Use the Decoded Serial Adapter to turn the 26-pin serial port on the
CK30 and CK31 Handheld Computers into a DB9 (9-pin) male
serial connector that you can connect to a decoded scanner.
Installing the Serial Adapter
1Hook the serial adapter into the battery on the CK30 or CK31 and
then snap it into place.
Serial adapter
Battery
DB9 connector
2Connect a scanner to the DB9 connector on the serial adapter.
3Use Intermec Settings to configure the serial port. For help using
Intermec Settings, see your computer user’s manual.
Decoded Serial Adapter Instructions

Worldwide Headquarters
6001 36th AvenueWest
Everett, Washington 98203
U.S.A.
tel [phone]
fax [phone]
www.intermec.com
©
2006 Intermec Technologies
Corporation. All rights reserved.
Decoded Serial Adapter Instructions
*943-029-002*
P/N 943-029-002
DB9 Connector Pin Assignments
1 - Data carrier detect (DCD)
2- Receive data (RXD)
3- Transmit data (TXD)
4- Data terminal ready (DTR)
5- Ground
Data set ready (DSR) - 6
Request to send (RTS) - 7
Clear to send (CTS) - 8
5VDC- 9
This illustration shows the pin assignments for the DB9 male connector on the
serial adapter.
Specifications
Electrical rating: 5 VDC, 350 mA
Communications port: DB9 male, RS-232
Operating temperature: -20°C to 50°C (-4°F to 122°F)
Storage temperature: -20°C to 60°C (-4°F to 140°F)
Supported scanners: 1400, 1470B, 1551E, 1553E, 1555E,
1800 (Trigger mode only)
