Quick Start Guide
700 Color
Mobile Computer
Single Battery Pack
Charger (AC15)

2 700 Color Single Battery Pack Charger Quick Start Guide
The Model AC15, 700C Battery Charger is suitable
for use only with Intermec battery pack model #
318-013-004. Use of any other battery pack may
present risk of fire or explosion hazard.
French:
Le modèle de chargeur de batterie 700C peut être utilisé avec les
numéros de référence de bloc de batterie Intermec suivants,
318-013-004. L’utilisation de tout autre bloc de batterie pré-
senteunrisqued’incendieoud’explosion.
German:
Das Batterieladegerät Modell 700C ist nur zum Laden der Inter-
mec Batteriesätze mit den Teilenummern 318-013-004 geeig-
net. Bei Verwendung eines anderen Batteriesatzes besteht
Brand- oder Explosionsgefahr.
Spanish:
El Cargador de batería Modelo 700C debe ser utilizado solo con
los paquetes de batería Intermec N/P 318-013-004. El uso de
cualquier otro paquete de batería puede ocasionar riesgos de in-
cendiooexplosión.
Power Usage
Each charger power supply uses approximately 150 mA of cur-
rent when used in a 120 V outlet.
Instructions
Insert battery pack into charging compartment. A complete
charge takes up to four hours.
Charging status LED indicates:
Off = no wall power to charger.
Red = charging
Green = charge complete
Yellow = pack may not be installed in compartment prop-
erly, remove and reinstall.
packmaybebad.IfonchargerforfivehoursandLED
goes from solid red to yellow, the pack is bad, replace pack.

3
700 Color Single Battery Pack Charger Quick Start Guide
Charge status LED
Tilt battery pack and posi-
tion in battery pack
compartment
Push down to “click” into
place
Slip battery pack under lip
of charger
Battery Pack Must Go In As Illustrated
Charger jack
Power supply
Connect Power Supply to Charger and charge pack for four hours
