Intel R1000EP series User manual

Thank you for buying an Intel® Server System. The following information will help you
assemble your Intel®Server System and install components.
If you are not familiar with ESD [Electrostatic Discharge] procedures used during
system integration, see the complete ESD procedures described in your Service Guide.
This guide and other supporting documents are located on the web at:
http://www.intel.com/support.
G62623-001
Intel® Server System R1000EP Family
Quick Installation User's Guide
* 3.5" hard drive bay system as shown

(This page is intentionally left blank.)

i
Table of Contents
General Installation Process ........................................................................................................ 2
Reference ............................................................................................................................................ 11
System Overview .............................................................................................................................. 1
Preparing the System ...................................................................................................... 2
Remove the Top Cover .................................................................................................... 2
Remove the Air Duct ........................................................................................................ 2
Remove Processor Heatsink(s) ................................................................................... 2
Install the Processor(s) .................................................................................................. 3
Install Processor Heatsink(s) ....................................................................................... 4
Install Memory Modules .................................................................................................. 4
Install Hard Drives .............................................................................................................. 5
Install Optical Drive ............................................................................................................ 7
Install the Air Duct ............................................................................................................. 7
Remove Add-in Card Riser Assembly ...................................................................... 7
Install Add-in Card(s) ......................................................................................................... 7
Install Add-in Card Riser Assembly ........................................................................... 8
Install Rack Handles .......................................................................................................... 8
Install Intel® I/O Expansion Module (optional) ..................................................... 8
Install Intel® RAID C600 Upgrade Key (optional) ............................................... 8
Install Intel® RAID Smart Battery (optional) ......................................................... 8
Replace Power Supply Module (optional) .............................................................. 9
Install Bezel (optional) ...................................................................................................... 9
Install the Top Cover ........................................................................................................... 9
Finishing Up ............................................................................................................................. 9
Software ............................................................................................................................... 10

ii
Warning
Read all caution and safety
statements in this document
before performing any of the
instructions. Also see the Intel
®
Server Board and Server Chassis
Safety Information document at:
http://www.intel.com/support/
motherboards/server/sb/cs-010770
.htm for complete safety information.
Warning
Installation and service
of this product to be
performed only by
qualified service personnel
to avoid risk of injury from
electrical shock or energy
hazard.
Caution
Observe normal ESD
[Electrostatic Discharge]
procedures during system
integration to avoid possible
damage to server board and/or
other components.
Tools Required
Anti-static
wrist strap
Phillips*
screwdriver
Intel is a registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. *Other names and brands may be claimed as the
property of others. Copyright © 2012, Intel Corporation. All rights reserved.
Thermal Operation and Configuration Requirements
To keep the system operating within supported maximum thermal limits, the system must meet the following operating and
configuration guidelines:
• Ambient in-let temperature cannot exceed 35º C and should not remain at this maximum level for long periods of
time. Doing so may affect long term reliability of the system.
• The CPU-1 processor + CPU heatsink must be installed first. The CPU-2 heatsink must be installed at all times,
with or without a processor installed.
• Memory Slot population requirements:
NOTE: Specified memory slots either can be populated with a DIMM or supplied DIMM Blank. Memory population
rules apply when installing DIMMs.
▪ DIMM Population Rules on CPU-1
Install DIMMs in order; Channels A, B, and C. Start with 1st DIMM slot (blue) on each channel, then slot 2.
▪ DIMM Population Rules on CPU-2
Install DIMMs in order; Channels D, E, and F. Start with 1st DIMM slot (blue) on each channel, then slot 2.
• All hard drive bays must be populated. Hard drive carriers either can be populated with a hard drive or supplied
drive blank.
• The air duct must be installed at all times.
• The system top-cover must be installed at all times.

1
System Overview
Hot Swap
Hard Drive Bays
CPU2
CPU1
Air Duct
Front Control Panel
PCI Riser
Power Supply
Server Board
System Fans
CPU2
Memory Slots
CPU1
Memory Slots
System Features and Components
* 3.5" Hard Drive Bay system as shown
Intel® Server System R1000EP Family
Useful Information:
• The SCU1 (4-7) port requires an Intel® RAID C600 Upgrade Key installed to be functional.

2
General Installation Process
The installation instructions in this section are for common components of Intel® Server System
R1000EP family.
Minimum Hardware Requirements
•Memory Type:
Minimum of one 512MB DDR3 800/1066/1333 MHz UDIMM or one 1GB
DDR3 800/1066/1333 MHz RDIMM.
•Processor:
Intel® Xeon® processor E5-2400 product family.
•Hard Disk Drives: SATA
For a complete list of compatible processors, heatsinks, and memory, see
http://www.intel.com/support.
To avoid integration difficulties and possible board damage, your system must
meet the following minimum requirements:
1
Preparing the System
Observe normal ESD (Electrostatic Discharge)
procedures.
Place your Intel®Server System on a flat anti-static
surface to perform the following integration procedures.
Observe ESD procedures before reaching inside to make
server board connections or install components.
A
B
B
2
Remove the Top Cover
B
Remove the four screws.
Slide cover back and lift upward.
A
IMPORTANT!
Before proceeding
further, check your
Intel®Server System
for disconnected or
loose cables and
components that
may have occurred
during shipping.
3
Remove the Air Duct
Remove the air duct by
lifting straight up.
4
Remove Processor Heatsink(s)
The heatsink is attached to the server board/processor socket with captive fasteners.
Lift the heatsink straight up.
A
B
C
CAUTION: The heatsink has thermal interface material (TIM) on the bottom
side of it. Use caution so that you do not damage the thermal interface
material. Use gloves to avoid sharp edges.
Using a #2 Phillips* screwdriver, loosen the four screws located on the
heatsink corners in a diagonal manner using the following procedure:
Using a #2 Phillips* screwdriver, start with screw 1 and loosen it by
giving it two rotations and stop. (IMPORTANT: Do not fully loosen.)
Proceed to screw 2 and loosen it by giving it two rotations and stop.
Similarly, loosen screws 3 and 4.
Repeat steps A and B by giving each screw two rotations each time
until all screws are loosened.
TIM
2
3
1
4
Chassis Front
A
B
C

3
General Installation Process
5Install the Processor(s)
Cautions:
1. When opening a socket,
DO NOT TOUCH the
golden socket wires.
A. Open the
Socket Lever
Rotate the lever open
all the way.
B. Open the
Load Plate
Open the load plate
as shown.
Push the lever handle
down and away from the
socket to release it.
A
B
Push the rear tab with your
finger tip to bring the front
end of the load plate
up slightly.
A
B
C. Remove the Processor
Protective Cover
2. When unpacking a
processor, hold only by the
edges to avoid touching the
golden contact wires.
A
B
A
B
A
Take the processor
out of the box and
remove the protective
shipping cover.
A
Install the Processor(s) ... continued
E. Close Load Plate and Socket Lever
Close the socket lever and ensure that
the load plate tab engages under the
socket lever when fully closed.
With your finger, push down on the
load plate as shown.
C
A
B
D. Install the Processor
CAUTION: The bottom
side of the processor has
components that may damage
the socket wires if installed
improperly.
DO NOT DROP processor
into the socket!
Processor must align
correctly with the socket
opening before installation.
Components
Orient the processor with the
socket so that the orientation
notches onthe processor align
with the two orientation posts
on the socket.
A
Install the processor as shown.
Orientation Posts
Orientation Notches
A
A
B
C
Close the load plate all
the way as shown.

4
General Installation Process
7Install Memory Modules
DDR3 DIMM Memory Identification:
Other
Memory
DDR3
CAUTION: Observe normal ESD (ElectroStatic
Discharge) procedures to avoid possible damage to
system components.
DIMM notch and socket bump must align as shown below.
6Install Processor Heatsink(s)
NOTE: Heatsink styles may vary.
Remove the protective film on the TIM if present.
D
CAUTION: The heatsink has thermal interface
material (TIM) on the bottom side of it. Use caution so
that you do not damage the thermal interface material.
Use gloves to avoid sharp edges.
E
C
A
BAlign heatsink fins to the front and back of
the chassis for correct airflow.
Airflow goes from front-to-back of chassis.
Each heatsink has four captive fasteners and
should be tightened in a diagonal manner using
the following procedure:
Using a #2 Phillips* screwdriver,
start with screw 1 and engage screw
threads by giving it two rotations
and stop. (Do not fully tighten.)
Proceed to screw 2 and engage screw
threads by giving it two rotations and
stop. Similarly, engage screws 3 and 4.
Repeat steps Cand Dby giving each
screw two rotations each time until
each screw is lightly tightened up to
a maximum of 8 inch-lbs torque.
C
AIRFLOW
Chassis Front
2
3
1
4
A
B
TIM
D
CAUTION:
Do not
over-tighten
fasteners.
E
DIMM_C2 DIMM_C1
DIMM_B1 DIMM_A1
DIMM_D1
DIMM_E1
DIMM_F1 DIMM_F2
CPU 2 Socket
CPU 1 Socket
Install Memory Modules ... Continued
Memory Configurations and Population Order:
Intel® Server Board S2400EP
For best performance, a minimum of four DIMMs per CPU is recommended, populated in the blue slot of each memory channel.
In a single-processor configuration, always populate A1 DIMM first.
In a dual-processor configuration, always populate A1 DIMM first for CPU 1 and D1 DIMM first for CPU2.
NOTE: For additional memory configurations, see the Service Guide on the Intel®Server Deployment & Management DVD that accompanied your Intel®
Server System, or go to http://www.intel.com/support.
Memory sizing and configuration is supported only for qualified DIMMs approved by Intel. For a list of supported memory, go to
http://serverconfigurator.intel.com.

5
General Installation Process
Install Memory Modules ... Continued
To Install DIMMs:
Open both DIMM socket levers.
C
A
D
E
Note location of alignment notch.
B
CAUTION: Avoid touching contacts
when handling or installing DIMMs.
A
C
DB
E
IMPORTANT! Visually check that each latch is fully closed and correctly engaged with
each DIMM edge slot.
Push down firmly on the DIMM until it snaps into place and both levers close.
Insert DIMM making sure the connector edge of the DIMM aligns correctly with the slot.
D
C
2.5" HDD
E
8Install
Hard Drives
2.5" Hard Drive Carrier (For system with 2.5" hard drive bay only)
Hard Drive Numbering Diagram
Drive 0 Primary
8 x 2.5" hard drive bay as shown
A
B
Remove the drive carrier by pressing the green latch
to unlock.
Pull out the black lever and slide the carrier out.
Remove the four screws securing the plastic drive blank
from the 2.5" HDD carrier.
Disengage the plastic drive blank from the HDD carrier.
Remove the plastic drive blank from the 2.5" HDD carrier.
C
D
Install the hard disk drive using the four screws as shown. Make Sure
the connector end of the drive matches the backplane connector.
E
With the lever open, insert the hard disk drive assembly into the chassis,
then push in the lever to lock it into place.
F
CAUTION: If you don't install
all drives, empty drive bays
must be occupied by carriers
with plastic drive blank
provided to maintain proper
system cooling.
A
B
F
0
1
2
3
4
5
67

6
General Installation Process
2.5" HDD
d3
d4
2.5" HDD
Install Hard Drives ... Continued
3.5" Hard Drive Carrier (For system with 3.5" hard drive bay only)
Hard Drive Numbering Diagram
Drive 0 Primary
A
B
Remove the drive carrier by pressing the green button and opening
the lever.
E
F
Slide the carrier out.
TOP
BREAK OFF TAB
BEFORE MOUTING
2.5´´ HARD DRIVE
C
Remove the four screws securing the HDD interface bracket and remove
the HDD interface bracket.
Install 2.5" Hard Drive as option:
3.5´´ HDD
D
D
Install the hard disk drive using the same four screws as shown. Make
sure the connector end of the drive matches the backplane connector.
With the lever open, insert the hard disk drive assembly into the chassis.
Push in the lever to lock it into place.
4 x 3.5’’ hard drive bay as shown
CAUTION: If you don't install
all drives, empty drive bays
must be occupied by carriers
with plastic drive blank
provided to maintain proper
system cooling.
d1 d4
d2 d3
Install the HDD interface bracket
from top. Secure the bracket with
three screws as shown.
Slide the 2.5" HDD into the
bracket to align the screw holes
with the right and left rail.
Break off the tab on the
HDD interface bracket.
Secure the hard disk drive using
the four screws for 2.5" HDD.
d1
Bottom
View
TOP
BREAK OFF TAB
BEFORE MOUTING
2.5´´ HARD DRIVE
d2
TOP
BREAK OFF TAB
BEFORE MOUTING
2.5´´ HARD DRIVE
A
B
F
E
0 1 2 3
C

7
General Installation Process
9Install Optical Drive
AB
IMPORTANT NOTE: If you do not
install a device at this location,
install the optical device bay filler
panel shown below. This is
required to maintain proper
system cooling.
Rear View
of Optical
Drive
A
Install the plastic guide onto the back
of the drive and attach with two screws
as shown.
Insert the optical drive into chassis opening
and push all the way until it stops.
CConnect the cables as shown.
Optical
Device
Assembly
B
Data
Power
Optical
Drive
C
10 Install the Air Duct
Align the two holes on the air duct with the alignment
pins on the chassis and install the air duct into place.
Use care to avoid pinching system cables.
Riser Card
Connector
11 Remove Add-in Card
Riser Assembly
Grasp the riser assembly with
both hands and pull up to
remove from system.
CAUTION:
Place the riser
assembly
upsidedown to
avoid damage
to the riser card
connector.
REMOVE Filler Panel
A
B
Add-in Card
C
Riser Connector
12 Install Add-in Card(s)
•Full-height PCIe Card Shown
A
B
C
CAUTION:
Observe normal ESD precautions
when installing add-in cards.
Insert add-in card until it seats in the riser connector.
Secure add-in card with screw as shown.
NOTE: Make sure that all empty add-in card slots have
filler panels installed.
NOTE: Add-in card install sequence for low-profile add-in
cards is the same.
Remove the filler panel from the add-in card slot and
remove the screw as shown.

8
General Installation Process
14 Install Rack Handles
NOTE: Rack handles are required to install
the bezel. For detailed instructions, see the
Service Guide.
Add-in Card
Slots (2)
Hooks (2)
13 Install Add-in Card Riser Assembly
Position the riser card edge
connector over the server
board riser socket and align
the two hooks of the riser with
the slots at the back of the
chassis, then press straight
down into riser socket.
NOTE: Riser Slot 2 is not
functional without having two
processors installed.
A
I/O Connector
I/O Module
C
B
D
15a
Install Intel® I/O Expansion
Module (optional)
A
D
B
Squeeze the sides of
the filler panel to
disengage it from the
server system back
panel and remove it.
Position the module
over the server board,
fit the front of the
module into the back
panel slot.
Secure the module with
the three screws as
shown.
C
Attach the module to
the server board
connector.
NOTE: If included, remember to install the EMI shield.
A
B
17 Install Intel® RAID Smart Battery (optional)
ALocate the BBU bracket inside the chassis. Align the tabs on the plastic battery holder
with mounting holes on the BBU bracket.
BSlide the plastic battery holder toward
the rear of the system until the tabs
engage with the mounting holes in
the BBU bracket.
CAUTION: Intel®
I/O Expansion
module and RMM4
module are
exclusive on Intel®
R1000EP system.
RMM 4 NIC
Connector
B
C
B
A
A
B
Push out and remove
the metal cover on the
chassis where the NIC
RJ-45 receptacle will
align.
Insert and fit the metal
adapter into the position
shown below. Secure the
adapter with two screws
as shown.
C
Position the module over
the server board, fit the
front of the module into
the back panel slot, then
attach the module to the
server board connector
Secure the module with
the two screws as
shown.
15b
Install Intel® RMM4 NIC Module
(optional)
STOR_UPG_KEY
Locate the white 4-pin key header next to Riser Slot 1.
Carefully pickup the Intel® RAID C600 Upgrade Key. Match
the Key and connector orientation and press down to install.
16 Install Intel® RAID C600
Upgrade Key (optional)

9
General Installation Process
A
B
19 Install Bezel (optional)
A
B
Lock the right end of the front bezel to the rack handle.
Rotate the front bezel clockwise till the left end clicks into place.
Lock the bezel if needed.
NOTE: Before installing the bezel, you must install the rack handles.
B
B
A
B
A
A
B
A
AInsert the power supply module into
the chassis
A
Unsecure the four screws from the
module as shown.
18 Replace Power Supply Module (optional)
Secure the module with the four screws
as shown.
B
Remove the power supply module.
B
20
Install the Top Cover
A
Install the three screws at the front and torque to 7-9in-lbs.
Then install the screw at the back and torque to 7-9in-lbs.
B
Place the top cover on system and slide towards the front of the
chassis until the recessed front edge is fully engaged.
B
A
A
Recessed
Edge
21
Finishing Up
1. Verify the system top cover is installed.
2. Install the server into the rack using the instructions
provided with the rack mounting kit.
3. Connect your USB keyboard/mouse, video and other
I/O cables/devices as shown.
Then connect the power cord(s).
CAUTION: This system must be operated with the
TOP COVER installed to ensure proper cooling.
Before installing your operating system, you
must finish your system installation, make I/O
connections, and plug in power cord(s).
For system BIK with S2400EP2
For system BIK with S2400EP4
Power
Supply
Module
Network
Network
NIC 1
NIC 2
Serial
Port A
USB
Ports
Intel ®RMM4
NIC Port
(optional)
Intel ®I/O
Module
(optional)
Add-in Card Slots
Video
or
Power
Supply
Module
NIC 3
NIC 1
NIC 2
NIC 4
Serial
Port A
USB
Ports
Intel ®RMM4
NIC Port
(optional)
Intel ®I/O
Module
(optional)
Add-in Card Slots
Video
or

10
General Installation Process
22
Software •BIOS, Drivers, and Operating System Installation
B. Configure your RAID Controller:
C. Install your Operating System:
D. Install Operating System Drivers:
A. Update the System Software:
E. Install Intel® System Management Software (optional):
2. Use the Wizard to access the latest versions on the Internet and update the BIOS, firmware, FRUSDRs, and Intel® RMM4.
NOTE: You may also download files on a USB key. The FRUSDR utility must be run for full platform management functionality.
1. Boot from the Intel®Server Deployment & Management DVD.
If using a RAID card, use the instructions provided with the RAID controller. If using on-board RAID, you must activate RAID in the BIOS setup.
See the Intel®Server System R1000EP Service Guide for more information.
Use the instructions provided with the RAID controller and with the operating system.
With the operating system running, insert the Intel®Server Deployment & Management DVD. If using a Microsoft Windows* operating system, the Express Installer will
autorun and allow you to select the appropriate drivers to install. On other operating systems, browse the DVD folders to locate and install the driver files.
Download the latest version of the Intel®System Management Software from http://www.intel.com/go/servermanagement and use the instructions provided at that link to
install the software.
* Other brands and names may be claimed as the property of others..

11
Reference
Front Panel Controls and Indicators Standard Control Panel
HIJ
A B C D E F G
Your system may include one of two front control panel types.The
features of each are as follows:
A. ID Button with integrated LED
B. NMI Button
C. LAN-1 Activity LED
D. LAN-3 Activity LED
E. System Cold Reset Button
F. System Status LED
G. Power Button with integrated LED
H. HDD Activity LED
I. LAN-4 Activity LED
J. LAN-2 Activity LED
DIMM_C2 DIMM_C1
DIMM_B1 DIMM_A1
DIMM_D1
DIMM_E1
DIMM_F1 DIMM_F2
CPU 2 Socket
CPU 1 Socket
VGA
SerialA
Status LED ID LED
Diagnostic
LED
Main Power
PMBus
CPU 2 Power
CPU 2
Fan
SCU 1
SCU 0
HSBP_I2C
IPMB
Front Panel
CPU 1 Power
CPU 1 Fan
USB 6
LCP
Sas Module Connector Battery
HDD LED
TPM
Chassis
Intrusion
USB 4/5
SATA 1
RMM4 LITE
SATA 0
Storage
Upgrade Key
SYS FAN_1 SYS FAN_2 SYS FAN_3 SYS FAN_4 SYS FAN_5
IO Module
RMM4 NIC
Slot 6 (PCIe x16 )
NIC3
(NIC1)
USB1
USB0
NIC4
(NIC2)
USB3
USB2
NIC1
NIC2
Intel® Server Board S2400EP Component Layout
See your Intel®Server System R1000EP Service Guide for expanded component and connection information.
* - For server systems integrated with Intel® Server Board S2400EP only.
NIC PORT SCHEME
S2400EP2 S2400EP4
NIC3NIC4 NIC1
NIC2
NIC1NIC2

12
Reference
A complete list of accessories and spares can be found at http://www.intel.com/support.
12345
CPU2 Socket
CPU1 Socket
FAN 1 FAN 2 FAN 3 FAN 4 FAN 5
System Fan Connection
Air Flow

13
Reference
CPU 2 Socket
CPU 1 Socket
FAN 1 FAN 2BBU FAN 3 FAN 4 FAN 5
8 x 2.5" HSBP
Front Panel
Front Panel USB
Optical Drive
I2C
HSBP_I2C
Power
Supply
Intel®Integrated
RAID Module
System Cabling Diagram
NOTE: To activate the port SCU1 (4-7) on the server board, a proper Intel®RAID C600 Upgrade Key must be
installed. For instructions, see Intel®RAID C600 Upgrade Key Installation Guide.
For system with 8 x 2.5” hard drive bay:

14
Reference
CPU 2 Socket
CPU 1 Socket
4 x 3.5" HSBP
SATA SGPIO
HDD O HDD 1 HDD 2
HDD 3
FAN 1 FAN 2 FAN 3 FAN 4 FAN 5
Optical Drive
I2C
HSBP_I2C
Power
Supply
Power
Supply
Front Panel
Front Panel USB
Intel®Integrated
RAID Module
BBU
System Cabling Diagram
NOTE: To activate the port SCU1 (4-7) on the server board, a proper Intel®RAID C600 Upgrade Key
must be installed. For instructions, see Intel®RAID C600 Upgrade Key Installation Guide.
For system with 4 x 3.5” hard drive bay:

( This page is intentionally left blank. )

G62623-001
