Intelix DIGI‐HD‐IR2 User manual

2222 Pleasant View Road
Suite #1
Middleton, WI 53562
Phone: [phone]
Toll-Free: 866-4-MATMIX
Fax: [phone]
DIGI‐HD‐IR2InstallationManual




TheIntelixDIGI‐HD‐IR2transmitsHDMIandIRupto300’
overtwotwistedpaircables,suchasCat5eorCat6.In
environmentswithhighelectromagneticinterference
(EMI),twoshieldedtwistedpaircablesshouldbeused.

Built‐inHDshāk®technologyprovidesdynamicHDMI,
EDID/DDCandHDCPmodeselection,guaranteeing
performanceandimagequality.

TheDIGI‐HD‐IR2featureselectrostaticdischarge(ESD)
protectioncircuitrywhichsafegaurdstheHDMIcircuit
againststaticelectricityandotherdestructivestray
voltage.

DesignwithIntelixandDesignwithIntelligence.

MaximumRecommendedDistances
1080p1080i720p576i/p480i/p
Cat6
(low‐skew)
150’300’ 300’300’350’
Cat6110’ 220’ 220’ 220’220’
Cat5e100’200’200’200’200’
















Caution: Do not attempt to disassemble or alter the extender
housing. There are no user-serviceable parts inside the unit.
Doin
g
so will void
y
our warrant
y
.
Instructions
1. Turnoffpoweranddisconnectthe
audio/videoequipmentbyfollowingthe
manufacturer’sinstructions.
2. Makecertainthatoutletsandcrossconnects
towhichyouwillconnecttheDIGI‐HD‐IR2are
configuredproperlyandlabeledcorrectlyto
identifythepoint‐to‐pointcircuit.
3. Verifythedesiredtwistedpairsarenotbeing
usedforotherLANortelephonyequipment.
4. Verifythatthesourceanddestination
equipmentworkwhendirectlyconnected
withHDMIcables.BesuretotestbothHDMI
cablesrequiredforsysteminstallation.
5. ConnecttheIRemittertotheDIGI‐HD‐IR2
sendextender.
6. ConnecttheDIGI‐HD‐IR2transmittertothe
HDMIoutputofthevideosource.Donot
connectthe5Vpowersupply.
7. ConnecttheIRreceivertotheDIGI‐HD‐IR2
receiveextender.
8. ConnecttheDIGI‐HD‐IR2receivertothe
HDMIinputofthereceivingdeviceatthe
remoteend.Donotconnectthe5Vpower
supply.
9. Completetheconnectionbetweenthe
transmitandreceiveextendersusingtwo
runsoftwistedpaircable.Ensurethecable
conformstoEIA568Bcrimpstandardsand
therearenosplitpairsortaps.
10. Connectthe5VpowersupplytotheDIGI‐HD‐
IR2receiver.
11. Connectthe5VpowersupplytotheDIGI‐HD‐
IR2transmitter.Power‐onthevideo
equipment.
12. Verifypicturequality.
13. Ifnecessary,adjusttheDIPswitchesonthe
transmitandreceiveextenderstoselect
modesofoperation.
Caution: To minimize the possibility of equipment damage
from electrostatic discharge (ESD), all source and destination
equipment must be powered off during installation.
Caution: Do not connect the extender to a
telecommunication outlet wired to unrelated equipment.
Doing so may damage the unit or any connected equipment.
Ensure all connected twisted pair cabling is straight-through

2222 Pleasant View Road
Suite #1
Middleton, WI 53562
Phone: [phone]
Toll-Free: 866-4-MATMIX
Fax: [phone]




DIGI‐HD‐IR2‐STransmitterDipSwitchPositions
Position1Position2Mode
OffOffReadEDIDdatafromdisplays
OffOnTurnonDolbyTrueHDandDTS‐HD
OnOffTurnonstereoaudio
OnOnNofunction
*TheDIGI‐HD‐IR2systemmustbepowercycledforthechanges
totakeeffect.
DIGI‐HD‐IR2‐RReceiverSwitchPositions
Position1Position2Mode
OffOffExtendedcable
OffOnForcesignaloutput
OnOffNormalcable
OnOnNofunction
*TheDIGI‐HD‐IR2systemmustbepowercycledforthechanges
totakeeffect.














Troubleshooting
SymptomPossibleSolutions
Nosignal
StatusLEDisoff
Verifythatbothendsofthetwistedpair
cablesuse568Bcrimppattern.
SwapthetwistedpaircablesintheAVand
HDCPRJ45inputsonthereceivebalun.
VerifyHDMIcablesandsourceand
destinationHDMIportsareoperational.
Nosignal Verifythepowersuppliesareconnectedto
boththesendandreceivebaluns.
VerifythepowerLEDsonboththesend
andreceiveunitsarebrightlyilluminated.
Unusualcolorsinthe
video
Poweroffthedestinationdeviceand
poweritbackontoforcerenegotiation.
Unplugandre‐plugtheHDMIcablefrom
receivebaluntoforcerenegotiation.
Nosignal
Screeniscompletely
snowy
Specklinginthevideo
image
Occasionalsignal
dropouts
Videowithoutaudio
Useshorterrunsoftwistedpaircabling.
DroptheHDMIsignaltothenextlower
resolution;i.e.,decreaseresolutionfrom
1080pto1080i,etc.
Replacethetwistedpaircablewitha
highergradetwistedpaircable;i.e.,
replaceCat5ewithCat6.
Specklinginthevideo
image
Ifthedestinationdeviceisincapableof
displayingthevideosignal,alterthesource
signal;i.e.,decreaseresolutionfrom1080p
to1080i,etc.
Videowithoutaudio Changesourcedeviceto outputPCMother
thanBitstreamaudio.
EnablePCMdownsamplingifsupportedby
yoursourcedevice.

TheIntelixDIGI‐HD‐
IR2conformsto
HDMIandHDCP
specifications.Intelix
doesnotguarantee
operationwithdevices
thatdonotconformto
thesespecifications.The
IntelixDIGI‐HD‐IR2
passesHDCPsignalsand
doesnotmanipulate
theminanyway.


Distancesandpicturequalitymaybeaffectedbycablegrade,cable
quality,sourceanddestinationequipment,RFandelectrical
interference,andcablepatches.
Note: Dip switches are located under the cap on the
side of the unit.
RecommendedTemperatures:Operating:0°to55°C
Storage:‐20°to85°C
Humidity:upto95%
