Intex FastFill AP619DA User manual

(20PO) AP619DA ELECTRIC PUMP ENGLISH 4.875” X 7.25” 08/25/2022
20
PO
READ AND SAVE THESE INSTRUCTIONS
Page 1
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
INTEX® OWNER’S MANUAL
FastFill™ Electric Pump
Model AP619DA 110V – 120V ~ 60Hz 0.9A
020-*PO-R0-2308
English
Babies Can Suffocate
To prevent suffocation and death,
never place a baby 15 months old or
younger on this product.
WARNING
Keep product fully inflated when in use.
Child Entrapment Hazard
Always position product 1ft (30cm) or
more away from objects such as walls
and dressers to prevent a child from
being entrapped.
Keep product fully inated when in use. See instructions for any additional warnings.
WARNING
Babies Can Suffocate
To prevent suffocation and death,
never place a baby 15 months old
or younger on this product.
Child Entrapment Hazard
Aways position product 1ft (30cm) or more
away from objects such as walls and dressers
to prevent a child from being entrapped.
Keep product fully inated when in use. See instructions for any additional warnings.
WARNING
Babies Can Suffocate
To prevent suffocation and death,
never place a baby 15 months old
or younger on this product.
Child Entrapment Hazard
Aways position product 1ft (30cm) or more
away from objects such as walls and dressers
to prevent a child from being entrapped.
To reduce the risk of burns, fire, electric shock, or injury to persons:
•
Never introduce any flammable substance into the inflatable air bed, SUCH AS AEROSOL TIRE REPAIR PRODUCTS, as it may ignite or explode.
• For indoor household use only.
• Unplug from outlet before putting on or taking off parts.
•
Close supervision is necessary when this furnishing is used by, or near children, invalids, or disable persons.
• Use this furnishing only for its intended use as described in these instructions. Do not use attachments not recommended by the manufacturer.
• Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
• This is not a toy. Children must not be left unattended when using the air bed.
• If a storage bag is included, keep the storage bag away from babies and children. The storage bag is
not a toy. When not in use, fold the bag and put it away out of the reach of children.
• Do not walk, stand on or jump on or use the air bed as a trampoline.
• Do not use on or near water. This is not a raft.
• Do not set up bed near stairs, doors, sharp edges or breakable objects. Provide adequate space
between bed and objects to avoid entrapment.
•
Make sure the area is flat, smooth, free of sharp objects that could puncture the bed and keep away from ledges.
• Keep pets away from the air bed. Pets may puncture the surface of the bed.
• Avoid sleeping on the edge of the air bed. Edges produce less support than the middle of the bed.
•
Do not operate air pump for more than 5 minutes at a time. Let pump cool at least 15 minutes between use.
• Unplug electrical power cord when not in use. To disconnect, turn all controls to the off position, then remove plug from outlet.
• Never operate the furnishing with the air openings blocked. Keep the air openings free of lint, hair,
and the like. Never drop or insert object into any opening.
•
Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been dropped
or damaged, or dropped into water. Return the furnishing to a service center for examination and / or repair
.
• If the AC supply cord is damaged, it must be replaced by the manufacturer or its service agent in order to avoid a hazard.
• Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord under furniture
or appliances. Arrange cord away from traffic area and where it will not be tripped over. Keep the cord away from heated surfaces.
FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID SUFFOCATION, PROPERTY DAMAGE, ELECTRIC SHOCK, BURNS OR OTHER INJURY.

(20PO) AP619DA ELECTRIC PUMP ENGLISH 4.875” X 7.25” 08/25/2022
20
PO
READ AND SAVE THESE INSTRUCTIONS
Page 2
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
Due to a policy of continuous product improvement, Intex reserves the right to change
specifications and appearance, which may result in updates to the instruction manual,
without notice.
PARTS REFERENCE
4
3
1
6
5
9
2
10
7
8
OPERATING INSTRUCTIONS
General
• The air pump can also be controlled via the Intex Air Mattress Remote App from your
mobile device, see “Intex Air Mattress Remote App” section for details.
• The USB power socket is suitable for charging mobile devices such as smartphones and
tablets. Output rating: 5 V , 2.0 A.
• Air beds are designed for temporary use and are NOT designed to be a replacement for
a traditional mattress.
• Make sure the area is flat, level, clean and free from sharp objects, and within reach of
an electrical outlet.
• The appliance must be positioned so that the plug is accessible.
• To prevent puncture or damage to the air bed, never drag the air bed across the floor. Lift
the inflated air bed when moving or changing location.
• No air pump maintenance is required.
• For cleaning use only clean cloth with mild soapy solution. Do not use any chemicals.
• In case of repairs, use only common PVC repair glue and patches. For flocked surfaces:
rub away the flocking material with an eraser first before applying the glue and/or patch.
Part Descriptions:
1. Inflation button ( )
2. Deflation button ( )
3. Deflation adjustment button ( )
4. Cord compartment cover
5. Cord compartment
6. AC line cord
7. Manual inflation port cap
8. Manual inflation port
9. USB power socket (5 V , 2.0 A)
10. Air bed front
SERVICING OF A DOUBLE-INSULATED PRODUCT:
In a double-insulated product, two systems of insulation are provided instead of
grounding. No grounding means is provided on a double-insulated product, nor should
a means for grounding be added to the product. Servicing of a double-insulated product
requires extreme care and knowledge of the system, and should be done only by qualified
service personnel. Replacement parts for a double-insulated product must be identical to
those parts in the product. A double-insulated product is marked with the words “DOUBLE
INSULATION” or “DOUBLE INSULATED” and with the symbol .

(20PO) AP619DA ELECTRIC PUMP ENGLISH 4.875” X 7.25” 08/25/2022
20
PO
READ AND SAVE THESE INSTRUCTIONS
Page 3
INFLATION
1. Open cord compartment cover and remove power cord. See Fig (1).
2. Plug in the AC power cord into an AC electrical outlet. See Fig (2).
3. Press the inflation button ( ) to inflate. See Fig (3).
4. When the air bed is inflated to the desired firmness, press “ ” again to switch OFF.
Note: The pump will automatically switch OFF after about five and half minutes of
operation when the pump is left unattended or when air bed is fully inflated.
5. Lie down on the air bed to test the firmness.
6. If the air bed feels too firm, adjust the firmness by pressing the deflation button ( ) to
deflate. See Fig (4).
NOTE: This will start deflating the
air bed quickly, press “ ” again to switch OFF after a
second or so. Test the firmness and repeat for a second at a time until you have reached
the desired firmness.
Alternatively, you can do this process by
pressing the deflation adjust button “ ”, which
will allow air to be released slowly and short. See Fig (5). It will automatically return to
the closed state after completion, press “ ” again to repeat deflating until the air bed
reaches the desired firmness.
FIG (3) FIG (4) FIG (5)
FIG (1)
Proper inflation of the air bed.
The ambient temperatures of air have an effect on the air bed internal pressure. At low
ambient temperature the air will contract within the air bed and the air bed will feel softer:
add air as necessary. At high ambient temperature the air within the air bed will expand
significantly and the air bed will become hard and may burst: release air to avoid damage
to the air bed or to soften the feel. Do not expose the air bed to extreme temperatures
(hot or cold). Stretching is a natural characteristic of new vinyl. During initial use, the air
bed may become soft and require additional inflation to maintain desired firmness. This is
normal for the first few days of use. Dimensions shown are approximate and will vary due
to the vinyl temperature and the air temperature.
In no event shall Intex, their authorized agents or employees be liable for damages
(such as pin holes) to the air bed caused by negligence, ordinary wear and tear,
abuse and carelessness, or external forces.
IMPORTANT NOTE
FIG (2)
110V – 120V
220V – 240V
√

(20PO) AP619DA ELECTRIC PUMP ENGLISH 4.875” X 7.25” 08/25/2022
20
PO
READ AND SAVE THESE INSTRUCTIONS
Page 4
MANUAL INFLATION OPTION
If electrical power is not available, a conventional foot, manual, or battery-operated air
pump can be used by connecting it to the manual inflation port located inside the line cord
compartment. See Fig (8). Follow these steps:
1. Open line cord compartment cover.
2. Remove the cap from the manual inflation port
and insert the nozzle of the pump into the port.
Inflate the airbed to desired firmness.
NOTE: Do not overinflate. The firmness should be
approximately the same as the level achieved with
the internal electric pump.
3. Remove nozzle from manual inflation port and
close the cap and the line cord cover.
FIG (8)
DEFLATION
1. Plug in the AC power cord into an AC electrical outlet. See Fig (2).
2. Press the deflation button ( ) to deflate. See Fig (6).
3. When all the air is removed from the air bed, press “ ” again to switch OFF.
Note: The pump will automatically switch OFF after about five and half minutes of
operation when the pump is left unattended.
4. With the air bed fully deflated begin rolling the air bed from the end opposite of the pump
towards the end where the pump is located. See Fig (7).
5. Disconnect the AC power cord from the electrical outlet, coil the line cord and place it
inside the cord compartment, then close the cover. Make sure the power cord is free of
twists, kinks or knots.
FIG (6)
FIG (7)
STORAGE INSTRUCTIONS
1. Deflate the air bed following the “DEFLATION” instructions.
2. Make sure the air bed is clean and dry.
3. Lay the air bed flat with the sleeping surface facing upwards and follow the folding steps
on Figs (9 - 13). Fold the air bed loosely and avoid sharp bends, corners and creases
which can damage the air bed.
FIG (9) FIG (10) FIG (11) FIG (13)
FIG (12)
4. Place the air bed inside the storage bag and store in a dry place.

(20PO) AP619DA ELECTRIC PUMP ENGLISH 4.875” X 7.25” 08/25/2022
20
PO
READ AND SAVE THESE INSTRUCTIONS
Page 5
1. Touch the menu icon on the top right corner and select language to change the App
control interface language. See Fig A.
2. A blue Bluetooth icon means a successful connection, while a red icon means a failed
connection. See Fig A - B. Refer to the “App Troubleshooting” section for details.
• INFLATE ( ): Touch this button to activate the inflation function.
When the inflation is completed, touch the “ ” button to stop the pump.
• STOP ( ): Touch this button to stop the pump at any time.
• ADJUST ( ): Touch this button to release a small and short amount of air at a
time.
• DEFLATE ( ): Touch this button to activate the deflation function. When the
deflation is completed, touch the “ ” button to stop the pump.
disconnect
INFLATE
STOP
ADJUST
DEFLATE
BK3633
INFLATE
STOP
ADJUST
DEFLATE
FIG A.
Menu
Blue
FIG B.
disconnect
INFLATE
STOP
ADJUST
DEFLATE
BK3633
INFLATE
STOP
ADJUST
DEFLATE
Red
APP QR Code
Intex®Air Mattress Remote App Setup User Guide
The App allows you to operate and control the electric air pump via Bluetooth
from a mobile device. Follow below steps to install and use the App:
1) Activate the Bluetooth function on the mobile device and ensure the air pump is plugged
into an electrical outlet and the interface panel light is on. NOTE: Keep the mobile
device within 5m (16ft) range of the air bed to ensure good signal and connectivity.
2) Scan the App QR code located on the pump panel or on this manual to install the App.
You may also download the “Intex Air Mattress Remote App” from your App store.
3) Open the App and select the air bed to be connected from the “Add Product” list. Tap
on the air bed name to rename it for easy identification. You can only connect to one air
bed at a time.
NOTE: On mobile devices with older operating system, you may be prompted to allow
the App to access your device’s location and information. If so, please allow the app
to access the location and information of the device in order to achieve a successful
connection between the device and the electric air pump of the air bed.
4) App control interface operation:

(20PO) AP619DA ELECTRIC PUMP ENGLISH 4.875” X 7.25” 08/25/2022
20
PO
READ AND SAVE THESE INSTRUCTIONS
Page 6
©2022 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Recreation Corp. All rights reserved/Tous droits réservés/Todos los derechos
reservados/Alle Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/Marcas registradas
utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/
a/an Intex Development Co. Ltd., Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union
by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Ettenseweg
46, 4706 PB Roosendaal – The Netherlands • Distributed in the UK by Unitex Service (UK) Limited, 21 Holborn Viaduct, London EC1A 2DY, UK.
www.intexcorp.com
WARNING: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
CAN ICES-005 (B)/NMB-005 (B)
PROBLEM CAUSE SOLUTION
Bluetooth connection
failed
• Mobile device
Bluetooth not
activated.
• Out of range.
• The pump is not
powered on.
• The connected
Bluetooth is not
the current pump
Bluetooth.
• Activate the Bluetooth function on the mobile
device.
• Make sure the mobile device is within 5 m
(16 ft) of the product to be connected.
• Make sure the pump is powered on.
• Make sure that the pump Bluetooth connection
correspond to the pump on the air bed to be
connected with.
• Close the App, re-launch the App and try to
connect the air bed with your mobile device
again.
App does not work
or respond
• The App does
not load.
• Force-quit the App, re-launch the App and try
to connect the air bed with your mobile device
again.
• Uninstall the App and reinstall it again.
APP TROUBLESHOOTING
