Intellian GX60 User manual

Global Leader in Marine Satellite Antenna Systems
GX60
Installation and Operation User Guide

Serial number of the product
This serial number will be required for the all troubleshooting or service inquiries.
© 2019 Intellian Technologies Inc. All rights reserved. Intellian and the Intellian
logo are trademarks of Intellian Technologies, Inc., registered in the U.S. and other
countries. The v-Series and the GX60 are trademarks of Intellian Technologies, Inc.
Intellian may have patents, patent applications, trademarks, copyrights, or other
intellectual property rights covering subject matter in this document. Except as
expressly provided in any written license agreement from Intellian, the furnishing
of this document does not give you any license to these patents, trademarks,
copyrights, or other intellectual property. Global Xpress Service
™
or GX
™
is a
trademark of Inmarsat PLC and refers to Inmarsat’s xed and mobile, land, maritime
and aero Inmarsat 5 Ka-band satellite services. All other logos, trademarks, and
registered trademarks are the property of their respective owners. Information in
this document is subject to change without notice. Every effort has been made to
ensure that the information in this manual is accurate. Intellian is not responsible for
printing or clerical errors.
Doc. No. UM-N2-190131-V1.9
Disclaimer
The information in this user manual is subject to change without prior notice through
a product life cycle. A printed version of the user manual is periodically updated and
may contain inaccuracies or omissions compared to the recent product information.
The most up-to-date information can be readily accessible on a supplied USB
memory stick or on our website at http://www.Intelliantech.com.

GX60 – Marine Satellite Communication System
4
THIS WAY UP
• Place the boxes/crates on the oor noting the direction of the arrow.
FRAGILE
• Since the Radome is fragile, handle it with care. Do not apply excessive pressure or shock.
These may cause surface cracking or other damage.
DO NOT STACK
• Do not stack boxes/crates as there is a risk boxes/crates may fall and be damaged.
KEEP DRY
• Always make sure the antenna is stored on a dried oor.
• The antenna can withstand ordinary rain. However it water resistance cannot be guaranteed
if submerged.
• Keep the antenna in dried place for sufcient ventilation. Do not store the antenna wrapped
in a tarp, tent, vinyl, and others.
General Precautions
Before you use the antenna, make sure that you have read and understood all safety requirements.

5
Table of Contents
Table of Contents
Certifications 8
Introduction 12
Intellian GX60 Introduction 12
Intellian GX60 Features 13
System Conguration 14
Tools Required for Installation 15
Installing Antenna 16
System Package 16
Antenna Unit 17
BDT (Below Deck Terminal) 18
Installation Kit 19
Planning Installation 20
Selection of Antenna Installation Site 20
Minimize Satellite Blockage 20
Avoid RF Interference 21
RF Hazard Precautions 21
Antenna Dimensions 22
Antenna Mounting Templates 23
Antenna Mounting Hole Pattern 24
Mast Design Recommendation 25
Mast Designing (Installation Example) 26
Position Radome 27
System Cables 28
RF Cable (Customer Supplied) 28
Labeling RF Cables 29
Power Cable (Customer Supplied) 29
Placing Cables on Mast 30
Power Connector Termination 31
Antenna Installation 32
Unpacking Wooden Crate 32
Placing Antenna on Mast 37
Connecting Cables (Customer Supplied) 38
Mounting Radome 39
Turning on Power Switch 40
Installing BDT 42

GX60 – Marine Satellite Communication System
6
Mounting BDT 42
19” Rack Mount Type 42
Table Mount Type 42
BDT Dimensions 43
Selection of BDT Installation Site 43
Connecting Cables to BDT 44
RF Cable Connection 44
Ship Gyrocompass Connection 45
Recommended Cable 45
PC to BDT Communication Setup 46
TCP/IP Connection 46
Wi-Fi Connection 46
Checking Modem Information 47
One-touch Commissioning 48
BDT Connector Guide 49
Operating BDT 51
Introduction 51
Normal Mode 52
Startup 52
Monitoring Current Antenna Status 53
Setup Mode 56
Antenna Settings 57
Manual Search 57
Antenna Diagnostic Test 58
Satellite Settings 60
Load Satellite 60
System Settings 61
Set Location 61
Management 63
Using Aptus PC 64
Introduction 64
Hardware 64
Operating System and Software 64
Software Installation 65
PC to BDT Communication Setup 66
Starting Aptus® 66
Establish Data Communication 67
Auto Update 68
Toolbar Menus 69
System Property Status Dashboard 72
Work View Tabs 75

7
1. Antenna – Basic Info. 75
2. Antenna – Advanced Info. 76
3. Satellite 79
4. Graph View 81
5. Monitor 82
6. Diagnostic / Modem 83
7. GUI 84
8. Work View Functions 85
Using Aptus Web 89
Introduction 89
Main Page 90
Page Login 90
Top Menus 91
Dashboard & Information 92
Antenna Settings 94
Ship Setting 94
Antenna Setting 95
Tracking Setting 97
Diagnostic 98
Library Setting 99
Firmware & Conguration 100
Antenna Firmware Upgrade 100
Antenna Log 102
Antenna Backup & Restore 104
Administration 105
Network Setting 105
User Management 107
iARM Upgrade 108
iARM Save & Reboot 109
Antenna Event Log 110
Modem Information 111
Technical Specification 112
Warranty 113

GX60 – Marine Satellite Communication System
8
Doc Number IT14-DC0901-03
Intellian Technologies, Inc.
EMEA & APAC Headquarters
18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-Si,
Si,
Gyeonggi-do 451-862, Korea
Tel: [phone]
Intellian Technologies USA, Inc.
US Headquarters
9004 Research Drive
Irvine, CA 92618 USA
Tel: [phone]
FCC Part 15 Subpart B Declaration of Conformity (DoC)
We, Intellian Technologies, Inc. located at 18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 451-862,
Korea, declare that the product described below to which this declaration relates is in conformity with the
requirement of the FCC Part 15 Subpart B.
Product Information:
Product Name: Intellian GX60, 65cm Ka-band Maritime Stabilized Antenna System
Test Result:
noitceseluRtseTdradnatS Test Report Number Result
FCC Part 15
Subpart B
AC power line conducted emission Section 15.107(a) ICES-003,
Section 6.1, Table 2 SKT-EFC-140043 Pass
Radiation emissionsbelow 1GHz Section 15.109(a) ICES-003,
Section 6.2, Table 5 SKT-EFC-140043 Pass
Radiation emissionsabove 1GHz Section 15.109(a) ICES-003,
Section 6.2.2, Table 7 SKT-EFC-140043 Pass
Supplementary Information:
Notified Body Involved:
(Testing Organization)
SK Tech Co., Ltd.
820-2, Wolmoon-ri, Wabu-up, Namyangju-si, Gyeonggi-do 482-905, Korea
Technical/Compliance
File Held by:
Intellian Technologies, Inc.
18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 451-862, Korea
Place and Date of issue: Gyeonggi-do, Korea onSeptember 1, 2014
Authority: Kevin Eom/
Director,
Research and Development
Signature:
Date: September 01, 2014
Certifications

9
Doc Number IT16-DC0502-03
Intellian Technologies, Inc.
EMEA & APAC Headquarters
348-5 Chungho-Ri, Jinwi-Myeon
Pyeongtaek-Si, Gyeonggi-Do, 451-862 Korea
Tel: [phone]
Intellian Technologies USA, Inc.
US Headquarters
11 Studebaker
Irvine, CA 92618 USA
Tel: [phone]
RED Declaration of Conformity (DoC)
We, Intellian Technologies, Inc. located at 18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 451-862,
Korea declare under our sole responsibility that the product(s) described in the below to which this declaration relates
is in conformity with the essential requirements and other relevant requirements of the Radio Equipment Directive
(2014/53/EU).
Product Information:
Product Name(s):
Intellian GX60, 65cm Ka-band Maritime VSAT Antenna System
To provide the presumption of conformity in accordance to Annex III(encompassing Annex II) of Directive
2014/53/EU; the following harmonized standards and normative documents are those to which the product’s
conformance is declared, and by specific reference to the essential requirements of Article 3 of the Directive
2014/53/EU.
1995/5/EC Article
Standard(s) Applied in Full
Result
SAFETY (Art 3.1.a)
EN 60950: A2
Pass
EMC (Art. 3.1.b)
EN 301 843-1
Pass
SPECRTUM (Art. 3.2)
EN 301-360
EN 301-459
EN 303-978
Pass
Supplementary Information:
Notified Body Involved:
(Testing Organization)
DT&C Co., Ltd.
42, Yurim-ro, 154 beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do 449-935, Korea
Technical/Compliance
File Held by:
Intellian Technologies, Inc.
18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-Si, Gyeonggi-Do 451-862, Korea
Place and Date of issue:
Gyeonggi-do, Korea on 20 Oct 2012
Authority: Steve Cha Signature: _________ ___
/ CTO, R&D
Date: 20
th
July, 2017

GX60 – Marine Satellite Communication System
10
Doc Number IT14-DC0901-01
Intellian Technologies, Inc.
EMEA & APAC Headquarters
18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-Si,
Si,
Gyeonggi-do 451-862, Korea
Tel: [phone]
Intellian Technologies USA, Inc.
US Headquarters
9004 Research Drive
Irvine, CA 92618 USA
Tel: [phone]
C-Tick Declaration of Conformity (DoC)
We, Intellian Technologies, Inc. located at 18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 451-862,
Korea, declare that the product described below to which this declaration relates is in conformity with the
essential requirements and other relevant requirements of the C-Tick.
Product Information:
Product Name: Intellian GX60, 65cm Ka-band Maritime Stabilized Antenna System
Test Result:
tluseRrebmuNtropeRtseTtseTdradnatS
AS/NZS CISPR 22
CISPR 22
EN 55022
Conducted disturbance at AC main port SKT-EET-140040 Pass
Conducted disturbance at telecommunication port SKT-EET-140040 Pass
Radiated disturbance below 1GHz SKT-EET-140040 Pass
Radiated disturbance above 1GHz SKT-EET-140040 Pass
Supplementary Information:
Notified Body Involved:
(Testing Organization)
SK Tech Co., Ltd.
820-2, Wolmoon-ri, Wabu-up, Namyangju-si, Gyeonggi-do 482-905, Korea
Technical/Compliance
File Held by:
Intellian Technologies, Inc.
18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 451-862, Korea
Place and Date of issue: Gyeonggi-do, Korea onSeptember 1, 2014
Authority: Kevin Eom/
Director,
Research and Development
Signature:
Date: September 01, 2014

11
Doc Number IT14-DC0901-02
Intellian Technologies, Inc.
EMEA & APAC Headquarters
18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-Si,
Si,
Gyeonggi-do 451-862, Korea
Tel: [phone]
Intellian Technologies USA, Inc.
US Headquarters
9004 Research Drive
Irvine, CA 92618 USA
Tel: [phone]
EMI Declaration of Conformity (DoC)
We, Intellian Technologies, Inc. located at 18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 451-862,
Korea, declare that the product described below to which this declaration relates is in conformity with the
essential requirements and other relevant requirements of the IEC60945 and IEC61000-4-2~6/11.
Product Information:
Product Name: Intellian GX60, 65cm Ka-band Maritime Stabilized Antenna System
Test Result:
tluseRetiustseTesualC.feRdradnatS
IEC60945
ssaPtropmaintaemissionsdetcudnoC2.9
ssaPzHM03wolebsnoissimedetaidaR3.9
ssaPzHG1wolebsnoissimedetaidaR3.9
ssaPzHG1evobasnoissimedetaidaR3.9
IEC61000-4-2 10.9 Electrost ssaP)DSE(egrahcsidcita
ssaP)SR(ytinummidetaidaR4.013-4-00016CEI
IEC61000-4-4 10.5 EFT/Burst on AC power ports, and signal and control ports Pass
ssaPstroprewopCAnoytinummiegruS6.015-4-00016CEI
IEC61000-4-6 10.3 Injected current (CS) on AC and DC power ports, signal and
control ports Pass
IEC61000-4-11 10.7 Power supply short term variation on AC power ports Pass
IEC61000-4-11 10.8 Power supply failure on AC and DC power ports Pass
Supplementary Information:
Notified Body Involved:
(Testing Organization)
SK Tech Co., Ltd.
820-2, Wolmoon-ri, Wabu-up, Namyangju-si, Gyeonggi-do 482-905, Korea
Technical/Compliance
File Held by:
Intellian Technologies, Inc.
18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 451-862, Korea
Place and Date of issue: Gyeonggi-do, Korea onSeptember 1, 2014
Authority: Kevin Eom/
Director,
Research and Development Signature:
Date: September 01, 2014

GX60 – Marine Satellite Communication System
12
Intellian GX60 Introduction
Intellian GX60 is a 65 centimeter Ka-band maritime stabilized antenna, a ready-to-use system for the super-fast,
Global Xpress™ (GX) Ka-band broadband service from Inmarsat. The GX60 offers robust Ka-band RF performance
optimized for Inmarsat GX service with all new GX BDT.
The GX60 BDT combines the Global Xpress Modem internally with the Below Deck Terminal, saving time and space
during installation. The BDT also includes Wi-Fi to allow wireless connection using the dedicated Intellian Aptus
software for system control and monitoring.
The Aptus software automatically congures the antenna system, enabling true One Touch Commissioning. Equipped
with Aptus®, the GX60 antenna can be remotely accessed, monitored and controlled through serial connection or
secured TCP/IP network. Its graphic-based user interface provides easy-to-use operating environment.
The GX60 also has an embedded web server and secured web user interface called Aptus Web for remote management
of the antenna on a web browser. Network connection can be easily setup through the front Management Ethernet
Port on the BDT that supports automatic IP conguration.
The antenna's 3-axis stabilized platform and advanced shock-resistant and vibration damping design of the Pedestal
is fully optimized to withstand the demanding maritime conditions and to ensure reliable broadband communications.
The unlimited azimuth range ensures continuous tracking without unwrapping the cables in the antenna and the low
elevation angle (-20°) supports seamless signal reception at extremely high latitudes.
The GX60 is built to meet or exceed the industry's most stringent standards such as FCC, ETSI, R&TTE. With its
frequency tuned radome and newly designed reector, the GX60 offers the maximized performance on a Ka-band
Inmarsat Global Xpress system.
Introduction

13
Introduction
Intellian GX60 Features
Ka-band optimized reector
The GX60 carbon ber reector is designed and engineered to operate on the Ka-band while maximizing the RF performance.
The reector of the GX60 is designed to be extremely precise and very stable in all operating conditions.
Frequency tuned radome
To ensure efcient operations for Ka-band Inmarsat Global Xpress™ systems, the signal loss of the radome itself is minimized
and the performance maximized with an optimized radome design that enhances the Ka-band system performance.
Combined BDT-Global Xpress™ Core Module
The all new GX BDT combines the Core Module internally with the Below Deck Terminal, saving time and space during installation.
The BDT also includes a Wi-Fi connection to allow wireless connectivity via the dedicated Intellian Aptus software for system
control and monitoring. The Aptus software also helps automatically congure the antenna system during initial commissioning.
Gyro-free satellite search capability
Intellian’s new generation gyro-free satellite search function enables the GX60 to acquire and lock onto the satellite without
requiring a separate input from the ship’s gyrocompass.
Graphical and user-friendly antenna control software: Aptus®
The GX60 provides a newly developed, graphic-based antenna remote control program with an additional Software Development
Kit (SDK), allowing the NOC or service center to integrate antenna monitoring and control into its existing network management
systems in an easier, user-friendly, and convenient manner.
Dedicated Management Ethernet Port
The GX60 has a Management Ethernet Port on the BDT front that enables direct and simple network connection between a PC
and the BDT. The Management Port allows Internet access and quick access to Intellian's remote management solution, the
Aptus Web.
Wireless access via Wi-Fi
The built-in Wi-Fi wireless network card enables the BDT to be wirelessly connected and can be turned on and off by a switch.
Wireless devices such as PCs, laptops and smartphones can be used to connect to the BDT and monitor, enabling users to
control and change the settings of Intellian antenna system wirelessly.
Industry-leading standards compliance
The GX60 is designed to meet or exceed FCC and ETSI specications, as well as EN60945, EN60950, R&TTE, DNV2.4 Class C
specication.
Automatic satellite switching
The GX60 supports auto satellite and beam switching for seamless continuous coverage.

GX60 – Marine Satellite Communication System
14
System Conguration
For your satellite communication system to work correctly, the system will have to be connected with all of
the provided components as shown in the gure below. A seperate purchase of a satellite modem and ship's
gyrocompass may be required.
Below Deck Terminal(BDT)
PC Interface
Antenna Tx
NMEA
Antenna Rx
PC
Ship’s Gyrocompass
(Not supplied)
AC 100 ~ 240V
(50~60Hz, 4A)
AC 100 ~ 240V
(50~60Hz, 1A)
Antenna

15
Introduction
Tools Required for Installation
Phillips Head Screwdriver
Flat Head Screwdriver
11 mm Wrench
19 mm Wrench
5 mm Allen/Hex key

GX60 – Marine Satellite Communication System
16
System Package
The package of Intellian GX60 consists of antenna unit, BDT and installation kit box.
Antenna unit
BDT
Installation kit box
Installing Antenna

17
Installing Antenna
Antenna Unit
The antenna unit includes an antenna pedestal inside a radome assembly unit. The pedestal consists of a satellite
antenna main dish with RF components mounted on a stabilized pedestal. The radome protects the antenna pedestal
assembly unit from the severe marine environment.
Antenna unit

GX60 – Marine Satellite Communication System
18
BDT (Below Deck Terminal)
The digital VFD (Vacuum Fluorescent Display) allows for easy operation of the BDT, even in the dark.
The functions of the BDT are as follows :
• Setting the satellite
• Editing satellite information
• Setting the antenna parameter
• Setting the antenna manual search
• Setting the LNB local frequency
• Setting block zones
• Setting GPS and Gyrocompass
• Display versions
• Built-in real-time diagnostics function
• Backup and restore the system settings
• Set up the interface with a PC
• Supports Wi-Fi BDT operation
• Recording antenna activities and rmware upgrade through USB
• Built-in web-based remote control management
• Front and rear panel Management Ethernet port
Rear Panel
Front Panel

19
Installing Antenna
Contains the items required for securing the antenna unit and BDT to the vessel.
Installation Kit
BDT box
Description Q'ty Size Remarks
Below Deck Terminal (BDT) 1 43.1 cm x 44.1 cm x 4.4 cm
(17" x 17.3" x 1.7") Below Deck Terminal
User Manual 1
RF Hazard Sticker 1 Radiation Safety Distance Label
Mounting Template 1
Wi-Fi Antenna 1 110mm
USB Flash Drive 1
Components box
Description Q'ty Size Remarks
BDT Bracket (Rack) 2 BDT-19inch Rack
BDT Bracket (Table) 2 BDT-Table
AC Power Cord (CEEE7/7) 1 1.5m BDT Power
AC Power Cord (USA) 1 1.5m BDT Power
4 Pin Power Connector 1 - CA 3 LD
PC Serial Cable 1 1.8m BDT to PC
USB Cable (A-A) 1 1.8m BDT to PC
Ethernet Cable (RJ45/LAN) 1 1.5m BDT to PC
N to F Adaptor 2 N(Male) to F(Female) Adaptor
Hex Bolt 5 M12 x 100L
Antenna-Deck 4 Sets :
Installation 1 Set : Spare
Flat Washer 5 M12
Spring Washer 5 M12
Hex Nut 10 M12
Hex Head Wrench Bolt 5 M6 x 40L
Radome (Spare Bolts)
Spring Washer and Flat Washer 5 M6
Self-Tapping Screw 5 M4 x 16 Table Mount Bracket
Flat Head Screw 10 M4 x 12L Rack Mount Bracket BDT
Sems Bolt 5 M3 x 12L Table Mount Bracket BDT
Radome Door Key 2 1 Door Key and 1 Spare Key

GX60 – Marine Satellite Communication System
20
Planning Installation
Selection of Antenna Installation Site
The mounting platform should be robust enough and not subject to vibration. The movement of the antenna can
be minimized by installing at the center of the vessel. If these conditions can be only partially satised, nd the
best compromised installation site.
look Angle
-20° to +115°
Obstruction
Antenna
Unit
Minimize Satellite Blockage
Install the antenna in accordance with the following procedures to ensure maximum performance of the antenna.
The ideal antenna site should have a clear view of the horizon or satellite with all around clearance. Please be
sure there are no obstacles within the EL range -20° to +115° from the center of the antenna. Obstacles can
prevent the antenna from transmitting and receiving the satellite signal.
Elevation Limit
of Obstacles
