Invacare 9153644014 Assembly instructions

Part No 1130250 1Installing Front Riggings on the At’m
For more information regarding Invacare products, parts, and services,
please visit www.invacare.com
Installing Front Riggings on the At’m
Kit Numbers: 9153644014, 9153644018
NOTE: Check all parts for shipping damage. In case of damage, DO NOT use. Contact
Carrier/Invacare for further instructions.
Safety Summary
To ensure the safe and proper installation and use of the front riggings on the At’m, these
instructions MUST be followed:
 WARNING
After ANY adjustments, repair or service and BEFORE use, make sure that all
attaching hardware is tightened securely - otherwise injury or damage may result.
Invacare products are specifically designed and manufactured for use in conjunction
with Invacare accessories. Accessories designed by other manufacturers have not
been tested by Invacare and are not recommended for use with Invacare products.
Description of the Kit
Kit Numbers 9153644014 and 9153644018 for Red or Blue At’m Front Riggings contain:
Installing Front Rigging Support Brackets
NOTE: For this procedure, refer to FIGURE 1.
NOTE: Perform the following steps one (1) side at a time.
1. Remove the plug button from the seat frame tube.
2. Note the orientation of the hardware that connects front seat support tube to the seat
frame tube.
3. Remove the mounting screw, coved washers, spacers, washers and locknut securing
front seat support tube to the seat frame tube. DO NOT discard.
Assembly, Installation and Operating Instructions
SAVE THESE INSTRUCTIONS
PART NUMBER DESCRIPTION QUANTITY
1132651 Right Legrest Support Assembly 1
1132652 Left Legrest Support Assembly 1
1133151 Mounting Hardware Assembly 1
1134702 70° Complete Right Footrest Assembly 1
1134703 70° Complete Left Footrest Assembly 1

Installing Front Riggings on the At’m 2Part No 1130250
4. Insert the proper (right or left) front rigging support bracket into the seat frame
tube until two (2) of the four (4) mounting holes on the front rigging support
bracket are aligned with the two (2) mounting holes in the seat frame tube.
CAUTION
Two (2) mounting screws are used to secure the front rigging support
bracket to the seat frame tube for any mounting position used.
5. Install the existing mounting screw, coved washers, spacers, washers and
locknut that secure front seat support tube to the seat frame tube in the
orientation noted in STEP 2. DO NOT tighten locknut at this time.
6. Install the new mounting screw, spacer and locknut (hardware supplied)
through the large mounting hole on the seat frame tube. Securely tighten.
NOTE: Make sure that the spacer is aligned with the large mounting hole in the seat frame
tube and is properly seated against the front rigging support bracket during and after
tightening. Refer to Detail “A” of FIGURE 1.
7. Tighten the locknut securing the front seat tube to the seat frame until it is snug
and then turn an extra 1/8-turn. DO NOT over-tighten as this is a pivot joint
when folding the seat.
8. Repeat STEPS 1-7 to install the front rigging support bracket on the other side.
FIGURE 1 Installing Front Rigging Support Brackets
Coved Washers
Spacer
Spacer Locknut
Locknut
Existing Mounting
Screw
New Mounting
Screw
Spacer
Front Rigging
Support
Bracket
Front Seat
Support
Tube
Seat Frame Tube
Front Rigging
Support
Bracket
Spacer
Front Seat
Support Tube
Seat Frame Tube
*Large
Mounting Hole
*Small
Mounting Hole
Mounting Holes
on Front Riggings
Support Bracket
DETAIL “A”
*NOTE: Mounting hole
arrangement on 16-inch wide
seat shown. On the 18-inch
wide seat, the mounting hole
positions are reversed.

Part No 1130250 3Installing Front Riggings on the At’m
Installing/Removing the Front Rigging Assembly
NOTE: For this procedure, refer to FIGURE 2.
Installing
1. Turn the front rigging assembly to the side (open footrest is perpendicular to
the wheelchair).
2. Insert the mounting pin on the front rigging assembly into the front rigging
support bracket.
3. Rotate the front rigging assembly towards the inside of the wheelchair until it
locks into place.
NOTE: The footplate will be facing the inside of the wheelchair when locked in place.
4. Repeat STEPS 1-3 for the other front rigging assembly.
5. If necessary, adjust the footrest height. Refer to Adjusting Footrest Height on
page 4.
Removing
1. Push the front rigging release lever inward while rotating the front rigging
assembly outward.
2. Lift the front rigging assembly out of the front rigging support bracket.
3. Repeat STEPS 1-2 for the other front rigging assembly, if necessary.
FIGURE 2 Installing/Removing the Front Rigging Assembly
Seat Frame Tube
Footrest
Mounting Pin
Front Rigging
Assembly
Front Rigging
Support Bracket
Front Rigging
Release Lever
Outside of
Wheelchair
Inside of
Wheelchair

Adjusting Footrest Height
NOTE: For this procedure, refer to FIGURE 3.
1. Remove the front rigging assembly. Refer to Installing/Removing the Front Rigging
Assembly on page 3.
2. Remove the hex screw and coved spacer.
3. Move the footrest with slide tube up or down on its mounting tube until the desired
footrest height is achieved.
4. Install the hex screw and coved spacer through the front rigging upper support and
the slide tube. Securely tighten.
5. Install the front rigging assembly. Refer to Installing/Removing the Front Rigging
Assembly on page 3.
6. Repeat STEPS 1-5 for the other side, if necessary.
FIGURE 3 Adjusting Footrest Height
Footrest
Slide Tube
Coved Spacer
Hex Screw
Front Rigging
Upper Support
Invacare Corporation www.invacare.com
USA
One Invacare Way
Elyria, Ohio USA
44036-2125
800-333-6900
Canada
570 Matheson Blvd E Unit 8
Mississauga Ontario
L4Z 4G4 Canada
800-668-5324
Invacare is a registered trademark of
Invacare Corporation.
Yes, you can. is a trademark of Invacare
Corporation
© 2005 Invacare Corporation
Part No 1130250
Rev A - 06/05
