Introduction
This pocket guide provides basic information on installing the TruVision
IP dome and wedge dome open-standard cameras.
For detailed information on installing and using the cameras, please
refer to the user manual.
Package contents
The camera is shipped with the following items:
Camera
Hex wrench
Mounting plate (excluding wedge dome cameras)
Video cable for testing (excluding wedge dome cameras)
Multilingual quick start guide
CD with user manual in several languages
Installation environment
Refer to the user manual for detailed information, but observe these
important requirements:
• Place the camera in a secure location.
• Ensure that the camera is in a well-ventilated area.
• Do not expose the camera to rain or moisture.
Camera dimensions
See Figure (Dome and IR dome cameras) and Figure (Wedge
dome cameras).

Quick Start Guide 7 EN
Setting up the camera
Note: If the light source where the camera is installed experiences
rapid, wide variations in lighting, the camera may not operate as
intended.
For detailed instructions, please refer to the user manual.
To quickly put the camera into operation:
1. Prepare the mounting surface.
2. Connect the required cables to the camera.
3. Mount the camera to the ceiling using the appropriate fasteners.
4. Set up the camera’s network and streaming parameters so that the
camera can be controlled over the network.
5. Program the camera to suit its location.
Connecting the devices
Dome cameras:
See Figure (Connections on the base of the dome and IR dome
cameras).
1. Ground. Connect to ground.
2. Ethernet RJ45 PoE port. Connect to network devices.
3. Audio output. Connect to an audio output. Line level, 600 Ω.
4. Initial set. Press to hard reboot camera.
5. Audio input. Connect to an audio input. 2.0 to 2.4 Vp-p, 1 kΩ.
6. RS-485 D+, D-. Connect to an RS-485 device such as a PTZ dome
camera.
7. Alarm outputs. Connect 1A/1B and 2A/2B to alarm output devices.
8. Alarm inputs. Connect IN1/GND and IN2/GND to alarm input
devices.
9. Power supply. Connect +12 VDC power supply.

EN 8 Quick Start Guide
Wedge dome cameras:
See Figure (Wedge dome camera connections).
1. Power input connector. Connect +12 VDC power supply. Optional.
2. Ethernet RJ45 PoE connector. Connect to the network devices.
3. Lens.
4. Power LED.
5. Lens positioning screws.
6. Network status LEDs.
7. Reset switch. Click to reset all parameters to factory default.
Accessing the SDHC card
Insert an SDHC card up to 32GB for local storage in the dome
cameras (see Figure , item ). The card is not supplied with the
camera.
Video and log files stored on the SDHC card can only be accessed via
the Web browser. You cannot access the card using TruVision
Navigator or a recording device.
Note: There is no SDHC card slot in the wedge dome cameras.
Accessing the camera over the internet
Use the camera Web browser to access and configure the camera
over the internet. Only one camera is accessible from a single Web
browser window.
To access the camera online:
1. In the Web browser enter the camera’s IP address (default is
192.168.1.70). The Login dialog box appears.
Note: Ensure that the Active X controls are enabled.
2. Enter your user name and password.
User name: admin
Password: 1234

Quick Start Guide 9 EN
3. Click OK. The Web browser window appears in live mode. See
Figure .
Overview of the camera Web browser
See Figure (Camera Web browser interface).
Item Name Description
1. PTZ controls For future use.
2. Live view Click to view live video.
3. Playback Click to play back video.
4. Log Click to search for event logs. There
are four main information types: All,
Alarm, Notification and Operation
5. Configuration Click to display the configuration
screen for setting up the camera.
6. Viewer Click to view live or play back video.
7. Current user Displays current user logged on.
8. Exit Click to log out from the system.
9. Full screen Click to view as full screen.
10. Start/stop live view Click to start/stop live view.
11. Capture Click to take a snapshot of the video.
The snapshot will be saved to the
default folder in jpeg format.
12. Start/stop
recording
Click to record live video.
13. Video image
settings
Click to adjust video image settings
such as brightness, contrast,
saturation, hue and exposure time.
14. e-PTZ Click to enable/disable e-PTZ.
When enabled, scroll on the mouse
wheel to zoom in and out of an image
on-screen.

EN 10 Quick Start Guide
Item Name Description
15. Audio setting Click to start/stop bi-directional audio.
Note: You need to have a microphone
attached to your PC to be able to send
out audio.
16. Audio on/off Click to turn the audio function on or
off.
Network and streaming configuration
In the camera Web browser screen click the Configuration button on
the toolbar to display the configuration screen. See Figure 
(Configuration screen).
Refer to the User Manual for detailed information on configuring the
cameras. See Table 1 on page 10 for an overview of the configuration
parameters.
Note: The On-screen display (OSD) menus are in English only.
Table 1: Overview of the configuration parameters
Configuration folders Description
Local configuration Defines the network type, display mode and
local storage paths.
Basic information Defines the camera name and RS-485 bus
ID. This screen also displays the MAC
address, device type, device SN and the
current firmware version.
Channel parameters Defines the OSD properties of camera
information, recording parameters and
schedules, motion detection parameters,
image quality, alarm responses, and overlay
text.
Network parameters Defines the network parameters required to
access the camera over the internet.

Quick Start Guide 11 EN
Configuration folders Description
Serial settings Defines the RS-485 and RS-232
communication settings.
Alarm parameters Defines how the camera handles alarms
such as input type, notification of alarms,
and response schedules and duration.
Deployment time Defines the schedules during which events
are registered.
User management Defines who can use the camera, their
passwords and access privileges.
HDD management Defines how to format the SDHC card used
in the camera.
Remote upgrade Defines how to upgrade the camera’s
firmware.
Default Restores default settings.
Reboot device Reboots the camera.
Specifications
Dome and IR dome cameras:
Electrical
Power consumption 4.5 W max. TVD-N210V-2-N(-P),
TVD-M2210V-2-N(-P),
TVD-M2215V-2-N(-P),
TVD-M3210V-2-N(-P),
TVD-M3215V-2-N(-P)
5 W max. TVD-M5225V-4-N(-P)
5.5 W max. TVD-N245V-2-N(-P)
7.5 W max. TVD-M1210V-2-N(-P),
TVD-M1225V-2-N(-P),
Miscellaneous
Dimensions (D × H) 140 × 120 mm (5.5 x 4.7 in.)

EN 12 Quick Start Guide
Weight 1.3 kg (2.8 lbs)
Environmental rating Indoor vandal-resistant
Wedge dome cameras:
Electrical
Power consumption 4 W max.
Miscellaneous
Dimensions (L × W × H) 100 × 98 × 47 mm (3.94 ×3.84 ×1.83 in.)
Weight 0.5 kg (1.1 lbs.)
Environmental rating IP66 vandal-resistant
All cameras:
Electrical
Voltage input 12 VDC, PoE (IEEE 802.3af)
I/O connection DC jack flying lead, RJ45 flying lead
Network
Protocols TCP/IP, HTTP, DHCP, DNS, DDNS,
RTP/RTCP, PPPoE, SMTP, NTP
Ethernet/IP CoS 802.1 p/Q, QoS, IPv4
PoE IEEE 802.3af
Miscellaneous
Operating temperature -10°C to +60°C (14 to 140°F)
Storage temperature -20 to +70 °C (-4 to +158 °F)
PC requirements
Intel-based PC 1 GHz or faster
Memory 1 GB RAM
Operating system Windows® XP, Vista or Windows 7
CGI Direct X 9.0 or later
Browser Microsoft Internet Explorer 6.0 or later

Quick Start Guide 13 EN
