Intel®Server System SR2520SA
User’s Guide
A Guide for Technically Qualified Assemblers of Intel® Identified Subassemblies/
Products
Intel Order Number D69842-003

ii Intel®Server System SR2520SA User’s Guide
Disclaimer
Information in this document is provided in connection with Intel® products. No license, express or implied, by
estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's
Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any
express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property
right. Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining
applications or for any other application in which the failure of the Intel product could create a situation where
personal injury or death may occur. Intel may make changes to specifications and product descriptions at any time,
without notice.
Intel server boards contain a number of high-density VLSI and power delivery components that need adequate
airflow for cooling. Intel's own chassis are designed and tested to meet the intended thermal requirements of these
components when the fully integrated system is used together. It is the responsibility of the system integrator that
chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to
determine the amount of airflow required for their specific application and environmental conditions. Intel Corporation
can not be held responsible if components fail or the server board does not operate correctly when used outside any
of their published operating or non-operating limits.
Intel, Intel Pentium, and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in
the United States and other countries.
* Other names and brands may be claimed as the property of others.
Copyright © 2010, Intel Corporation. All Rights Reserved

Intel®Server System SR2520SA User’s Guide iii

iv Intel®Server System SR2520SA User’s Guide
§

Preface
About this Manual
Thank you for purchasing and using the Intel® Server System SR2520SA.
This manual is written for system technicians who are responsible for troubleshooting,
upgrading, and repairing this server system. This document provides reference
information, feature information, and step by step instructions on how to add and replace
components on the server system. For the latest version of this manual, see http://
support.intel.com/support/motherboards/server/s5000vsa/.
Manual Organization
Chapter 1 provides a list of reference resources. In this chapter you will find a list of
technical documents that give additional details on the Intel® Server System SR2520SA,
and the location where they can be found.
Chapter 2 provides a brief overview of the server system. In this chapter, you will find a
list of the server system features, illustrations of the product, and product diagrams to help
you identify components and their locations.
Chapter 3 provides instructions on using the utilities that are shipped with the board or
that may be required to update the system. This includes how to navigate through the
BIOS Setup screens, how to perform a BIOS update, and how to reset the password or
CMOS. Information about the specific BIOS settings and screens is available in the Intel®
5000 Series Chipsets Server Board Family Datasheet. See “Server System References” for
a link to the Intel®5000 Series Chipsets Server Board Family Datasheet.
Chapter 4 provides instructions on adding and replacing components. Use this chapter for
step-by-step instructions and diagrams for installing or replacing components such as the
fans, power supply, drives, and other components.
At the back of this manual, you will find technical specifications, regulatory information,
"getting help" information, and the warranty.
Product Contents
The Intel® Server System SR2520SA ships with the Intel®Server Board S5000VSA. For
further information, see the Intel®Server Board S5000VSA User’s Guide.

vi Intel®Server System SR2520SA User’s Guide
There are three versions of this server system: the Intel®Server Systems SR2520SAX/
SR2520SAXS and SR2520SAXR/SR2520SAXSR (SAS/SATA versions) and the Intel®
Server System SR2520SAF/SR2520SAFR (SATA only version). The contents of each
server system are listed below.
Intel®Server System SR2520SAX/SR2520SAXR Contents
Your Intel®Server System SR2520SAX/SR2520SAXR ships with the following items:
•Intel®Server Board S5000VSA (SATA SKU), installed in the server system
•One 600 W hot-swap power supply module, installed in the server system
•Hot-swap power cage, installed in the server system
•Two 80mm system fans, installed in the server system
•One 60mm system fan, installed in the server system
•Passive backplane, installed in the server system
•CPU air duct, installed in the server system
•Four hot-swap drive carriers, installed in the server system
•Standard control panel, installed in the server system
•Slimline USB floppy drive, installed in the server system
•Six SATA cables, installed in the server system
•SPGIO cable, installed in the server system
•Front panel cable, installed in the server system
•USB Y cable for floppy drive and front panel cable, installed in the server system
•I/O shield, installed in the server system
•Quick Reference Label, installed inside the server system top cover
•Front panel sub-bezel assembly, installed in the server system
•CD-ROM cable, in the server system product box
•Attention document, in the server system product box
•Quick Start User's Guide, in the server system product box
•Rack handles, in the server system product box
•Rails, in the server system product box
•Intel Software CD combo kit, in the server system product box
•3rd party software CD, in the server system product box

Intel®Server System SR2520SA User’s Guide vii
Intel®Server System SR2520SAXS/SR2520SAXSR Contents
Your Intel®Server System SR2520SAXS/SR2520SAXSR ships with the following items:
•Intel®Server Board S5000VSA (SAS SKU), installed in the server system
•One 600 W hot-swap power supply module, installed in the server system
•Hot-swap power cage, installed in the server system
•Two 80mm system fans, installed in the server system
•One 60mm system fan, installed in the server system
•Active backplane, installed in the server system
•CPU air duct, installed in the server system
•Four hot-swap drive carriers, installed in the server system
•Standard control panel, installed in the server system
•Slimline USB floppy drive, installed in the server system
•Two SAS cables, installed in the server system
•I2C cable, installed in the server system
•Front panel cable, installed in the server system
•USB Y cable for floppy drive and front panel cable, installed in the server system
•I/O shield, installed in the server system
•Quick Reference Label, installed inside the server system top cover
•Front panel sub-bezel assembly, installed in the server system
•CD-ROM cable, in the server system product box
•Attention document, in the server system product box
•Quick Start User's Guide, in the server system product box
•Rack handles, in the server system product box
•Rails, in the server system product box
•Intel Software CD combo kit, in the server system product box
•3rd party software CD, in the server system product box

viii Intel®Server System SR2520SA User’s Guide
Intel®Server System SR2520SAF/SR2520SAFR Contents
Your Intel®Server System SR2520SAF/SR2520SAFR ships with the following items:
•Intel®Server Board S5000VSA (4 DIMM SKU), installed in the server system
•One 600 W fixed power supply module, installed in the server system
•Two 80mm system fans, installed in the server system
•One 60mm system fan, installed in the server system
•CPU air duct, installed in the server system
•Standard control panel, installed in the server system
•Slimline USB floppy drive, installed in the server system
•Front panel cable, installed in the server system
•USB Y cable for floppy drive and front panel cable, installed in the server system
•I/O shield, installed in the server system
•Quick Reference Label, installed inside the server system top cover
•Front panel sub-bezel assembly, installed in the server system
•CD-ROM cable, in the server system product box
•Six SATA cables, in the server system product box
•Bagged screws, in the server system product box
•Attention document, in the server system product box
•Quick Start User's Guide, in the server system product box
•Rack handles, in the server system product box
•Rails, in the server system product box
•Intel Software CD combo kit, in the server system product box
•3rd party software CD, in the server system product box

Safety Information
Important Safety Instructions
Read all caution and safety statements in this document before performing any of the
instructions. See also Intel Server Boards and Server Chassis Safety Information on the
Intel®Server Deployment Toolkit 2.0 CD and/or at http://support.intel.com/support/
motherboards/server/sb/cs-010770.htm.
Wichtige Sicherheitshinweise
Lesen Sie zunächst sämtliche Warnund Sicherheitshinweise in diesem Dokument, bevor
Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu
Intel-Serverplatinen und Servergehäusen auf der Intel®Server Deployment Toolkit 2.0 CD
oder unter http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.
Consignes de sécurité
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce
document avant de suivre toute instruction. Consultez Intel Server Boards and Server
Chassis Safety Information sur le Intel®Server Deployment Toolkit 2.0 CD ou bien
rendez-vous sur le site http://support.intel.com/support/motherboards/server/sb/cs-
010770.htm.
Instrucciones de seguridad importantes
Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar
cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety
Information en el Intel®Server Deployment Toolkit 2.0 CD y/o en http://
support.intel.com/support/motherboards/server/sb/cs-010770.htm.

xIntel®Server System SR2520SA User’s Guide
重要安全指导
在执行任何指令之前，请阅读本文档中的所有注意事项及安全声明。 和/或
http://support.intel.com/support/motherboards/server/sb/CS-010770.htm 上的 Intel
Server Boards and Server Chassis Safety Information（《Intel
服务器主板与服务器机箱安全信息》）。
