Invacare HomeFill Oxygen System User manual

Invacare®HomeFill®Oxygen
System
ModelIOH200
enCompressor
UserManual
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,readthismanualandsaveforfuturereference.

©2018InvacareCorporation
Allrightsreserved.Republication,duplicationormodicationinwholeorinpartisprohibited
withoutpriorwrittenpermissionfromInvacare.Trademarksareidentiedby™and®.Alltrademarks
areownedbyorlicensedtoInvacareCorporationoritssubsidiariesunlessotherwisenoted.
PlatinumisaregisteredtrademarkintheU.S.A.,EuropeandAustralia.
MakingLife’sExperiencesPossibleisaregisteredtrademarkintheU.S.A.
3-in-1oilisaregisteredtrademarkofAmericanHomeProductsCorporation.
WD-40isaregisteredtrademarkoftheWD-40Company.
Updatedversionsofthismanualareavailableonwww.invacare.com.

Contents
1General.........................................4
1.1Symbols.....................................4
1.2IntendedUse.................................5
2Safety..........................................7
2.1GeneralGuidelines.............................7
2.2LabelLocations................................10
2.3DealerInformation.............................11
2.4Double-InsulatedProducts........................11
2.5EMCInformation...............................11
3Setup...........................................13
3.1Unpacking....................................13
3.2CompressorInitialSetupChecklist..................13
3.3ChoosingaLocation............................14
3.4TransportingtheCompressor......................14
3.5InstallingthePowerCord........................15
3.6ConnectingtheCompressortotheConcentrator.......16
4Usage..........................................17
4.1CompressorOperationChecklist...................17
4.2CylinderPrellInspection........................17
4.3ConnectingtheCylindertotheCompressor...........19
4.4DisconnectingtheCylinderfromtheCompressor.......20
4.5TurningtheCompressorOnandOff................21
5Maintenance.....................................23
5.1MaintenanceInfo..............................23
5.2WearandTear................................23
5.3ServiceLife...................................23
5.4CleaningtheCompressorFilter....................24
5.5CleaningtheCabinet............................24
5.6ReplacingtheFuse.............................25
6AfterUse........................................26
6.1Disposal.....................................26
7Troubleshooting...................................27
7.1IndicatorLights................................27
7.2Troubleshooting...............................29
8TechnicalData....................................32
8.1TechnicalDescription............................32
8.2Specications.................................32
9Warranty........................................34
9.1LimitedWarranty..............................34

Invacare®HomeFill®OxygenSystem
1General
1.1Symbols
SymbolsintheManual
Signalwordsareusedinthismanualandapplytohazards
orunsafepracticeswhichcouldresultinpersonalinjuryor
propertydamage.Seetheinformationbelowfordenitions
ofthesignalwords.
DANGER!
–Dangerindicatesanimminentlyhazardous
situationwhich,ifnotavoided,willresultin
deathorseriousinjury.
WARNING!
–Warningindicatesapotentiallyhazardous
situationwhich,ifnotavoided,couldresultin
deathorseriousinjury.
CAUTION!
–Cautionindicatesapotentiallyhazardous
situationwhich,ifnotavoided,mayresultin
propertydamageorminorinjuryorboth.
IMPORTANT
–Indicatesahazardoussituationthatcouldresult
indamagetopropertyifitisnotavoided.
Givesusefultips,recommendationsandinformation
forefcient,trouble-freeuse.
SymbolsontheProduct
Thefollowingsymbolsarefoundonthecompressor,
compressorpackagingortheoxygencylinder.
ReadtheManual(Compressor)
ReadtheManual(Cylinder)
ElectricalHazard
AlternatingCurrent
TypeBFequipment—AppliedParts
Powerswitch“ON”
Powerswitch“OFF”
DONOTsmoke
41100873-M

General
NoOpenFlame
ClassII,DoubleInsulation.Referto
2.4Double-InsulatedProducts,page
11.
Keepdryintransportorstorageand
duringuse
Fuse
Oxidizer
TransportandStorageTemperature
TransportandStorageHumidity
Recyclethisproduct.Referto6.1
Disposal,page26.
1.2IntendedUse
WARNING!
–Theuseofthisdeviceislimitedtorellinga
specicpatient’sownoxygencylinders.The
designatedcylindersMUSTbeusedONLYby
thespecicoxygenpatientandarenotto
bedistributedtoanyotherindividualforany
purpose.
–Nootheruseofthisdeviceisindicated.
WARNING!
RiskofDeath,InjuryorDamage
TheInvacareHomeFillcompressorwas
designedtobeusedonlywithInvacareoxygen
concentrators.Usewithothertypesofdevices
maycauseinjury,deathorpropertydamage.
–DONOTusetheInvacareHomeFillcompressor
withanythingotherthananInvacareoxygen
concentrator .
–UseonlywithspeciallydesignedInvacare
oxygenconcentratorsthatareHomeFill
compatible.
TodetermineifyouroxygenconcentratorisHomeFill
compatible,examinethelowerrightcorneroftherearof
theoxygenconcentratorAforanoutletttingB.
1100873-M5

Invacare®HomeFill®OxygenSystem
Platinum®—TopViewPerfecto2™—RearView
TheintendeduseofanInvacareHomeFillcompressoris
anaccessorydevicetoanInvacareoxygenconcentrator
thatenablesthepatienttorellcustomportableoxygen
cylindersforpersonaluse.
Thisproductisintendedforsinglepatientuseintheindoor
homecareenvironmentonlyandisnottobeusedforbulk
cylinderrelling.
Nospecicproductknowledgeortrainingisrequired,
otherthanwhatiscontainedinthismanual,tooperate
theproduct.
Itisnotintendedforsupplyingoxygentherapyduring
relling.
Thisproductisintendedtobeusedbyorunderadult
supervisiononlyafterreadingandunderstandingthe
instructionsandwarningsofthisusermanual.
61100873-M

Safety
2Safety
2.1GeneralGuidelines
DANGER!
RiskOfDeath,Injury,OrDamage
Improperuseoftheproductmaycausedeath,
injuryordamage.Thissectioncontainsimportant
informationforthesafeoperationanduseofthis
product.
–DONOTusethisproductoranyavailable
optionalequipmentwithoutrstcompletely
readingandunderstandingtheseinstructions
andanyadditionalinstructionalmaterialsuch
asusermanuals,servicemanualsorinstruction
sheetssuppliedwiththisproductoroptional
equipment.
–Ifyouareunabletounderstandthewarnings,
cautionsorinstructions,contactahealthcare
professional,dealerortechnicalpersonnel
beforeattemptingtousethisequipment.
–CheckALLexternalcomponentsandcartonfor
damage.Incaseofdamage,oriftheproduct
isnotworkingcorrectly,contactatechnician
orInvacareforrepair.
–Inordertoensurethesafeinstallation,
assemblyandoperationoftheHomeFill
CompressortheseinstructionsMUSTbe
followed.
–THEINFORMATIONINTHISDOCUMENTIS
SUBJECTTOCHANGEWITHOUTNOTICE.
DANGER!
RiskOfDeath,Injury,OrDamageFromFire
Textiles,oilorpetroleumsubstances,grease,
greasysubstancesandothercombustiblesare
easilyignitedandburnwithgreatintensityin
oxygenenrichedairandwhenincontactwith
oxygenunderpressure.Toavoidre,death,
injuryordamage:
–DONOTSMOKEwhileusingthisdevice.
–DONOTusenearOPENFLAMEorIGNITION
SOURCES.
–DONOTuseanylubricantsonthecompressor
unlessrecommendedbyInvacare.
–NOSMOKINGsignsshouldbeprominently
displayed.
–Avoidcreationofanysparknearoxygen
equipment.Thisincludessparksfromstatic
electricitycreatedbyanytypeoffriction.
–Keepallmatches,lightedcigarettesorother
sourcesofignitionoutoftheroominwhich
thiscompressorislocatedandawayfrom
whereoxygenisbeingdelivered.
–Keeptheoxygentubing,cord,andcompressor
outfromundersuchitemsasblankets,
bedcoverings,chaircushions,clothing,and
awayfromheatedorhotsurfacesincluding
spaceheaters,stoves,andsimilarelectrical
appliances.
1100873-M7

Invacare®HomeFill®OxygenSystem
DANGER!
RiskOfDeath,Injury,OrDamageFromFire
Textiles,oilorpetroleumsubstances,grease,
greasysubstancesandothercombustiblesare
easilyignitedandburnwithgreatintensityin
oxygenenrichedairandwhenincontactwith
oxygenunderpressure.Toavoidre,death,
injuryordamage:
–DONOTallowoilfromyourhandsorother
sourcestocomeintocontactwiththe
compressorcouplingorcylinderttings.These
substancesmaybecomeammableinthe
presenceofoxygenandcauseinjury.Avoid
touchingthecylinderttingwheneverpossible.
Exampleofitemstoavoidarehandcreamsor
lotions,cookingoils,suntanoilsorsunblocks
andsimilaroilyproducts.Ifyouusethese
typesofproductsInvacaresuggestsyouwash
yourhandspriortousingtheHomeFillunit.
Ifthecylinderttingshouldcomeincontact
withsuchsubstancesitshouldbecleanedoff
withadampclothpriortoconnectingittothe
compressor .
–NEVERoilorlubricatethecompressorcoupler
orcylinderttings.NEVERuseanypenetrating
oilorlubricantsuchasWD-40®or3-in-1
Oil®.Ifconnectiondifcultyisexperienced
verifythatthecylinderttingisbeinginserted
straightdownintothecompressorcoupler.If
continueddifcultyisexperiencedcontactyour
supplierforassistance.
DANGER!
RiskofElectricShock
Thisunitcontainsmovingandhighpressure
components.Therearenouserserviceableparts
insidethecover.Toavoidelectricshock,injury
ordeath:
–DONOTremovethecover.
–Referservicingtoqualiedpersonnel.
WARNING!
RiskofSeriousInjuryorDamage
Useofnon-Invacareaccessoriesmayresultin
seriousinjuryordamage.
–Invacareproductsarespecicallydesigned
andmanufacturedforuseinconjunctionwith
Invacareaccessories.Accessoriesdesignedby
othermanufacturershavenotbeentestedby
Invacareandarenotrecommendedforuse
withInvacareproducts.
–DONOTusenon-Invacareaccessories.
–ToobtainInvacareaccessories,contactInvacare
byphoneoratwww.invacare.com
WARNING!
Riskofinjuryordamage
Blockingtheairowintoandoutofthe
compressormaycauseinjuryordamage.
–NEVERblocktheairopeningsoftheproduct
orplaceitonasoftsurface,suchasabedor
couch,wheretheairopeningmaybeblocked.
–Keeptheopeningsfreefromlint,hairand
similarforeignitems.
81100873-M

Safety
WARNING!
RiskofInjuryorDamage
Adamagedproductmaymalfunctionandcause
injuryordamage.Toavoidinjuryordamage:
–DONOTgetthecompressorwet.
–Ifthecompressorhasadamagedcordorplug,
ifitisnotworkingproperly,ifithasbeen
droppedordamaged,orsubmersedinwater,
callaqualiedtechnicianforexaminationand
repair .
WARNING!
–DONOTusethecompressoroutdoors.Indoor
useonly.
–Ifanyleakageoftheoxygencylinderisdetected
DONOTattempttousethecylinder.Turnthe
owselectorknobontheregulatorto“Off”.If
leakagepersists,placethecylinderoutdoors
andnotifyyourHomeHealthCareProvideror
ServiceRepresentativeofthiscondition.
–ChildrenshouldALWAYSbesupervisedaround
theHomeFillunit.Whenusedwiththe
HomeFilltableorsimilarelevatedsupport
surfaces,achildcouldpulloveranysuchtable
causingtheunittofall.Failuretoobserve
thiswarningmayresultinpersonalinjuryor
productdamage.
WARNING!
Riskofinjuryordamage
TheHomeFillisequippedwithahighpressure
reliefvalvetoensuretheuser’ssafety.When
activated,thissafetyfeaturewillmakean
extremelyloudnoise.Toavoidinjuryordamage:
–Ifthisnoiseoccurs,turntheunitOffand
contactyourHomeHealthCareProvideror
ServiceRepresentative.
WARNING!
Riskofinjuryordamage
Ifimproperlypositionedandsecured,thepower
cordandinterconnecthosecancauseinjurydue
totrippingandfalling.Productdamagemayalso
occur.
–ThepowercordandinterconnecthoseMUST
beroutedandsecuredproperly.
–Avoidpositioningpowercordsacrossareasof
hightrafc.
–Beforemovingorrepositioningeitherthe
compressororconcentrator,ALWAYSdisconnect
theACpowercordsandtheinterconnecthose
betweenthecompressorandconcentrator.
CAUTION!
Federal(statutory)lawrestrictsthisdevicesale
toorontheorderofamedicalpractitioner
licensedbyagovernmentalagencywherehe/she
practices.
–ONLYalicensedmedicalpractitionermayorder
thepurchaseoruseofthisdevice.
1100873-M9

Invacare®HomeFill®OxygenSystem
2.2LabelLocations
A
B
C
D
E
101100873-M

Safety
2.3DealerInformation
Invacarerecommendsleavingafullcylinderof
oxygenwiththepatientaftersettinguptheHomeFill
compressor .
BeforeleavingaHomeFillCompressorwithauser,the
followingchecklistMUSTbecompleted:
qMakesurethepressuretestoncylinderhasnotexpired.
qInstructtheuseronthesafeoperationofthe
concentratorandreviewallwarnings.
qInstructtheuseronthesafeoperationoftheHomeFill
compressorandreviewallwarnings.
qLeaveafullcylinderofoxygenwiththeuser.
qLeaveacopyofallwarningsandllinginstructionswith
theuser.
2.4Double-InsulatedProducts
CAUTION!
–DONOTunplugthepowercordbypullingon
thecord.Tounplug,grasptheplugnotthe
cord,otherwisedamagemayoccur .
Inadouble-insulatedproduct,twosystemsofinsulation
areprovidedinsteadofgrounding.Nogroundingmeansis
requiredonadouble-insulatedproduct,norisameansfor
groundingtobeaddedtotheproduct.Adouble-insulated
productismarkedwiththewords“DOUBLEINSULATION”or
“DOUBLEINSULATED”orthesymbol:
2.5EMCInformation
WARNING!
RiskofInjuryorDamage
Toreducetheriskofinjuryorproductdamage
frominterferencewithwirelessequipment:
–Keepthecompressoratleast9.8ft(3.0m)
awayfromwirelesscommunicationequipment
suchaswirelesshomenetworkdevices,mobile
phones,cordlessphonesandbasestations,
walkie-talkies,etc.
MedicalElectricalEquipmentneedstobeinstalledandused
accordingtotheEMCinformationinthismanual.
Thisequipmenthasbeentestedandfoundtocomply
withEMClimitsspeciedbyIEC/EN60601-1-2forType
BFequipment.Theselimitsaredeterminedtoprovide
reasonableprotectionagainstelectromagneticinterference
inatypicalhomehealthcareenvironment.Thisequipment
isnotintendedforuseinaprofessionalhealthcare
environment.
PortableandmobileRFcommunicationsequipmentcan
affecttheoperationofthisequipment.Thecompressor
maybestackedontoponanInvacareHomeFillcompatible
oxygenconcentratorduringsetup.Thecompressoroperation
shouldbeobservedtoverifynormalcylinderllingineither
situation.
Otherdevicesmayexperienceinterferencefromeven
thelowlevelsofelectromagneticemissionspermitted
bytheabovestandard.Todetermineiftheemissions
fromthecompressorarecausingtheinterference,turn
thecompressorOff.Iftheinterferencewiththeother
1100873-M11

Invacare®HomeFill®OxygenSystem
deviceoperationstops,thenthecompressoriscausing
theinterference.Insuchrarecases,interferencemaybe
reducedorcorrectedbyoneofthefollowingmeasures:
•Reposition,relocate,orincreasetheseparationbetween
thedevices.
•Connecteitherlinepowereddevicetoadifferent
electricalpowercircuit.
ContactInvacareforanyadditionalEMCinformationorEMC
tablesforthedeviceenvironment.
121100873-M

Setup
3Setup
3.1Unpacking
PARTNUMBERDESCRIPTION
1102311CompressorAssembly
1102315PackagingAssembly
1105177SupplyLineAssembly
1112949PowerCord
1100873UserManual(notshown)
1.Checkforanyobviousdamagetothecartonorits
contents.Ifdamageisevident,notifythecarrier,or
yourlocaldealer .
2.Removeallloosepackingfromthecarton.
3.Carefullyremoveallofthecomponentsfromthecarton.
UnlessthecompressoristobeusedIMMEDIATELY ,
leavethecompressorinitspackagingforstorage
untiluseofthecompressorisrequired.
3.2CompressorInitialSetupChecklist
DealersONLY—Referto2.3DealerInformation,
page11beforeperformingthisprocedure.
UsersONLY—ContactyourInvacaredealeror
Invacareforassistancewiththesetupprocedureand
toreportunexpectedoperationorevents.
BeforeoperatingtheHomeFillCompressorforthersttime,
completethefollowingchecklist:
qChoosealocationforthecompressor .
qTransportthecompressortothedesiredlocation.
qConnectthepowercordtothecompressor.
1100873-M13

Invacare®HomeFill®OxygenSystem
qConnectthecompressortotheconcentrator.
3.3ChoosingaLocation
DANGER!
RiskOfDeath,Injury,OrDamageFromFire
Textiles,oilorpetroleumsubstances,grease,
greasysubstancesandothercombustiblesare
easilyignitedandburnwithgreatintensityin
oxygenenrichedairandwhenincontactwith
oxygenunderpressure.Toavoidre,death,
injuryordamage:
–DONOTSMOKEwhileusingthisdevice.
–DONOTusenearOPENFLAMEorIGNITION
SOURCES.
–DONOTuseanylubricantsonthecompressor
unlessrecommendedbyInvacare.
–NOSMOKINGsignsshouldbeprominently
displayed.
–Avoidcreationofanysparknearoxygen
equipment.Thisincludessparksfromstatic
electricitycreatedbyanytypeoffriction.
–Keepallmatches,lightedcigarettesorother
sourcesofignitionoutoftheroominwhich
thiscompressorislocatedandawayfrom
whereoxygenisbeingdelivered.
–Keeptheoxygentubing,cord,andcompressor
outfromundersuchitemsasblankets,
bedcoverings,chaircushions,clothing,and
awayfromheatedorhotsurfacesincluding
spaceheaters,stoves,andsimilarelectrical
appliances.
Thecompressorshouldbeatleastthreeinchesawayfrom
walls,draperiesorfurnituretoensuresufcientairow.
Avoidplacingthecompressornexttoheaters,radiatorsor
hotairregisters.
DONOTuseinacloset.
Thecompressorshouldsitonahardatstablesurface,such
asatableortheReadyRack.
3.4TransportingtheCompressor
WARNING!
–NEVERtransportacompressorwithacylinder
connectedtoorstoredonthecompressor,
otherwiseinjuryordamagecanoccur .
CAUTION!
–Whentransportingthecompressor,becareful
nottobumpthecompressorortheconnectors
intoobstacles.Otherwise,damagetothe
compressormayoccur.
141100873-M

Setup
1.Therearetwomethodstosafelytransportthe
compressor:
•OneHand-GraspthehandgripAatthebottom
rearofthecompressor.
•TwoHands-GraspthehandgripsBonthesides
ofcompressor.
3.5InstallingthePowerCord
Thisproductmaycomewithapolarizedplug(one
bladeiswiderthantheother).Asasafetyfeature,
thisplugwilltinapolarizedoutletonlyoneway.
Iftheplugdoesnottfullyintheoutlet,reverse
theplug.Ifitstilldoesnott,contactaqualied
electrician.DONOTattempttodefeatthissafety
feature.
1100873-M15

Invacare®HomeFill®OxygenSystem
1.Chooseaproperlocation.Referto3.3Choosinga
Location,page14.
2.MakesurethepowerswitchisintheOff(O)position.
3.PlugthepowercordintotheelectricconnectorAin
thebackofthecompressorB.
4.PlugtheoppositeendofthepowercordCintothe
walloutletD.
5.Leaveaminimumof3”(7.6cm)clearancetothepower
cordendsfordisconnectionaccess.
Thepowerinletactsasthemainsdisconnection
devicetoremoveallpowertotheunitwhenthe
linecordisdisconnected.
3.6ConnectingtheCompressortothe
Concentrator
1.InsertoneendoftheinterconnecthoseCintothe
outletttingBonthebackoftheconcentratorA.
2.Inserttheoppositeendoftheinterconnecthoseinto
theinletttingDonthesideofthecompressor.
ThemetaltabsEontheconcentratoroutlet
ttingandthecompressorinletttingwillpop
outwithanaudible“click”whentheendofthe
interconnecthoseisproperlyinstalled.
3.Loopanyexcessinterconnecthoseandsecuretothe
backoftheconcentratorwiththefasteningstraps.
161100873-M

Usage
4Usage
4.1CompressorOperationChecklist
EachtimetheHomeFillCompressorisusedtollacylinder,
completethefollowingchecklist:
qEnsuretheconcentratorhasbeenOnforatleastthirty
minutes.RefertotheconcentratorUserManual.
qPerformtheprellinspectiononthecylinder.
qConnectthecylindertothecompressor .
qPushthecompressorpowerswitchtotheOn(I)
position.
qExaminetheindicatorlightsonthecontrolpanel.
qDisconnectandremovethefullcylinder .
qPushthecompressorpowerswitchtotheOff(O)
position.
qIfllinganothercylinder,repeatthischecklist.
4.2CylinderPrellInspection
WARNING!
–ONLYusecylindersthathavetheInvacare
HomeFillconnectionandHomeFilllabel.
–AllcylindersMUSTbeinspectedbefore
attemptingtoll.Otherwise,injuryordamage
mayoccur .
ToidentifyaHomeFillcompatiblecylinderA,lookfora
blackstripeBinthegreenareaConthetopofthe
cylinderandlookfortheHomeFilllabelD.
1100873-M17

Invacare®HomeFill®OxygenSystem
TheHydrostaticTestingDate
AluminumcylindersMUSTundergotestingeveryveyears.
WARNING!
–DONOTllcylindersthathavenotbeentested
inthepastveyears.Otherwise,serious
personalinjurymayresult.Contactyourdealer
forreplacement.
ExternalExamination
1.Examinetheoutsideofthecylinderforthefollowing
conditions,andreplacethecylinderiftheyexist:
•Dentsordings
•Arcburns
•Oilorgrease
•Anyothersignsofdamagethatmightcausea
cylindertobeunacceptableorunsafeforuse.
2.Examinethecylinderforevidenceofreorthermal
damage.Evidenceincludescharringorblisteringof
thepaint,orotherprotectivecoatingorheatsensitive
indicator .Ifreorthermaldamageisfound,replace
thecylinder.
3.Inspectthecylinder/regulatorassemblyforthefollowing
andreplaceiffound:
•Debris,oilorgrease
•Noticeablesignsofdamage
•Signsofcorrosioninsidethevalve
•Signsofexcessiveheatorredamage
181100873-M

Usage
4.3ConnectingtheCylindertotheCompressor
WARNING!
–NEVERusetoolsofanykindto
connect/disconnectthecylinderandthe
compressor .Otherwise,severeinjuryand/or
damagemayoccur.
WARNING!
–DONOTdropoxygencylinders.Usetwohands
whenhandling/transportingoxygencylinders.
Otherwise,injuryordamagemayoccur .
–DONOTusealiquidleakdetectortotestfor
leaks.
Fillportcoversnotshownforclarity.
1.Examinethecylindergauge.Ifthecylinderpressureis
lessthan1500psig,proceedtoSTEP2.
Forlocationofthecylindergauge,refertothe
cylinder’smanual.
Ifthecylinderpressureisgreaterthan1500
psig,DONOTattempttotopoffthiscylinder .
Itmaynotll.
2.SettheregulatorowdialonthecylinderAtoOff.
Refertothecylinder’smanual.
1100873-M19

Invacare®HomeFill®OxygenSystem
3.Removethecylinderandconnectorllportcovers(if
present).
4.MomentarilypushDOWNontheouterring(sleeve)B
oftheconnectorllportCuntilGREENdotsDare
visibletoresettheconnector.
Iftheouterring(sleeve)isintheUPposition
(GREENdotsnotvisible),theconnectorllport
willnotbeabletoacceptthecylinderllportE.
PushingDOWNFmomentarilywillresetthe
connectorllport(GREENdotsvisible)toaccept
thecylinderllport.
5.Graspthecylinderintheareabehindthecylinder
llport.
6.PositionthecylinderinthecompressorcradleG.
7.Alignthecylinderllportwiththeconnectorllport.
8.PullUPontheouterring(sleeve)oftheconnector
llportwhilepushingDOWNonthecylindertocouple
thecylinderllportintotheconnectorllport.
Thecylinderisproperlyconnectedwhenan
audible“click”isheard.
4.4DisconnectingtheCylinderfromthe
Compressor
WARNING!
–NEVERusetoolsofanykindto
connect/disconnectthecylinderandthe
compressor .Otherwise,severeinjuryand/or
damagemayoccur.
1.PressthecompressorpowerswitchAtotheOff(O)
position.
2.GraspthecylinderBintheareabehindthecylinder
llportC.
201100873-M
