Intel®Desktop Board
D865PERL
Specification Update
Release Date: August 2004
Order Number: C41596-009
The Intel®Desktop Board D865PERL may contain design defects or errors known as errata,
which may cause the product to deviate from published specifications. Current characterized
errata are documented in this Specification Update.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED
BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS,
INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY,
RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO
FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR
OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT INTENDED FOR USE IN MEDICAL, LIFE
SAVING, LIFE SUSTAINING APPLICATIONS.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved” or “undefined”.
Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from
future changes to them.
The Intel®desktop board D865PERL may contain design defects or errors known as errata which may cause the product to
deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be
obtained from:
Intel Corporation
P.O. Box 5937
Denver, CO 80217-9808
or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,
Germany 44-0-1793-421-333, other Countries 708-296-9333
Intel, Pentium, Celeron, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the
United States and other countries.
* Other names and brands may be claimed as the property of others.
Copyright ©2003, 2004 Intel Corporation.

CONTENTS
REVISION HISTORY ................................................................................................................................... v
PREFACE................................................................................................................................................... vi
Specification Update for the Intel®Desktop Board D865PERL
GENERAL INFORMATION ..........................................................................................................................3
SPECIFICATION CHANGES .......................................................................................................................7
ERRATA .................................................................................................................................................... 12
SPECIFICATION CLARIFICATIONS ......................................................................................................... 15
DOCUMENTATION CHANGES ................................................................................................................. 24

Intel®Desktop Board D865PERL Specification Update
v
REVISION HISTORY
Date of Revision Version Description
June 2003 -001 This document is the first Specification Update for the
Intel®Desktop Board D865PERL. Added Errata 1, 2 and
Specification Clarifications 1, 2.
July 2003 -002 Added Specification Clarification 3.
November 2003 -003 Added Specification Change 1, Specification Clarification 4 and
Documentation Changes 1.
January 2004 -004 Added Specification Changes 2, 3. Added Errata 5-8. Added
Specification Clarifications 5, 6.
March 2004 -005 Added Specification Change 4.
April 2004 -006 Added Erratum 9.
May 2004 -007 Added Specification Change 1. Updated Erratum 9. Added
Specification Clarification 7.
July 2004 -008 Updated Specification Clarifications 3 and 7.
August 2004 -009 Added Erratum 10.

Intel®Desktop Board D865PERL Specification Update
v
i
PREFACE
This document is an update to the specifications contained in the Intel
®
Desktop Board D865PERL Technical
Product Specification
(Order number C31764). It is intended for hardware system manufacturers and
software developers of applications, operating systems, or tools. It will contain Specification Changes, Errata,
Specification Clarifications, and Documentation Changes.
Refer to the
Intel
®
Pentium
®
4 Processor Specification Update (Order number 249199) for specification
updates concerning the Intel Pentium 4 processor and that may apply to the desktop board D865PERL.
Unless otherwise noted in this document, it should be assumed that any processor errata for a given stepping
are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.
Refer to the
Intel
®
865PE Chipset: 82865PE Memory Controller Hub (MCH) Specification Update (Order
Number 252523) for specification updates concerning the 82865PE MCH Controller and that may apply to the
desktop board D865PERL. Unless otherwise noted in this document, it should be assumed that any MCH
errata for a given stepping are applicable to the Altered Assembly (AA) revision(s) associated with that
stepping.
Refer to the
Intel
®
82801EB I/O Controller Hub (ICH5R) / 82801ER I/O Controller Hub (ICH5) Specification
Update
(Order Number 252517) for specification updates concerning the 82801ER I/O Controller Hub and
that may apply to the desktop board D865PERL. Unless otherwise noted in this document, it should be
assumed that any ICH 5 errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)
associated with that stepping.
Nomenclature
Specification Changes are modifications to the current published specifications. These changes will be
incorporated in the next release of the specifications.
Errata are design defects or errors. Characterized errata may cause the desktop board D865PERL’s
behavior to deviate from published specifications. Hardware and software designed to be used with any
given Altered Assembly (AA) and BIOS revision level must assume that all errata documented for that AA
and BIOS revision level are present on all desktop boards.
Specification Clarifications describe a specification in greater detail or further highlight a specification’s
impact to a complex design situation. These clarifications will be incorporated in the next release of the
specifications.
Documentation Changes include typos, errors, or omissions from the current published specifications.
These changes will be incorporated in the next release of the specifications.

Specification Update for the
Intel®Desktop Board D865PERL

Intel®Desktop Board D865PERL Specification Update
3
GENERAL INFORMATION
Basic Desktop Board D865PERL Identification Information
AA Revision BIOS Revision Notes
C27648-206 RL86510A.86A.0046.P03 1-5
C27648-207 RL86510A.86A.0052.P06 1-5
C27648-208 RL86510A.86A.0061.P09 1-5
C27648-209 RL86510A.86A.0071.P13 1-5
C27648-210 RL86510A.86A.0075.P15 1-5
C26719-207 RL86510A.86A.0046.P03 1-5
C26719-208 RL86510A.86A.0052.P06 1-5
C26719-209 RL86510A.86A.0056.P07 1-5
C26719-210 RL86510A.86A.0058.P08 1-5
C26719-211 RL86510A.86A.0061.P09 1-5
C26719-212 RL86510A.86A.0075.P13 1-5
C26719-213 RL86510A.86A.0075.P15 1-5
C27646-206 RL86510A.86A.0046.P03 1-5
C27646-207 RL86510A.86A.0052.P06 1-5
C27646-208 RL86510A.86A.0056.P07 1-5
C27646-209 RL86510A.86A.0058.P08 1-5
C27646-210 RL86510A.86A.0061.P09 1-5
C27646-211 RL86510A.86A.0075.P13 1-5
C27646-212 RL86510A.86A.0075.P15 1-5
C27650-206 RL86510A.86A.0046.P03 1-5
C27650-207 RL86510A.86A.0052.P06 1-5
C27650-208 RL86510A.86A.0056.P07 1-5
C27650-209 RL86510A.86A.0061.P09 1-5
C27650-210 RL86510A.86A.0071.P13 1-5
C27650-211 RL86510A.86A.0075.P15 1-5
C40926-201 RL86510A.86A.0052.P06 1-5
C40926-202 RL86510A.86A.0061.P09 1-5
C40926-203 RL86510A.86A.0071.P13 1-5
C40926-204 RL86510A.86A.0075.P15 1-5

Intel®Desktop Board D865PERL Specification Update
4
NOTES:
1. The AA number is found on a small label on the component side of the board.
2. The 82865PE Chipset kit used on this AA revision consists of two components as follows:
Device Stepping S-Spec Numbers
82865PE MCH A2 SL722
82801EB ICH
82801ER ICH
A3
A3
SL73Z
SL742
3. Refer to the Intel
®
Pentium
®
4 Processor Specification Update (Order Number 249199) for errata related to the Pentium 4
processor and that may apply to the desktop board D865PERL.
4. Refer to the
Intel
®
865PE Chipset: 82865PE Memory Controller Hub (MCH) Specification Update (Order Number 252524)
for errata related to the 82865P MCH
that may apply to the desktop board D865PERL.
5. Refer to the
Intel
®
82801EB I/O Controller Hub (ICH5R) / 82801ER I/O Controller Hub (ICH5) Specification Update (Order
Number 252517) for errata related to the 82801ER I/O Controller Hub that may apply to the desktop board D865PERL.

Intel®Desktop Board D865PERL Specification Update
5
Summary Table of Changes
The following table indicates the Specification Changes, Errata, Specification Clarifications, or Documentation
Changes that apply to the Intel®desktop board D865PERL. Intel intends to fix some of the errata in a future
revision of the desktop board, and to account for the other outstanding issues through documentation or
specification changes as noted. This table uses the following notations:
CODES USED IN SUMMARY TABLE
Doc: Document change or update that will be implemented.
PlanFix: This erratum may be fixed in a future revision of the desktop board, driver, or
BIOS.
Fixed: This erratum has been previously fixed.
NoFix: There are no plans to fix this erratum.
Shaded: This erratum is either new or modified from the previous version of the document.
NO. PLANS SPECIFICATION CHANGES
1 Doc Change to description of the SMBIOS specification listed in Table 3, Section 1.4
2 Doc Change to description of the SMBIOS specification listed in Table 3, Section 1.4
3 Doc Change to description of Section 2.11.1, DC Loading
4 Doc Change to Thermal Considerations, Section 2.12
5 Doc Change to description of Section 1.7.3.3, serial ATA RAID. Addition of RAID 1 support
NO. PLANS ERRATA
1 No Fix Audio driver creates a popping noise during operating system startup.
2 Plan Fix Front panel audio connector signals routed incorrectly.
3 Plan Fix PCI slot 1 cannot be used with long PCI add-in cards
4 No Fix Advance jack sense may not recognize devices connected to a front panel audio port
5 No Fix Advance jack sense on boards with 6-channel audio will report “Microphone” for any
device connected to the back panel microphone port (pink)
6 No Fix Advance jack sense will not detect devices connected to the Center/LFE and Surround
ports
7 No Fix Advance jack sense may report amplified speakers as an array microphone when
connected to the microphone port (pink)
8 No Fix An additional reboot may be required after installing audio drivers for Microsoft
Windows* 98SE or Windows ME
9 Plan Fix System memory may be reduced in excess of the amount of AGP aperture size when
4GB of system memory are used
10 Plan Fix Some systems may hang if the mouse is moved when entering standby mode

Intel®Desktop Board D865PERL Specification Update
6
Summary Table of Changes (cont)
NO. PLANS SPECIFICATION CLARIFICATIONS
1 Doc Add note that specifies Enhanced Mode IDE/Serial ATA requirements to Section 3.3.2,
PCI IDE Support.
2 Doc Updates to the design specifications applicable to the desktop board D865PERL.
3 Doc Change to description of Table 28, Front Panel Audio Connector.
4 Doc Clarification of SMBus routing
5 Doc Clarification of DDR voltage
6 Doc Clarification of Section 2.11.1, DC Loading
7 Doc Change to Description of Section 2.9.1, Front Panel Audio Connector/Jumper Block
NO. PLANS DOCUMENTATION CHANGES
1 Doc Removal of Intel®branding from subtitle of Section 1.10.2

Intel®Desktop Board D865PERL Specification Update
7
SPECIFICATION CHANGES
The Specification Changes listed in this section apply to the Intel
®
Desktop Board D865PERL Technical
Product Specification
(Order Number C31764). All Specification Changes will be incorporated into a future
version of that specification.
1. Change to Description of the SMBIOS Specification Listed in
Table 3, Section 1.4
Table 3, Section 1.4, SMBIOS specification will change as follows:
Table 3. Specifications
Reference
Name
Specification
Title
Version, Revision Date,
and Ownership
The information is
available from…
SMBIOS
System
Management
BIOS
Version 2.3.2,
October 12, 2001,
Distributed Management
Taskforce, Inc (DMTF)
http://www.dmtf.org/stand
ards/documents/SMBIOS
/DSP0130.pdf
2. Change to Description of the SMBIOS Specification Listed in Table
3, Section 1.4
Table 3, Section 1.4, SMBIOS specification will change as follows:
Table 3. Specifications
Reference
Name
Specification
Title
Version, Revision Date,
and Ownership
The information is
available from…
SMBIOS
System
Management
BIOS
Version 2.3.4,
December 6, 2002,
Distributed Management
Taskforce, Inc (DMTF)
http://www.dmtf.org/stand
ards/documents/SMBIOS/
DSP0134.pdf
3. Change to Description of Section 2.11.1, DC Loading
Table 43, Section 2.11.1, DC Loading, will change in its entirety as follows:
2.11.1 DC LOADING
Table 43 lists the DC loading characteristics of the board.

Intel®Desktop Board D865PERL Specification Update
8
Table 43. DC Loading Characteristics
DC Current at:
Mode DC Power +3.3 V +5 V +12 V -12 V +5 VSB
Minimum loading 190.00 W 5.00 A 11.00 A 9.00 A 0.03 A 0.60 A
Maximum loading 310.00 W 11.00 A 15.00 A 15.00 A 0.10 A 1.38 A
4. Change to Thermal Considerations, Section 2.12
Section 2.12, Thermal Considerations will change in its entirety as follows:
2.12 Thermal Considerations
CAUTION
The use of an Intel®Pentium®4 processor operating above 2.80 GHz with this
Intel®desktop board requires the following:
• A chassis with appropriate airflow to ensure proper cooling of the
components on the board
• A processor fan heatsink that meets the thermal performance targets for
Pentium 4 processors operating above 2.80 GHz
The use of an Intel Pentium 4 processor with 1 MB of L2 cache on this Intel
desktop board requires the following:
• A chassis with a maximum internal ambient temperature of 38 Degrees
Celsius
• A processor heatsink that provides omnidirectional airflow so that air is
drawn across the processor voltage regulator area (item A in Figure 30).
Figure 29a illustrates an omnidirectional airflow heatsink.

Intel®Desktop Board D865PERL Specification Update
9
Figure 29a. Omnidirectional Airflow Heatsink
Failure to ensure appropriate airflow may result in reduced performance of both
the processor and/or voltage regulator or, in some instances, damage to the
desktop board. For a list of chassis that have been tested with Intel®desktop
boards please refer to the following website:
http://developer.intel.com/design/motherbd/cooling.htm
All responsibility for determining the adequacy of any thermal or system design
remains solely with the reader. Intel makes no warranties or representations that
merely following the instructions presented in this document will result in a
system with adequate thermal performance.
CAUTION
Ensure that the ambient temperature does not exceed the Desktop Board
D865PERL’s maximum operating temperature. Failure to do so could cause
components to exceed their maximum case temperature and malfunction. For
information about the maximum operating temperature, see the environmental
specifications in Section 2.14.

Intel®Desktop Board D865PERL Specification Update
10
CAUTION
Ensure that proper airflow is maintained in the processor voltage regulator
circuit. Failure to do so may result in damage to the voltage regulator circuit.
The processor voltage regulator area (item A in Figure 30) can reach a
temperature of up to 85 °C in an open chassis.
Figure 30 shows the locations of the localized high temperature zones.
OM15903
B
A
D
C
Item Description
A Processor voltage regulator area
B Processor
C Intel®82865PE MCH
D Intel®82801EB ICH5 or 82801ER ICH5-R
Figure 30. Localized High Temperature Zones

Intel®Desktop Board D865PERL Specification Update
11
Table 45 provides maximum case temperatures for components on the Desktop Board
D865PERL that are sensitive to thermal changes. The operating temperature, current
load, or operating frequency could affect case temperatures. Maximum case
temperatures are important when considering proper airflow to cool the Desktop Board
D865PERL.
Table 45. Thermal Considerations for Components
Component Maximum Case Temperature
Intel®Pentium®4 processor For processor case temperature, see processor
datasheets and processor specification updates
Intel®82865PE MCH 99 oC (under bias)
Intel®82801EB ICH5 or
82801ER ICH5-R
115 oC (under bias)
For information about Refer to
Intel Pentium 4 processor datasheets and specification
updates
Section 1.2, page 16
5. Change to Description of Section 1.7.3.3, Serial ATA RAID.
Addition of RAID 1 Support
Section 1.7.3.3 will change in its entirety as follows:
1.7.3.3 Serial ATA RAID
The ICH5-R supports RAID (Redundant Array of Independent Drives) level 0
and level 1 on the Serial ATA ports. RAID 0 provides the ability to support
striping. Two physical drives, of identical size, can be teamed together to create
one logical drive. As data is written or retrieved from the logical drive, both
drives operate in parallel, thus increasing the throughput. RAID 1 provides the
support of disk mirroring. Data is written simultaneously to two physical drives,
of identical size, providing fault tolerance if one of the two drives fails.
✏NOTE
The ICH5-R provides support for RAID O, RAID 1 and RAID boot in
Windows* XP and Windows 2000 only.

Intel®Desktop Board D865PERL Specification Update
12
ERRATA
1. Audio Driver Creates a Popping Noise During Operating System
Startup
PROBLEM:The audio jack-sensing feature requires reading the impedance of the device connected to the
audio jack. A voltage is needed so a current can be measured, and the impedance is derived from the
voltage and current. The application of the voltage results in a popping noise that is emitted from the
speakers.
IMPLICATION:A popping noise from the speakers may be heard at the end of the operating system startup
tune, while loading Microsoft Windows operating systems.
WORKAROUND:None.
STATUS:This erratum will not be fixed.
2. Front Panel Audio Connector Signals Routed Incorrectly
PROBLEM:The front panel audio connector pin definition is not correct. Pin 4 is defined as +5 V and should
be ground. Pin 7 is defined as ground and should be +5V.
IMPLICATION:Front panel audio cards that route their +5 V rail to Pin 4 will not function correctly.
WORKAROUND:Front panel audio cards that require +5 V should route the +5 V rail to Pin 7.
STATUS:This erratum may be fixed in a future hardware revision.
3. PCI Slot 1 Cannot be Used With Long PCI Add-in Cards
PROBLEM:A tall capacitor is located 3 ¼ inches behind PCI slot 1.
IMPLICATION:PCI cards conforming to the PCI specification but exceed 8 inches in length, may not be
useable in PCI slot 1.
WORKAROUND:None.
STATUS:This erratum may be fixed in a future hardware revision.

Intel®Desktop Board D865PERL Specification Update
13
4. Advance Jack Sense May Not Recognize Devices Connected to a
Front Panel Audio Port
PROBLEM:The advanced jack sense with Auto Topology Switching, that is used by the audio codec to
recognize what device is connected to an audio port, may fail to report devices connected to a front-panel
port.
IMPLICATION:Devices connected through a front panel audio port will be detected and function correctly, but
the advance jack sense wizard will only report the device at start up.
WORKAROUND:None.
STATUS:This erratum will not be fixed.
5. Advance Jack Sense on Boards with 6-Channel Audio Will Report
“Microphone” for Any Device Connected to the Back Panel
Microphone Port (Pink)
PROBLEM:For boards with 6-channel audio, the advanced jack sense with Auto Topology Switching, that is
used by the audio codec to recognize what device is connected to an audio port, will report “Microphone” for
any device connected to the back panel pink microphone port.
IMPLICATION:The advanced jack sense wizard will report any device connected through the back panel
microphone port to be a “Microphone” and the wizard will prompt the user to verify this detection assumption.
WORKAROUND:None.
STATUS:This erratum will not be fixed.
6. Advance Jack Sense Will Not Detect Devices Connected to the
Center/LFE and Surround Ports
PROBLEM: Polling devices connected to the Center/LFE and Surround port would cause popping noise once
speakers are connected. Due to this anomaly, the advance jack sense wizard will not poll and report devices
connected to the Center/LFE and Surround ports although these devices will work correctly.
IMPLICATION:Devices connected to the Center/LFE or Surround port will be detected and function correctly,
but the advance jack sense wizard will not poll and report the device.
WORKAROUND:None.
STATUS:This erratum will not be fixed.
7. Advance Jack Sense May Report Amplified Speakers as an Array
Microphone When Connected to The Microphone Port (Pink)
PROBLEM:The presence of voltage bias on the microphone jack during the detection phase is required for
accurate detection, but amplified speakers and array microphones have very similar impedance values.
IMPLICATION:Amplified speakers will be detected and function correctly, but the advance jack sense
wizard may report the device as an array microphone.

Intel®Desktop Board D865PERL Specification Update
14
WORKAROUND:None.
STATUS:This erratum will not be fixed.
8. An Additional Reboot May Be Required After Installing Audio
Drivers for Microsoft Windows 98SE or Windows ME
PROBLEM: An application post-installer completes the driver installation and requires an additional reboot to
get full functionality in Windows 98SE or Windows ME.
IMPLICATION:An additional reboot is required after installing audio drivers for Windows 98SE or
Windows ME.
WORKAROUND: None.
STATUS:This erratum will not be fixed.
9. System Memory May Be Reduced in Excess of the Amount of AGP
Aperture Size When 4GB of System Memory are Used
PROBLEM:The AGP aperture size setting in the system BIOS will consume, from available system memory,
2 times the amount applied in the AGP aperture setting when the maximum of 4 GB of system memory is
installed.
IMPLICATION:When 4GB of system memory are used, and system memory is allocated to AGP aperture
size in BIOS Setup, available system memory may be reduced by twice the amount allocated. A similar
impact to available system memory may occur from any allocation of system memory when 4 GB of system
memory is used. For example, increasing the video frame buffer in BIOS may also reduce available memory
in excess of the amount requested.
WORKAROUND:None.
STATUS:This erratum may be fixed in a future BIOS revision.
10. Some Systems May Hang if the Mouse is Moved When Entering
Standby Mode
PROBLEM:Moving the mouse after placing the system into standby with the mouse may cause the system
to immediately awaken and hang.
IMPLICATION:The system may hang if the user is moving the mouse directly after using the mouse to place
the system into standby mode.
WORKAROUND:None.
STATUS:This erratum may be fixed in a future board revision.
