load proofread parameter: Load proofread parameter file
that have been saved before.
12. Input coordinate: Open dialogue box to input coordinate. you
can draw point, line and arc/circle,In this box.
13. Coordinate translate: Translate present coordinate system to
a new position to set a new coordinate system.
14. Image correction: Use a standard circle to correct the
software.
1. Point drawing: Draw a point and record its coordinate.
2. Line drawing: Input two points and click right mouse button to
end to get a line. Input at least three points and click right mouse
button to end to get a regression line.
3. Circle drawing: Input at least three points and click right
mouse key to end to get a circle. parameters like circle
center, radius, roundness proportion will be acquired
also.(in data-tree) .
4. Arc drawing: Input at least three points, the first point as
the start point, the second point to determine arc direction
and the last point as the end point. Click right mouse key to
end points input to get the arc, program will calculate
parameters like center, radius, length, inclination of the arc.
5. Auto-catch edge point(s): When this button is pressed down,
program will find the strongest black-white contrast point in
image zone and make it as the input point, otherwise (the button
is not pressed down), program will take the mouse key click
position as the input point.
6. Auto-line measurement: Input a rectangle by a mean of
dragging the mouse, adjust the size and position of rectangle and
then right click, the program will regress most suitable line
automatically in rectangle box.
7. Auto-circle measurement: create two concentric circles by
dragging mouse, and right mouse click after adjusting the two
circles size, then the program will automatically regress another
concentric circle in the annulus area between the two concentric
circles, and the arrow expresses the way of regressing, from
inside to outside or from outside to inside.
8. Auto-arc measurement: concentric circle is changed into
concentric arc.
9. Box select points group: Use left mouse key to box select a
field in the image zone, program will get all the edge points inside
the field and display them in points group style automatically.
10. Box select line: Use left mouse key to box select a field in the
image zone, program will fit the line inside the field automatically.
11. Box select circle: Use left mouse key to box select a field in
the image zone, program will find the circles inside the field
automatically.
12. Box select arc: use left mouse key along the same
direction (clockwise or counter-clockwise) to select one or
some non-overlapping panes, program will fit a arc
automatically according to the points within these panes.
13. Point- select point group: Use left key to click in the
video zone, the program will regard the point as the center
and look for the edge around, then display the edge data
acquired in the form of point group.
