4420 and 4440 Cutter Installation Instruction Sheet
This instruction sheet explains how to install a cutter on a 4420 or 4440 printer. The
following procedures cover attaching the cutter to the printer and connecting the
cutter to the main printed circuit board (PCB). A qualified field service technician
must install the cutter.
Caution
Integrated circuits on printed circuit boards (PCBs) in this equipment are
sensitive to damage by electrostatic discharge (ESD). Prevent ESD by always
wearing skin contact ground straps firmly attached to the equipment metal
base assembly when working inside of the equipment housing. Failure to
comply may result in damage to PCB components.
To install the cutter
1. Turn off the printer.
2. Unplug the printer AC power cord from the back of the printer.
3. Pull the bottom of the media cover away from the base of the printer, lift the
front of the media cover upward to release it from the printer frame, and lift the
media cover away from the top of the printer.
44XXC.001
Feed/Pause
Power/Data
Alert
Empty/Pause
IntermecIntermec
4420

2
4. Remove the three Phillips screws that secure the PCB cover to the main deck and
the three Phillips screws that secure the PCB cover to the base of the printer.
Retain the screws to replace the PCB cover later.
Feed/Pause
Power/Data
Alert
Empty/Pause
IntermecIntermec
4420
44XXC.002
Screw
(typical
3 places)
Screw
(typical
3 places)
Base
of
cover
PCB
cover
PCB
cover
Main
deck
Base of
printer
PCB
cover
5. Pull the bottom of the PCB cover away from the base of the printer, slide the top
of the PCB cover away from the main deck, and lift the PCB cover away from the
printer.
6. Remove the eight Phillips screws that secure the front cover to the printer.
Feed/Pause
Power/Data
Alert
Empty/Pause
Intermec
4420
44XXC.003
Front
cover
Media
access
door
Screw
(8 places)

3
7. Holding onto the media access door, pull the front cover and media access door
forward and away from the printer.
8. Using the eight Phillips screws, replace the front cover without the media access
door.
9. If the printer has a metal filler plate attached with screws, remove the two
Phillips screws on the metal filler plate in the main deck and remove the metal
filler plate.
44XXC.005
Main
deck
Metal
filler
plate
If the printer has a plastic filler plate attached with adhesive, peel off the plastic
filler plate.
44XXC.004
Main
deck
Plastic
filler
plate

4
10. With the screw extrusions toward the cutter connector, hook the bottom of the
cutter connector onto the hole in the connector plate, press down on the clip on
top of the cutter connector, and press the connector plate onto the cutter
connector.
Connector
plate
Cutter
connector
44XXC.007
11. Using a Phillips screwdriver and two screws, attach the connector plate to the
main deck on the lower right of the PCB side. The screws attach from the media
side.
44XXC.006
J23
Cutter
Main
deck
Connector
plate
Adapter
cable

5
12. Making sure that pin 1 is plugged on the adapter cable and cut on J23, plug the
adapter cable into J23 on the main PCB. If the self-strip motor is installed, make
sure the adapter cable is not resting against the motor.
J23
Cutter
Pin 1
Connector
plate
44XXC.009
Adapter
cable
Caution
Do not plug the adapter cable into the self-strip connector. The change in
voltage from the self-strip circuit to the cutter circuit will destroy the main
PCB.
13. Reinstall the PCB cover using the six Phillips screws.
14. Orient the mounting plate so that the notch is down and the two thumbscrews at
the top of the plate cover the holes on the front of the printer.
15. Use the top two thumbscrews to attach the mounting plate to the printer.

6
Attaching the Mounting Plate
Feed/Pause
Power/Data
Alert
Empty/Pause
Intermec
44XXC.011
Notch
Mounting
plate
Thumbscrew
16. Use the bottom two thumbscrews to attach the cutter to the mounting plate.
Make sure the cutter cable goes through the notch in the mounting plate.
Feed/Pause
Power/Data
Alert
Empty/Pause
Intermec
4420
44XXC.012
Front of
cutter
Cutter
connector
Cutter
cable
Front of
cutter
Mounting
plate
Thumbscrew
Notch

7
17. Plug the cutter cable into the cutter connector at the base of the main deck.
18. Using a straight-slot screwdriver, loosen the screw on the top of the cutter and
swing the cutter cover down.
Feed/Pause
Power/Data
Alert
Empty/Pause
IntermecIntermec
4420
Cutter
cover
44XXC.013
19. Check that the safety tab on the cutter cover connects with the disable switch on
the cutter. When you close the cutter cover, you will hear a click if the safety tab
and disable switch connect.
44XXC.014
Safety tab
Disable
switch

8
20. Swing the cutter cover up and tighten the screw on the top of the cover.
21. Feed the media through the cutter. The media should extend past the opening in
the cutter cover.
22. Reinstall the media cover.
23. Plug in the AC power cord.
24. Turn on the printer.
