Intel Gigabit Ethernet Expansion Card for IBM
ER s e r v e r BladeCenter
Installation Instructions


Intel Gigabit Ethernet Expansion Card for IBM
ER s e r v e r BladeCenter
Installation Instructions


Note: Before using this information and the product it supports, read the general
information in Appendix B, “IBM Statement of Limited Warranty Z125-4753-07 11/2002,”
on page 21 and Appendix C, “Notices,” on page 43.
First Edition (May 2004)
© Copyright International Business Machines Corporation 2004. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by
GSA ADP Schedule Contract with IBM Corp.

Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . .v
Chapter 1. Introduction . . . . . . . . . . . . . . . . . .1
Inventory checklist . . . . . . . . . . . . . . . . . . . .2
Related documentation . . . . . . . . . . . . . . . . . . .2
Features and specifications . . . . . . . . . . . . . . . . . .3
Notices and statements used in this document . . . . . . . . . . .4
Major components of the Intel Gigabit Ethernet Expansion Card . . . . .5
Chapter 2. Installing the I/O expansion card . . . . . . . . . . .7
Installation guidelines . . . . . . . . . . . . . . . . . . .7
Handling static-sensitive devices . . . . . . . . . . . . . . . .7
Installing the I/O expansion card on a blade server . . . . . . . . .8
Chapter 3. Troubleshooting . . . . . . . . . . . . . . . .17
Appendix A. Getting help and technical assistance . . . . . . . .19
Before you call . . . . . . . . . . . . . . . . . . . . .19
Using the documentation . . . . . . . . . . . . . . . . . .19
Getting help and information from the World Wide Web . . . . . . .20
Software service and support . . . . . . . . . . . . . . . .20
Hardware service and support . . . . . . . . . . . . . . . .20
Appendix B. IBM Statement of Limited Warranty Z125-4753-07 11/2002 21
Part 1 - General Terms . . . . . . . . . . . . . . . . . . .21
Part 2 - Country-unique Terms . . . . . . . . . . . . . . . .25
Part 3 - Warranty Information . . . . . . . . . . . . . . . .39
Appendix C. Notices . . . . . . . . . . . . . . . . . . .43
Edition notice . . . . . . . . . . . . . . . . . . . . .44
Trademarks . . . . . . . . . . . . . . . . . . . . . .44
Important notes . . . . . . . . . . . . . . . . . . . . .45
Product recycling and disposal . . . . . . . . . . . . . . . .45
Electronic emission notices . . . . . . . . . . . . . . . . .46
Federal Communications Commission (FCC) statement . . . . . . .46
Industry Canada Class A emission compliance statement . . . . . .46
Australia and New Zealand Class A statement . . . . . . . . .46
United Kingdom telecommunications safety requirement . . . . . .47
European Union EMC Directive conformance statement . . . . . .47
Taiwanese Class A warning statement . . . . . . . . . . . .47
Chinese Class A warning statement . . . . . . . . . . . . .48
Japanese Voluntary Control Council for Interference (VCCI) statement 48
© Copyright IBM Corp. 2004 iii

Index . . . . . . . . . . . . . . . . . . . . . . . .49
iv Intel Gigabit Ethernet Expansion Card for IBM ER s e r v e r BladeCenter: Installation Instructions

Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety
Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
© Copyright IBM Corp. 2004 v

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette
produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Antes de instalar este producto, lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Important::
All caution and danger statements in this documentation begin
with a number. This number is used to cross reference an English
caution or danger statement with translated versions of the
caution or danger statement in the IBM Safety Information book.
For example, if a caution statement begins with a number 1,
translations for that caution statement appear in the IBM Safety
Information book under statement 1.
Be sure to read all caution and danger statements in this
documentation before performing the instructions. Read any
additional safety information that comes with your server or
optional device before you install the device.
vi Intel Gigabit Ethernet Expansion Card for IBM ER s e r v e r BladeCenter: Installation Instructions

Statement 1:
DANGER
Electrical
current from power, telephone, and communication cables is
hazardous.
To avoid a shock hazard:
v Do not connect or disconnect any cables or perform
installation, maintenance, or reconfiguration of this product
during an electrical storm.
v Connect all power cords to a properly wired and grounded
electrical outlet.
v Connect to properly wired outlets any equipment that will
be attached
to this product.
v When possible, use one hand only to connect or disconnect
signal cables.
v Never turn on any equipment when there is evidence of
fire, water, or
structural damage.
v Disconnect the attached power cords, telecommunications
systems,
networks, and modems before you open the device covers, unles
instructed
otherwise in the installation and configuration procedures.
v Connect and disconnect cables as described in the following
table when installing, moving, or opening covers on this product
or attached devices.
To Connect: To Disconnect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
Safety vii

Statement 3:
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
v Do not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable
parts inside the device.
v Use of controls or adjustments or performance of procedures other than
those specified herein might result in hazardous radiation exposure.
DANGER
Some
laser products contain an embedded
Class 3A or
Class 3B laser diode. Note the following.
Laser radiation when open. Do not stare into the beam,
do not view directly with optical instruments, and avoid direct
exposure to the beam.
Class 1 Laser Product
Laser Klasse 1
Laser Klass 1
Luokan 1 Laserlaite
Appareil A Laser de Classe 1
`
viii Intel Gigabit Ethernet Expansion Card for IBM ER s e r v e r BladeCenter: Installation Instructions

Statement 21:
CAUTION:
Hazardous energy is present when the blade is connected to the power
source. Always replace the blade cover before installing the blade.
WARNING: Handling the cord on this product or cords associated with
accessories sold with this product, will expose you to lead, a chemical known
to the State of California to cause cancer, and birth defects or other
reproductive harm. Wash hands after handling.
ADVERTENCIA: El contacto con el cable de este producto o con cables de
accesorios que se venden junto con este producto, pueden exponerle al plomo,
un elemento químico que en el estado de California de los Estados Unidos está
considerado como un causante de cancer y de defectos congénitos, además de
otros riesgos reproductivos. Lávese las manos después de usar el producto.
Safety ix

x Intel Gigabit Ethernet Expansion Card for IBM ER s e r v e r BladeCenter: Installation Instructions

Chapter 1. Introduction
This Installation Instructions document contains information for installing and
configuring the Intel
™
Gigabit Ethernet Expansion Card in an IBM
®
Eserver
BladeCenter
™
HS40 Type 8839 blade server.
The Intel Gigabit Ethernet Expansion Card has a dual-channel integrated
Gigabit Ethernet controller capable of connecting to either 10/100/1000-Mbps
networks through an Ethernet switch module or 1000 Mbps through other
supported I/O modules, on the BladeCenter unit. Communication signals are
routed from the blade server through the I/O expansion connectors on the
Intel Gigabit Ethernet Expansion Card to I/O-module bay 3 and bay 4 in the
BladeCenter unit.
Notes:
1. The modules in I/O-module bay 3 and bay 4 in the BladeCenter unit must
both be compatible with the Intel Gigabit Ethernet Expansion Card.
2. Unless otherwise stated, references to the BladeCenter unit also apply to
the BladeCenter T unit.
Your Intel Gigabit Ethernet Expansion Card comes with a limited warranty. For
information about your warranty, see Appendix B, “IBM Statement of Limited
Warranty Z125-4753-07 11/2002,” on page 21. You can obtain up-to-date
information about the Intel Gigabit Ethernet Expansion Card and other IBM
xSeries
®
server products at http://www.ibm.com/eserver/xseries/.
For service or assistance, see Appendix A, “Getting help and technical
assistance,” on page 19.
The Intel Gigabit Ethernet Expansion Card is also referred to throughout this
book as the I/O expansion card or the expansion card.
© Copyright IBM Corp. 2004 1

Inventory checklist
The Intel Gigabit Ethernet Expansion Card option package contains the
following items:
v Intel Gigabit Ethernet Expansion Card
v I/O expansion tray
v Intel Gigabit Ethernet Expansion Card Installation Instructions
For updated information about configuring your Ethernet controller, go to the
IBM Support Web site at http://www.ibm.com/pc/support/ and navigate to
the area for your specific server type. From this area, you can download
documentation, the most current device drivers for your server, and software
that supports advanced networking functions.
Related documentation
This Installation Instructions contains setup and installation instructions for your
I/O expansion card, including information about getting started and how to
configure your I/O expansion card.
In addition to this Installation Instructions, the following documentation is
provided in PDF on the IBM BladeCenter Documentation CD or the IBM
BladeCenter T Documentation CD that comes with your blade server:
v IBM 4-Port Gb Ethernet Switch Module for BladeCenter Installation and User’s
Guide
This document contains instructions for setting up and configuring the IBM
4-Port Gb Ethernet Switch Module for BladeCenter and a description of the
switch module features.
v Nortel Networks Layer 2-7 GbE Switch Module for IBM Eserver BladeCenter
Installation Guide
This document contains instructions for setting up and configuring the
Nortel Networks Layer 2-7 GbE Switch Module for IBM Eserver
BladeCenter and a description of the switch module features.
v BladeCenter Optical Pass-thru Module Installation Guide
This document contains instructions for setting up and configuring the IBM
Eserver BladeCenter Optical Pass-thru Module and a description of the I/O
module features.
v BladeCenter Type 8677 Installation and User’s Guide
This document contains instructions for setting up and configuring the
BladeCenter unit and basic instructions for installing some options. It also
contains general information about the BladeCenter unit.
2 Intel Gigabit Ethernet Expansion Card for IBM ER s e r v e r BladeCenter: Installation Instructions

v BladeCenter T Types 8720 and 8730 Installation and User’s Guide
This document contains instructions for setting up and configuring the
BladeCenter T unit and basic instructions for installing some options. It also
contains general information about the BladeCenter T unit.
v BladeCenter Type 8677 Rack Installation Instructions
This document contains the instructions for installing your BladeCenter unit
in a rack.
v BladeCenter T rack installation instructions
These documents contain instructions for installing the BladeCenter T unit in
4-post, universal telco frame (UTF), and 2-post racks.
v Hardware Maintenance Manual and Troubleshooting Guides
These documents contain information to help you solve problems yourself,
and they contain information for service technicians.
v BladeCenter blade server Installation and User’s Guides
Each type of blade server has a customized Installation and User’s Guide.
These documents provide general information about your blade server.
v Safety Information
This document contains translated caution and danger statements. Each
caution and danger statement that appears in the documentation has a
number that you can use to locate the corresponding statement in your
language in the Safety Information document.
Depending on your blade server model, additional documents might be
included on the IBM BladeCenter Documentation CD or the IBM BladeCenter T
Documentation CD.
In addition to reviewing the documents in this library, be sure to review the
IBM BladeCenter Planning and Installation Guide or the IBM BladeCenter T
Planning and Installation Guide at http://www.ibm.com/pc/support/ for
information to help you prepare for system installation and configuration.
Features and specifications
The Intel Gigabit Ethernet Expansion Card has the following features:
v Connection to 1000BASE-TX environments
v Serialiser/Deserialiser (SerDes) interface to the backplane
v Compliance with U.S. and international safety and emissions standards
v Specialized connector for supporting PCI-X 64-bit/133-Mhz signaling
v Full-duplex (FDX) capability, enabling simultaneous transmission and
reception of data on the Ethernet local area network (LAN)
v Wake on LAN
®
support
v Failover support
Chapter 1. Introduction 3

Notices and statements used in this document
The caution and danger statements that appear in this document are also in
the multilingual Safety Information document, which is on the IBM BladeCenter
Documentation CD and the IBM BladeCenter T Documentation CD. Each
statement is numbered for reference to the corresponding statement in the
Safety Information document.
The following types of notices and statements are used in this document:
v Note: These notices provide important tips, guidance, or advice.
v Important: These notices provide information or advice that might help you
avoid inconvenient or problem situations.
v Attention: These notices indicate possible damage to programs, devices, or
data. An attention notice is placed just before the instruction or situation in
which damage could occur.
v Caution: These statements indicate situations that can be potentially
hazardous to you. A caution statement is placed just before the description
of a potentially hazardous procedure step or situation.
v Danger: These statements indicate situations that can be potentially lethal or
extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.
4 Intel Gigabit Ethernet Expansion Card for IBM ER s e r v e r BladeCenter: Installation Instructions

Major components of the Intel Gigabit Ethernet Expansion
Card
The following illustration shows the top of the Intel Gigabit Ethernet
Expansion Card.
Note: The illustrations in this document might differ slightly from your
hardware.
Gigabit Ethernet
controller
Gigabit Ethernet controller: Each channel of the dual-channel Gigabit Ethernet
controller on the I/O expansion card provides an output that is routed to a
different I/O-module bay on the BladeCenter unit.
Chapter 1. Introduction 5

The following illustration shows the components on the bottom of the Intel
Gigabit Ethernet Expansion Card.
I/O expansion
card connectors
6 Intel Gigabit Ethernet Expansion Card for IBM ER s e r v e r BladeCenter: Installation Instructions

Chapter 2. Installing the I/O expansion card
This chapter provides detailed instructions for installing the I/O expansion
card in your blade server.
Installation guidelines
Before you begin installing the I/O expansion card in your blade server, read
the safety information beginning on page v and the guidelines in “Handling
static-sensitive devices.” This information will help you work safely with your
blade server and options.
Handling static-sensitive devices
Attention: Static electricity can damage electronic devices, including your
blade server. To avoid damage, keep static-sensitive devices in their
static-protective packages until you are ready to install them.
To reduce the possibility of damage from electrostatic discharge, observe the
following precautions:
v When working on the BladeCenter T unit, use an electrostatic discharge
(ESD) wrist strap especially when you will be handling modules, options,
and blades. To work properly, the wrist strap must have a good contact at
both ends (touching your skin at one end and firmly connected to the ESD
connector on the front or back of the BladeCenter T unit).
v Limit your movement. Movement can cause static electricity to build up
around you.
v Handle the device carefully, holding it by its edges or its frame.
v Do not touch solder joints, pins, or exposed circuitry.
v Do not leave the device where others can handle and damage it.
v While the device is still in its static-protective package, touch it to any
unpainted metal surface of the BladeCenter unit or any unpainted metal
surface on any other grounded rack component in the rack you are installing
the device in for at least 2 seconds. (This drains static electricity from the
package and from your body.)
v Remove the device from its package and install it directly into the blade
server without setting down the device. If it is necessary to set down the
device, place it back into its static-protective package. Do not place the
device on your blade server cover or on a metal surface.
v Take additional care when handling devices during cold weather. Heating
reduces indoor humidity and increases static electricity.
© Copyright IBM Corp. 2004 7

Installing the I/O expansion card on a blade server
Important: Installation of an I/O expansion card requires removal of the IDE
drive (hard disk drive or flash drive) that is installed in IDE
connector 2. The I/O expansion card occupies the same space as
this IDE drive and replaces it. You cannot install an IDE drive in
IDE connector 2 while an I/O expansion card is installed in the
blade server.
v If the IDE drive installed in IDE connector 2 contains any
information that you want to keep, back it up to another storage
device.
v If the IDE hard disk drive installed in IDE connector 2 is part of
a RAID array, delete this IDE RAID array configuration before
removing the hard disk drive. When you delete the RAID array,
the array configuration information is removed; no data is
deleted. See the blade server Installation and User’s Guide for
instructions.
Note:
The illustrations used in this procedure depict the installation process on
a BladeCenter HS40 blade server in a BladeCenter Type 8677 unit. These
illustrations might differ slightly from your hardware.
Complete the following steps to install the I/O expansion card in a blade
server:
1. Make sure that you are using the latest versions of device drivers,
firmware, and BIOS for your blade server and management module. Go to
the IBM Support Web site, http://www.ibm.com/pc/support/ for the
latest information about upgrading the device drivers, firmware, and BIOS
for BladeCenter components. The latest instructions are in the
documentation that come with the updates.
Note: Unless otherwise stated, references to the BladeCenter unit also
apply to the BladeCenter T unit.
2. Read the safety information beginning on page v and the “Installation
guidelines” on page 7.
3. Make sure that IBM BladeCenter I/O modules that support your I/O
expansion card are installed in I/O-module bays 3 and 4 in the
BladeCenter unit. See the documentation that came with the I/O module
for instructions.
8 Intel Gigabit Ethernet Expansion Card for IBM ER s e r v e r BladeCenter: Installation Instructions
