Intelix NT-HD70-TXWP User manual

11675 Ridgeline Drive
Colorado Springs, CO
80921
Rev 181130 Phone: [phone]
Toll-Free: 800-530-8998
Fax: [phone]
INT-HD70-TXWP Quick Install Guide
This guide is for quick installaon only.
For complete owners manual go to www.libav.com or use a QR reader to access the
manual via QR code below.
Scan QR Code with your Smart-phone or Tablet

INT-HD70-TXWP Quick Guide
3
The Intelix INT-HD70-TXWP extends HDMI, IR, and RS232 over a single solid core shielded Category 5e
or greater cable using the Valens VS010TX HDBaseT chip. The INT-HD70-TXWP supports 1080p video
signal up to 70m and 4K signals up to 4K@60Hz / 4:2:0 / 8 bit color up to 40m. The INT-HD70-TXWP
supports CEC pass through and is HDCP 2.2 compliant. 48V PoH built in allows the transmier to be
powered from a compable Intelix receiver, the transmier also has 12V DC output for powering 3rd
party device nearby.
The INT-HD70-TXWP is compable with all Intelix HDBaseT product oerings and any product that
meets the HDBaseT specicaons.
Product Overview
Package Contents
• INT-HD70-TXWP HDBaseT Wall Plate Transmier
• Quick Install Guide
• (3) 2 pin Phoenix connector
• (1) 3 pin Phoenix connector
• (2) Mounng Screws

INT-HD70-TXWP Quick Guide
4
Transmier View
1
5
6
7
3
8
9
4
2
FRONT BACK
1. POWER LED - Illuminates RED when power is applied
2. LINK LED - Illuminates GREEN when the transmier is connected to receiver successfully
3. IR - Built in IR sensor / receiver for IR pass through control
4. HDMI IN - HDMI input port for connecon to HDMI video source
5. RS232 - 3 pin terminal block for RS232 pass through control
6. IR IN - 2 pin terminal block for IR receiver
7. HDBT OUT / POH IN - HDBaseT output; RJ45 connecon. Supports 48V PoH
8. DC IN - 2 pin terminal to connect 12V DC power adapter.
9. DC OUT - 2-pin terminal block to connect / power 3rd party device

INT-HD70-TXWP Quick Guide
5
Connecvity Instrucons
1. Verify all components included with the extender set are present before installaon.
2. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instrucons.
3. Connect Category 6 or greater twisted pair cable with RJ45 connectors between the
INT-HD70-TXWP and a compable Intelix HDBaseT receiver. TIA/EIA-568B straight-through wiring
connecons must be used with all HDBaseT extenders.
4. Connect an HDMI cable and any desired IR or RS232 control accessories between the display and a
compable Intelix HDBaseT receiver.
5. Connect an HDMI cable and any desired IR or RS232 control accessories between the source and
the INT-HD70-TXWP transmier.
6. Connect a power supply to the compable Intelix HDBaseT receiver. and lock the power supply to
the power connector by twisng the locking collar clockwise.
7. Power on aached audio/video devices.
Passing IR Signals:
The INT-HD70-TXWP is capable of passing IR signals between 30 and 50 KHz. To pre-
vent damage to any of the electronics, the extender should be powered o while in-
serng or removing any IR components. Inserng an IR transmier into the IR IN port
may damage the IR circuit for that extender.

INT-HD70-TXWP Quick Guide
6
Cabling Wiring Requirements
Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category 6
connecon between send and receive
units.
HDBaseT Cabling
To ensure proper performance of the INT-HD70-TXWP, it is recommended that you use
solid core, shielded Category 6 F/UTP cabling at a minimum. Category 5e F/UTP may
perform well but may not support power over HDBaseT reliably over longer distances.
For opmized HDBaseT performance use the following Liberty Wire and Cable branded
cabling;
Category 6 plenum; 24-4P-P-L6SH
Category 6A plenum; 24-4P-P-L6ASH
Category 6 NON-plenum; 24-4P-L6SH
Category 6A NON -plenum; 24-4P-L6ASH
When using shielded category cabling ALWAYS...
....use shielded connectors
....properly ground the category cable

INT-HD70-TXWP Quick Guide
7
Technical Specicaons
Supported Audio and Video
Video Compliance HDMI 2.0+, HDCP2.2, and CEC (Consumer Electronics Control)
Input / Output Resoluon Support Up to 4096x2160@60Hz (4:2:o chroma sub-sampling / 8 bit deep color)
Embedded Audio Up to PCM 8 channel, Dolby Digital, DTS, TrueHD, DTS-HD Master Audio and
Dolby Atmos
IR Carrier Frequency Range 30-50kHz at 5 volts
HDBaseT Signal Characteriscs
Maximum Distance 1080p: 70 meters / 231 feet
4K@60Hz 4:2:0 40 meters / 132 feet
Cable Requirements Solid core shielded Category 6 F/UTP or greater with TIA/EIA-568B crimp
paern
Bandwidth 10.2 Gbps
Chassis and Environmental
Dimensions (H x W x D) 103 mm x 50 mm x 50 mm (4.07 in x 1.9 in x 1.9 in)
Product Weight 180g / 0.39lbs
Operang Temperature -5° to +55° C (+23° to +131° F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Operang Humidity (Environment) 10% to 90%, Non-condensing
ESD Protecon Human-body Model:
±8kV (Air-gap discharge)
±4kV (Contact discharge
Surge Protecon Voltage: ±1 kV
Power
Maximum Power Consumpon 9 was
Power Supply Input Voltage 100-240V AC at 50-60 Hz
Power Supply Output Voltage 12V DC
Regulatory CE, FCC, RoHS
Other
Standard Warranty 5 Years
Included Items Quick Guide, (3) 2 pin Phoenix connectors, (1) 3 pin Phoenix connector, (2)
Mounng screws
Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF and
electrical interference, and cable patches.

Thank you for your purchase.
For Technical Support please call our toll free number at
800-530-8998 or email us at [e-mail]
www.libav.com
Intelix is a brand of:
11675 Ridgeline Drive
Colorado Springs, Colorado
80921 USA
Phone: [phone]
Fax: [phone]
Toll-Free: 800-530-8998
