ISL85009EVAL1Z Evaluation Board User Guide
Description
The ISL85009 is a 3.8V to 18V input, 9A synchronous buck
regulator for applications with input voltage from multi-cell
batteries or regulated 5V and 12V power rails. The device also
provides an integrated bootstrap diode for the high-side gate
driver to reduce the external parts count. The
ISL85009EVAL1Z platform allows quick evaluation of the
high-performance features of the ISL85009 buck regulator.
Specifications
This board has been configured and optimized for the following
operating conditions:
• Input voltage range from 4.5V to 18V
• 1.8V nominal output voltage
• Up to 9A output current capability
• Default internally set to 600kHz switching frequency
• Default internally set to 3ms soft-start
• Operating temperature range: -40°C to +85°C
Key Features
• Switch selectable EN (enabled/disabled)
• Frequency synchronization option
• Jumper selectable mode (DEM/Forced CCM)
• Jumper selectable OCP mode (Hiccup/Latch-Off)
• Jumper selectable frequency (600kHz/300kHz)
• Connectors and test points for easy probing
•Compactdesign
Related Literature
• For a full list of related documents, visit our website
-ISL85009 product page
Ordering Information
PART NUMBER DESCRIPTION
ISL85009EVAL1Z Evaluation board for ISL85009
FIGURE 1. BLOCK DIAGRAM
PVIN 9
FB
COMPEN
PG
DNCDNC
BOOTVDDFREQSYNC
123456
10
11
12131415
MODE
VIN
CIN
L1
COUT
VOUT
GND
C3
PVIN
GND C4
R3
4.5V TO 18V
1.8V/9A
DEM
FCCM
LATCH-OFF
HICCUP
300kHz
600kHz
ENABLE
DISABLE
PHASE 8
GND 7
R2R1
C1
February 15, 2017
UG112.0
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774 |Copyright Intersil Americas LLC 2017. All Rights Reserved
Intersil (and design) is a trademark owned by Intersil Corporation or one of its subsidiaries.
All other trademarks mentioned are the property of their respective owners.
User Guide 112

User Guide 112
UG112.0
February 15, 2017
Submit Document Feedback 2
Connector and Test Point
Descriptions
The ISL85009EVAL1Z evaluation board includes I/O connectors
and test points as shown in Table 1.
Selection Switch and Jumper
Descriptions
•SwitchSW5(Enable)
The switch enables and disables the ISL85009:
- When the switch is in the ON position, ISL85009 enabled.
- When the switch is in the OFF position, ISL85009 disabled.
•JumperJ9
The jumper provides selection of different operating modes
detailed as following:
- When the jumper is in the FCCM position, the ISL85009
operates in Forced CCM.
- When the jumper is in the DEM position, the ISL85009
operates in Diode Emulation mode and enables automatic
transition from CCM to DCM at light-load conditions.
• Jumper J10 sets the switching frequency at either 600kHz or
300kHz.
• Jumper J11 sets the OCP scheme in either Hiccup mode or
Latch-Off mode.
Quick Setup Guide
Refer to the following instructions to configure and power-up the
board for proper operation.
1. Set the power supply voltage to 12V and turn off the power
supply. Connect the positive output of the power supply to J1
(PVIN) and the negative output to J3 (GND).
2. Connect an electronic load to J2 (VOUT) for the positive
connection and J4 (GND) for the negative connection.
3. Measure the output voltage (test points VOUT and GND) with
the voltmeter.
4. Place scope probes on VOUT test point (J7) and other test
points of interest.
5. Toggle selection switch SW5 to ON position.
6. Set the load current to be 0.1A and turn on the power supply.
The output voltage should be in regulation with a nominal
1.8V output.
7. Slowly increase the load up to 9A while monitoring the output
voltage, which should remain in regulation with a nominal
1.8V output.
8. Slowly sweep VIN from 4.5V to 18V. The output voltage should
remain in regulation with a nominal 1.8V output.
9. Decrease the input voltage to 0V to shut down the regulator.
Frequency Synchronization
The ISL85009 can be synchronized to an external clock with
frequency ranges from 100kHz to 1MHz by applying the external
clock to test point SYNC on the ISL85009EVAL1Z evaluation
board. The external clock should meet the specifications of pulse
width and voltage level described in the ISL85009 datasheet.
Evaluating Other Output
Voltages
The ISL85009EVAL1Z has a nominal 1.8V output voltage. The
output voltage is programmable by an external resistor divider
formed by R1and R2as shown in Figure 1 on page 1. R1 is
usually chosen first, then the value for R2can be calculated
based on R1 and the desired output voltage using Equation 1.
PCB Layout Considerations
The PCB layout is critical for proper operation of the ISL85009.
The following guidelines should be followed to achieve good
performance.
1. Use a multilayer PCB structure to achieve optimized
performance. A four-layer PCB is recommended for this design.
2. Use a combination of bulk capacitors and smaller ceramic
capacitors with lower ESL for the input capacitors, and place
them as close to the IC as possible.
3. Place the VDD decoupling capacitor close to the IC between
VDD and GND. A 1µF ceramic capacitor is typically used.
4. Place a bootstrap capacitor close to the IC between the BOOT
and PHASE pins. A 0.1µF ceramic capacitor is typically used.
5. Connect the feedback resistor divider between the output
capacitor positive terminal and AGND pin of the IC, and place
the resistors close to the FB pin of the IC.
6. Connect the GND of the IC to the ground planes underneath
using multiple thermal vias to improve thermal performance.
TABLE 1. CONNECTORS AND TEST POINTS
REFERENCE
DESIGNATOR DESCRIPTION
J1 Input voltage positive connection
J2 Output voltage positive connection
J3 Input voltage return connection
J4 Output voltage return connection
J6 Two-position socket connector for PHASE to GND test
J7 Two-position socket connector for VOUT to GND test
PVIN PVIN positive test point
GND GND test point
VIN VIN positive test point
VOUT Output voltage positive test point
SYNC External synchronization clock connection
EN Enable test point
VDD Internal LDO output test point
PG Power-good output
R2
R10.6V
VOUT 0.6V–
----------------------------------
=(EQ. 1)

User Guide 112
UG112.0
February 15, 2017
Submit Document Feedback 3
ISL85009EVAL1Z Evaluation Board
FIGURE 2. TOP VIEW
ISL85009EVAL1Z Schematic
FIGURE 3. SCHEMATIC
Enable
Disable
Internal Compensation
600kHz
300kHz
FCCM
DEM
Hiccup
Latch off
-

&
X)
3*
5

5

-

5
'13
&
Q)
-



&
X)
-

&
'13
-

5

&
X)9
9''
&
X)
6<1&
9287
&
X)
-

39,1
5
N
5
N
5
N
9,1
8
,6/
6<1&


02'(

)5(4
3*

9''

%227


*1'

39,1

3+$6(
)% 
&203 
1& 
1& 
(1 
9,1 
6:
6:63'7
&
X)
5
N
&
'13
&
X)
&
Q
5
'13
&
'13
/
X+
(1
&
X
-



*1'
-



-

&
S
&
X)

User Guide 112
UG112.0
February 15, 2017
Submit Document Feedback 4
Bill of Materials
MANUFACTURER
PART QTY UNITS
REFERENCE
DESIGNATOR DESCRIPTION MANUFACTURER
ISL85009EVAL1ZREVAPCB 1 ea PWB-PCB, ISL85009EVAL1Z, REVA, ROHS IMAGINEERING INC
25SVPF330M 1 ea C6 CAP-OSCON, SMD, 10mm, 330µF, 25V, 20%, 14mΩ,
ROHS
PANASONIC
GRM32ER71E226KE15L 3 ea C9, C13, C14 CAP, SMD, 1210, 22µF, 25V, 10%, X7R, ROHS MURATA
C0402X7R500-102KNE 1 ea C7 CAP, SMD, 0402, 1000pF, 50V, 10%, X7R, ROHS VENKEL
C1005X7R1H104K 1 ea C4 CAP, SMD, 0402, 0.1µF, 50V, 10%, X7R, ROHS TDK
04025A4R7CAT2A 1 ea C3 CAP, SMD, 0402, 4.7PF, 50V, 0.25pF, NPO, ROHS AVX
GRM188R61E105KA12D 1 ea C5 CAP, SMD, 0603, 1µF, 25V, 10%, X5R, ROHS MURATA
GRM188R71A225KE15D 1 ea C8 CAP, SMD, 0603, 2.2µF, 10V, 10%, X7R, ROHS MURATA
GRM31CR60J107ME39L 3 ea C10, C11, C12 CAP, SMD, 1206, 100µF, 6.3V, 20%, X5R, ROHS MURATA
7443340100 1 ea L1 COIL-PWR INDUCTOR, SMD, 8.4x7.9, 1.0µH, 20%, 17A,
WW, ROHS
WURTH ELECTRONICS
111-0702-001 2 ea J1, J2 CONN-GEN, BIND.POST, INSUL-RED, THMBNUT-GND JOHNSON COMPONENTS
111-0703-001 2 ea J3, J4 CONN-GEN, BIND.POST, INSUL-BLK, THMBNUT-GND JOHNSON COMPONENTS
5002 8 ea VDD, SYNC, PG,
EN, GND, VIN,
PVIN, VOUT
CONN-MINI TEST POINT, VERTICAL, WHITE, ROHS KEYSTONE
68000-236HLF 3 ea J9, J10, J11 CONN-HEADER, 1x3, BREAKAWY 1x36, 2.54mm, ROHS BERG/FCI
929950-00 1 ea Jumper CONN-JUMPER, SHORTING, 2PIN, BLK, OPEN TOP,
2.54mmPITCH, ROHS
3M
ISL85009FRZ 1 ea U1 IC-9A BUCK REGULATOR, 15P, TDFN 3.5x3.5, ROHS INTERSIL
ERJ2RKF20R0 1 ea R7 RES, SMD, 0402, 20Ω, 1/16W, 1%, TF, ROHS PANASONIC
CR0402-16W-00T 1 ea R9 RES, SMD, 0402, 0Ω, 1/16W, 5%, TF, ROHS VENKEL
ERJ2RKF1003 3 ea R2, R4, R6 RES, SMD, 0402, 100k, 1/16W, 1%, TF, ROHS PANASONIC
ERJ-2RKF2000X 1 ea R10 RES, SMD, 0402, 200Ω, 1/16W, 1%, TF, ROHS PANASONIC
MCR01MZPF2003 1 ea R1 RES, SMD, 0402, 200k, 1/16W, 1%, TF, ROHS ROHM
0 ea R3, R5 RES, SMD, 0402, DNP, DNP, DNP, TF, ROHS
GT11MSCBE 1 ea SW5 SWITCH-TOGGLE, SMD, 6PIN, SPDT, 2POS, ON-NONE-ON,
ROHS
ITT INDUSTRIES/C&K DIVISION
PMSSS 440 0025 PH 4 ea Four corners SCREW, 4-40x1/4in, PHILLIPS, PANHEAD, STAINLESS,
ROHS
BUILDING FASTENERS
2204 4 ea Four corners STANDOFF, 4-40x3/4in, F/F, HEX, ALUMINUM, 0.25 OD,
ROHS
KEYSTONE
212403-013 1 ea Place assy in bag BAG, STATIC, 5x8, ZIPLOC, ROHS INTERSIL
310-87-102-41-001101 2 ea J6, J7 CONN-SOCKET STRIP, TH, 2P, 2.54mm PITCH, ROHS PRECI-DIP
0 ea C1, C2, C16 DO NOT POPULATE OR PURCHASE
LABEL-DATE CODE 1 ea AFFIX TO BACK
OF PCB
LABEL-DATE CODE_LINE 1: YRWK/REV#, LINE 2: BOM
NAME
INTERSIL

User Guide 112
UG112.0
February 15, 2017
Submit Document Feedback 5
ISL85009EVAL1Z PCB Layout
FIGURE 4. TOP LAYER FIGURE 5. LAYER 2
FIGURE 6. LAYER 3 FIGURE 7. BOTTOM LAYER

User Guide 112
6
Intersil Corporation reserves the right to make changes in circuit design, software and/or specifications at any time without notice. Accordingly, the reader is
cautioned to verify that the document is current before proceeding.
For information regarding Intersil Corporation and its products, see www.intersil.com
UG112.0
February 15, 2017
Submit Document Feedback
Typical Performance Curves VIN = 12V, VOUT = 1.8V, L = 1µH, fSW = 600kHz, TA= +25°C, unless otherwise noted.
FIGURE 8. EFFICIENCY vs LOAD FIGURE 9. START-UP WITH EN, IOUT = 9A
FIGURE 10. SHUTDOWN WITH EN, IOUT = 9A FIGURE 11. OUTPUT VOLTAGE RIPPLE, IOUT = 9A
30
40
50
60
70
80
90
100
0123456789
OUTPUT CURRENT (A)
Vin = 12V, fsw = 600kHz
Vin = 5V, fsw = 600kHz
EFFICIENCY (%)
C2: EN, 10V/DIV
C1: VOUT, 1V/DIV
C4: IL, 5A/DIV
C3: PGOOD, 5V/DIV
1ms/DIV
C2: EN, 10V/DIV
C1: VOUT, 1V/DIV
C4: IL, 5A/DIV
C3: PGOOD, 5V/DIV
200µs/DIV
5µs/DIV
C2: PHASE, 10V/DIV
C1: VOUT, 20mV/DIV, ac-coupled
C4: IL, 5A/DIV
