Intel R1000SPO series User manual

Intel® Server System R1000SPO
Product Family
System Integration and Service Guide
A guide providing instructions for the insertion and extraction of system components and available Intel
accessories and spares
Revision 1.0
April 2016
Intel® Server Boards and Systems

Intel® Server System R1000SPO Product Family System Integration and Service Guide
ii
<This page is intentionally left blank.>

Intel® Server System R1200SP Product Family System Integration and Service Guide
i
Document Revision History
Date
Revision
Number
Modifications
January 2016
0.7
First Preliminary version
April 2016
1.0
First External Public Release
Additions:
Raid Maintenance Free Backup Unit replacement
procedures
I/O Module replacement procedures
Front Panel board replacement procedures
Optical Disk Drive Installation and Removal
Changes
Updated Illustrations

Intel® Server System R1000SPO Product Family System Integration and Service Guide
ii
Disclaimers
No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this
document.
Intel disclaims all express and implied warranties, including without limitation, the implied warranties of
merchantability, fitness for a particular purpose, and non-infringement, as well as any warranty arising from
course of performance, course of dealing, or usage in trade.
This document contains information on products, services and/or processes in development. All information
provided here is subject to change without notice. Contact your Intel representative to obtain the latest
System Integration and Service Guide.
The products and services described may contain defects or errors known as errata which may cause
deviations from published specifications. Current characterized errata are available on request.
You may not use or facilitate the use of this document in connection with any infringement or other legal
analysis concerning Intel products described herein. You agree to grant Intel a non-exclusive, royalty-free
license to any patent claim thereafter drafted which includes subject matter disclosed herein.
Intel, the Intel logo, are trademarks of Intel Corporation in the U.S. and/or other countries.
*Other names and brands may be claimed as the property of others
© 2016 Intel Corporation.

Intel® Server System R1000SPO Product Family System Integration and Service Guide
iii
Safety Information
Important Safety Instructions
Read all caution and safety statements in this document before performing any of the instructions. See also
Intel Server Boards and Server Chassis Safety Information at
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.
Wichtige Sicherheitshinweise
Lesen Sie zunächst sämtliche Warnund Sicherheitshinweise in diesem Dokument, bevor Sie eine der
Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu Intel-Serverplatinen und
Servergehäusen auf der
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.
Consignes de sécurité
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce document avant de
suivre toute instruction. Consultez Intel Server Boards and Server Chassis Safety Information sur le site
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.
Instrucciones de seguridad importantes
Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar cualquiera de las
instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.
重要安全指导
在执行任何指令之前，请阅读本文档中的所有注意事项及安全声明。和/或
http://www.intel.com/support/motherboards/server/sb/cs-010770.htm 上的 Intel® Server Boards and Server
Chassis Safety Information（《Intel 服务器主板与服务器机箱安全信息》）。

Intel® Server System R1000SPO Product Family System Integration and Service Guide
iv
Warnings
Heed safety instructions: Before working with your server product, whether you are using this guide or any
other resource as a reference, pay close attention to the safety instructions. You must adhere to the assembly
instructions in this guide to ensure and maintain compliance with existing product certifications and
approvals. Use only the described, regulated components specified in this guide. Use of other
products/components will void the UL listing and other regulatory approvals of the product and will most
likely result in noncompliance with product regulations in the region(s) in which the product is sold.
System power on/off: The power button DOES NOT turn off the system AC power. To remove power from
the system, you must unplug the AC power cord from the wall outlet. Make sure the AC power cord is
unplugged before you open the chassis, add, or remove any components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be present on power,
telephone, and communication cables. Turn off the server and disconnect the power cord,
telecommunications systems, networks, and modems attached to the server before opening it. Otherwise,
personal injury or equipment damage can result.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips over two jumper
pins. Some jumpers have a small tab on top that you can grip with your fingertips or with a pair of fine needle
nosed pliers. If your jumpers do not have such a tab, take care when using needle nosed pliers to remove or
install a jumper; grip the narrow sides of the jumper with the pliers, never the wide sides. Gripping the wide
sides can damage the contacts inside the jumper, causing intermittent problems with the function controlled
by that jumper. Take care to grip with, but not squeeze, the pliers or other tool you use to remove a jumper,
or you may bend or break the pins on the board.
Electrostatic Discharge (ESD)
Electrostatic discharge can cause damage to your computer or the components within it. ESD can occur
without the user feeling a shock while working inside the system chassis or while improperly handling
electronic devices like processors, memory or other storage devices, and add-in cards.
Intel recommends the following steps be taken when performing any procedures described within this
document or while performing service to any computer system.
•Where available, all system integration and/or service should be performed at a properly equipped ESD
workstation
•Wear ESD protective gear like a grounded antistatic wrist strap, sole grounders, and/or conductive shoes
•Wear an anti-static smock or gown to cover any clothing that may generate an electrostatic charge
•Remove all jewelry
•Disconnect all power cables and cords attached to the server before performing any integration or
service
•Touch any unpainted metal surface of the chassis before performing any integration or service
•Hold all circuit boards and other electronic components by their edges only
•After removing electronic devices from the system or from their protective packaging, place them
component side up on to a grounded anti-static surface or conductive foam pad. Do not place electronic
devices on to the outside of any protective packaging.

Intel® Server System R1000SPO Product Family System Integration and Service Guide
v
Preface
About this document
This document is written for system integrators and service technicians who are responsible for system
assembly, server upgrades, server repair, and component replacement.
This document is divided into two major sections. The first half of the document provides detailed
instructions on how to install critical components to the system like memory, processor and others. It will
guide you through the installation of system components and available accessories. The second half of the
document is focused on system service. It provides many reference diagrams used to identify all key
physical features of the system. It also provides detailed instructions for the replacement of field replaceable
components.
For the latest revision of this document, go to http://www.intel.com/support
Document Organization
System Integration
Chapter 1 - Server Chassis Identification - provides basic information about component identification in the
system.
Chapter 2 – Essential System Component Installation and Service – provides instructions for adding
essential system components required to complete the integration of the server system. This includes
installation of Processors, Memory, Add-in Cards, and hot-swap storage devices
Chapter 3 – Option and Accessory Kit Integration and Service– provides instructions for adding and
removing various system options and available accessory option kits that maybe installed in the system
Chapter 4 – System Software Updates and Configuration - provides instructions for completing the
integration of the server system by updating the system software and navigating through the BIOS Setup
screens.
Chapter 5 – System Packaging Assembly – Provides package assembly instructions when re-using the Intel
packaging the system was originally shipped in.
System Service
Chapter 6 – System Service - System Features Overview – provides a high level overview of the Intel® Server
System R1000SPO product family. In this chapter, you will find a list of the server system features and
illustrations identifying the major system components.
Chapter 7 – System Service - FRU Replacement – provides guidance for the replacement of system
components considered as field replaceable units (FRUs).
Appendix A – Getting Help
Appendix B - System Cable Routing Diagrams
Appendix C - System Status LED Operating States and Definition
Appendix D – POST Code Diagnostic LED Decoder Table
Appendix E – POST Code Errors

Intel® Server System R1000SPO Product Family System Integration and Service Guide
vi
Additional Information and Software
For additional information about this family of products or any of their supported accessories, refer to the
following resources available at http://www.intel.com/support.
Table 1. Server System References
For this information or software
Use this Document or Software
For in-depth technical information about this product.
•Intel®Server System R1000SPO Product Family
Technical Product Specification
•Intel®Server Board S1200SP Technical Product
Specification
•Intel® Server System BIOS Setup Utility Guide
•Product Safety and Regulatory Compliance
http://www.intel.com/content/www/us/en/support.html
For a list of available systems within the product family
and supported Intel spares and accessories
Intel®Server Board S1200SP Product Family Spares and
Accessories List and Configuration Guide
For server configuration guidance and compatibility
Intel®Server Configurator tool
http://serverconfigurator.intel.com
To determine appropriate SAS/SATA cables
Intel® Server S1200SP Product Family Configuration Guide
and Spares/Accessories List
For system power budget guidance
Intel®Server Board S1200SP Product Family Power Budget
Tool and Thermal Configuration Guide
http://www.intel.com/content/www/us/en/support/server-
products/000017502.html?wapkw=s1200sp
For system firmware updates, onboard device drivers, and
software to manage your Intel® Server System.
https://downloadcenter.intel.com/search?keyword=S1200S
P
Product Safety and Regulatory Information
Intel Server Products - Product Safety and Regulatory
Compliance Document
The server system has support for several software utilities which can be used to configure system
parameters and aid in troubleshooting system issues. All available utilities can be downloaded from the
following Intel web site: http://downloadcenter.intel.com/

Intel® Server System R1000SPO Product Family System Integration and Service Guide
vii
Table of Contents
1Server Chassis Identification ................................................................................................................................. 12
1.1 Server Chassis Component Identification.......................................................................................................................12
2Essential System Component Installation and Service ................................................................................... 13
2.1 Internal Cable Routing............................................................................................................................................................13
2.2 System Cover Removal / Installation................................................................................................................................14
2.2.1 System Cover Removal ..................................................................................................................................................14
2.2.2 System Cover Installation.............................................................................................................................................14
2.3 Air Duct Removal / Installation ...........................................................................................................................................15
2.3.1 Air Duct Removal..............................................................................................................................................................15
2.3.2 Air Duct Installation.........................................................................................................................................................15
2.4 Processor Installation / Removal........................................................................................................................................16
2.4.1 Processor Installation.....................................................................................................................................................16
2.4.2 Processor Heatsink Installation..................................................................................................................................19
2.4.3 Processor Heatsink Removal.......................................................................................................................................20
2.4.4 Removing the Processor ...............................................................................................................................................20
2.5 Memory Installation and Removal ....................................................................................................................................21
2.5.1 Memory Slot population requirements ..................................................................................................................21
2.5.2 DDR4 DIMM Installation ................................................................................................................................................21
2.5.3 Removing Memory ..........................................................................................................................................................21
2.6 Storage Device Installation / Removal.............................................................................................................................22
2.6.1 4 x 3.5” Front Drive Bay Storage.................................................................................................................................22
2.6.2 8 x 2.5” Front Drive Bay Storage.................................................................................................................................25
2.7 Riser Card Assembly - Removal / Integration / Installation ....................................................................................27
2.7.1 Riser Card Assembly Removal....................................................................................................................................27
2.7.2 Mounting a Riser Card to the Riser Bracket...........................................................................................................28
2.7.3 PCI Add-in Card Installation ........................................................................................................................................28
2.7.4 PCI Riser Assembly Installation..................................................................................................................................29
2.8 Rack Handles – Installation / Removal ............................................................................................................................30
2.8.1 Installing the Rack Handles..........................................................................................................................................30
2.8.2 Removing the Rack Handles........................................................................................................................................30
3Option and Accessory Kit Integration and Service........................................................................................... 31
3.1 Slimline Optical Drive – Installation and Removal......................................................................................................32
3.1.1 Slimline Optical Drive Installation.............................................................................................................................32
3.1.2 Slimline Optical Drive Removal..................................................................................................................................33
3.2 Power Supply Module – Installation / Removal............................................................................................................34
3.2.1 Power Supply Module Installation............................................................................................................................34
3.2.2 Power Supply Module Removal .................................................................................................................................34
3.3 Intel® SAS RAID Module Installation / Removal............................................................................................................35
3.3.1 Intel® SAS RAID Module Installation ........................................................................................................................35
3.3.2 Intel® SAS RAID Module Removal..............................................................................................................................35
3.4 Intel® I/O Expansion Module – Installation / Removal................................................................................................35
3.4.1 Intel® I/O Expansion Module Installation ...............................................................................................................35
3.4.2 Intel® I/O Expansion Module Removal.....................................................................................................................36
3.5 SATA RAID 5 Upgrade Key – Installation / Removal...................................................................................................37
3.5.1 Installing the SATA RAID 5 Upgrade Key................................................................................................................37
3.5.2 Removing the SATA RAID 5 Upgrade Key ..............................................................................................................37
3.6 Intel® Remote Management Module 4 Lite Key – Installation / Removal ...........................................................38
3.6.1 Intel® RMM4 Lite Key Installation...............................................................................................................................38

Intel® Server System R1000SPO Product Family System Integration and Service Guide
viii
3.6.2 Intel® RMM4 Lite Key Removal ....................................................................................................................................38
3.7 Trusted Platform Module (TPM) Installation..................................................................................................................39
3.8 Front Bezel Replacement .......................................................................................................................................................40
3.8.1 Front Bezel Installation..................................................................................................................................................40
3.8.2 Front Bezel Removal.......................................................................................................................................................40
3.9 Intel® RAID Maintenance Free Backup Unit (RMFBU) ..................................................................................................41
3.9.1 Intel® RAID Maintenance Free Backup Unit (RMFBU) Installation.................................................................41
3.9.2 Intel® RAID Maintenance Free Backup Unit (RMFBU) Removal......................................................................42
4System Software Updates and Configuration.................................................................................................... 43
4.1 Updating the System Software Stack...............................................................................................................................43
4.2 Using the BIOS Setup Utility.................................................................................................................................................43
4.2.1 No Access to the BIOS Setup Utility.........................................................................................................................44
4.2.2 Navigating the BIOS Setup Utility..............................................................................................................................44
4.2.3 Restoring BIOS Default Values....................................................................................................................................45
5System Packaging Assembly.................................................................................................................................. 46
5.1 System Packaging Assembly Instructions ......................................................................................................................47
6System Service - System Features Overview ..................................................................................................... 50
6.1 System Feature Reference Diagrams................................................................................................................................50
6.1.1 Front Drive Bay Options.................................................................................................................................................51
6.1.2 Control Panel Features...................................................................................................................................................51
6.1.3 Front I/O Features ............................................................................................................................................................51
6.1.4 Back Panel Features ........................................................................................................................................................52
6.1.5 Server Board Features....................................................................................................................................................53
6.2 System Configuration and Recovery Jumpers ..............................................................................................................55
6.2.1 BIOS Default Jumper Block..........................................................................................................................................55
6.2.2 Password Clear Jumper Block ....................................................................................................................................56
6.2.3 Management Engine (ME) Firmware Force Update Jumper Block ..............................................................56
6.2.4 BMC Force Update Jumper Block..............................................................................................................................57
6.2.5 BIOS Recovery Jumper..................................................................................................................................................58
7System Service - FRU Replacement ..................................................................................................................... 59
7.1 System Fan Removal / Installation....................................................................................................................................60
7.1.1 System Fan Removal.......................................................................................................................................................60
7.1.2 System Fan Installation..................................................................................................................................................60
7.2 Replacing the System Battery..............................................................................................................................................62
7.3 Replacing a Backplane...........................................................................................................................................................64
7.3.1 Removing the Backplane ..............................................................................................................................................64
7.3.2 Installing the Backplane................................................................................................................................................64
7.4 Replacing the Standard Front Control Panel.................................................................................................................65
7.4.1 Standard Front Control Panel Removal...................................................................................................................65
7.4.2 Standard Front Control Panel Installation .............................................................................................................65
7.5 Replacing the Server Board..................................................................................................................................................66
7.5.1 Server Board Removal ...................................................................................................................................................66
7.5.2 Server Board Installation ..............................................................................................................................................67
Appendix A: Getting Help............................................................................................................................................... 68
Appendix B: System Cable Routing Diagrams........................................................................................................... 69
Appendix C: System Status LED Operating States and Definition........................................................................ 70
Appendix D: POST Code Diagnostic LED Decoder Table........................................................................................ 72
Appendix E: POST Code Errors..................................................................................................................................... 82

Intel® Server System R1000SPO Product Family System Integration and Service Guide
ix
List of Figures
Figure 1. Intel® Server System R1304SPOxxxx – 4 x 3.5” Front Drive Bay.......................................................12
Figure 2. Intel® Server System R1208SPOxxxx – 8 x 2.5” Front Drive Bay.......................................................12
Figure 3. Chassis Components/Features ............................................................................................................12
Figure 4. Internal Cable Routing..........................................................................................................................13
Figure 5. System Cover Removal.........................................................................................................................14
Figure 6. System Cover Installation ....................................................................................................................14
Figure 7. Air Duct Removal ..................................................................................................................................15
Figure 8. Air Duct Installation..............................................................................................................................15
Figure 9. Processor Installation – Open the Socket Lever ................................................................................16
Figure 10. Processor Installation– Open the Load Plate...................................................................................16
Figure 11. Processor Installation – Install the Processor..................................................................................17
Figure 12. Processor Installation – Close the Load Plate..................................................................................17
Figure 13. Processor Installation – Latch the Locking Lever ............................................................................18
Figure 14. Processor Installation – Remove the Socket Cover .........................................................................18
Figure 15. Processor Heatsink Installation ........................................................................................................19
Figure 16. Processor Heatsink Removal .............................................................................................................20
Figure 17. DDR4 DIMM Installation.....................................................................................................................21
Figure 18. DDR4 DIMM Removal .........................................................................................................................21
Figure 19. Installing Hot-swap storage devices – 3.5” carrier extraction........................................................22
Figure 20. 3.5” Drive Installation – Remove the drive blank ............................................................................23
Figure 21. 3.5” Drive Installation – Mounting drive to carrier ..........................................................................23
Figure 22. Option to install 2.5” SSD into a 3.5” carrier....................................................................................24
Figure 23. Drive Installation – Inserting 3.5” HDD assembly...........................................................................25
Figure 24. Installing Hot-swap storage devices – 2.5” carrier extraction........................................................25
Figure 25. 2.5” Storage Device Installation – Remove the drive blank............................................................26
Figure 26. 2.5” Storage Device Installation – Mount Drive to Carrier ..............................................................26
Figure 27. 2.5” Storage Device Installation – Inserting 2.5” Drive assembly ..................................................27
Figure 28. PCI Riser Assembly Removal.............................................................................................................27
Figure 29. Riser Card Installation to Riser Bracket ............................................................................................28
Figure 30. PCI Add-In Card Installation..............................................................................................................28
Figure 31. Installing PCI Riser Assembly............................................................................................................29
Figure 32. Installing the Rack Handle.................................................................................................................30
Figure 33. Removing the Rack Handle................................................................................................................30
Figure 34. Removing the Optical Disk Drive Filler.............................................................................................32
Figure 35. Slimline Optical Drive Installation....................................................................................................33
Figure 36. Slimline Optical Drive Removal.........................................................................................................33
Figure 37. Power Supply Module Installation....................................................................................................34
Figure 38. Power Supply Module Removal ........................................................................................................34
Figure 39. Intel® SAS RAID Module Installation.................................................................................................35
Figure 40. Installing Intel® I/O Expansion Module .............................................................................................35
Figure 41. Removing an I/O Expansion Module.................................................................................................36
Figure 42. Installing the SATA RAID 5 Upgrade Key..........................................................................................37
Figure 43. Installing the Intel® RMM4 Lite ..........................................................................................................38
Figure 44. Trusted Platform Module (TPM) Installation ...................................................................................39
Figure 45. Front Bezel Installation......................................................................................................................40
Figure 46. Front Bezel Removal...........................................................................................................................40
Figure 47. Intel® RAID Maintenance Free Backup Unit (RMFBU) Installation ..................................................41
Figure 48. Intel® RAID Maintenance Free Backup Unit (RMFBU) Removal.......................................................42

Intel® Server System R1200SP Product Family System Integration and Service Guide
x
Figure 49. Package Assembly Reference Diagram.............................................................................................47
Figure 50. Intel® Server System R1000SPO Features Overview .......................................................................50
Figure 51. 3.5" Drive Bay – 4 Drive Configuration (Model R1304SPOxxxxx)...................................................51
Figure 52. 2.5” Drive Bay – 8 Drive Configuration (Model R1208SPOxxxxx)...................................................51
Figure 53. Control Panel Features.......................................................................................................................51
Figure 54. Front I/O Panel Features ....................................................................................................................51
Figure 55. Back Panel Features............................................................................................................................52
Figure 56. Server Board Feature Identification..................................................................................................53
Figure 57. Intel® Light-Guided Diagnostic LEDs - Server Board........................................................................54
Figure 58. System Fan Connections....................................................................................................................54
Figure 59. System Configuration and Recovery Jumpers.................................................................................55
Figure 60. System Fan Removal ..........................................................................................................................60
Figure 61. System Fan Installation......................................................................................................................60
Figure 62. Connect System Fan Cables...............................................................................................................61
Figure 63. Replacing the Backup Battery ...........................................................................................................63
Figure 64. Removing the Backplane ...................................................................................................................64
Figure 65. Standard Front Control Panel Removal ............................................................................................65
Figure 66. Server Board Removal........................................................................................................................66
Figure 67. Server Board Installation...................................................................................................................67
Figure 68. System Cable Routing Diagrams .......................................................................................................69
Figure 69. POST Diagnostic LED Location..........................................................................................................72

Intel® Server System R1200SP Product Family System Integration and Service Guide
xi
List of Tables
Table 1. Server System References......................................................................................................................vi
Table 2. BIOS Setup: Keyboard Command Bar...................................................................................................44
Table 3. System Status LED State Definitions....................................................................................................70
Table 4. POST Progress Code LED Example.......................................................................................................73
Table 5. POST Progress Codes ............................................................................................................................73
Table 6. MRC Progress Codes ..............................................................................................................................79
Table 7. POST Progress LED Codes.....................................................................................................................81
Table 8. POST Error Codes and Messages..........................................................................................................82
Table 9. POST Error Beep Codes.........................................................................................................................84
Table 10. Integrated BMC Beep Codes................................................................................................................84

Intel® Server System R1000SPO Product Family System Integration and Service Guide
12
1Server Chassis Identification
Figure 1. Intel® Server System R1304SPOxxxx – 4 x 3.5” Front Drive Bay
Figure 2. Intel® Server System R1208SPOxxxx – 8 x 2.5” Front Drive Bay
1.1 Server Chassis Component Identification
Figure 3. Chassis Components/Features

Intel® Server System R1000SPO Product Family System Integration and Service Guide
13
2Essential System Component Installation and Service
Purpose
This chapter provides instructions for the installation and removal of essential system components including
processors, memory, storage devices, riser cards, and add-in cards.
Before You Begin
Before working with your server product, observe the safety and ESD precautions found in the Warnings
section at the beginning of this document.
Tools and Supplies Needed
•Anti-static wrist strap and conductive foam pad (recommended)
•Phillips* (cross head) screwdriver (#1 and #2 bits)
System Reference
All references to left, right, front, top, and bottom assume the reader is facing the front of the chassis.
Instruction Format
Each procedure described in this section will follow an illustration first format. This format will give the
reader the option to follow a quicker path to system integration by first seeing an illustration of the intended
procedure. If necessary, the reader can then follow the step-by-step instructions that will accompany each
procedure.
2.1 Internal Cable Routing
All cables should be routed using the cable channels around the Server Board as shown in the following
illustration. When routing cables front-to-back, none should be routed through the center of the system or
in the area between the system fans and the DIMMs slots.
See Appendix B. System Cable Routing Diagrams for additional cable routing details.
Figure 4. Internal Cable Routing

Intel® Server System R1000SPO Product Family System Integration and Service Guide
14
2.2 System Cover Removal / Installation
2.2.1 System Cover Removal
The server system must be operated with the system cover in place to ensure proper cooling. The top cover
must be removed to add or replace components inside of the system. Before removing the top cover, power
down the system and unplug the power cable(s).
NOTE:A non-skid surface or a stop behind the server system may be needed to prevent the server system
from sliding on your work surface.
Figure 5. System Cover Removal
1. Remove the 240VA safety screw (see label “A”).
2. Pushing down the latches at each side, slide the cover back and lift upward (see label “B”).
2.2.2 System Cover Installation
Figure 6. System Cover Installation
1. Place the system cover onto the chassis and slide forward until the front edge of the system cover is
pressed up against the back edge of the front drive bay (see label “B”).
2. (Optional) Install the 240VA Safety Screw (see label “A”).
NOTE: Product safety regulations in some countries require that the system include a 240VA safety screw to
secure the top cover to the chassis. Use of this screw should be followed as appropriate in the country of
use. Intel recommends installing this screw before the system is shipped to the end user site.

Intel® Server System R1000SPO Product Family System Integration and Service Guide
15
2.3 Air Duct Removal / Installation
Always operate your server system with the air duct in place. The air duct is required for proper airflow within
the server system.
2.3.1 Air Duct Removal
Figure 7. Air Duct Removal
•Remove the air duct by lifting it straight up.
•
2.3.2 Air Duct Installation
Figure 8. Air Duct Installation
1. Position the air duct in front of the two system fans alongside each other.
2. Carefully lower into place. If placed correctly, the air duct should sit flat and securely in place.

Intel® Server System R1000SPO Product Family System Integration and Service Guide
16
2.4 Processor Installation / Removal
2.4.1 Processor Installation
CAUTION: Processor must be appropriate: You may damage the server board if you install a processor that is
inappropriate for your server. For a web link to the list of compatible processor(s), see section “Additional
Information and Software”found earlier in this document.
CAUTION:See Electrostatic Discharge precautions in the Warnings section within the opening pages
of this document.
Figure 9. Processor Installation – Open the Socket Lever
1. Remove the processor heatsink if present. See Section 2.4.3 for instructions.
2. Unlatch the CPU Load Plate
Push the lever handle (see label “A”) down and away from the CPU socket.
3. Lift open the Load Plate.
Figure 10. Processor Installation– Open the Load Plate
4. Install the Processor (CPU)
CAUTION: The pins inside the processor socket are extremely sensitive. Other than the processor, no object
should make contact with the pins inside the processor socket. A damaged processor socket pin will render
the socket inoperable, and will produce erroneous processor or other system errors if used.
NOTE: The underside of the processor has components that may damage the socket pins if installed
improperly. The Processor must align correctly with the socket opening before installation. DO NOT DROP
the processor into the socket!
When possible, a processor insertion tool should be used when placing the processor into the processor
socket.

Intel® Server System R1000SPO Product Family System Integration and Service Guide
17
Figure 11. Processor Installation – Install the Processor
1) Remove processor from its packaging.
2) If present, carefully remove the protective cover from the bottom side of the processor, taking care
not to touch any processor contacts.
Orient the processor with the socket so that the processor cutouts match the two orientation posts on the
socket (see label ‘A’). Note the location of the gold key on the corner of processor (see label ‘B’). Carefully
place (Do NOT drop) the processor into the socket.
5. Close the Load Plate.
Figure 12. Processor Installation – Close the Load Plate
Carefully lower the load plate down over the processor.
6. Lock down the Load Plate.

Intel® Server System R1000SPO Product Family System Integration and Service Guide
18
Figure 13. Processor Installation – Latch the Locking Lever
Push down on the lever (see label ‘A’). Slide the tip of the lever under the notch in the load plate (see
label ‘B’). Make sure the load plate engages under the socket lever when fully closed.
7. Remove the plastic processor socket cover.
Figure 14. Processor Installation – Remove the Socket Cover
NOTE: The plastic processor socket cover should be saved and re-used should the processor need to be
removed at any time in the future.
