Front Runner SHOW013 User manual

SHOW013_REV_A00 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
front runner
SHOW013
ENG
1
Thank you for purchasing Front Runner Shower Cubicle Curtain / Caddy.
Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
READ ME !
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.
SHOWER CUBICLE CURTAIN / CADDY

SHOW013_REV_A00 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 2
TOOLS NEEDED
FIGURE 1.1
GET ORGANIZED
1
IN THE BOX
1 1 X Shower Caddy
2 2 X Carabiner
3 2 X M8 Eyenut
4 2 X M8 Nylon Flat Washer
5 2 X M8 x 25 Hex Bolt
4mm
1
2
3
4
5

SHOW013_REV_A00 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
3
FIT AND SECURE2
2.1
2.2
2.3
DO NOT TIGHTEN, as the M8 Eyenuts will
still need to be adjusted.
4mm
Loosen and remove the corner of the Rack
as shown
Slide two M8 x 25 Hex Bolts ( Item 5 ) into
the channel of the side profile as shown.
Assemble the M8 x 25 Hex Bolts ( Item 5 ) to
the Side Profile using M8 Eyenuts ( Item 3 ) &
M8 Nylon Flat Washers ( Item 4 )
Adjust the M8 Eyenuts ( Item 3 ) to measure
1210mm centre to centre as shown.
Fully tighten.
1210mm
5
4
3

SHOW013_REV_A00 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 4
FIT AND SECURE2
2.4
2.5
Assemble the Carabiners ( Item 2 ) to the
Shower Caddy ( Item 1 ) as shown.
Assemble the Shower Caddy & Carabiners
( Step 2.4 ) to the M8 Eyenuts ( Step 2.3 )
as shown.
2
1

Congratulations! You did it. Take a step back and admire your work!
SHOW013_REV_A00 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
5
FINISHED
3
3.1
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner Dealer in person or online.
Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam
Share your adventures on:
