Interroll RollerDrive EC200 User manual

User Manual
Interroll RollerDrive
EC200

Version 1.0 (11/2007) en
Original language
Manufacturer
Interroll Corporation
3000 Corporate Drive
USA-Wilmington, NC 28405
Tel. [phone]
Fax. [phone]
www.interroll.com
Copyright
The copyright of this manual remains with Interroll Corporation. This manual
includes regulations and technical drawings which may not be copied or
duplicated either whole or in part. Unauthorized use, publication or application
of this document is prohibited.

1
Version 1.0 (11/2007) en
Original language
RollerDrive EC200
Table of contents
Table of contents
Introduction
Handling of the user manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warning notices in this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Further symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety
General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Unintended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Qualified persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Risks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product information
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
RollerDrive label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Product identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Performance data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Performance charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
DriveControls for the RollerDrive EC200 . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Motor plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Speed settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
RL definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Dimensions of the motor shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Dimensions of idler cartridges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Groove locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Conical RollerDrives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Transport and storage
Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Assembly
Warning notices concerning assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Warning notices concerning the electrical installation. . . . . . . . . . . . . . . . 19
Setting up a roller conveyor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Inserting the RollerDrive EC200 in the conveyor frame . . . . . . . . . . . . . . . 20
Mounting tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Initial startup and operation
Initial startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Procedure in case of accident or malfunction . . . . . . . . . . . . . . . . . . . . . . 24
Maintenance and cleaning
Warning notices concerning maintenance and cleaning . . . . . . . . . . . . . . 25
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Troubleshooting
Error search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Abandonment and disposal
Abandonment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Appendix
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Manufacturer's declaration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

2Version 1.0 (11/2007) en
Original language
Introduction
RollerDrive EC200
Introduction
Handling of the user manual
Content of the manual This manual contains important advice, notes and information about the
RollerDrive EC200 in all phases of its lifecycle:
• Transport, assembly and commissioning
• Safe operation, maintenance and troubleshooting, disposal
• Accessories
Validity of the manual The manual describes the RollerDrive EC200 as it is delivered by Interroll.
Special application designs require validation from Interroll and additional
technical instructions.
The manual is part of the
product
¾For trouble-free, safe operation and warranty claims, read the manual and
follow the instructions before handling the RollerDrive EC200.
¾Keep the manual near to the RollerDrive EC200.
¾Pass the manual on to any subsequent operator or occupant of the
RollerDrive EC200.
¾Interroll does not accept any liability for malfunctions or defects due to non-
observance of this manual.
¾If you have any questions after reading the user manual, feel free to contact
our customer service. See the last page for contact information.
Warning notices in this manual
The warning notices in this document refer to risks which may arise during
usage of the RollerDrive EC200. For relevant warning notices, see "Safety",
page 4 and the warning notices at the beginning of each chapter.
There are three categories of danger. The following signal words are used in the
document as required:
•Danger
• Warning
•Caution
Structure of warning notices
Signal word Meaning
Danger Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Warning Indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
Caution Indicates a hazardous situation which, if not
avoided, may result in minor or moderate injury.
Nature and source of the hazard
Possible consequence of non-observance
¾Information about how to avoid the hazard.
DANGER

3
Version 1.0 (11/2007) en
Original language
RollerDrive EC200
Introduction
Further symbols
¾This symbol marks the steps that have to be carried out.
This symbol identifies possible material damage.
¾Information about how to avoid the damage.
Important
This symbol displays safety instructions.
Hint
This symbol marks useful and important information.

4Version 1.0 (11/2007) en
Original language
Safety
RollerDrive EC200
Safety
General safety instructions
The RollerDrive EC200 is designed according to the technical state of the art
and is reliable in operation, once distributed. However, risks may still arise.
• Risks of physical injury to the user or bystanders.
• Adverse effects of the RollerDrive and other material.
¾Always read the entire operating and safety instructions before starting to
work with the RollerDrive and follow the information contained therein in full.
¾Only instructed and qualified persons may work with the RollerDrive.
¾Always keep the user manual at hand when working at the RollerDrive so you
can consult it quickly if required.
¾Always comply with relevant national safety regulations.
¾If you have any questions after reading the operation manual, feel free to
contact our customer service. See the last page for contact information.
Intended use
The RollerDrive EC200 may only be used for industrial applications and in an
industrial environment to convey goods such as parts, cartons, totes or boxes. It
must be integrated in a conveyor module or a conveying system. Any other use
is considered inappropriate.
Use of the RollerDrive EC200 is only allowed in the areas described under
product information.
Any changes that affect the safety of the product are not allowed.
The RollerDrive EC200 may only be used within the given operation limits.
Unintended use
The RollerDrive EC200 may not be used to transport persons, bulk cargo or
small parts.
The RollerDrive is not intended for use under impact or shock loads.
Applications not according to the intended use of the RollerDrive EC200 require
approval from Interroll.
Qualified persons
Qualified persons are persons who read and understand the manual and, taking
national regulations into account, can competently execute incidental work.
Only instructed and qualified persons may work with the RollerDrive, taking the
following into account:
• the relevant manuals and diagrams,
• the warning and safety instructions in this manual,
• the system specific regulations and requirements,
• national or local regulations and requirements for safety and accident
prevention.
Important
Disregarding the warning notices in this manual may lead to serious injury.

5
Version 1.0 (11/2007) en
Original language
RollerDrive EC200
Safety
Risks
Persons ¾Maintenance or repair work must only be executed by authorized and
qualified persons in accordance with the applicable regulations.
¾Before turning on the RollerDrive, ensure that no unauthorized persons are
near the conveyor.
Electricity ¾Only perform installation and maintenance work after you have switched off
the power. Ensure that the RollerDrive cannot be turned on accidentally.
Rotating parts ¾Keep fingers and hair away from the torque transmission between rollers.
¾Tie up long hair.
¾Do not wear loose clothing.
¾Remove jewellery such as bracelets or wristbands.
Working environment ¾Do not use the RollerDrive in explosive atmospheres.
¾Remove equipment or material which is not required from the workspace.
¾Always wear safety shoes.
¾Clearly specify and monitor the way goods are placed on the conveyor.
Avoiding malfunctions in
operation
¾Regularly check the RollerDrive for visible damage.
¾In case of fumes, unusual noise or blocked or damaged goods, stop the
RollerDrive at once and ensure that the RollerDrive cannot be started
accidentally.
¾Contact qualified personnel immediately to find the source the malfunction.
¾Do not step on the RollerDrive during operation.
Maintenance ¾As the product is maintenance free, you only need to check regularly for
visible damages, unusual noise and that the screws and nuts are still
tightened.
¾Do not open the RollerDrive.
Accidental motor starts ¾Use caution while installing or maintaining the RollerDrive, or while it is under
error conditions, since it may start accidently.
Interfaces
By assembling the RollerDrive in a conveyor module, potential hazards may
occur. These are not part of this manual and have to be analyzed during the
design, installation and startup of the conveyor module.
¾After assembling the RollerDrive in a conveyor module, check the whole
system for a new potential dangerous spot before turning on the conveyor.
Important
The following list informs you about the various types of danger or damage that
may occur while working with the RollerDrive EC200.

6Version 1.0 (11/2007) en
Original language
Product information
RollerDrive EC200
Product inf ormation
Components
Product description
The RollerDrive EC200, a completely self-contained electronically powered
roller, replaces external components such as motors and gearboxes that require
frequent maintenance.
The RollerDrive EC200 can be used in dusty and/or moist environments due to
its protection class IP54 or IP66.
The RollerDrive EC200 is powered by a brushless electronically commutated
24 VDC motor with an integrated 4 quadrant motor control. This control system
guarantees a constant speed over the whole load range and a constant torque
over all selectable speed settings.
1Motor plug with cable
2Motor cartridge shaft
3Fixed bearing housing assembly
4Motor
5Idler cartridge shaft
6Idler bearing housing assembly
7Tube
8Non-slip drive
9Gearbox

7
Version 1.0 (11/2007) en
Original language
RollerDrive EC200
Product information
Overload protection devices There are several overload protection devices installed:
•Stall timing device: If the RollerDrive EC200 is stalled while there is a run
command, the motor tries to restart ten times each three seconds for one
second. If stall continues after these ten attemps, a failure signal is set and
the RollerDrive tries to restart with a 60:1 cycle (restart for one second every
60 seconds) until the stall is removed. The RollerDrive will not be damaged by
operating in a stall time device mode for long periods of time. If the
RollerDrive is running at chosen speed again, or the run command is
withdrawn, the failure signal will be cancelled.
•Slow run: If there is a speed deviation of +/- 20% from the chosen value for
more than 10 seconds, the motor will be switched off and the failure signal
will be set. The RollerDrive EC200 will try to start again after 60 seconds. If
the RollerDrive is running at chosen speed again or the run command is
withdrawn, the failure signal will be cancelled.
•Temperature monitor: The motor and electronic assemblies are temperature
controlled. If the temperature is too high, the incline of the accelerating
ramps will be reduced and the motor will go back to nominal current. This
reduces the heat in the motor.
If suitably applied, the roller can be installed in the conveyor with the required
controls and then left alone for the life of the product.
RollerDrive label
The specifications on the RollerDrive label are used to identify the RollerDrive.
This is required to use the RollerDrive EC200 as intended.
Type plate
1Type of RollerDrive
2Gear ratio
3Nominal voltage
4Manufacturer
5Date of production
6Speedrange
7Product name
24 VDC
EC200 36:1
0.33 - 0.05 m/s
10.07
R
O
L
L
E
R
D
R
I
V
E

8Version 1.0 (11/2007) en
Original language
Product information
RollerDrive EC200
Product identification
To identify a RollerDrive, the following information is required. You may enter the
values of your RollerDrive in the last column.
Technical data
Information Possible value Own value
RollerDrive label Motor type
Gear ratio
RollerDrive EC200
Tube diameter 50 mm or 1.9 in
Tube material Zinc-plated, galvanized,
aluminum or stainless steel (with
or without sleeves)
Roller length RLUS or RLEU (see "RL
definition", page 13)
Roller transmission see "Groove locations", page 15
Idler shaft Spring-loaded or floating
(see "Dimensions of idler
cartridges", page 14)
Nominal voltage 24 VDC
Voltage range 18 to 28 VDC
No load current 0.4 A
Maximum continuous current 2.1 A
Maximum peak current 5.5 A
Mechanical performance 25 W
System efficiency (drive) 49 %
Maximum ripple from power supply 3 %
Noise emission (mounted) 55 dB(A)
Lifetime under nominal conditions 15000 h
Maximum start/stop per minute 30
Protection classification IP54 (IP66)
Ambient temperature for operation 0 °C to 40 °C (32 °F to 104 °F)
Ambient temperature for transport and
storage
-20°Cto75°C(-4°Fto167°F)
Ambient temperature changes max. 1 °K/min; 3 h; two cycles
according to IEC 68-2-14
Ambient humidity max. 90% not condensing
Installation altitude above sea level max. 1000 m (max. 3300 ft)
Hint
• UL approval is not required for RollerDrive products as they operate under a
recommended maximum voltage of 30 VDC. The RollerDrive EC200 is
recognized as an UL Class II product.
• Mechanical performance, performance data and performance charts are on
basis of 20 °C (68 °F).

9
Version 1.0 (11/2007) en
Original language
RollerDrive EC200
Product information
Performance data
Performance charts
Gear ratio 12:1 16:1 36:1 48:1 64:1
Nominal torque 0.7 Nm
(6.2 in-lbf)
0.9 Nm
(8.0 in-lbf)
1.7 Nm
(15.0 in-lbf)
2.3 Nm
(20.4 in-lbf)
3.6 Nm
(31.9 in-lbf)
Peak torque 1.2 Nm
(10.6 in-lbf)
1.8 Nm
(15.9 in-lbf)
3.6 Nm
(31.9 in-lbf)
5.4 Nm
(47.8 in-lbf)
8.0 Nm
(70.8 in-lbf)
Speed range 0.98 to 0.14 m/s
(192.7 to
28.1 fpm)
0.74 to 0.11 m/s
(144.5 to
21.1 fpm)
0.33 to 0.05 m/s
(64.2 to 9.4 fpm)
0.25 to 0.04 m/s
(48.2 to 7.0 fpm)
0.18 to 0.03 m/s
(36.1 to 5.3 fpm)
Nominal load 1) 25 kg
(55 lb)
45 kg
(99 lb)
100 kg
(220 lb)
140 kg
(309 lb)
220 kg
(485 lb)
1) Maximum static load per Roller not more than 40 kg (88 lb). Data refer to continuous operation under maximum
load (S1-operation).



















6SHHG
YV7RUTXH
&XUUHQW
YV7RUTXH




7RUTXHLQOE
7RUTXH1P
7DQJHQWLDO
IRUFH)7OEI
7DQJHQWLDO
IRUFH)71
V
PG
H
H
S
6yyyyyy
P
S
I


GHHS6

yyy
y
yy
$WQHUUX&VX%yyyy
(&
0D[LPXP
FRQWLQXRXV
FXUUHQW
$UHDRI
FRQWLQXRXV
RSHUDWLRQ





















6SHHG
YV7RUTXH
&XUUHQW
YV7RUTXH




7RUTXHLQOE
7RUTXH1P
VPGHHS6yyyyyy
PSIGHHS6yyyyyy

$
W
QHU
U
X&VX%

y
y
yy
(&
0D[LPXP
FRQWLQXRXV
FXUUHQW
$UHDRI
FRQWLQXRXV
RSHUDWLRQ
7DQJHQWLDO
IRUFH)7OEI
7DQJHQWLDO
IRUFH)71





















6SHHG
YV7RUTXH
&XUUHQW
YV7RUTXH




7RUTXHLQOE
7RUTXH1P
VPGHHS6yyyyyy
PSIGHHS6yyyyyy

$
W
QHUUX&V
X%

y
yy
y
(&
0D[LPXP
FRQWLQXRXV
FXUUHQW
$UHDRI
FRQWLQXRXV
RSHUDWLRQ
7DQJHQWLDO
IRUFH)7OEI
7DQJHQWLDO
IRUFH)71



















6SHHG
YV7RUTXH
&XUUHQW
YV7RUTXH




7RUTXHLQOE
7RUTXH1P
VPGHHS6yyyyyy
PSIGHHS6yyyyyy

$
W
QHUUX
&
V
X%

y
yy
y
(&
0D[LPXP
FRQWLQXRXV
FXUUHQW
$UHDRI
FRQWLQXRXV
RSHUDWLRQ
7DQJHQWLDO
IRUFH)7OEI
7DQJHQWLDO
IRUFH)71

10 Version 1.0 (11/2007) en
Original language
Product information
RollerDrive EC200
DriveControls for the RollerDrive EC200
Interroll recommends using the RollerDrive EC200 in combination with the
Interroll DriveControls DC-EC200/EC300 (13:1) or Z-Card EC.



















6SHHG
YV7RUTXH
&XUUHQW
YV7RUTXH




7RUTXHLQOE
7RUTXH1P
VPGHHS6yyyyyy
PSIGHHS6yyyyyy
$

WQHU
U
X&VX%yyyy
(&
0D[LPXP
FRQWLQXRXV
FXUUHQW
$UHDRI
FRQWLQXRXV
RSHUDWLRQ
7DQJHQWLDO
IRUFH)7OEI
7DQJHQWLDO
IRUFH)71
Hint
For DriveControl details, see the corresponding operation manual, catalogs or
publications on www.interroll.com.

11
Version 1.0 (11/2007) en
Original language
RollerDrive EC200
Product information
Motor plug
Pin Color Function Value
1 brown Power input from
power supply (+)
Nominal: 24 VDC
Range: 18 to 28 VDC
2 white Rotation direction,
seen from cable end
of the RollerDrive
Low U < 0.8 V = ccw
High U > 2.4 V = cw
3 blue Ground for power
and signal (-)
Ground
4 black Failure output Low = no failure
High = failure
5 gray Speed/start signal
analog
Range: 0 to 24 VDC
Stop (brake): 0 to 2 VDC
Speed: 2.4 VDC to 5 VDC
(Incline ratio: 1 V ~ 114.6 revs/min / gear
ratio)
Max. speed: 5 VDC to 24 VDC
(also see "Speed settings", page 12)
Hint
In case the RollerDrive is not directly connected to the refering DriveControl or
the Interroll extension cable, connect the motor plug by use of a Lumberg Fixcon
Coupling 5-FKT.
Pins 1 and 3 are not protected against incorrect
polarity connection.
Damage to the motor.
¾Ensure the correct polarity.

12 Version 1.0 (11/2007) en
Original language
Product information
RollerDrive EC200
Speed settings
If you do not use the recommended DriveControl (see "DriveControls for the
RollerDrive EC200", page 10), you may change the speed of the RollerDrive
EC200 by altering the voltage on pin 5 of the motor plug.
Input voltage of Pin 5 at motor plug is not polarity-
proof
Damage to the RollerDrive
¾Ensure the correct polarity.
$QDORJYROWDJHVHWWLQJRQSLQRIPRWRUSOXJ>9'&@

6SHHG3HUFHQWDJH>@










Hint
In the hatched area the RollerDrive does not run within the specified tolerance of
±5%.
Rotary switch
speed setting at
DriveControl
Voltage setting
on pin 5
[VDC]
Speed of transport [m/s (ft/min)] ± 5 %
Gear ratio
12:1
Gear ratio
16:1
Gear ratio
36:1
Gear ratio
48:1
Gear ratio
64:1
0/8 5 to 24 0.98 (192.7) 0.74 (145.6) 0.33 (64.2) 0.25 (49.2) 0.18 (36.1)
1/9 0.98 (192.7) 0.74 (145.6) 0.33 (64.2) 0.25 (49.2) 0.18 (36.1)
2/A 4 0.75 (147.2) 0.56 (110.4) 0.25 (49.1) 0.19 (36.8) 0.14 (27.6)
3/B 3.75 0.56 (110.4) 0.42 (82.8) 0.19 (36.8) 0.14 (27.6) 0.11 (20.7)
4/C 3.30 0.41 (80.1) 0.31 (60.1) 0.14 (26.7) 0.10 (20.0) 0.08 (15.0)
5/D 2.93 0.30 (58.5) 0.22 (43.8) 0.10 (19.5) 0.07 (14.6) 0.06 (11.0)
6/E 2.68 0.21 (41.1) 0.16 (30.9) 0.07 (13.7) 0.05 (10.3) 0.04 (7.7)
7/F 2.44 0.14 (28.1) 0.11 (21.1) 0.05 (9.4) 0.04 (7.0) 0.03 (5.3)

13
Version 1.0 (11/2007) en
Original language
RollerDrive EC200
Product information
RL definition
There are two definitions of the roller length RL:
•RL
EU is mainly used in Europe and Asia
•RL
US is mainly used in North and South America
Spring loaded 11 mm
(0.44 in) hex
Female threaded M8 (FTM8),
floating
Dimensions of the motor shaft
Standard configuration
IP66 configuration
RLEU
RLUS
RL
EU
RL
US
5/(8
5/86
+H[VKDIW$)PPLQ
PPLQ
PPLQ
PP
LQ
0[PP
PPLQ
5/(8
5/86
+H[VKDIW$)PPLQ
PPLQ
PPLQ
PP
LQ
0[PP
PPLQ

14 Version 1.0 (11/2007) en
Original language
Product information
RollerDrive EC200
Dimensions of idler cartridges
11 mm (0.44 in) hex,
spring-loaded
Female threaded M8 (FTM8),
floating
Straight
O-ring hub
Multi-rib hub
Timing belt hub Poly-Chain GT; 8 mm pitch; 18 teeth
RLEU
RLUS
5 mm (0.2 in)
15.5 mm (0.61 in)
5/(8
5/86
PPLQ
$)PPLQ
PPLQ
ÛPPLQ
5/(8
5/86
PPLQ
PPLQ
m
PPLQ PPLQ
PPLQ
5/(8
5/86
PPLQ
PPLQ PPLQ
$)PPLQ
ÛPPLQ
4 mm (0.16 in)
31 mm (1.22 in)
RLEU
RLUS
11 mm (0.44 in)
ø43 mm (1.7 in)
PPLQ
PPLQ
5/(8
5/86
ÛPPLQ
$)PPLQ
PPLQ
5/(8
5/86
PPLQ
PPLQ
ÛPPLQ
$)PPLQKH[

15
Version 1.0 (11/2007) en
Original language
RollerDrive EC200
Product information
Groove locations
FTM8, floating,
single bearing
Spring-loaded hex,
double bearing
Roller chain hub 11 mm (0.44 in) hex shaft; 3/8 in pitch;
20 teeth
11 mm (0.44 in) hex,
spring-loaded
Female threaded M8 (FTM8),
floating
9.5 mm (0.37 in)
16.8 mm (0.66 in)
35 mm (1.38 in)
RLEU
RLUS
ø60.9 mm (2.4 in)
PLQPPLQ
PLQPPLQ
IRUWXEHGLDPHWHUPP
IRUWXEHGLDPHWHULQ
PLQPPLQ PLQPPLQ
ÛPPLQ
ÛPPLQ
PLQPPLQ
IRUWXEHGLDPHWHUPP
IRUWXEHGLDPHWHULQ
PLQPPLQ
PLQPPLQ
PLQPPLQ
m
ÛPPLQ
ÛPPLQ
Hint
Other tube groove locations possible.

16 Version 1.0 (11/2007) en
Original language
Product information
RollerDrive EC200
Conical RollerDrives
Conical RollerDrives are only available in three versions:
• Without roll-to-roll transmission (no grooves)
• With grooved tubes [RLEU = B/F - 11 mm (0.44 in) / RLUS = B/F - 3 mm
(0.12 in)]
• With O-ring hub [RLEU = B/F - 37 mm (1.46 in) / RLUS = B/F - 3 mm (0.12 in)]
B/F: Width between the conveyor frames
Due to the conical sleeves they are only available in certain standard lengths.
For conical RollerDrives there must be a 1.8° angle compensation on the motor
end to avoid bending forces on the RollerDrive.
Hint
For details contact Interroll, see the catalogs or refer to publications at
www.interroll.com.

17
Version 1.0 (11/2007) en
Original language
RollerDrive EC200
Transport and storage
Transport and storage
Transport
• Each RollerDrive is covered at its ends with end-protectors.
¾Do not stack pallets.
¾Check the fixation of the RollerDrives before transport.
¾Avoid hard shocks during transport.
¾Check each RollerDrive visually for damage after transport.
¾In case of damage, take photos of the damaged parts.
¾To maintain the warranty, report any damage caused by transport instantly to
the transport company and Interroll.
¾Do not transfer the RollerDrives between warm and cold environments. This
may cause condensing water.
Storage
¾Check each RollerDrive for damage after storage.
Risk of injury due to improper transport
¾Transport may only be carried out by qualified and
authorized persons.
¾Observe the following notices.
CAUTION
Risk of injury due to improper storage
¾Do not stack pallets.
¾Do not stack more than four carton boxes.
CAUTION
Hint
With IP66 RollerDrives, due to the sealing, condensing water inside the
RollerDrive may cause corrosion.

18 Version 1.0 (11/2007) en
Original language
Assembly
RollerDrive EC200
Assembly
Warning notices concerning assembly
¾Do not drop or mishandle the RollerDrive to avoid internal damage.
¾Check each RollerDrive visually for damage before assembly.
¾Do not hold, carry, or support the RollerDrive by the wires extending out of
the mounting shaft to avoid damage to the internal solder joints.
¾Do not force the RollerDrive when inserting it into the conveyor frame. It
should fit easily into the holes in the frame.
¾Ensure that the proper torque (see assembly instructions) is applied to the
RollerDrive hex nut to prevent the shaft spinning in the frame and the wires
twisting.
¾Do not twist the motor cable.
Rotating parts and accidental motor starts
Risk of pinched fingers
¾Do not insert fingers between the RollerDrive and the
O-ring belt, multi-rib belt or roller chain.
¾Install a protection device (such as a guard plate) to
prevent fingers from getting trapped in the O-ring belt,
multi-rib belt or roller chain.
¾Install an appropriate warning on the conveyor.
Risk of damage leading to failure or shortened life
expectancy of the RollerDrive
¾Observe the following notices.
CAUTION
