Intelix DIGI-HD-IR2 User manual

Intelix DIGI-HD-IR2
Installation Manual
Introduction
The Intelix DIGI-HD-IR2 transmits HDMI and IR up to 300’ over two twisted pair
cables, such as Cat 5e or Cat 6. In environments with high electromagnetic
interference (EMI), two shielded twisted pair cables should be used.
Built-in HDshāk® technology provides dynamic HDMI, EDID/DDC and HDCP
mode selection, gauranteeing performance and image quality.
The DIGI-HD-IR2 features electrostatic discharge (ESD) protection circuitry which
safegaurds the HDMI circuit against static electricity and other destructive stray
voltage.
Design with Intelix and Design with Intelligence.

Installation
To install the Intelix DIGI-HD-IR2 baluns, perform the following steps:
1. Turn off power and disconnect the audio/video equipment by following the
manufacturer’s instructions.
2. Make certain that outlets and cross connects to which you will connect the DIGI-
HD-IR2 are configured properly and labeled correctly to identify the point-to-point
circuit.
3. Verify the desired twisted pairs are not being used for other LAN or telephony
equipment.
4. Verify that the source and destination equipment work when directly connected with
HDMI cables. Be sure to test both HDMI cables required for system installation.
5. Connect the DIGI-HD-IR2 send balun to the HDMI output of the video source. Do
not connect the 5V power supply.
6. Connect the DIGI-HD-IR2 send balun to the IR emitter.
7. Connect the DIGI-HD-IR2 receive balun to the HDMI input of the receiving device
at the remote end. Do not connect the 5V power supply.
8. Connect the DIGI-HD-IR2 receive balun to the IR receiver.
9. Complete the connection between the send and receive baluns using two runs of
twisted pair cable. Ensure the cable conforms to EIA 568B crimp standards and
there are no split pairs or taps.
10. Connect the 5V power supply to the DIGI-HD-IR2 receive balun.
Caution: Do not attempt to disassemble or alter the balun housin
g
. There are no
user-serviceable parts inside the unit. Doing so will void your warranty.
Caution: Do not connect the balun to a telecommunication outlet wired to
unrelated equipment. Doin
g
so ma
y
dama
g
e the unit or an
y
connected equipment.
Ensure all connected twisted pair cabling is straight-through (point-to-point).
Caution: To minimize the possibilit
y
of equipment dama
g
e from electrostatic
dischar
g
e (ESD), all source and destination equipment must be powered off durin
g
installation. This includes signal extenders, splitters, and switches.
Note: For
y
our convenience, it is recommended that
y
ou uniquel
y
mark the ends
of the twisted pair cable before pulling them through a wall or conduit.

11. Connect the 5V power supply to the DIGI-HD-IR2 receive balun Power-on the
video equipment.
12. Verify picture quality.
13. If necessary, adjust the dip switches on the send and receive baluns to select modes
of operation.
Note: Dip switches are located under the cap on the side of the unit.

DIGI-HD-IR2-S Transmitter Dip Switch Positions
Position 1 Position 2 Mode
Off Off Read and store EDID data from displays
Off On Turn on Dolby TrueHD and DTS-HD
On Off Turn on stereo audio
On On No function
DIGI-HD-IR2-R Receiver Switch Positions
Position 1 Position 2 Mode
Off Off Extended cable
Off On Force signal output
On Off Normal cable
On On No function

Troubleshooting
Symptom Probable Causes Possible Solutions
No signal
Status LED is off
Incorrect cable
termination
Verify that both ends of the twisted pair
cables use 568B crimp pattern.
No signal
Status LED is off
Incorrect cable
connection
Swap the twisted pair cables in the AV and
HDCP RJ45 inputs on the receive balun.
No signal Insufficient power Verify the power supplies are connected to
both the send and receive baluns.
Verify the power LEDs on both the send
and receive units are brightly illuminated.
Unusual colors in
the video
HDMI
synchronization
issues
Power off the destination device and power
it back on to force renegotiation.
Unplug and re-plug the HDMI cable from
receive balun to force renegotiation.
No signal
Screen is
completely snowy
Speckling in the
video image
Occasional signal
dropouts
Video without
audio
Video signal exceeds
bandwidth of cabling
Use shorter runs of twisted pair cabling.
Drop the HDMI signal to the next lower
resolution; i.e., decrease resolution from
1080p to 1080i, etc.
Replace the twisted pair cable with a
higher grade twisted pair cable; i.e.,
replace Cat 5e with Cat 6.
Speckling in the
video image
Unsupported video
resolution
If the destination device is incapable of
displaying the video signal, alter the source
signal; i.e., decrease resolution from 1080p
to 1080i, etc.
Video without
audio
Unsupported audio
codec
Change source device to output PCM other
than Bitstream audio
Enable PCM down sampling if supported
by your source device

Technical Specifications
Video Amplifier Bandwidth 1.65 Gbps
Supported Video Resolutions 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Max Distance
(Cat 5e)
1080p: 100’
1080i/720p: 200’
Max Distance
(Cat 6 – low skew recommended)
1080p: 150’
1080i/720p: 300’
Supported IR Carrier Frequencies 36-40 kHz
Input Video Signal 1.2 volts p-p
Input DDC Signal 5.0 volts p-p (TTL)
Input Unit Connectors (1) Type A HDMI connector to (2) RJ45s
(1) 1/8” mini (3.5 mm) female IR connector
Output Unit Connectors (2) RJ45s to (1) Type A HDMI connector
(1) 1/8” mini (3.5 mm) female IR connector
Cabling Two individual runs of Cat 5e or Cat 6
Power External 5 VDC
Power Connector Powered on both ends
Dimensions 4.38” x 2.50” x 1.00”
Temperature Operating: 0° to 55°C
Storage: -20° to 85°C
Humidity: up to 95%
Shipping Weight 1 lb.
Warranty 2 years
Regulatory CE, RoHS
Intelix Part Number DIGI-HD-IR2
Ordering Information DIGI-HD-IR2 package includes one send unit, one
receive unit, one IR emitter, one IR receiver, and two
power supplies
The Intelix DIGI-HD-IR2 conforms to HDMI and HDCP specifications. Intelix
does not guarantee operation with devices that do not conform to these
specifications. The Intelix DIGI-HD-IR2 passes HDCP signals and does not
manipulate them in any way.
Distances and picture quality may be affected by cable grade, cable quality, source
and destination equipment, RF and electrical interference, and cable patches. Intelix
specifications are based on straight-through cabling with standard-grade Cat 5e.

Thank you for your purchase.
