Integratech HEAT MASTER User manual

5. Trouble Shooting
Problem Possible Cause Solutions
HEAT MASTER cannot be turned
on after pressing the power
switch.
Low battery. Charge at least 4-6 hours.
Battery defect. Replace the battery with the same
type
LCD flashes and alarm beeps
continuously when utility power is
normal.
The HEAT MASTER is overload. Remove some loads first. Before
reconnecting equipment, please
verify that the load matches
capacity specified in the specs.
Circuit breaker trip. Reset the breaker.
Battery defect. Replace the battery with the same
type of battery.
When power fails, back-up time is
shorten.
It is overload. Remove some critical load.
Battery voltage is too low. Charge it at least 4-6 hours.
Battery defect. It might be due
to high temperature operation
environment, or improper
operation to battery.
Replace the battery with the same
type of battery.
The mains is normal but it is
battery mode.
Power cord is loose. Reconnect the power cord
properly.
6. Specifications
HEAT MASTER
Rated Output Capacity / Capacidad Nominal
Peak Capacity / Capacidad Pico 800 VA / 640 W (< 5 s)
Input - Entrada
Voltage / Voltaje - Frequency / Frecuencia
Output - Salida
Voltage / Voltaje - Frequency / Frecuencia
Auto-restart / Auto-arranque Yes / Si
Internal Batteries - Baterías Internas
Type / Tipo
Back-up Time / Autonomía (*)
Recharge Time / Tiempo de Recarga
Protections / Protecciones
Overloads / Sobre-Cargas
Surge/Spikes Protection / Protección contra Picos
Product Features / Características del Producto
Power Outlets / Tomas
Product Size-Weight / Dimensiones-Peso Producto
Operating / Condiciones de Operación
Specifications may change without further notice / Las especificaciones pueden cambiar sin previo aviso.
see related backup table / revisar tabla de autonomía
6-8 hours to 90% capacity / 6-8 Horas hasta 90%
Circuit Breaker with Manual Reset / Disyuntor Rearmable
MOV protection L-N / Protección MOV entre L-N
1 x SCHUKO (CEE 7/4) or 1 x FRENCH
319 x 190 x 150 - (9 Kg)
< 95% RH (non condensing) / < 40 dB / 0-40ºC
250 VA / 200 W
230V (162-268 Vac) - 50Hz
230V (+/- 10'%) - 50Hz
Maintenance Free VRLA-AGM / Sellada Sin Mantenimiento
HEAT MASTER
1. Introduction
HEAT MASTER is exclusively designed for electronically controlled boilers and home heaters that
contains electronic control circuitry and electric water pump. Featuring with dynamic voltage regulator,
this device can ensure stable power to connected loads as utility. Equipped with LCD digital display, it
provides real-time system vitals to users. The built-in DC start function enables the HEAT MASTER to
be started up without a supply of AC power. The main features of this HEAT MASTER are listed below:
Microprocessor control guarantees high reliability
Built-in enhanced boost & buck AVR
Fast charger
Green power function for energy saving
Auto restart during AC recovery
Comprehensive LCD display
External battery connection available for long-term operation
2. Product Overview
LCD Panel:
1Inputvoltage 4 Battery mode indicator
2Outputvoltage 5 Load level indicator, flashing indicates overload
3 AC mode indicator 6 Battery capacity indicator, flashing indicates low battery
Power switch
Output receptacles
AC input
Circuit breaker
External battery connector

3. Installation and Initial Startup
NOTE: Before installation, please inspect the unit. Be sure nothing inside the package is damaged.
Placement Conditions
Install the HEAT MASTER in a protected area that is free of excessive dust and has adequate air flow.
Please place the HEAT MASTER away from other units at least 20 cm to avoid interference. Do NOT
operate the HEAT MASTER where the temperature and humidity is outside the specific limits.
(Please check the specs for the limitations.)
Connect to Utility and Charging
Plug in AC input cord to the wall outlet. The unit charges its battery while connecting to the utility.
Connect to External Battery Bank
Simply connect to external battery connector with battery cables.
Connect the Loads
Simply plug in the motor-typed load to output receptacles on the side of the HEAT MASTER. Simply
turn on the power switch of HEAT MASTER unit. Then, the device connected to the HEAT MASTER
will be protected by HEAT MASTER unit.
Turn On/Off the Unit
Turn on the HEAT MASTER unit by pressing the power switch. Turn off the HEAT MASTER unit by
pressing again the power switch.
Wall Mount the Unit
The unit can be mounted to a wall surface.
1. Refer to Chart 1 to mark 6 black dot on the wall.
2. Use a sharp nail to puncture the center of each black dot.
3. Mount the unit by positioning the key-hole slots over the mounting nails. (see chart 2)
Chart 1 Chart 2
4. Important Safety Warning (SAVE THESE INSTRUCTIONS)
CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled
indoor area free of conductive contaminants. (See the specifications for the acceptable temperature
and humidity range.)
CAUTION! To reduce the risk of overheating the HEAT MASTER, do not cover the HEAT MASTER
cooling vents and avoid exposing the unit to direct sunlight or installing the unit near heat emitting
appliances such as space heaters or furnaces.
CAUTION! Do not plug the HEAT MASTER input into its own output.
CAUTION! Do not allow liquids or any foreign object to enter the HEAT MASTER. Do not place
beverages or any other liquid-containing vessels on or near the unit.
CAUTION! Connection to any other type of receptacle other than a two-pole, three-wire grounded
receptacle may result in shock hazard as well as violate local electrical codes.
CAUTION! In the event of an emergency, press the “OFF” button and disconnect the power cord from
the AC power supply to properly disable the HEAT MASTER.
Attention hazardous through electric shock. Also with disconnection of this unit from the mains,
hazardous voltage still may be accessible through supply from battery. The battery supply should be
therefore disconnected in the plus and minus pole at the quick connectors of the battery when
maintenance or service work inside the HEAT MASTER is necessary.
CAUTION! Servicing of batteries should be performed or supervised by personnel knowledgeable of
batteries and the required precautions. Keep unauthorized personnel away from batteries.
CAUTION! When replacing the batteries, use the same number and type of batteries.
CAUTION! Internal battery voltage is 12VDC. Its technology is sealed, free-maintenance, lead-acid
battery.
CAUTION! Do not dispose of batteries in a fire. The battery may explode. Do not open or mutilate the
battery or batteries. Released electrolyte is harmful to the skin and eyes.
CAUTION! Unplug the HEAT MASTER prior to cleaning and do not use liquid or spray detergent. It
does not require internal cleaning.
CAUTION! A battery can present a risk of electric shock and high short circuit current. The following
precaution should be observed before replacing batteries: Remove watches, rings, or other metal
objects. Use tools with insulated handles. Wear rubber gloves and boots. Do not lay tools or metal
parts on top of batteries. Disconnect charging source prior to connecting or disconnecting batteries
terminal.
