Invacare Action 2NG User manual

This manual must be given to the user of the product.
Before using this product, read this manual and safe for future reference
Invacare® Action® 2 NG Range
User guide EN

1
Foreword
The information contained in this manual is subject to change without notice. Some information is submitted
under copyright – all rights reserved. Any information in this document cannot be photocopied or duplicated
without prior written authorization by Invacare.
As the European and world's leading manufacturer of wheelchairs, Invacare endeavours to supply a wide
range of wheelchairs to meet all the needs of the user in everyday life. However, nal selection of the wheel-
chair rests solely with the user and his/her qualied health advisor.
Proper and efcient use of the wheelchair that you have chosen is based upon the medical prescription
which was issued for you on the basis of your pathology and the nature of your disability.
Your wheelchair is especially designed to be used indoors, and with certain restrictions outdoor.
(Please look at Warning paragraphs; Part A General Guidelines). Please comply with trafc regulations.
Stamp of the Distributor

1
Introduction
Dear Customer
Thank you for purchasing an Invacare wheelchair.
This model was designed to provide you with all the benets and features to meet your needs. Only
quality components were selected for your wheelchair based upon rigorous inspections during the entire
manufacturing process.
This manual describes the operating limits of your wheelchair, maintenance operations and adjustments
that you or your assistant can make.
However, all the repairs (except for inner tubes) as well as some adjustments, require specic technical
training and, therefore, must be performed by your distributor.
The Invacare® Action®
2 NG range is designed for both indoor and outdoor use with the purpose of
helping people who are not able to walk over a long distance.
Even though your Invacare® wheelchair has been designed to provide a long and trouble free life it is
inevitable that wear, tear and usage will eventually render the product unusable. Invacare® recommends
that the average usable life of this product is ve years, providing the product has been correctly
maintained according to the manufacturers recommendations.

2
3
A. GENERAL GUIDELINES
Page
1. Safety and operating limits
1.1. Reaching an object from the chair 3
1.2. Transferring to other seats 5
1.3. Tilting 6
1.4. Tilting, Kerbs 6
1.5. Stairways 7
1.6. Slopes 7
2. Operating instructions
2.1. Folding and Unfolding the wheelchair 8
2.2. Wheelchair propulsion 9
2.3. Lifting the wheelchair 9
3. Safety inspection and maintenance
3.1. Performance control 10
3.2. General inspection 10
4. Transportation 11
4.1. Test report 11
4.2. Observations 12
4.3. Restraint systems 13
5. Summary of warranty terms 14
5.1. Standard terms 14
5.2. Limitation of liability 14
6. Operating instructions for optimal safety 14
B. DESCRIPTION OF YOUR WHEELCHAIR
Page
1. Presentation
1.1. Introduction 15
1.2. General description 15
2. Adjustments
2.1. Seat elements 16
2.1.1 Seat upholstery 16
2.1.2 Type of backrest 17
2.1.3 Backrest upholstery 18
2.1.4 Footrest supports 18
2.1.5 Armrests 19
2.2. Frame 20
2.2.1 Side frame 20
2.2.2 Folding system 20
2.3. Rear wheel 21
2.3.1 24" wheels 21
2.3.2 Handrims 21
2.3.3 Axles 22
2.4. Castors 22
2.4.1 8" wheels 22
2.4.2 Front fork 22
2.5. Brakes 23
2.5.1 Manual brakes 23
2.6. Options 24
2.6.1 Seating options 24
2.6.2 Propulsion options 24
2.6.3 Safety equipment and options 24
3. Specication and tool's
3.1. Standard wheelchair specifications 26
3.2. Tools for adjustments and regular maintenance (Not supplied) 27
3.3. Dimensions 27
TABLE OF CONTENTS

2
3
within the points of contact of the forward and rear wheels
with the ground.
- Weight Limit
The maximum recommended weight of the user is 125kg.
However, the level of activity is an essential factor. For
example, an active user who weighs 75 kg may subject the
wheelchair to more stress than user who weighs 100 kg. To
this purpose, we recommend that you consult your retailer
when choosing the model of wheelchair based upon your
daily life style.
1.1. Reaching an object from the chair
The limitations on reaching out from a wheelchair indicated
in the following diagrams have been calculated based on a
representative sample of wheelchair users:
- Only the arms should be extended beyond the seat of the
wheelchair. (gure 2).
- In any case the body and head shouldn't remain without the
boundaries of the seat. (gure 3).
123
A GENERAL GUIDELINES
1. Safety and operating limits
For a safe operation of your wheelchair, the following para-
meters should be observed :
- Stability and balance
Your wheelchair has been designed to provide the stability
you need during normal daily activities.
Any movement in the wheelchair will have an impact on
the position of the centre of gravity, which may lead to the
wheelchair tipping and a fall.
To improve your safety when you move a lot or you trans-
fer your weight from one place to another, we recommend
using seat belts.
- Weight distribution (gure 1)
Many actions cause the user of a wheelchair to reach out,
lean over or move about within the wheelchair and outside
it. Any movement you make whilst sat in your wheelchair
will move the combined centre of gravity (Gc) of you and
the wheelchair (Gw). You will remain stable in the wheel-
chair whilst the line of your combined centre of gravity lies

4
5
1.1.1 Leaning forward
Do not extend your chest beyond the armrest (gure 4).
In order to reach an object in front of you, you must lean and
bend down ; therefore, you must use the castors as a tool
(pointing them forward) to maintain stability and balance. An
accurate alignment of the wheels is essential for your safety
(gure 5).
1.1.2 Leaning backward
Position wheelchair as close as possible to the desired object
so that you can simply pick it up by stretching your arm
while sitting in the chair in a normal position (gure 6). In any
case, do not lean backwards because you may cause the chair
to tip (gure 7).
Warning :
The hanging of additional load (back pack or similar items)
onto your chair backposts can affect the rearward stability of
your chair, especially when used in combination with recliner
backrests. This can cause the chair to tip backwards causing
injury. Therefore, Invacare® strongly recommend the use
of anti-tippers (available as an option) when using your
backposts with additional load (back pack or similar items).
5 7
6
4

4
5
1.2. Transferring to other seats
1.2.1 Sideways transfer
This may be done without assistance provided that you are
sufciently mobile and have a strong enough torso.
- Move the wheelchair as close as possible to the seat
to which you would like to sit, with the castors pointed
forward. Lock the rear wheels by applying the brakes.
Fold both footplate up and push the footrest/legrest to
the side, remove / swing away the armrest to facilitate the
transfer.
Shift your body towards the place where you want to sit
while distributing your weight to the arms and hands
(gures 8 & 8A).
- While moving from the wheelchair to the seat, your body
will have little or no support. Where possible use a transfer
board during transfers.
1.2.2 Front transfer (gure 9)
If you are more or less able to stand up and if your upper
body is strong and mobile enough, you can transfer forward
to another seat.
If you nd this movement difcult, we recommend that you
obtain some assistance from an attendant or carer to ensure
the transfer is as smooth and safe as possible.
Lock both brakes and ensure both castor wheels are facing
the forward position.
Please note that the brakes should not be used in any case as
support for transfers. Fold the footplate up, then grip rmly
the armrest handle, take care of your nails on the skirt-guard
edges.
Push on your arms to easily lift yourself up and the attendant
can help you to nalise the transfer to the place where you
wish to sit.
Warning :
- Position yourself as close as possible to the place where
you wish to sit.
88A 10
9

6
7
- When transferring, position yourself as far back as possible
in the seat to prevent breaking screws, damaging the seat
upholstery or causing the wheelchair to tip forward.
- Lock the two brakes ; they should not be used in any case
as support for transfers.
- Never stand on the footrests when you are getting in or
out of the wheelchair (gure 10).
1.3. Tilting (balancing on the rear wheels)
For greater safety, this operation must be performed by an
attendant. The attendant should be aware of the required
physical effort and use appropriate positioning in order to
relieve the strain on his/her back (keep a straight back and
bend your knees during this operation).
To tilt the wheelchair, the attendant must rmly grab the han-
dles making sure both are properly xed. Warn the occupant
in the wheelchair before tilting it and remind him / her to
lean backwards and make sure that both feet and hands of
the user are clear of the wheels.
Place a foot on the footstep tube and move continuously
until the chair reaches the equilibrium point. At this stage, the
assistant will feel a difference in weight distribution, which
usually occurs at approximately 30°. At this point, the
wheelchair can get over the obstacle easily.
Finally, the attendant slowly and gradually lowers the front
down to the ground, while rmly holding the handles.
Warning :
- Be aware of detachable parts such as armrests or legrests :
they must NEVER be used as lifting supports as they may be
inadvertently released, resulting in possible injury to the user
and / or attendant.
- Do not lower the wheelchair suddenly, even if it is several
centimetres from the ground, as this may result in injury of
the user.
1.4. Tilting, Kerbs
To get on the pavement :
- Method 1 (gure 11)
The attendant positions the wheelchair in front of the pave-
ment facing forward. Press down on the lower tube of the
frame (or on tipping levers, delivered as an option) as well
as pulling on the push handles. Attendant tilts the wheelchair
backwards until the castors reach the pavement; attendant
pushes the wheelchair forward until the rear wheels are
against the kerb and again pushes the wheelchair until the
rear wheels climb over the kerb.
11 12

6
7
- Method 2 (gure 12)
In this case, the attendant stays on the pavement and tilts
the wheelchair in a backwards position with the rear wheels
against the kerb. The attendant tilts the wheelchair bac-
kwards until it is balanced and pulls the wheelchair with a
steady movement until the rear wheels climb over the kerb ;
then he / she lowers the castors, while making sure that the
chair is far enough on the pavement so that the castors do
not fall into empty space.
To get off the pavement :
The attendant positions the wheelchair facing forward on
the pavement and tilts it backwards until it is balanced, then
he/she pushes the wheelchair forward until the rear wheels
touch the road after getting over the obstacle; then, he / she
gradually lowers the castors to the ground.
1.5. Stairways
Because this is a difcult movement, we recommend using
two attendants, one in front of the wheelchair and one
behind the wheelchair.
Warning :
We recommend that users over 100 kg in weight do not use
this stairway manoeuvre !
To climb stairway (gure 13) :
After tilting the wheelchair to the point of equilibrium, one
assistant (at the back) holds the wheelchair up against the
rst step grasping the handles rmly to lift.
The second assistant, lifts the wheelchair above the stairs,
while holding rmly a xed part of the frame, and holds it
while the rst assistant takes a step and repeats the opera-
tion. The wheelchair must not be lowered until the last step
has been passed and the chair is clear of the stairs.
To descend stairways :
Same operation as above, however, reverse steps as above.
Warning :
- Do not attempt to lift the wheelchair by any removable
parts (such as armrests, legrests or footrests).
- Avoid using an escalator which may lead to serious injury
in the event of a fall.
13 14

8
9
1.6. Slopes
It is recommended to avoid using ramps with a slope higher
than 9°. The wheelchair risks tipping over in the event of
spinning or side movement (gure 14).
Upward slopes (gure 15) :
Lean the upper body forward and your centre of gravity will
move forward to a more stable position. Now move the
wheelchair forward with short quick pushes on the hand
rims to maintain speed and direction control. If you want to
rest, apply both brakes when stopping.
Downward slopes (gure 16) :
Lean backward cautiously and your centre of gravity will
move backward to a more stable position. Now let the hand
rims slide in your hands. Be ready to react at any moment to
control speed and direction.
Warning :
The position of the rear wheel axle and the angle of your
wheelchair’s backrest are two of the key adjustments that can
affect your stability whilst sat in the wheelchair (see figure
14A).
- Avoid turning suddenly and never try to climb and descend
a ramp diagonally (figure 17).
18
16 17
15
Warning :
It is recommended to avoid using ramps with a slope greater
than 9 degrees and do not attempt to turn whilst on a slope.
The wheel position is usually factory set and should not be
change unless by the direction of a competent person who
must have assessed the impact of the change on your stability
in normal use. If your wheelchair is tted with a recliner
backrest it is recommended that anti tippers are also tted
and used whenever the backrest is reclined from the upright
position.
2. Operating instructions
2.1. Unfolding and Folding the wheelchair
2.1.1 Unfolding the wheelchair (gure 18) :
- With one hand, grab the armrest or the seat support tube
on one side of the wheelchair and slightly tilt it towards you
(so that the rear wheel and castor lift from the ground) ;
- With the other hand, push on the seat tube until upholstery
is fully extended and seat tube sits in receiver.
eg : Standard configuration
for fixed backrest
14A

8
9
- Then, engage the two manual brakes, open the footrest/
legrest and check the ground clearance (footrest/ground
distance - see paragraph B-2.1.4). You can now sit down in
the wheelchair.
2.1.2 Folding the chair (gures 19 and 20) :
- Fold and lock the footrest/legrest toward the front of the
wheelchair.
- Swivel the plates into the vertical position. Using both
hands, take the centre front and back edges of the seat
upholstery and lift it. Or, tilt the wheelchair to one side
and close it using the handles on the backrest.
Warning :
- Fold the wheelchair while keeping the seat upholstery
upwards to avoid damage by the folding system.
- Caution possible finger pinch.
2.2. Wheelchair propulsion
Self propelling wheelchair propulsion is achieved through the
use of the handrims mounted on the wheels.
The distance between the wheels axle position and the seat
height can be adjusted to allow you to hold the handrims
properly.
Qualied medical and paramedical staff will be able to
provide you with advice regarding the propulsion which is best
adapted to your disability.
Any wheels adjustments to the set up of your wheelchair (see
paragraph 2.2.2) should only be performed at the direction of
a competent person who has fully risk assessed the implication
of any changes to the wheelchair conguration.
2.3. Lifting the wheelchair
First, fold the chair (see paragraph 2.1.2), always lift the wheel-
chair by gripping the frame at the points (A) shown in the
gure 21.
Warning :
Never lift the wheelchair by removable parts (armrests, foo-
trests). Ensure the backrest posts are securely in place.
19
20
A
21

10
11
3. Safety inspection and maintenance
3.1. Performance control
As the user, you will be the rst to notice any possible
operational defects with your wheelchair. The following table
indicates the easiest troubleshooting symptoms to identify
and the preliminary inspection that you can perform.
In the event that the symptoms persist after adjusting the
pressure in the tyres, please consult your retailer.
The inner tubes of the wheels are the only components that
you can repair yourself (see paragraph B-2.3).
If the screws and nuts are not tight enough or loose, the axle
fork angle is not perpendicular to the ground, please consult
your retailer to get a competent person to re-set them to
the correct position and tighten appropriately.
(Recommended torque minimum : M5 = 4 Nm; M6 = 7 Nm
& M8 = 17 Nm)
3.2. General inspection
Your distributor, who has the required technical expertise, is
responsible for any wheelchair repairs.
We recommend that you take the wheelchair to your
retailer at least once a year for a complete inspection.
Regular maintenance allows the identication and replace-
ment of defective and worn parts, which improves the daily
operation of your wheelchair.
Regular inspections to be performed by you or your
assistants :
a. General
Make sure that the wheelchair folds and unfolds easily.
Make sure that the wheelchair moves in a straight line. (no
resistance or deviation)
b. Manual brakes
Make sure that the manual brakes do not touch the moving
tyres.
Make sure that the manual brakes operate easily.
Make sure that the joints are not worn and do not have play.
c. Folding system
Check the folding system for worn or distorted parts.
d. Skirtguard/armrest upholstery
Make sure that all the ttings are properly tightened.
e. Armrests
Make sure that the armrests are rmly attached, but easy to
remove.
f. Armpad
Make sure that the armpads are in good condition.
The
wheelchair
swerves
to the
right
The
wheelchair
swerves
to the left
The
wheelchair
turns or
moves
slowly
The
castors
lift
Creaking
and
clinking
Play in
the
wheelchair Inspections
Make sure that
pressure in the
pneumatic tyre is
correct (cf. § B-2.3)
Make sure that the
bolts are tight
Check the adjustment
on the fork angle
Make sure that the
2 castors come in
contact with the
ground at the same
time

10
11
g. Seat and backrest upholstery
Make sure that the upholstery is in good condition.
h. Rear wheels
Make sure that the wheel nuts and precision bearings are
tight.
Make sure that the wheels are parallel to the frame.
i. Handrims
Check for rough patches.
j. Spokes
Make sure that the spokes are not distorted, loose or bro-
ken.
k. Castors
Make sure that the axle is tight by turning the wheel the
wheel must gradually come to a stop.
l. Fork/steering tube
Make sure that all the ttings are well tightened.
m. Pneumatic and solid tyres
Check the pressure of the pneumatic tyres (Rear=350 kPa)
check the wear of the solid tyre tread.
n. Cleaning and disinfection
Cleaning: Use only damp clothes and gentle detergent.
Do not use abrasive or scouring liquid. Rinse the wheel-
chair with a high-pressure cleaning or ordinary jet of water
depending on how dirty the chair is. Do not aim the jet
towards ball bearings (front & rear wheels, fork axles) and
drainage holes.
Make sure you dry the wheelchair if it is wet (e.g. after
washing it or going out in the rain).
Disinfection: Spray or wipe disinfection using a tested and
recognised product is permitted.
Please pay attention to the manufacturer's instructions of the
medical product disinfectant you are using.
4. Transportation
Transport of wheelchairs in vehicles
The Invacare® Action® 2 NG range has been tested for
safety in collisions according to ISO-7176-19:2001, Invacare®
Action® 2 NG can be used for transport in vehicles that have
been specially adapted for this purpose. The wheelchair must
be securely fastened in the vehicle according to the methods
described on the following pages.
Remember that the best solution is always to move
the user from the wheelchair into a normal car seat
and to stow the wheelchair safely and securely in a
separate compartment.
Test no : S10757 (Self propulsion)
Customer : Invacare UK Ltd,
Date : 24.04.2009
Test no : S10880 (Transit version)
Customer : Invacare UK Ltd,
Date : 01.09.2009
The safety restraint devices used in this test must be approved
according to ISO-10542. We have chosen to work with Unwin,
a well-known quality manufacturer of safety restraint devices
for wheelchairs. Restraint system manufacturer may improve
its products, please contact them for more details.

12
13
4.1. Observations before transport of wheelchairs in
vehicles
• We recommend that wheelchair users should transfer to the
seat of the vehicle and use the installed restraint system of the
vehicle whenever feasible.
• The wheelchairs are tested in a basic conguration. The use
in other congurations has not been tested. Please contact
your dealer for further information.
• Auxiliary wheelchair equipment is either secured to the
wheelchair or removed from the wheelchair and secured in
the vehicle during transit. (i.e. table trays).
• Alterations or substitutions are not to be made to points of
the wheelchair or to structural and frame parts without the
written consent of Invacare®.
• A wheelchair-anchored posture belt with metal buckle must
be tted across the wheelchair occupant in addition to the lap
and diagonal occupant restraint (3-point belt).
• Belt restraints are not to be held away from the body by
wheelchair components or parts such as armrests, postural
restraints, wheels, etc. (Picture 22)
• The wheelchair must be securely fastened in the vehicle with
an ISO 10542-2 approved 4-point belt system, according to
the methods described in the manual.
• The occupied wheelchair must be tied down in an forward-
facing position, with the parking brake applied.
• The wheelchair backrest should be positioned as close as
possible to 90 degrees.
Please observe that even if these products and recommen-
dations are provided in order to increase safety, injury to
vehicle occupants still might occur in the event of a collision
or other accidents and no guarantee is given in this respect.
Correct and incorrect placements of 3-point belt
(picture 22).
4.2. Restraint systems (picture 23A, details A & B)
* Non contractual picture, only for information !
Please refer to best practice recommended instructions from
the safety belt manufacturer.
A. Front restraints with straps (picture 23A & detail A)
1. Connect the front straps around the front part of the
frame. (See location of the attachment labels).
2. Release brakes and apply tension front straps by pulling the
wheelchair backwards from the rear.
3. Re-apply wheelchair brakes.
B. Rear restraints (picture 23B for Self propelling & 23C
for Transit version)
1. Attach the snap hooks on the rear straps to the rear
orange ring (A) just below the backrest tube bracket.
2. Tighten the straps.
Warning :
No other rear attachment is permitted!

12
13
C. Posture belt
1. The posture posture belt is mounted on the back frame
(picture 24).
2. Check that the posture belt on the wheelchair is correctly
fastened.
If posture belt on the wheelchair is missing we recommend
that the user should transfer to the seat of the vehicle, if
possible. The posture belt should be used in addition to but
never as a substitute for an approved passenger restraint
system (3-point belt).
D. Fastening of 3-point belt (vehicle safety belt device).
Although all three points may be anchored to the vehicle
oor, the diagonal belt passing over the users shoulder should
be routed through a point above and behind the seated user
which is xed to the vehicle sides, before passing down to
the oor. The 3-point belt should not be kept from the user's
body by the parts of the wheelchair.
23A
B
A
C
22
23B
A
24
23C

14
15
6. Operating instructions for
optimal safety
- Maximum user’s recommended weight : 125 kg.
- Do not attempt to reach objects if you have to move
forward in the seat.
- Do not attempt to pick up objects from the oor by reaching
down between your knees.
- Do not lean over the top of the upholstery back to reach
objects located behind you : this may cause you to tip over
- Always engage both manual brakes simultaneously.
- Manual brakes are parking brakes : they must not be used in
any way to slow down the wheelchair or as support during
transfers.
- Do not tilt the wheelchair (down kerbs or steps) without
using an assistant. Press down on the lower tube of the frame
as well as pulling on the push handles
- Do not carry the wheelchair up or down stairway or esca-
lators with the user seated in the wheelchair, with only one
attendant. This may cause serious injury.
- Do not use the wheelchair unless it has the proper tyre
pressure (rear = 350 kPa).
- Do not overinate the tyres : this may cause the tyres to
explode and cause bodily harm.
- Do not expose the wheelchair to a temperature higher than
40°C.
- To avoid injury, keep your ngers away from mobile parts (ar-
mrests, folding system, legrests/footrests), and maintain good
posture before lifting the wheelchair.
Warning :
Avoid operating on wet areas as well as gravel, grass, etc. (sand
and sea water particularly damage ball bearings). When using
the wheelchair inside, we recommend using solid tyre castors,
especially when riding on carpet.
5. Summary of warranty terms
5.1. Standard Invacare terms and conditions
This is to certify that your manual wheelchair is warranted
by Invacare for a period of 2 years for the frame and cross-
bars, all others parts 2 years also but subject to the following
conditions :
- If a defect or fault is discovered the supplier / dealer from
whom the appliance was purchased should be notied imme-
diately.
- The manufacturer will not accept responsibility for damage
caused by misuse or non-observance of the instructions set
out in the user manual.
- During the period of warranty, any parts that have become
defective due to faulty workmanship or materials, will be
renewed or repaired without charge by the Invacare dealer/
supplier.
- The warranty will be forfeited should any unauthorised
alteration be made to the equipment.
- The Purchaser’s statutory rights under the Consumer
Protection Act are not affected.
5.2. Limitation of liability
This warranty does not extend to the consequential costs
resulting from fault clearance, in particular freight and travel
costs, loss of earnings, expenses, etc.
Invacare shall not be liable for :
- Natural wear and tear.
- Inappropriate or incorrect use.
- Defective assembly or setting-up by the purchaser or third
parties.
- Defective or neglectful treatment. Use of unsuitable spares.

14
15
B. DESCRIPTION OF YOUR WHEELCHAIR
1. PRESENTATION
1.1. Introduction
Your wheelchair has been factory set before you purchased
it. However, it must be specically adapted to your needs.
The following detailed paragraphs describe the various
functions and possible adjustments as well as available
options. You can make some adjustments yourself, while
others can be made only by your dealer.
Important: based upon the selected model or options, your
new Action2 NG wheelchair may be not equipped with all of
the components or options which are described in the
following pages.
NB: Some models or options are not be available in your
country.
This is a warning symbol, it is essential that the
instructions in these paragraphs are followed in
order to prevent personal injury to yourself and
others around you.
This is an information symbol about possibility to
contact your Dealer for more information.
1.2. General description (see photo)
Your wheelchair is made of various parts and this manual
describes only the main parts. We recommend that you
become acquainted with the following terms in order to
better understand your wheelchair operation :
 The seat consists of the seat and backrest upholstery,
the backrest and armrests. This unit is designed to provide
optimal comfort.
 The swing-away footrest support : this is the suppor-
ting part between the frame and the footrest which swivels
to facilitate transfers and can be removed during transport.
 The footrest consists of an adjustable tube and the
footplate which supports the foot.
 The folding frame consists of side frames and a folding
system including the seat rails. These parts constitute the
frame, which is the supporting component of the wheelchair
and its strength is well tested (checked at 125 kg).
 The rear wheel consists of the wheel, axle and handrim.
The position of the rear wheels relative to the seated user
determines the rearward stability and also the ease by wich
the user can propel the wheelchair using the handrims. They
are mounted on wheel support brackets .
Changing the rear wheel position will have a signicant
impact on the stability of the user.

16
17
 The castor consists of the front wheel and the fork. The
castors provide front contact with the ground and determine
the steering by the direction of the forks.
 The manual brake is a parking brake. The two manual
brakes are used to secure the wheelchair when stationary.
2. Adjustments
2.1. Seat
2.1.1 Seat upholstery
- Standard seats
• Nylon upholstery seat with or without Velcro fastener : the
Velcro fasteners are required for the proper positioning of
the cushion (photo 1) ; please make sure that the cushion is
properly positioned on the seat.
• Depth adjustable seat: fold the seat sightly. Lift up the front
part. Pull into required depth.
• Padded seat : it provides comfortable support to the user.
Standard seats are not adjustable; in the event that they
become slack, it is recommended that you ask your dealer to
replace them.
Always use upholstery equipped with Velcro fasteners
when you have a cushion in order to prevent sliding.
Adding a cushion to the seat will raise your height above
the ground and can affect your stability in all directions. If a
cushion is changed it may also change the users stability.
Seat
upholstery
Armrest
Backrest upholstery
Backrest
Footplate
Folding
frame
Rear wheel
Rear wheel axle
Handrim
Manual
brake
Front wheel
Armpad
Adjustable
footrest tube
Rear wheel
support
Swing away
footrest
1

16
17
A
Invacare provides a wide range of seat cushions adapted to
your needs. Please contact your dealer.
The upholstery and casing of the seat will wear, please
contact your dealer for possible replacement.
Make sure that the seat is properly positioned on the 2
seat rails to provide safety and comfort for the user.
Keep your ngers away from movable parts to prevent
injuries during folding and unfolding !
2.1.2 Type of backrests
- Folding backrest (photos 2 & 2A)
43 cm backrest height.
• To save space when transporting folded and unoccupied,
operate lever (A) by pulling it and fold the top of the backrest.
To return to the initial position, bring the top in the vertical
position; it locks automatically.
Always make sure that the backrest is properly locked
in place before the user settles down in the wheelchair to
prevent any injuries !
- Reclining backrest, 0° to 30°, 43 cm backrest height (photo 4).
The intended use of reclining backrest is to get a relaxing,
comfort position for the user. It is not indented to be used in
a dynamic situation and it should be used on horizontal sur-
face when the backrest is reclined (especially when the bac-
krest angle is more than 10°). Anti-tippers are recommended
for those who need to feel safer or have a specic usage.
Simultaneously pull the levers (A) to provides the same angle
on both sides, release the levers when you reach the desired
angle.(Photo 3)
There are 4 angles position by step of 10°.
Note : Push on the backrest canes before operating the levers,
this is to release the auto-locked security system. (Photo 3A).
It is recommended that this operation be performed
only by the attendant. Always make sure that the backrest is
locked in place to ensure perfect safety for the user.
Keep away ngers from moving parts (levers, cylinders,
mechanisms, etc.) to prevent injuries !
3A
A
2 2A 3A

18
19
A
The backbrace (B) (photos 4 & 5) links the two push han-
dles and must always be in position on recliner version (see
paragraph 2.6.1). Avoid operating levers (A) (photo 5) during a
sideways transfer, for example, in order to prevent destabili-
sing the user’s position !
To ensure safety for the user, when backrest is reclined, we
recommend to use anti-tippers (available as an option).
Maintenance of reclining backrest mechanism varies with
use. Please contact your Dealer.
Based upon the development of your disability, you can choose
an Action2 NG backrest that meets your needs. Please consult
with your Dealer.
The hanging of back packs or similar items onto your
chair backposts can affect the rearward stability of your chair,
especially when used in combination with recliner backrests.
This can cause the chair to tip backwards causing injury.
Therefore, Invacare® strongly recommend the use of anti-
tippers (available as an option) when using your backposts to
carry a back pack or similar items.
2.1.3 Backrest upholstery
- Standard upholstery backrests
• The padded backrest provides excellent daily comfort for
the user who does not need specic support for the upper
body.
In the event that the upholstered backrest slackens, ask for
a replacement from your Dealer.
2.1.4 Footrest supports
- Standard footrest supports (photo 6) swing away during
transfers and can be removed during transport.
Operate lever (A) by pushing sideways and swivelling towards
outside or inside in case there is not enough space. To return
to the initial position, align the footrest support it locks auto-
matically.
To remove the footrest support, simply pull up after
unlocking the assembly. Reverse the procedure to reassem-
ble, while still in the unlocked position.
5
A
4B
B
6
