Intex Quick-Fil AP634 User manual

(194IO) AP634 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 05/22/2019
194
IO
SAVE THESE INSTRUCTIONS
Page 1
NAMES OF PARTS
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
INTEX®OWNER'S MANUAL
Quick-Fill™ Electric Air Pump
Model AP634; 12 V ; 32 W
194-*IO-R0-2005
• Adult use only.
• Do not drop unit into water or expose unit to rain or water.
• Do not direct air stream at face or body.
• Do not operate for more than 5 minutes at a time. Unplug and let cool at least 15 minutes.
• Unplug unit when not in use.
• Do not obstruct vent holes or open source.
• Do not insert objects into the inflation or deflation connector.
•
The DC supply cord cannot be replaced. If the cord is damaged the appliance should be scrapped.
• To reduce the risk of electric shock, do not expose to rain. Store indoors.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved.
• Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
• The appliance must only be supplied at safety extra low voltage corresponding to the
marking on the appliance.
• The appliance is only to be used with the power supply unit provided with the appliance.
• Suitable for inflating air mats, airbeds, inflatable pools and inflatable toys only.
FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID PROPERTY DAMAGE,
ELECTRIC SHOCK, BURNS OR OTHER INJURY.
WARNING
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
PARTS DESCRIPTION:
1. PUMP
2. DEFLATION CONNECTOR
3. INFLATION CONNECTOR
4. SWITCH
5. AC ADAPTER
6. DC CIGARETTE CORD
7. NOZZLES
8. VENT HOLES / SLOTS
7
84
3
25
1
6

(194IO) AP634 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 05/22/2019
194
IO
SAVE THESE INSTRUCTIONS
Page 2
INSTRUCTIONS
GENERAL
• Return pump and nozzles to package when not in use.
• No specific air pump maintenance is required.
INFLATION
1. Attach nozzle to the inflation connector if necessary and hold pump against inflation valve on item to be inflated.
See Fig (1).
NOTE: Use the appropriate nozzle on small inflation valves as on small air mattresses, etc.
2.1. Connect the end of the pump line cord to the DC cigarette cord (6) first, then plug in the DC line cord into a car
cigarette lighter outlet. See Fig (2.1).
2.2. Connect the end of the pump line cord to the AC adapter (5) first, then plug in the AC adapter into an AC electrical
outlet. See Fig (2.2)
3. SWITCH ON: Press "I"; SWITCH OFF: Press "0". See Fig (3).
DEFLATION
1. Attach nozzle to the deflation connector if necessary and hold pump against inflation valve on item to be deflated.
See Fig (4).
NOTE: On large items like inflatable boats and large air mattresses, the pump will fit directly into the inflation valves and
provide faster deflation times. Use the appropriate nozzle on small inflation valves as on small air mattresses, etc.
2.1. Connect the end of the pump line cord to the DC cigarette cord (6) first, then plug in the DC line cord into a car
cigarette lighter outlet. See Fig (2.1).
2.2. Connect the end of the pump line cord to the AC adapter (5) first, then plug in the AC adapter into an AC electrical
outlet. See Fig (2.2)
3. SWITCH ON: Press "I"; SWITCH OFF: Press "0". See Fig (3).
FIG (1): ATTACH NOZZLE
FIG (3): SWITCH
FIG (4): ATTACH NOZZLE
FIG (3): SWITCH
