Inter-m PW-6242B Installation manual

Operation Manual
Program Timer
PW-6242B
* Rack mount products in the Western Hemisphere(North America, South America,
and the Caribbean) do not have handles installed due to customer preference.
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 표1

PROGRAM TIM R
Welcome
Welcome
A personal welcome to you from the management and employees of Inter-M
All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value,
and we are delighted you have purchased one of our products.
We sincerely trust this product will provide years of satisfactory service, but if anything is not to your complete
satisfaction, we will endeavor to make things right.
Welcome to Inter-M, and thank you for becoming part of our worldwide extended family!
ISK OF ELECT IC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO EDUCE THE ISK OF ELECT IC SHOCK.
DO NOT EMOVE COVE (O BACK).
NO USE -SE VICEABLE PA TS INSIDE.
EFE SE VICING TO QUALIFIED SE VICE PE SONNEL.
ATTENTION : ISQUE DE CHOC ELECT IQUE
NE PAS QUV I
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
*WA NING FO YOU P OTECTION PLEASE EAD THE FOLLOWING-WATE AND MOISTU E: Unit should not be used near water(e.g.
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken so than objects do
not fall and liquids are not spilled into the enclosure through openings.
*Do not install this equipment in a confined space such as a book case or similar unit.
*Warning : To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture and objects filled with liquids, such as vases,
should not be placed on this apparatus.
*This apparatus shall be connected to a mains socket outlet with a protective earthing connection.
*
To completely disconnect this apparatus from the AC mains, disconnect the power supply cord plug from the AC receptacle.
* The mains plug of the power supply cord shall remain readily accessible.
CAUTION
*These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing
other than that contained in the operating instructions unless you are qualified to do so.
NOTE
*This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC ules. These limits are
designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
This symbol is intended to alert the user to the
presence of important operation and maintenance
(servicing) instructions in the literature accompanying
the appliance.
Caution: To prevent electric shock do not use this (polarized) plug with
an extension cord, receptacle or other outlet unless the
blades can be fully inserted to prevent blade exposure.
Attentions: Pour prévenir les chocs électriques ne pas utiliser cette
fiche polarisée avec un prolongateur, une prise de courant
on une autre sortie de courant, sauf si les lames peuvent
étre insérées à fond sans en laisser aucune partie à
découvert.
Pour deconnecter completement l’appareil du reseau
d’alimentation. deconnecter le cordon d’alimentation de la
prise murale.
La prise du reseau d’alimentation doit demeurer aisement
accessible.
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 표2

PROGRAM TIM R
1
PW-6242B
Contents
Contents
Unpacking .......................................................................................................................................2
Installation
nvironment....................................................................................................................................2
Important Safety Instructions.............................................................................................................2
Features ...........................................................................................................................................3
ackage and accessory includes ................................................................................................3
Front anel ......................................................................................................................................4
Rear anel.......................................................................................................................................8
How to Operate............................................................................................................................10
Application ....................................................................................................................................20
C and RS-232C Connection......................................................................................................21
Block Diagram ..............................................................................................................................22
Specifications ................................................................................................................................23
Service
Procedures....................................................................................................................................25
Schematic.....................................................................................................................................25
Parts List .......................................................................................................................................25
Variations and Options...............................................................................................................25
Warranty .......................................................................................................................................25
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 1

PROGRAM TIM R
2PW-6242B
Installation
Unpacking
Unpacking
Although your PW-6242B is neither complicated nor difficult to operate, we recommend you take a few minutes
to read this brief manual and familiarize yourself with the important information regarding product features,
setup and operation.
As with most electronic devices, we strongly recommend you retain the original packaging. In the unlikely event
the product must be returned for servicing, the original packaging (or reasonable equivalent) is required.
Installation
Environment
Never place this product in an environment which could alter its performance or reduce its service life. Such
environments usually include high levels of heat, dust, moisture, and vibration.
IM ORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
S3125A
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 2

PROGRAM TIM R
3
PW-6242B
Features
Features
- Considering user convenience
For the convenience of timer program input and use, we made it for user to operate easily by separating digit button
& multi-function button.
- Adopting Large Vacuum Fluorescent Display
By adopting large Vacuum Fluorescent Display, you can verify the operation status to each function as well as various
text displays at a look.
- rograming using C
You can easily schedule via management program by connecting PC with RS-232C port.
- Various melodies and voices output
You can play various melodies and voices by interlocking SD Card mounted to this device and PV-6232A, our model.
- HOSTING Using USB Terminal
You can download MP3 file from computer to SD Card mounted to the device by connecting USB cable or mount USB
memory to save the file into internal memory through COPY function.
You can save 9999 melodies additionally other than 15 melodies provided initially and for storage capacity, please
leave 10% of SD Card capacity (up to 32GB supported).
- BACK-U ower
Under the setting of current time, even though AC power turns off, power can be maintained for about a week of time
with internal Back-Up power. Within the time which Back-Up power is maintained, even though AC power is re-
authorized, there is no need to re-adjust the time.
- Blackout Measurement
Separate Memory is used to prevent the data loss from blackout or other instable power.
- Automatic Return
When entering schedule data not using PC but using the front button, if any button is pushed for 1 minute, it is
regarded as input cancellation and it returns to normal operation status.
- AC ower Output Control
After connecting other equipment with AC OUTL T terminal, by turning ON/OFF AC OUTL T button in front, it
enables to control ON/OFF of AC Power connected to other equipment.
- AC ower Output Time Control
In order to prevent TIMING D LAY when interlocking with external POW R AMP, you can adjust AC Power Output
Time of this device from 1 second up to 20 seconds.
- KEY LOCK
Schedule and user setting can be protected.
ackage and accessory includes
ackage and accessory includes
1. AC power cord x 1
2. RS-232 cable x 1
3. B-type USB cable x 1
4. Screw for rack mounting x 4
5. User manual x 1
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 3

PROGRAM TIM R
4PW-6242B
Front anel
Front anel
1. AC OUTLET ( OWER OUT UT) BUTTON
It is a button to turn ON/OFF AC power output of AC OUTL T 1, 2 terminals in back side and R MOT
OUTL T contact terminal output. If pushing this button more than 2 seconds in default status, you can adjust
AC power output time.
2. C CONNECTING TERMINAL (USB B TY E)
It is a terminal to upload or download MP3 file saved to PC from/into SD Card in back side of equipment
via USB terminal connected to external PC. Under the status connecting with PC via USB cable, functional
buttons do not operate and if you want to play the file saved to mounted memory, remove the cable
connected with PC.
3. USB MEMORY CONNECTING TERMINAL (USB A TY E)
It is a terminal used when connecting USB memory with the device. You can copy the sound source saved to
USB memory Into SD Card in back side of equipment.
- File system: FAT 32 (NTFS unsupported)
4. OUT UT (MELODY OUT UT) BUTTON
It is a button to control M LODY output. M LODY output turns ON/OFF depending on ON/OFF of output
button.
5. VOICE BUTTON
It is a button used when changing VOIC scheduling and scheduled content.
- If pushing the button at default status, it moves into VOIC scheduled content verification mode.
- If pushing the button more than 2 seconds at default status, it moves into VOIC scheduling mode.
6. MELODY BUTTON
It is a button used when changing M LODY play, scheduling and scheduled content.
PROGRAM TIMER
P W
6242B
PC AC OUTLET
OUTPUT LEVEL
MEMORY OUTPUT
VOICE
MODIFY
MELODY
DOWN
AC CH1 MON
TUE
WED
THU
FRI
SAT
SUN
CH2
TIME
1 2 3
4 5 6
7 8
0
9
AM/PM
DAY
CANCEL
HOUR /
MINUTE
TRACK
CHANNEL
DELETE
COPY
CH3
CH4
UP
MIN MAX
1 4 56 7 12 22221
3 8 9 10 11 13 14 15 16 17 18 19 20
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 4

PROGRAM TIM R
5
PW-6242B
- If pushing the button at default status, it moves into M LODY scheduled content verification mode.
- If pushing the button more than 2 seconds at default status, it moves into M LODY scheduling mode.
7. AC BUTTON
It is a button used when changing the scheduling and scheduled content of AC OUTL T output.
- If pushing the button at default status, it moves into the scheduled content verification mode of AC OUTL T
output.
- If pushing the button more than 2 seconds at default status, it moves into the scheduling mode of AC
OUTL T output.
8. MODIFY BUTTON
It is a button used when changing the scheduled content. If pushing the button during verifying the schedule
of VOIC /M LODY/AC OUTL T output, it moves into the saved scheduling modification mode.
9. DOWN, U BUTTON
It is a button used when selecting the scheduled content verification and various modes.
- If pushing the button during verifying the scheduled content, it moves into previous/next scheduled content.
- If pushing the button more than 2 seconds during verifying the scheduled content, it moves into the
scheduled content of previous/next day.
- It is used when selecting the item of copying/deleting sound source or scheduled content or setting the
day.
- If pushing the button more than 2 seconds at default status, it moves into communication speed setting
mode.
- If pushing the button during setting communication speed, communication speed value is changed.
10. OUT UT CHANNEL DIS LAY LED
It is a L D to display the channel which is output during the playing of VOIC or M LODY sound source.
If selecting the output channel during scheduling, the selected channel displays and if the scheduling is
completed, L D turns off.
11. DAY DIS LAY LED
It is a L D to display the day of current time or scheduled time. At default status, current day displays and
during the scheduling, the day of scheduled time displays.
12. DIS LAY WINDOW (VFD: VACUUM FLUORESCENT DIS LAY)
It is a window to display manipulation and operation status when manipulating each functional button.
Current equipment status, current time, scheduled content, and progress status such as play/delete/copy are
displayed.
13. OUT UT LEVEL VOLUME CONTROLLER
It is a volume controller to control output volume of internal melody.
14. TIME BUTTON
It is a button used when setting the current time.
- If pushing the button at default status, it moves into time setting mode.
- If pushing the button more than 2 seconds at default status, it moves into time error calibration mode.
- In case of time error calibration, you can select the sign of input value by pushing the button.
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 5

PROGRAM TIM R
6PW-6242B
15. AM/ M, HOUR/MIN, DAY BUTTON
It is a button used when setting the current time and scheduled time.
- AM/PM button sets up morning/afternoon, HOUR/MIN button sets up hour, minute, and second, and
DAY button sets up day.
- If pushing the button during setting AM/PM, AM changes into PM and PM changes into AM.
- If pushing the button during setting HOUR/MIN, it is changed from HOUR input to MIN input and from
MIN input to HOUR input.
- If pushing the button more than 2 seconds during setting MIN, it moves into second setting.
- If pushing the button during setting day, it changes into the next day.
16. CANCEL BUTTON
It is a button used when canceling during setting.
- If pushing the button during setting, the setting is not saved and it moves into the default status.
- If pushing the button during verifying the schedule, it moves into the default status.
- If pushing the button during playing M LODY, the sound source stops and it moves into the default status.
17. DIGIT BUTTON
It is a button used when selecting time setting, track input and channel. You can enter the digit from 0 to 9.
18. ENTER BUTTON ( )
It is a button used when saving the set content or performing the function.
- When completing the setting and pushing the button, the set content is saved and it moves into the default
status.
- If pushing the button during entering the set item, it sets the selected item and moves into the next
procedure.
- If pushing the button during setting M LODY play, the sound source plays.
19. DELETE BUTTON
It is a button used when deleting the scheduled content and file.
- If pushing the button at default status, it moves into sound source/scheduling deletion function.
- If pushing the button more than 2 seconds at default status, it moves into schedule deletion & day selection
modes.
20. CO Y BUTTON
It is a button used when deleting the scheduled content and file. If pushing the button at default status, it
moves into sound source/scheduling copy function.
21. CH BUTTON
It is a button used when selecting the output channel in case of M LODY & VOIC scheduling and M LODY
PLAY operation. If pushing the button during scheduling, it moves into the item to select the output channel.
22. TRACK BUTTON
It is a button used when selecting the track in case of M LODY & VOIC setting.
- If pushing the button at default status, the number of total sound sources saved to the current SD Card
displays.
- If pushing the button more than 2 seconds at default status, it moves into sound source to be played setting
mode.
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 6

PROGRAM TIM R
7
PW-6242B
- If pushing the button during M LODY & VOIC scheduling, it moves into the item to select the sound
source.
- If pushing the button during M LODY Play operation setting, it moves into the item to select the sound
source.
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 7

PROGRAM TIM R
8PW-6242B
Rear anel
Rear anel
1. AC OWER IN UT TERMINAL
It is a terminal to connect the power cord.
- It inputs AC power by connecting the power cord.
- When opening the fuse cap, AC power fuse is contained and in case of exchange, make sure to check the
rated and to exchange with the one of same capacity. (Fuse, 20mm, 250V T5AL)
2. AC OWER OUT UT1 (AC OUTLET1)
It is an AC power output terminal. It can be used up to 500W.
3. AC OWER OUT UT2 (AC OUTLET2)
It is an AC power output terminal. It can be used up to 500W.
4. SD CARD SLOT
It is a slot to mount SD CARD. Basically 8GB of SD CARD is provided.
- SD Card supported capacity: Up to 32GB
- File system: FAT 32 (NTFS unsupported)
※TLC type of SD CARD is recommended and other type of SD CARD may not be compatible.
5. SD CARD O ERATION STATUS DIS LAY LED
It is a L D to display the mounting and operation status of SD CARD. When SD Card is on R AD/WRIT
status, Green L D lights.
6. DC OWER IN UT TERMINAL
It is a terminal to input DC 24V power. (DC 24V, 350mA)
ACCESS
AC INPUT
350mA
SD MEMORY
1 2 348
6 7 910
115
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 8

PROGRAM TIM R
9
PW-6242B
7. REMOTE CONTROL TERMINAL (REMOTE OUT UT)
- When AC OUTL T is ON, the contact is printed out and when OUTL T is OFF, the contact is not printed
out.
-It can be used by connecting to contact terminal of external device.
- You can make a remote control of power ON/OFF by connecting to PD-6359A, CS-6216P.
8. VOICE FILE IN UT TERMINAL (AUDIO IN FROM VOICE FILE)
It is a terminal to connect the audio output terminal of PV-6232A.
9. SERIAL TERMINAL (RS-232C)
It is a terminal to connect with PV-6232A. Also, you can add the scheduling through the management
program by connecting with PC.
10. CHANNEL OUT UT TERMINAL (CHANNEL OUT)
It is a terminal to print out melody & voice.
11. CHANNEL IN UT TERMINAL (CHANNEL IN)
It is a terminal to take the input of audio signal from the outside. In normal condition, the input signal is
printed out by bypassing to channel output terminal.
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 9

PROGRAM TIM R
10 PW-6242B
How to Operate
How to Operate
1. TIME SETTING
It is a function to set the current time.
1) If pushing TIM button at standby mode, AM or PM flashes on display window.
2) Whenever pushing once by selecting morning/afternoon using AM/PM button, AM & PM change.
3) If pushing HOUR/MIN button, TIM flashes on display window and input time using digit button.
4) If pushing HOUR/MIN button once again, MIN flashes on display window and input MIN using digit
button. Whenever pushing the button once, TIM and MIN setting status converts and if pushing
HOUR/MIN button under MIN status, you can set up S C.
5) If pushing DAY button, DAY flashes on display window and select the day to input by continuing to push
DAY button.
6) When pushing NT R button, the setting is completed. When intending to cancel the setting, if pushing
CANC L button, the setting is not save and it moves into the standby mode.
tiMEaM/PMHour/MinHour/MinDayCanCElEntErPW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 10

PROGRAM TIM R
11
PW-6242B
7) When TIM setting is completed, L D of due day lights on the day indicator.
※Caution: In case of not connecting the power for a long time, time may be reset.
※Caution: When normal charging is completed, TIM will be preserved for about 12 days.
8) When connecting the power after being left for a long time, if AM 00:00 MON flashes on display
window, please reset TIM .
2. VOICE SCHEDULE
It is a setting function to play the sound source file saved to PV-6232A(MULTI-VOIC FIL ) which is our
model at desired time.
1) If pushing VOIC button longer, the setting starts as L D of the button flashes.
2) Scheduled Time Setting: 1. Set in same way with time setting instruction.
3) Scheduled Track Setting: After setting the scheduled time, if pushing TRACK button, track number flashes
on display window. Then, input the track number using digit button. (You can choose up to 9999.
Provided that if sound source files are not registered by 9999, it may not operate normally. Therefore, set
the proper number according to the number of registered sound source file.
4) Channel Setting: If pushing CH button, display window moves into output channel setting mode.
- Select the desired channel (CH 1~4) using digit button.
At this point, if pushing the digit button which is same with the
selected channel number or pushing CH button, ON/OFF converts.
When it is set as ON,
L D of due channel lights on the channel indicator.
- If pushing CH button longer at channel setting mode, CH ALL ON displays on display window and All
of CH 1~4 change into ON status. traCkCHVoiCEPW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:53 페이지 11

PROGRAM TIM R
12 PW-6242B
- If pushing CH button longer when all channels are set as ON, CH ALL OFF displays on display window
and All of CH 1~4 change into OFF status.
5) When pushing NT R button after setting the channel, the setting is completed.
6) When the set time comes, the play starts with scheduled content.
※When saving by setting VOIC schedule as the same time with already scheduled M LODY, previously
saved M LODY scheduled content is deleted.
3. MELODY SCHEDULE
It is a setting function to play the sound source file saved to this device at desired time.
1) If pushing M LODY button longer, the setting starts as L D of the button flashes.
2) Set in the same way with 2. VOIC Schedule Instruction.
3) When the set time comes, the play starts with scheduled content.
※When saving by setting M LODY schedule as the same time with already scheduled VOIC , previously
saved VOIC scheduled content is deleted.
4. MELODY LAY
It is a function to play by selecting the desired track and the channel to be printed of sound sources saved to
this device.
1) When pushing TRACK button longer, the setting starts.
※When pushing TRACK button shortly, you can verify the number of total melodies saved to internal
memory.
2) Input the track to play with digit button and if pushing NT R button or CH button, it moves into channel
setting mode.
3) Set the channel in the same way with 2. VOIC Schedule Instruction.
4) When pushing NT R button after setting, the selected track plays.
When the play is over, it stops automatically.
5) Input the track setting by choosing from 1 to 9999 and if the selected track is none when playing, TRACK
RROR statement displays on display window.
※During M LODY/VOIC scheduled play, you cannot use this function.
MEloDytraCkPW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:53 페이지 12

PROGRAM TIM R
13
PW-6242B
5. AC SCHEDULE
It is a function to turn ON or OFF AC power output (AC OUTL T) and R MOT OUTPUT contact output at
desired time.
AC power output and R MOT OUTPUT contact will operate simultaneously.
1) If pushing AC button longer, L D of the button lights on and the contact is printed at remote control
terminal of back side.
2) Scheduled time setting is same with VOIC /M LODY scheduling function.
3) ON/OFF of AC OUTL T can be set by pushing Ch button. Whenever pushing CH button, ON/OFF
converts.
4) When pushing NT R button, the setting is completed.
※When playing M LODY/VOIC , AC OUTL T and R MOT OUTPUT are printed and when the play
ends, the output of AC OUTL T and R MOT OUTPUT is turn back to the prior state.
※If making AC schedule (AC OUTL T ON) in the same time with M LODY/VOIC scheduled time, even
though the play ends, AC OUTL T and R MOT OUTPUT continues to maintain the output status.
6. SCHEDULED CONTENT VERIFICATION
If there are scheduled content of VOIC , M LODY, AC, you can verify with the following method and if no
scheduled content, NO M MORY will be displayed on display window.
1) VOIC Scheduled Content Verification
- If pushing VOIC button, L D of the button lights on and it displays from the scheduled content saved
on Monday.
- At this point, in order to verify other scheduled content, you can search by the order of scheduled time
using DOWN/UP button and if verifying the content of other day, you can push DOWN/UP button
longer. If there is any scheduled content on other day, you can search by moving into that day.
2) In case of M LODY & AC, you can verify in the same way with VOIC .
Provided that when verifying M LODY scheduled content, push M LODY button to start the verification
and when verifying AC scheduled content, push AC button to start the verification. For example, in the
following screen, you can verify that VOIC track no. 2 will provide CH 2 and CH 4 output on Monday
PM 2:08.
3) If pushing CANC L button, it returns to the standby mode.
7. MODIFY
It is a function used when changing VOIC , M LODY, AC scheduled content.
1) In scheduled content verification mode, select the content to change using DOWN/UP button.
2) If pushing MODIFY button, it returns to the modify mode. At this point, button L D of due modes (VOIC ,
M LODY, AC) flashes and MODIFY button L D lights on.
aC▶PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:53 페이지 13

PROGRAM TIM R
14 PW-6242B
8. CO Y (SCHEDULE/MEMORY)
1) SCH DUL COPY
It is a function used when copying schedule content to other day.
- If pushing COPY button at the standby mode, SCH DUL / M MORY displays on display window and
the selected mode flashes.
- If pushing NT R button after selecting SCH DUL with UP/DOWN button, the setting starts.
- At displayed screen, previous day is the day of original and next day is the day to be copied.
- When previous original day flashes, select the desired day using DOWN/UP button or DAY button.
- If pushing COPY button again, next day to be copied flashes and at this point, select the desired day
using DOWN/UP button or DAY button.
- If pushing NT R button after setting, COPY performs.
2) M MORY COPY
It is a function to copy the file in USB memory to internal memory. COPY from internal memory to USB
memory is not acceptable.
- Mount the USB Memory into USB memory connecting terminal (USB A Type).
- If pushing COPY button at the standby mode, SCH DUL / M MORY displays on display window and
the selected mode flashes.
- If pushing NT R button after selecting M MORY with UP/DOWN button, it converts into the mode to
set COPY range.
* TRACK: COPY by selecting the track range.
* ALL: COPY the whole memory files.
<Partial COPY>
- If pushing NT R button after selecting TRACK, the number of total melodies saved to USB memory is
displayed on display window and you can designate the area to copy.
- Input Start track no. by using digit button. CoPyMoDifyPW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:53 페이지 14

PROGRAM TIM R
15
PW-6242B
- After pushing NT R or UP button, input nd track no.
- When modifying Start track no. again, use DOWN button to move.
- If pushing NT R button, COPY performs.
- If pushing CANC L button during copying, the mode is unlocked and by the completed file, it is saved
to internal memory.
<All COPY>
- If pushing NT R button after selecting ALL, the number of total melodies saved to USB memory is
displayed on display window and the ready to copy all is completed.
- If pushing NT R button, COPY performs.
- If pushing CANC L button during copying, the mode is unlocked and by the completed file, it is saved
to internal memory.
※Caution:
1) If memory space is short during COPY operation, M MORY FULL is displayed on display window.
In this case, delete unnecessary file using D L T function and then use.
2) The content to be copied is saved as MP3 format file. When copying WMA format file, it will be
saved as MP3 file but as file capacity increases more than two times, make sure to check the
remained space of memory.
3) When copying the saved sound source file to the inside of USB memory, save the sound source file
to the top position of USB memory as following. Otherwise, copy will not be performed:
9. DELETE (SCHEDULE/MEMORY)
1) SCH DUL Deletion
It is a function to delete scheduled information.
<Individual Deletion>
- After selecting the content to delete from scheduled content verification, push D L T button.
- If pushing NT R button, the selected content is deleted.
DElEtEPW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:53 페이지 15

PROGRAM TIM R
16 PW-6242B
<Delete Day/All>
- If pushing D LT button at the standby mode, SCH DUL / M MORY displays on display window and
the selected mode flashes.
- If pushing NT R button after selecting SCH DUL with UP/DOWN button, the day to delete flashes.
- Push UP/DOWN button or DAY button to select day or all deletion.
- If pushing NT R button after selecting the day to delete, all contents of selected day are deleted and if
pushing NT R button after selecting ALL, all contents are deleted.
2) M MORY Deletion
It is a function to delete the file saved to internal memory.
Provided that the files from TR-001 to TR-015 are fixed sound source files and cannot be deleted.
- If pushing D LT button at the standby mode, SCH DUL / M MORY displays on display window and
the selected mode flashes.
- If pushing NT R button after selecting M MORY with UP/DOWN button, it moves into the mode to set
D L T range.
* TRACK: Delete by selecting the track range.
* ALL: Delete the whole memory files.
- If pushing NT R button after selecting TRACK, the number of total melodies saved to internal memory is
displayed on display window and you can designate the area to delete.
- Input Start track no. by using digit button.
(As the files from TR-001 to TR-015 are sound source files which cannot be deleted, you cannot
designate them.)
- After pushing NT R or UP button, input nd track no.
- When modifying Start track no. again, use DOWN button to move.
- If pushing NT R button, D L T performs.
- If pushing NT R button after selecting ALL from the above delete range selection mode, all contents are
deleted.
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:53 페이지 16

PROGRAM TIM R
17
PW-6242B
10. AC OUT UT TIME CONTROL
It is a function used to export the output of AC OUTL T and R MOT OUTPUT in advance as much as the
set time before the scheduled broadcasts. If using this function, you can operate the device connected for
broadcasting in advance to use without delay in case of the output of the scheduled broadcasting.
1) In standby mode, if pushing AC OUTL T button longer, you can adjust AC output time.
2) Input AC power output time using digit button.
3) When pushing NT R button, it sets.
4) The setting can be made withing the range of 1~20 seconds and the default setting is 10 seconds.
11. TIME ERROR CALIBRATION
1) When pushing TIM button longer, the setting starts.
2) Input the setting value with digit button. You can set within the range of -12~+12 and be cautious that
calibration time may change depending on the change of surrounding temperature.
3) If pushing TIM button, you can change +/- before the number. (+) calibrates TIM faster and (-)
calibrates TIM slower. About 1.5 seconds will be calibrated on monthly average for each stage. For
example, if setting as +12, about 18 seconds (1.5 sec x 12 = 18) a month will be calibrated faster.
4) When pushing NT R button, SAV ends.
12. KEY LOCK
1) It is a function to protect the user’s setting and if pushing NT R button longer, K Y LOCK is displayed on
display window and all function buttons will not be operated.
2) If pushing NT R button longer again, K Y UNLOCK is displayed on display window and all function
buttons operate normally.
13. SETTING USING A LICATION ROGRAM
APPLICATION PROGRAM is a program to manage the setting and current schedule status of equipment in
case of installation and maintenance more efficiently. It enables the database setting by day and you can
save much time in setting the equipment with database auto creation function. In addition, it provides the
interface among equipment using GUI type clean display and RS-232 port.
(Download APPLICATION PROGRAM and manual at Inter-M website and use.)
tiMEaCoutlEtPW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:53 페이지 17

PROGRAM TIM R
18 PW-6242B
14. OTHERS
1) AC power output can be ON/OFF with AC OUTL T button. When intending to provide AC power output,
light on L D by pushing AC OUTL T button.
2) Under the status L D of OUTPUT button is OFF, even though M LODY plays, it doesn’t provide the output.
When intending to provide AC channel output, light on L D by pushing OUTPUT button.
※VOIC scheduled broadcasting output is always provided regardless of the status of OUTPUT button.
15. M 3 FILE DOWNLOAD AND DELETE FUNCTION USING C CONNECTING TERMINAL
It is a function to download or delete the file inside SD CARD from PC by connecting PC with PC connecting
terminal.
1) Sizes of all storage media memory are supported up to 32GB.
2) For the file system of storage device, only FAT 32 is supported. Format PC with FAT 32, then use.
3) Sub-folder structure is supported and refer to the below picture for default folder structure of file system.
4) When connecting PC with PC connecting terminal at front side of this device using USB cable, portable
disk is automatically recognized at PC. Then PC CONN CT D is displayed to display window of this
device and portable disk driver appears to PC.
5) When double clicking the portable disk at PC, you can verify the content of internal memory. There are
INT R-M folder and US R folder and another two folders are within INT R-M folder.
6) The files copied from USB memory are saved within MP3 COPY folder and they can be
uploaded/downloaded from/into PC or deleted directly.
※Caution
1) As 15 files within INT R-M folder are fixed sound source files responding to TRACK 1~TRACK 15, be
cautious not to delete. When they are deleted, output is not provided.
2) When downloading the file from PC to internal memory, if the play order is important, configure the
separate folder at PC in advance to save the necessary file. Give the number (0016~9999) before the
name of each saved file in the order and download the whole folder to internal memory. Otherwise, it
cannot be played in order of file name.
AC OUTLET
OUTPUT
aCoutlEt
AC OUTLET
OUTPUT
outPutPW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:53 페이지 18
