Intellian V110 User manual

V110
Installation and Operation
User Guide
Marine Satellite Communication Antenna System

Serial number of the product
This serial number will be required for the all
troubleshooting or service inquiries.
© 2009 Intellian Technologies Inc. All rights reserved.
Intellian and the Intellian logo are trademarks of Intellian
Technologies, Inc., registered in the U.S. and other countries.
v-Series and v110 are trademarks of Intellian Technologies, Inc.
Intellian may have patents, patent applications, trademarks,
copyrights, or other intellectual property rights covering subject
matter in this document. Except as expressly provided in any
written license agreement from Intellian, the furnishing of this
document does not give you any license to these patents,
trademarks, copyrights, or other intellectual property.
All other logos, trademarks, and registered trademarks are
the property of their respective owners. Information in this
document is subject to change without notice.
Every effort has been made to ensure that the information
in this manual is accurate. Intellian is not responsible
for printing or clerical errors.
Intellian Technologies Inc.
2F. Dongik Bldg, 98 Nonhyun-dong,
Gangnam-gu, Seoul 135-010, Korea
Tel: [phone]
Fax: [phone]
Email: [email protected]
November 16, 2009
Intellian Technologies USA, Inc.
9261, Irvine Blvd.
Irvine, CA 92618
Tel: [phone]
Fax: [phone]
Email: [email protected]
Doc. No. PM-v110-v1.0

Contents
INTRODUCTION.............................................................................................1
Introduction to Intellian v110............................................................................ 1
Features of Intellian v110.................................................................................... 2
Basic System Configuration ............................................................................... 3
INSTALLING THE ANTENNA ............................................................................4
System Components............................................................................................. 4
Tools Required for Installation .......................................................................... 9
Planning the Installation....................................................................................10
Configure Radiation Hazard/Blockage Zones...........................................11
Preparing the Installation..................................................................................13
INSTALLING THE ACU..................................................................................24
ACU Dimensions...................................................................................................24
Selection of ACU Installation Site ..................................................................24
Installing the ACU ................................................................................................25
Connecting the System to a Ship’s Gyro .....................................................26
ACU Connector Guide ........................................................................................27
OPERATING THE ACU..................................................................................28
Introduction............................................................................................................28
ACU Soft Keys........................................................................................................30
Normal Mode ........................................................................................................31
Setup Mode............................................................................................................34
Installation Settings.............................................................................................35
Antenna Settings..................................................................................................38
Satellite Settings ...................................................................................................50
System Settings.....................................................................................................57
PC CONTROLLER PROGRAM.........................................................................64
Introduction............................................................................................................64
Program Initialing and Communication Setup.........................................65
Main Menu..............................................................................................................66
Controller Menu....................................................................................................68
WARRANTY ................................................................................................76
Appendix : v110 Technical Specification.....................................................77

1Introduction
Introduction
Introduction to Intellian v110
The Intellian v110 is a 1.05 meter Ku-band marine VSAT communication
antenna system for SCPC, broadband, or hybrid networks and is suitable
for high-speed Internet, email, file transfer, video conference, VOIP, VPNs
and database backup. The v110 is a 3-axis stabilization system designed
for the oceangoing vessels that require “always on” and “high quality”
broadband communications no matter how rough the weather and sea
conditions are.
The v110 has an unlimited azimuth range for continuous tracking
without the needs to unwrap the cables in the antenna. The wide
elevation range from -15 to 120 degrees enables the v110 to have
seamless signal reception while the vessel is traveling near the equator
or Polar Regions.
The v110 meets the FCC’s 2-degree spacing requirement and is built
with Intellian’s extremely high vibration and shock standards. The simple
design of the v110 offers lighter weight and greater reliability than any
competitor’s system in its class. With easiest installation design and
most-user friendly interface you can find in the market, the v110
guarantees that you will have a whole new broadband experience at sea.
Introduction

2 V110 – Marine Satellite Communication System
Features of Intellian v110
Enjoy always-on broadband connection at sea
Intellian v110 is the most modern communication system that enables
you to receive a high-speed and always-on broadband connection at sea,
where the atmospheric and environmental conditions are very harsh.
Best solution for all kinds of vessels
The v110 is the best solution for all kinds of vessels that require the
satellite broadband connection around the globe. The v110 is a high-
gain, high-efficient system that offers an extraordinary signal gain than
any other systems in its class.
3-axis stabilized system with a wide elevation angle
The v110 has a wide elevation range from -15 to 120 degrees which
offers seamless signal reception while the vessel is traveling near the
equator or Polar Regions.
Outstanding reliability
Intellian v110 provides highly reliable system through the
implementation of a modularized design, the usage of strictly proven
components and Intellian’s rigorous environmental test standards.
Built-in GPS
Intellian v110 has an imbedded GPS, which allows for the system to
upload the GPS data automatically into the system for an even faster
and stable system.
Built-in automatic skew angle control system
The automatic skew control system allows Intellian v110 to maintain the
optimal skew angle at all times and ensure maximum level of satellite
signal level.

3Introduction
Satellite Modem
(Not supplied)
Antenna Control Unit
AC
110/220V
NMEA/Synchro/SMS TCP/IP
8W BUC Power (+48V)
Tx
Rx
Rx/Power/Data
Ship’s
Gyrocompass
(Not supplied)
Basic System Configuration
For your satellite communication system to work properly, the system
will have to be connected with all of the provided components properly,
as shown in the figure below (see the “Installation” section of this
manual). Separate purchase of a satellite modem is required.
Figure 1. Basic System Configuration
Introduction

4 V110 – Marine Satellite Communication System
Installing the Antenna
The components of the Intellian v110 have been designed to be
modular so that it is suitable for simple installation on all types of
vessels.
System Components
The Intellian v110 consists of two major units, antenna assembly unit
and antenna control unit.
Antenna Unit
The antenna unit includes an antenna pedestal inside a radome
assembly unit. The pedestal consists of a satellite antenna main dish with
RF components mounted on a stabilized pedestal. The radome protects
the antenna pedestal assembly unit from the severe marine environment.
Figure 2. Antenna Unit

5
Antenna Control Unit (ACU)
The Antenna Control Unit (ACU) provides the power to the antenna and
the BUC (block upconverter) for controlling the various settings of the
antenna. The digital VFD (Vacuum Fluorescent Display) allows for easy
operation of the ACU, even in the dark.
Front Panel
Rear Panel
Figure 3. Antenna Control Unit
The functions of the ACU are as follows,
System startup.
Setting the satellite.
Editing satellite information.
Setting the antenna parameter.
Setting the antenna manual search.
Setting the LNB local frequency.
Setting radiation hazard or blockage zone.
Setting modem connections
Setting GPS and Gyrocompass.
Display versions.
Display power status.
Performing diagnostic tests.
Backup the system settings.
Restore the system.
Set up the interface with a PC.
Installing the Antenna

6 V110 – Marine Satellite Communication System
Installation Kit
Contains the items required for securing the antenna unit and ACU to
the vessel.
Antenna Size Q’ty Remark
Hex. Bolt M12x60L 5EA
Antenna-Deck
Hex Head
Wrench
Bolt
M6x40L 5EA
Dome
Washer M6 5EA
Flat
Washer M12 5EA
Spring
Washer M12 5EA
Hex. Nut M12 10EA
ACU Size Q’ty Remark
Ta p pi n g
Screw Ø4x16 5EA Ta b l e M ou n t B r a c k e t-
Ta b l e
Flat Head
Screw M3x8L 10EA Rack Mount Bracket- ACU
Sem’s
Bolt M3x12L 5EA Ta b l e Mo u n t B r a c k et- ACU
Figure 4. Installation Kit Components

7
Other Components
Item Image Description Size Q’ty Remark
1
ACU
Bracket
Rack - 2EA ACU-19inch Rack
Table - 2EA ACU-Table
2 RG6 Cable 3m 1EA ACU(MODEM RX) to
Modem
3 RG6 Cable 15m 2EA
Antenna(MODEM IN)
to Modem &
Antenna(ACU RX)
to ACU(ANT RX)
4.
BUC Power
Cable 15m 1EA
Antenna (BUC IN) to
ACU (BUC POWER)
5
AC Power Cord
( CEE7/7) 1.5m 1EA ACU Power
6 PC Serial Cable 1.8m 1EA ACU to PC
7.
USB Cable
(A-A / M-M) 1.8m 1EA ACU to PC
8.
iDirect
Interface Cable 1.5m 1EA ACU to Modem
9.
D-Sub
9 Pin Male
Connector 2EA ACU
10
Gyro NMEA /
BUC Power
Connector
AK950-2 3EA
ACU(Gyro NMEA /
BUC Power ) &
Antenna (BUC IN)
11
Install CD - 1EA -
Installing the Antenna

8 V110 – Marine Satellite Communication System
12 Manual - 1EA -
13
Mounting
Tem p l ate - 1EA -
14
Unpack Wooden
Crate Instruction
Guide
- 1EA -
Figure 5. Component Box Parts List

9
Tools Required for Installation
Power Drill
Cross-Head
Screwdriver
11mm Spanner
13mm Spanner
Φ13mm Drill Bit
Minus-Head
Screwdriver
Pencil
4mm
Allen key
19mm Spanner
5mm
Allen key
Figure 6. Tool Sets for Installation
Installing the Antenna

10 V110 – Marine Satellite Communication System
Antenna Unit
15°
Obstacle
Planning the Installation
Selection of Antenna Installation Site
Install the antenna in accordance with the following procedures to insure
maximum performance of the
antenna. The ideal antenna site has
a clear view of the horizon or
satellite all around. Please be sure
there are no obstacles within 15
degrees above the antenna. Any
obstacles can prevent the antenna
from transmitting and receiving
the satellite signal.
Do not install the antenna near by the radar especially on the same
plane as their energy levels may overload the antenna front-end circuits.
It is recommended to position the antenna at least 4 feet (1.2m) above
or below the level of the radar and minimum of 15 feet (4.6m) away
from the high power short wave radars.
The mounting platform should be rigid enough and not subjected to
excessive vibration. The movement of the antenna can be minimized by
installing at the center of the vessel. If these conditions can be only
partially satisfied, find the best compromised installation site between
the various considerations.
Figure 7. Elevation Limit of Obstacles

11
Configure Radiation Hazard/Blockage Zones
It is important to setup the radiation hazard or blockage zones for
Intellian VSAT TX/RX communication systems. (See the “Block Zone
Setting” section of this manual). The ACU can be programmed with
relative azimuth and elevation sectors to create up to five zones where
transmit power would endanger personnel who are frequently in that
area or blockage exists. Several things happen when the antenna is
within one of these zones.
1. “BLOCK” will be displayed on the ACU screen.
2. Tracking continues as long as the signal level is greater than the
predefined threshold value. When the signal level drops below
the threshold value the antenna will wait “Search Wait Time”
parameter amount of time and re-target the satellite you
targeted last. The antenna will continue to re-target the satellite
until the satellite is re-acquired and tracking can be resumed.
3. A transmit inhibit output from the ACU will disable/mute the
modem transmit
Installing the Antenna

12 V110 – Marine Satellite Communication System
System Cables
Before installing the system cables, you need to take the following
points into consideration.
All cables need to be well clamped and protected from physical
damage and exposure to heat and humility.
Cable with an acute bend is not allowed.
Where a cable passes through an exposed bulkhead or deck
head, a watertight gland or swan neck tube should be used.
RF Cables (Customer Furnished)
Due to the voltage losses across the length of the RF coaxes at L-Band,
Intellian recommends the following 75 ohm coax cable types for
standard system installations. For cable runs longer than 70 meter,
please consult Intellian Technologies.
Run Length Coaxial Cable Type
Up to 30 meters RG-6 or LMR-300-75
Up to 70 meters RG-11 or LMR-400-75
Up to 120 meters LMR-600-75
Figure 8. Recommended RF Cables
Gyro Compass / GPS Interface Cable (Customer Furnished)
Type Multi-conductor, Shielded
Number of wires 4 Conductors for Step-By-Step Gyro
5 Conductors for Synchro
2 Conductors for NMEA
Figure 9. Recommended Gyro/ GPS Cables
BUC Power Cable
Cable Length mm2per conductor
Up to 30m 1.25mm2
Up to 50m 2mm2
Up to 70m 2.5mm2
Up to 100m 3.5mm2
Figure 10. Recommended BUC Power Cables
Power Requirements
Intellian v110 has been designed to work on a vessel’s power supply
rated at 90-260 V AC.

13
Preparing the Installation
Unpack the v110 box
The antenna pedestal is shipped completely assembled in its radome.
Remove the four shipping blots which mount the antenna to the pallet.
The pallet should be lifted by means of suitable sized lifting equipment.
(Refer to the supplied instruction guide for details on how to unpack
wooden crate of v110.)
19mm Spanner
Figure 11. Remove 4 bolts from the bottom of the box
Installing the Antenna

14 V110 – Marine Satellite Communication System
Antenna Dimension
The method of installation and mounting of antenna may vary with
vessel design but the following procedures are applicable in most
situations, and will result in a secure and effective installation. Confirm
the height and diameter the antenna before installing it.
Ø146.8cm
(57.8”)
151.7cm
(59.7”)
Figure 12. Radome Dimension
