Intermec AN3 User manual

AN3 Communications Adapter Instructions
*943-135-002*
P/N 943-135-002
AN3
Communications Adapter Instructions
Removing the AN3
Press the release tabs and pull the AN3 off the AR4.
Electrical rating: x12V, 1.5A. For power supply, use only
Intermec Model 851-065-001 (P/N 851-065-005), or Model AE23
(P/N 851-065-105).
Where to Find More Information
www.intermec.com
In the U.S.A. and Canada, call 1.800.755.5505.
Worldwide Headquarters
6001 36th Avenue West
Everett, Washington 98203
U.S.A.
tel [phone]
fax [phone]
www.intermec.com
©2008 Intermec Technologies
Corporation. All rights reserved.

About the AN3 Communications Adapter
The AN3 provides Ethernet and USB connectivity to a 751G
Mobile Computer when the AR4 accessory is installed on the
computer.
The AN3 is powered by the computer. When the AN3 is
installed, you can also use an external power supply
(P/N 851-065-005 or 851-065-105) to operate and charge the
computer without removing the AN3.
AN3
Caution: See Compliance Insert for use restrictions
associated with this product.
Installing the AN3
Slide the AN3 onto the AR4 until the adapter snaps into place.
Connecting the AN3
When you connect the external power supply or turn on the
computer, the Power LED turns green. When you connect the
AN3 to a USB host such as a desktop PC, the USB LED turns
green.
Ethernet cable
to network
USB cable
to host
To power
supply
Power
LED
USB
LED
Note: The AR4 fingerprint imager and card readers
are disabled when the AN3 is installed.
