Rhymebus RM6E1 Series User manual

VARIABLE FREQUENCY
DRIVE
Operation Manual
RM6E1 series

Quality․Satisfaction․Improvement․Innovation
http://www.rhymebus.com.tw
2015.05.05 Revised

Thank you for using RHYMEBUS RM6E1 series drive. For proper operations and
safety purposes, please do read and follow specific instructions contained in this
manual before using the product. The manual shall be placed on the top of the
machine, and all the setup parameters and reference numbers must be properly
recorded inAttachment 1 to facilitate future maintenance and repairs.
PREFACE

i
Please read this manual thoroughly and pay attention to the safety precautions
marked with ― DANGER ‖ or ― CAUTION ‖ before the installation, wiring,
maintenance, or troubleshooting.
Only the qualified personnel may proceed with the installation, wiring, testing,
troubleshooting, or other tasks.
※Qualified Personnel: Must be familiar with the fundamentals, structures,
characteristics, operating procedures, and installation, and this personnel must
read the manual in details and follow the steps of security measures to prevent
possible dangers.
DANGER
User may cause the casualty or serious damages if user
does not abide by the instructions of the manual to execute
the tasks.
CAUTION
User may cause injuries to the people or damage the
equipment if user does not abide by the instructions of the
manual to execute the tasks.
※Although the ― ‖ mark may indicate minor damages, serious damages or
injuries may be possibly incurred if the caution is not under user’s attention.
Installation
CAUTION
a. The installation shall take place only on top of the metal surface or any material
with the fire resistant.Any place or location of high temperature, moist, oil and
gas, cotton fiber, metal powder and erosive gas shall be avoided.
b. If the product specification indicates IP00 (the protective level of the equipment
structure), any human contact is forbidden at the installation location to avoid the
electric shock. The option of installingAC reactor(ACL) shall be very cautious.
c. Please note the surrounding temperature shall not exceed 50°C when the
installation needs to be placed inside the control panel.
d. For the environment of storage and installation, please follow the instructions of
the environmental conditions illustrated in the sections of the common
specification of RM6E1.
SAFETY PRECAUTION

ii
Wiring
DANGER
a. Do Not conduct any wiring during the system power ON to avoid the electric shock.
b. R/L1,S/L2,T/L3 are power inputs (electric source terminals) and U/T1,V/T2,W/T3
are drive’s outputs to a motor. Please Do Not connect these input and output
terminals to terminals P⊕, N○
－, and PR.
c. Once the wiring is complete, the cover of the drive must be put back and must
seal the drive to avoid other’s accidental contact.
d. The drives have three specifications base on the input power source 100V / 200V
/ 400V, Do Not input the voltage exceed the specifications.
e. The grounding terminal( ) must be exactly grounded. Ground the drive in
compliance with the NEC standard or local electrical code.
f. Please refer to the manual page 16 and 17 for the screwing torque of the wiring
terminal.
g. Please refer to the national or local electric code for the appropriate spec of the
cords and wires.
h. Please install an appropriate Molded Case Circuit Breaker (MCCB) or Fuse at
each path of power lines to a drive.
i. Please install the thermal relay between the individual motor and the drive when
using one drive to propel several motors.
j. Do Not connect power factor leading capacitor, surge absorber, or
non-three-phase motor to the drive’s U/T1, V/T2, or W/T3 side.
k. AC reactor(ACL) installation is required when the power capacity exceeds
500kVA or 10 times or more than the drive rated capacity.
l. Do Not touch the drive or performing any unwiring actions before drive indicator
light turns off after the power off. Use a multi-meter with the DC voltage stage to
measure the cross voltage between P⊕and N○
－terminals (The voltage must
be less than 25V).
m. When the motor do the voltage-proof, insulation testing, unwiring the
U/T1,V/T2,W/T3 terminal of drive at first.
CAUTION
a. The RM6E1 series outputs are designed to drive a three-phase induction motor.
Do Not use for single-phase motor or using for other purposes.
b. The main circuit and control circuit must be wired separately; control circuit must
use a shielded or twisted-pair shielded wires to avoid possible interferences.

iii
Operation
DANGER
a. Do Not open or remove the cover while power is on or during the drive operation.
Do close up the cover before powering on the drive. Do Not remove the cover
except for wiring or periodic inspection when power off.
b. At the function F3.30= 1 or 3, the drive will automatically restart when the power
is restored. Stay away from the motor and machine.
c. At the function F1.05=0 and F1.00=0 or 1 or 10, the
STOP
RESET
key on the operation
panel is ineffective. Please use an emergency stop switch separately for safe
operations.
d. The drive can produce high frequency outputs. Before adjusting the frequency,
please check the specs of motor carefully to prevent the motor from unexpected
damages.
e. If any of the protective functions have been activated, and the start command is
set to terminal control(F1.00=0 or 1 or 10), first remove the case and check the
all run commands set to OFF. Then press the
STOP
RESET
key to release the alarm.
CAUTION
a. Do Not touch the heat sink or brake resistors due to the high heat.

iv
Features
a.
With the temperature management and fan control functions
to increase the lifetime of cooling fan and saving the energy.
a. User can monitor the temperature of drive and setting the pre-alarm level to forecast the
maintenance cycle of cooling fan.
b. Fan will be standby under idle speed, light-duty load or low surrounding temperature
conditions.
c.
b.
Special function key(SPEC):
Programmable function key for forward/reverse running, jog speed,
selection of primary/secondary frequency command…etc.
c.
Allow RS-485 communication interface control (Modbus RTU
communication protocol).
d.
6 sets of fault records:
Record 4 types of information under fault condition, respectively. (fault
code, output current, DC bus voltage, output frequency)
e.
Built-in dynamic braking unit(DBU); braking level and control function are
adjustable.
f.
Running hours and supply power time of drive can be saved and
displayed.
g.
Group design for the functions ease the function setting and
management.
h.
Sequential operation control and PID control function.
i.
Provide 8 sets of monitor displays(three of displays can be defined as
another extra displays).
j.
Provide PTC sensor setting functions for preventing the motor from
overheating.
k.
Energy-saving selection for light-duty load.
l.
Auto-torque boost function.
m.
Provide 16 preset speeds control.
n.
The analog input signal of filter can be adjusted.
o.
The response time of digital input signal is adjustable(adjustable dead
band detection).
p.
Independent adjustment selection of V, F for analog input signal.
q.
Two sets of motor overload protection function.
r.
Programmable input and output terminals and two modes selection
(SINK/SOURCE) for input signal.
s.
User can connect KP-601 keypad(option) for remote control, parameters
duplication and saving.
t.
The switching frequency can be adjust between 800Hz ~ 16kHz.
INTRODUCTIONS

v
CHAPTER 1CAUTIONS BEFORE INSTALLATION --------------------------- 1
1-1 PRODUCT VERIFICATION-----------------------------------------------------------------1
1-1-1 Confirmation of Appearance--------------------------------------------------------1
1-1-2 The description of nomenclature --------------------------------------------------1
1-1-3 Confirmation of Accessories--------------------------------------------------------2
1-2 STANDARD SPECIFICATIONS -----------------------------------------------------------2
1-2-1 Single-Phase 100V Series ----------------------------------------------------------2
1-2-2 Single-Phase 200V Series ----------------------------------------------------------3
1-2-3 Three-Phase 200V Series-----------------------------------------------------------3
1-2-4 Three-Phase 400V Series-----------------------------------------------------------4
1-3 COMMON SPECIFICATIONS--------------------------------------------------------------6
1-3-1 The Features of Control and Operation------------------------------------------6
1-4 THE DISASSEMBLED SKETCH OF RM6E1------------------------------------------8
CHAPTER 2INSTALLATION AND CONFIRMATION--------------------------10
2-1 BASIC EQUIPMENT------------------------------------------------------------------------10
2-2 ENVIRONMENTAL CONDITIONS------------------------------------------------------10
2-3 DESCRIPTIONS OF TERMINAL AND WIRING DIAGRAM---------------------13
2-3-1 Wiring Diagram-----------------------------------------------------------------------13
2-3-2 SINK / SOURCE Definition--------------------------------------------------------14
2-3-3 Description of Terminals -----------------------------------------------------------15
2-3-4 Wiring Cautions and Specifications---------------------------------------------19
CHAPTER 3THE SETTING OF OPERATION PANEL &REMOTE
CONTROLLER--------------------------------------------------------------------23
3-1 FUNCTIONS OF OPERATION PANEL------------------------------------------------23
3-1-1 Indicators of Operation Panel ----------------------------------------------------23
3-1-2 Keys of Operation Panel-----------------------------------------------------------24
3-1-3 Knob of Operation Panel ----------------------------------------------------------24
3-2 FUNCTIONS OF REMOTE CONTROLLER(KP-601 KEYPAD)----------------25
3-2-1 Indicators of Keypad----------------------------------------------------------------25
3-2-2 Keys of Keypad ----------------------------------------------------------------------26
3-2-3 Knob of Operation Panel ----------------------------------------------------------26
3-3 THE OPERATION OF THE OPERATION PANEL AND MONITOR MODE--27
3-3-1 The Operation of Operation Panel----------------------------------------------27
3-3-2 Monitor Mode-------------------------------------------------------------------------28
3-3-3 The Status of Multi-function Terminals-----------------------------------------29
3-3-4 The Function Setting Mode-------------------------------------------------------29
3-3-5 Parameter Setting Mode-----------------------------------------------------------30
TABLE OF CONTENTS

vi
3-3-6 The Operation in the Monitor Mode---------------------------------------------31
3-3-7 Start/Stop of the Drive--------------------------------------------------------------31
3-3-8 Save and Restore the Setting Value.-------------------------------------------32
CHAPTER 4PARAMETER LIST-----------------------------------------------34
F0 SYSTEM PARAMETERS-------------------------------------------------------------------35
F1 OPERATION PARAMETERS -------------------------------------------------------------36
F2 FREQUENCY PARAMETERS------------------------------------------------------------39
F3 CONTROL PARAMETERS----------------------------------------------------------------42
F4 PROTECTION PARAMETERS -----------------------------------------------------------45
F6 SPECIAL PARAMETERS------------------------------------------------------------------52
CHAPTER 5PARAMETER SETTING DESCRIPTION ------------------------61
F0 SYSTEM PARAMETERS-------------------------------------------------------------------61
F1 OPERATION PARAMETERS -------------------------------------------------------------64
F2 FREQUENCY PARAMETERS------------------------------------------------------------72
F3 CONTROL PARAMETERS----------------------------------------------------------------79
F4 PROTECTION PARAMETERS -----------------------------------------------------------85
F5 MULTI-FUNCTION PARAMETERS -----------------------------------------------------94
F6 SPECIAL PARAMETERS---------------------------------------------------------------- 112
CHAPTER 6COMMUNICATION DESCRIPTION -----------------------------124
6-1 KP-601 / MODBUS PORT (RJ-45) --------------------------------------------------- 124
6-2 THE SETTING OF COMMUNICATION PARAMETER-------------------------- 125
6-3 COMMUNICATION PROTOCOL------------------------------------------------------ 125
6-4 MESSAGE FORMAT --------------------------------------------------------------------- 126
6-5 CRC CHECKSUM ALGORITHM------------------------------------------------------ 129
6-6 PROCESSING TIME OF COMMUNICATION TRANSMISSION-------------- 130
6-7 COMMUNICATION TROUBLESHOOTING---------------------------------------- 131
6-8 DRIVE REGISTERS AND COMMAND CODE ------------------------------------ 132
6-9 PROGRAMMING EXAMPLES –REGISTER AND COMMAND-------------- 136
CHAPTER 7OPERATION PROCEDURES AND FAULT PROTECTION---140
7-1 OPERATION PROCEDURES---------------------------------------------------------- 140
7-2 FAULT PROTECTION DISPLAY AND TROUBLESHOOTING --------------- 142
APPENDIX APERIPHERAL EQUIPMENT OF DRIVE----------------------149
APPENDIX BSELECTION OF AC REACTOR(ACL) ---------------------150
APPENDIX CSELECTION OF EMC FILTER-------------------------------152

vii
APPENDIX DZERO-PHASE RADIO FREQUENCY FILTER SELECTION 153
APPENDIX ESELECTION OF MOTOR -------------------------------------156
APPENDIX FINSTRUCTION OF DRIVE CHARGING-----------------------158
APPENDIX GDYNAMIC BRAKE AND RESISTOR-------------------------159
APPENDIX HOUTLINE DIMENSION DRAWINGS -------------------------163
ATTACHMENT 1SETTING MEMO ------------------------------------------166
ATTACHMENT 2FAULT DISPLAYS -----------------------------------------171

viii
No Text on This Page

Chapter 1 Cautions Before Installation
1
1
Chapter 1 Cautions Before Installation
1-1 Product Verification
The product has passed the strictest quality test before shipped out from the
factory. However, the product might possibly sustain minor damages due to the
impact, shaking, vibration, and other factors during the transportation. Please
make sure to verify the following items after receiving this product. If the
product verification finds anything abnormal, please contact the agent
immediately for the further assistance.
1-1-1 Confirmation of Appearance
1.Check up the drive’s model number is identical with the shipping label on
the carton.
2.Check up the appearance of the drive for any paint chipped off,
smearing, deformation of shape, etc.
3.Check up the nameplate (as below figure) of the drive to verify the
product descriptions with the order specification.
ISO 9001 IP20
Rhymebus Corporation, Taiwan
XXXXXXX
9748-1
3PH AC200-240V 8A 0.1-400.00Hz
3PH AC200-240V 8.4A 50/60Hz
RM6E1-2002B3
SERIAL NO.
PGM NO.
OUTPUT
INPUT
TYPE Model Number
Input Power Specs
Output Current & Capacity
Software Number
Product Serial Number
1-1-2 The description of nomenclature
RM6E1 —2 002 B 3 Input Power Phase
1: Single-Phase
3: Three-Phase
Brake Type
B: with Braking Transistor
Horse Power Code (see HP Table)
Input Voltage
1: 100V ~ 120V
2: 200V ~ 240V
4: 380V ~ 480V
Product Series
HP (Horse Power) Table for Drive Horse Power Code Conversion
Horse power code
Horse power
Horse power code
Horse power
0P5
0.5
003
3
001
1
004
4
1P5
1.5
005
5
002
2
007
7.5

Chapter 1 Cautions Before Installation
2
1
1-1-3 Confirmation of Accessories
One user manual is inclusive. Please verify other accessories inclusively
such as braking resistor, AC reactor, etc..
※Please refer to the standard specifications to verify the product
specifications with your requirements.
1-2 Standard Specifications
1-2-1 Single-Phase 100V Series
Model name
(RM6E1-□□□□B1)
10P5
1001
1002
1003
Maximum applicable
motor (HP / kW)
0.5 / 0.4
1 / 0.75
2 / 1.5
3 / 2.2
Rated output capability
(kVA)
1.0
1.6
2.9
3.8
Rated output current (A)
2.5
4.2
7.5
10
Rated output voltage (V)
Three-phase 200~240V
Range of output
frequency (Hz)
0.1~400.00Hz
Power source (ψ, V, Hz)
Single-phase 100~120V 50/60Hz
Input current (A)
9.1
15.3
30
40
Permissible AC power
source fluctuation
88V~132V
Overload protection
150% of drive rated output current for 1 min.
Cooling method
Nature cooling
Fan cooling
Applicable safety
standards
－
Protective structure
IP20
IP20
Weight / Mass(kg)
1.1
1.2
－
－

Chapter 1 Cautions Before Installation
3
1
1-2-2 Single-Phase 200V Series
Model name
(RM6E1-□□□□B1)
20P5
2001
2002
2003
Maximum applicable
motor (HP / kW)
0.5 / 0.4
1 / 0.75
2 / 1.5
3 / 2.2
Rated output capability
(kVA)
1.1
1.9
2.9
3.8
Rated output current (A)
3
4.2
7.5
10
Rated output voltage (V)
Three-phase 200~240V
Range of output
frequency (Hz)
0.1~400.00Hz
Power source (ψ, V, Hz)
Single-phase 200~240V 50/60Hz
Input current (A)
5.8
7.7
13.7
20
Permissible AC power
source fluctuation
176V~264V
Overload protection
150% of drive rated output current for 1 min.
Cooling method
Nature cooling
Fan cooling
Applicable safety
standards
－
Protective structure
IP20
Weight / Mass(kg)
1.1
1.2
1.2
2.5
※Single-Phase 200V Series 3HP model is under development.
1-2-3 Three-Phase 200V Series
Model name
(RM6E1-□□□□B3)
20P5
2001
21P5
2002
Maximum applicable
motor (HP / kW)
0.5 / 0.4
1 / 0.75
1.5 / 1.1
2 / 1.5
Rated output capability
(kVA)
1.1
1.6
2.3
3
Rated output current (A)
3
4.2
6
8
Rated output voltage (V)
Three-phase 200~240V
Range of output
frequency (Hz)
0.1~400.00Hz
Power source (ψ, V, Hz)
Three-phase 200~240V 50/60Hz
Input current (A)
3.2
4.4
6.3
8.4
Permissible AC power
source fluctuation
176V~264V
Overload protection
150% of drive rated output current for 1 min.
Cooling method
Nature cooling
Fan cooling
Applicable safety
standards
－
Protective structure
IP20
Weight / Mass(kg)
1.1
1.1
1.1
1.2

Chapter 1 Cautions Before Installation
4
1
Model name
(RM6E1-□□□□B3)
2003
2004
2005
Maximum applicable
motor (HP / kW)
3 / 2.2
4 / 3
5 / 3.7
Rated output capability
(kVA)
3.8
5
6.5
Rated output current (A)
10
13
17
Rated output voltage (V)
Three-phase 200~240V
Range of output
frequency (Hz)
0.1~400.00Hz
Power source (ψ, V, Hz)
Three-phase 200~240V 50/60Hz
Input current (A)
11.5
15
19
Permissible AC power
source fluctuation
176V~264V
Overload protection
150% of drive rated output current for 1 min.
Cooling method
Fan cooling
Applicable safety
standards
－
Protective structure
IP20
Weight / Mass(kg)
1.2
2.5
2.5
※Please refer to the page 140 for the single-phase application.
※Three-Phase 200V Series 4HP model is under development.
1-2-4 Three-Phase 400V Series
Model name
(RM6E1-□□□□B3)
4001
4002
4003
Maximum applicable
motor (HP / kW)
1 / 0.75
2 / 1.5
3 / 2.2
Rated output capability
(kVA)
1.9
3
4.2
Rated output current (A)
2.5
4
5.5
Rated output voltage (V)
Three-phase 380~480V
Range of output
frequency (Hz)
0.1~400.00Hz
Power source (ψ, V, Hz)
Three-phase 380~480V 50/60Hz
Input current (A)
2.8
4.4
6.1
Permissible AC power
source fluctuation
332V~528V
Overload protection
150% of drive rated output current for 1 min.
Cooling method
Nature cooling
Fan cooling
Applicable safety
standards
－
Protective structure
IP20
Weight / Mass(kg)
1.1
1.2
1.2

Chapter 1 Cautions Before Installation
5
1
Model name
(RM6E1-□□□□B3)
4005
4007
Maximum applicable
motor (HP / kW)
5 / 3.7
7.5 / 5.5
Rated output capability
(kVA)
6.9
11
Rated output current (A)
9
14
Rated output voltage (V)
Three-phase 380~480V
Range of output
frequency (Hz)
0.1~400.00Hz
Power source (ψ, V, Hz)
Three-phase 380~480V 50/60Hz
Input current (A)
10.3
16
Permissible AC power
source fluctuation
332V~528V
Overload protection
150% of drive rated output current for 1 min.
Cooling method
Fan cooling
Applicable safety
standards
－
Protective structure
IP20
Weight / Mass(kg)
2.5
2.5

Chapter 1 Cautions Before Installation
6
1
1-3 Common Specifications
1-3-1 The Features of Control and Operation
Control Characteristics
Control method
․Voltage vector sinusoidal PWM control(V/F control);
․Switching frequency: 800Hz~16kHz
Range of
frequency setting
0.1~400.00Hz
Resolution
of frequency
setting
․Operation panel: 0.01Hz
․Analog signal: 0.06Hz / 60Hz
Resolution
of output
frequency
0.01Hz
Overload
protection
150% of drive rated output current for 1 minute
DC braking
․Start/stop braking time: 0~60.0sec
․Stop braking frequency: 0.1~60Hz
․Braking ability: 0~150% of inverter
Braking torque
Approximately 20%(with the external braking resistor
connected, braking torque is approximately 100%)
V/F pattern
․V/F pattern (2 V/F points)
․Square curve, 1.7th power curve, 1.5th power curve.
․Output voltage adjustment of V/F pattern(Variable voltage
(V) adjustment of V/F pattern for acceleration /
deceleration).
Acceleration/
deceleration time
․0sec(coast to stop), 0.0~3200.0sec(Independent setting of
the acceleration / deceleration).
․The time setting range of the speed acceleration from 0 to
60Hz is 0.015sec ~ 19200000sec(222 days).
Stall prevention
Stall prevention at acceleration / constant speed(the current
level of stall prevention is 30~200%), Stall prevention at
deceleration
Other functions
Slip compensation, auto-torque compensation,
auto-adjustment for output voltage stability, auto-operation for
energy-saving, auto-adjustment of switching frequency,
restart after instantaneous power failure, speed tracing,
over-torque detection, DC braking, dynamic braking duty
control, sequential operation control, counter function, PID
control, Modbus communication, jump frequency, holding
frequency, upper/lower limits of output frequency, 16-preset
speeds, acceleration/deceleration switch, S-curve
acceleration/deceleration, fan control, parameters
duplication,motor overload detection

Chapter 1 Cautions Before Installation
7
1
Operation Characteristics
Input
Start method
Command the drive via 6 programmable multi-function input
terminals(X1~X6): Forward command / Reverse command,
3-wire start/stop control, 16 sets preset speed control.
Communication control.
Multi-function
inputs
6 programmable input terminals: X1~X6
Response time:1~255 ms
Refer to the chapter of function setting description for
F5.19~F5.24.
Analog inputs
1 set of analog inputs: AI(DC 0~10V / 2~10V or DC 0~20mA /
4~20mA)
Analog filter (0~255, unit: 5ms), the dead band of
Analog frequency, gain and bias are adjustable.
Refer to the chapter of function setting description for F5.01,
F5.02, F5.05~F5.08
Output
Multi-function
outputs
1-set programmable output terminal: Ta /Tb/ Tc
Refer to chapter of function setting description for F5.26.
Analog
outputs
1 set of analog output: FM(DC 0~10V / 2~10V or DC 0~20mA
/ 4~20mA) gain and bias are adjustable.
The gain and bias are adjustable.
Refer to the chapter of function setting description for
F5.12~F5.15.
Display
Build-in operation
panel
4-digit 7-segment display unit, 8 status indicators, 8 buttons,
1 analog knob. 8 monitor modes: output frequency, frequency
command, output voltage, DC voltage, output current, and
three programmable monitor modes (see function
F1.09~F1.11): terminal status, heat sink temperature, motor
speed (RPM), machine speed (MPM), the phase of
sequential operation control, the period of sequential
operation control, counting value, current limit level, primary
frequency command, secondary frequency command, PID
command, PID feedback
External keypad
(KP-601)
Keypad KP-601 is available for external connection to the
drive *Note 2
protection
Fault protection
Error trip
messages of
drive
Under voltage during operation(LE1), Drive over current(OC),
Grounding fault(GF), Over voltage(OE), Drive overheat(OH),
Motor overload(OL), System overload(OLO), Keypad
interruption during copy(PAdF), IGBT module error(Fot)*Note
1, Drive overload(OL1), Drive current limit(OL2), Braking
transistor overload(OL3), Motor overheat(OH2), PID
feedback signal error(noFb), External fault(EF), Internal
memory error(EEr1, EEr2), EEPROM error(EEr), A/D
converter error(AdEr)

Chapter 1 Cautions Before Installation
8
1
Warning
messages of
drive
Power source under voltage(LE), Drive output
interruption(bb), Coast to stop(Fr), Braking transistor is active
(db), Keypad cable trip before connecting(Err_00), Keypad
cable trip during operation(Err_01), System overload(OLO),
Power source under voltage(Hv), Power source under
voltage(LE), Drive overheat(OHt), Motor overheat(OH1),
FWD/REV command input simultaneously(dtF)、Different
software version inter-copy(wrF)、Modbus communication
overtime(Cot)
Cooling method
All models belong to fan cooling except single-phase
10P5,20P5 and three-phase 20P5, 2001, 4001
Environment
Atmosphere
Non-corrosive or non-conductive, or non-explosive gas or
liquid, and non-dusty
Surrounding
temperature
-10°C (14°F) ~ +50°C (122°F) (Non-freezing and
non-condensing)
Storage
temperature
-20°C (-4°F) ~ +60°C (149°F)
Relative humidity
90% RH or less (No-condensing atmosphere)
Vibration
Less than 5.9m/sec²(0.6G)
Altitude
Less than 1000m (3280 ft.)
Note1: Only 3HP below(100V/200V series) have IGBT module error protection (Fot).
Note2: KP-601 is an optional accessory.
1-4 The Disassembled Sketch of RM6E1
○
1：Cover of main circuit
○
2：Screws of main circuit
○
3：Cover of multi-function terminal
○
4：The protection cover of fan
○
5：Cooling fan
○
6：Drive
○
1
○
2
○
3
○
5
○
4
○
6

Chapter 1 Cautions Before Installation
9
1
No Text on This Page
