Invacare Nutron R32TM Instruction Manual

Yes, you can. ™
Nutron®
R32™
R32™ LX
R50™ LX
R51™
R51™ LX
R51™ LXP
RWD
Power Wheelchairs
Parts Catalog Issued: Apr 23, 2012

The information contained in this document is subject to change without notice. This catalog contains
service parts for Form No. 01-220. If you have any questions regarding this catalog, please contact one
of our Customer Service Representatives.
For Customer Service Support Call:
1-800-333-6900
For Faxed In Orders Call:
1-800-678-4682 or
1-440-366-0709
For Technical Service Call:
1-800-832-4707
Literature Can Be Found at:
www.invacare.com or
1-800-828-6272
SYMBOL DEFINITION
Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the
bottom of the page or below specified charts.
HARDWARE MEASUREMENTS
Examples: = Special Comments
= General information pertaining to that specific page
= No Longer Available
NOTE:
NLA
The measurements for the hardware will be listed as follows:
Screws, Bolts
Washers
Spacers
For your convenience, we have supplied an area for you to list your Invacare Representatives.
A,B,C etc.
Diameter X Thread Count/Pitch X Length
Inside Diameter X Outside Diameter X Thickness
Inside Diameter X Outside Diameter X Length
Name Phone Numbers
© 2012 Invacare Corporation. Elyria, Ohio. Invacare, Yes, you can., the Medallion Design, and Nutron are registered trademarks and R32, R50, R51, MKIV,
and NX are trademarks of Invacare Corporation.
Parts Catalog Usage Guide
1
Form No. 01-220
To order call toll free 1-800-333-6900, or www.invacare.com

Accessories - Miscellaneous .................................................................................................... 91
Accessories - Oxygen Holder Assembly .................................................................................. 93
Accessories - Power Wheelchair Tool Kit ................................................................................ 95
Accessories - Solid Seat Inserts ............................................................................................... 87
Accessories - Wheel Locks (After 2/14/03) .............................................................................. 89
Accessories - Wheel Locks (Before 2/15/03) ........................................................................... 88
Arms - Adjustable Height .......................................................................................................... 25
Arms - Fixed Height .................................................................................................................. 23
Battery Boxes & Trays .............................................................................................................. 34
Battery Chargers ...................................................................................................................... 37
Canes - Back with Hardware - Adjustable Height and Adjustable Angle Back ........................ 13
Canes - Back with Hardware - Fold Down Adj. Height Angle Back .......................................... 15
Casters & Forks ........................................................................................................................ 27
Electronics - MK5 Controllers, Programmer and Hardware (After 2/14/03) ............................. 85
Electronics - MK5 SPJ Joystick and Mounting Hardware (After 2/14/03) ................................ 70
Electronics - MK5 SPJ+ Joystick and Mounting Hardware (Introduced 8/16/05) ..................... 72
Electronics - MKIV Controllers, Harness , Programmer and Hardware (Before 2/15/03) ........ 83
Electronics - MKIV Joystick Switch Options ............................................................................. 81
Electronics - MKIV Joysticks and Mounting Hardware (Before 2/15/03) .................................. 68
Electronics - MKIV Joysticks, PSF and PSR (Before 2/15/03) ................................................. 74
Electronics - MKIV Mid-Line Swing Bracket Assembly .......................................................... 76
TABLE of CONTENTS
Description
Page
Number
2
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Electronics - Quad Link Assembly (Before 4/07/06) ................................................................. 77
Electronics - Quad Link Assembly (QL) (After 4/06/06) ........................................................... 79
Finishes - Touch-Up Paint & Upholstery Options ..................................................................... 5
Frames - Crossbraces & Seat Extensions ............................................................................... 11
Frames - Frame Hardware & Anti-Tippers ............................................................................... 8
Front Riggings - Adjustable Angle Footplate Assemblies - AT5543 ......................................... 62
Front Riggings - Footrest & Legrest Accessories ..................................................................... 64
Front Riggings - Footrest Supports - P93M .............................................................................. 49
Front Riggings - Footrest Supports - PW93 ............................................................................. 43
Front Riggings - Footrest Supports - PW93E ........................................................................... 45
Front Riggings - Footrest Supports - PW93ST ......................................................................... 47
Front Riggings - Front Rigging Hanger .................................................................................... 67
Front Riggings - Legrest - Articulating PAS4A/PAL4A ............................................................. 53
Front Riggings - Legrest Supports - P904A ............................................................................. 50
Front Riggings - Pivot & Slide Tube w/ Footplate - P904, PAL4A, and PAS4A ....................... 60
Front Riggings - Pivot & Slide Tube w/ Footplate - P93M, PW93, and PW93E ....................... 56
Front Riggings - Pivot & Slide Tube w/ Footplate - PW93ST ................................................... 58
Front Riggings - Reference Chart ............................................................................................ 39
Motors, (2-Pole), Gearbox and Drive Wheel ............................................................................ 29
Motors, (4-Pole) and Gearbox - Model R51LXP only ............................................................... 32
Packaging - Cartons, Bags, Literature & Decals ...................................................................... 6
TABLE of CONTENTS
Description
Page
Number
3
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Upholstery - Back ..................................................................................................................... 20
Upholstery - Seat ...................................................................................................................... 17
Warranty Replacement Parts ................................................................................................... 97
TABLE of CONTENTS
Description
Page
Number
4
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Frame Finishes and Touch-Up Paint
Color Number Part Number Bottle Size Color
Wet Black.6 oz103145024P Red.6 oz103145533P Electric Red.6 oz104632161P Electric Blue.6 oz104632062P Silver VeinN/AN/A71P Jeweled Green.6 oz1101325101P
Upholstery Options
Lightweight Vinyl Nylon
U240 BlackU05 Black
Frame Finishes, Touch-Up Paint & Upholstery Options
5
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Cartons, Bags, Literature & Decals
6
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Cartons, Bags, Literature & Decals
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1023167 Carton, Battery Boxes 1 11 40131X148 Carton, Hardware 1 12 1108625 Insert, Carton 1 13 1074355 Carton 1 14 40131X011 Carton, Front Riggings 1 15 B 1023607 Carton 1 16 1023165 Insert, Carton 1 17 1015592 Bag, Poly (72" L x 35" W x 19" D) 1 18 1035900 Decal, Transportation 1 19 1107645-NLA NLA - Decal, Model - R32 1 210 1107646-NLA NLA - Decal, Model - R32LX 1 210 1107647-NLA NLA - Decal, Model - R50LX 1 210 1107648 Decal, Model - R51 1 210 1107649-NLA NLA - Decal, Model - R51LX 1 210 1107650 Decal, Model - R51LXP 1 210 1107653 Decal, 2 Pole Motor (350 Watts) 1 211 1107654 Decal, 4 Pole Motor (650 Watts) 1 211 1104797 Decal, Drive/Push 1 212 1095489 Decal, Invacare 3-D Logo (2-1/2" L) 1 213 1107651 Decal, Front Battery Cover 1 114 1107652 Decal, Rear Battery Cover 1 115 1095272 Instruction Manual, MKIV RII 1 1A 1095273-NLA NLA - Instruction Manual, MKIV RII LP 1 1A 1106644 Owner's Manual - R32 and R32LX 1 1A 1106645 Owner's Manual - R50LX R51 R51LX and R51LXP 1 1A 1110532 Instruction Manual, MK5 NX/NX-LP 1 1A
A - Not Shown.
B - Required only with Hemi Models.
Note
: When adjusting or replacing parts, please refer to your Owner's Manual.
NOTE:
7
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Frames, Frame Hardware & Anti-Tippers
8
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Frames, Frame Hardware & Anti-Tippers
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1055298 Screw, Hex Head (1/4-28 x 1-5/8") 1 21 1085134 Screw, Socket Flat Head (#10-32 x 1-5/8") 1 22 1007541 Clamp, Seat 1 23 1036485 Socket, Arm 1 24 1025765 Locknut (1/4-28) 1 25 1106315 Brace, Arm Socket 1 26 1119977 Screw, Socket Head (1/4-20 x 2-1/4") 1 27 1058520 Fastener, Panel Snap-In 1 28 1022597 Screw, Phillips Pan Head Tap (#10-32 x 3/8") 1 29 1025731 Locknut (#10-32) 1 210 1071505 Screw, Socket w/ Patch (M6 x 20) 1 311 1080712 Screw, Socket Head (M6 x 30) 1 312 1106283 Plug, Anti-tip 1 213 1026907 Washer (1/4 x 1/2 x 1/16") 1 414 1056406 Cup, Socket Pivot 1 215 1106320 Hardware, Frame, Side, 17-3/4"-19-3/4" Seat to
Floor (Pair) 2 1B,D
40117X006 Bearing (5/8") 1 216 1124839 Screw, Socket Head (M6 x 1 x 40MM) 1 617 1124840 Screw, Socket Head (M6 x 1 x 55MM) 1 618 1124829 Spacer, Motor, Black 1 219 1124842 Pin, Roll (4MM x 16MM) 1 420 1124833 Extension, Motor Lock 1 221 1124828 Hardware, Frame, Side, 21" Seat to Floor (Pair) 2 1A,D 1025763 Spring, Torsion with Double Button 1 222 1106298 Anti-Tipper, Rear 1 123 F 1124838 Anti-Tipper, Rear 1 123 G See Chart #24 Side Frames 1 124 1025736 Locknut (1/4-20) 1 1E 1018739 Washer (1/4 x 5/8 x 3/32") 1 1E 1037610 Screw, Hex Head (1/4-20 x 1-5/8") 1 1E
A - Includes items 1-10, 13-15, & 17-21
B - Includes items 1-11, 13-15
D - Not Shown.
E - Wheel Lock hardware for replacement side frame built before 2/15/03.
F - 17-3/4"-19-3/4" Seat to Floor configuration
G - 21" Seat to Floor configuration
NOTE:
9
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Frames, Frame Hardware & Anti-Tippers
#24 Side Frames
Frame Style R51LXPR32 R32LX R50LX R5I R51LX 8881107663
8881107663 8881107663 8881107663 8881107659 8881107659 Adult - Right
See Note(s) C See Note(s) C, A See Note(s) C, A See Note(s) C, A See Note(s) C, A See Note(s) C, A See Note(s) C, A
8881107664 8881107664 8881107664 8881107664 8881107660 8881107660 Adult - Left
Before 4/7/03 See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A
8881119136 8881119136 8881119136 8881119136 8881119134 8881119134 Adult - Left
After 4/6/03 See Note(s) B, A See Note(s) B, A See Note(s) B, A See Note(s) B, A See Note(s) B, A See Note(s) B, A
8881107661 8881107661 8881107661 8881107661 8881107657 8881107657 Hemi - Right
See Note(s) C See Note(s) C, A See Note(s) C, A See Note(s) C, A See Note(s) C, A See Note(s) C, A See Note(s) C, A
8881107662 8881107662 8881107662 8881107662 8881107658 8881107658 Hemi - Left
Before 4/7/03 See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A
8881119135 8881119135 8881119135 8881119135 8881119133 8881119133 Hemi - Left
After 4/6/03 See Note(s) B, A See Note(s) A, B See Note(s) A, B See Note(s) A, B See Note(s) B, A See Note(s) B, A
A - Specify frame finish when ordering, see page titled "Frame Finishes".
B - Threaded inserts removed from left side frame that mounted the MKIV controller. MK5 controller mounts differently and the
threaded inserts are no longer used
C - Right Side Frames were Not affected by the MK5 change. Right Frame part nos. shown are applicable regardless of when chair
was built.
NOTE:
10
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Crossbraces & Seat Extensions
11
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Crossbraces & Seat Extensions
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1064409 Crossbrace Assembly, Black 1 21 C 1064410 Crossbrace Assembly, Black 1 21 D 1064411 Crossbrace Assembly, Black 1 21 E 1064412 Crossbrace Assembly, Black 1 21 F 1028835 Cap, Hub, Black 1 42 60264X001 Locknut (5/16-24) 1 23 1028491 Washer, Caplugs (11/32" I.D. x 1" O.D.) 1 44 1056708 Plug, Pivot Tube 1 45 1038179 Screw, Hex Head (5/16-24 x 4-1/4") 1 26 1057830 Hardware, Crossbrace Pivot Tube 1 1A,B 1055348 Screw, Hex Head (1/4-28 x 1-3/4") 1 27 1029501 Plug Button, Black (1") 1 48 1065362 Locknut (1/4-28) 1 49 1057828 Strap, Pivot Link 1 210 1057384 Link, Pivot, Adult, Black (14 - 15" W) 1 211 C 1057385 Link, Pivot, Adult, Black (16 - 18" W) 1 211 G 1057386 Link, Pivot, Adult, Black (19 - 20" W) 1 211 F 1030949 Screw, Hex Head (1/4-20 x 1-1/2") 1 212 1025736 Locknut (1/4-20) 1 213 1098625 Screw, Hex Head (5/16-24 x 3-1/2") 1 114 16308X000 Washer, Flat (5/16 x 11/16 x 1/16") 1 215 1037913 Bushing (5/16 x 7/16 x 9/32") 1 116 1016263 Spacer, Coved (3/4 x 1 x 1/2") 1 417 1016301 Washer, Nylon (5/16 x 7/8 x 1/8") 1 118 1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 119 1025730 Locknut (5/16-24) 1 120 1057832 Hardware, Crossbrace 1 121 H 1058616-NLA NLA - Seat Extension Kit - 1" (Pair) 2 122 I 1058617 Seat Extension Kit - 2" (Pair) 2 122 I 1076284 Screw w/ Washer (#10 x 7/8") 1 223 1026298 Package, Screw with Washer (#10 x 7/8") (Pair) 2 123
A - Not Shown.
B - Includes items 2-6.
C - 14" Wide.
D - 16" Wide.
E - 18" Wide.
F - 20" Wide.
G - 16-18" Wide.
H - Includes items 14-20.
I - Includes the Extension Tubes and item #23 Screw w/ Washer.
NOTE:
12
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Back Canes and Hardware
Adjustable Height and Adjustable Angle
13
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Back Canes and Hardware
Adjustable Height and Adjustable Angle
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1057248 Grip, Hand, Foam (4-3/4") 1 11 1070759 Screw, Hex Head (1/4-20 x 1-1/2") 1 12 1056551 Insert 1 13 7930307 Locknut (1/4-20") 25 34 1107655 Back Cane Assembly 1 15 A 1006229 Grip, Foam (8") 1 16 1028372 Back Cane Assembly, 10 Degree Bend 1 17 7930323 Package, Locknut (1/4-20) 25 48 1026907 Washer (1/4 x 1/2 x 1/16") 1 49 1024793 Screw, Hex Head (1/4-20 x 1-3/4") 1 210 1008432 Screw, Socket Button Head (1/4-20 x 1-1/4") 1 211 1108621 Bracket with Adjustable Back Tube, Black 1 112 1107668 Adjustable Angle Back Hardware (1 pair) 2 113 B
A - 16-18" Back Height
B - Includes Items 8-12.
NOTE:
14
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Back Canes and Hardware
Fold Down Adjustable Height Angle Back
15
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Back Canes and Hardware
Fold Down Adjustable Height Angle Back
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1006229 Grip, Foam (8") 1 11 1027848 Back Cane Assembly, Black - Right/Left 1 12 7930323 Package, Locknut (1/4-20) 25 13 1058832 Tube, Backrest, Black 1 14 40157X020 Spacer, Coved (1/4 x 1 x 9/16") 1 45 7930334 Locknut (1/4-28) 25 56 1026907 Washer (1/4 x 1/2 x 1/16") 1 47 1108626 Bracket, Pivot, Black 1 28 7930313 Package, Washer, Nylon (5/16 x 7/8 x 1/8") 25 29 1055349 Screw, Hex Head (1/4-28 x 2") 1 310 1059127 Pin, Locking 1 111 1058232 Plug, Latch 1 112 1011511 Spring, Compression (5/8 x 1 x 3/64") 1 113 1058545 Lever, Actuator 1 114 1059271 Tip, Plastic, Black 1 115 1008432 Screw, Socket Button Head (1/4-20 x 1-1/4") 1 116 1107667 Fold Down Back Hardware 2 1A,B
A - Includes Items 3-16
B - Not Shown
NOTE:
16
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Seat Upholstery
17
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Seat Upholstery
Lightweight Vinyl Seat Upholstery
R32 and R51 (Before 11/15/02)
Chair Width 16" Depth 17" Depth 18" Depth
88810523018881052296888101820014" 88810233608881020690888101692016" 88810233598881020691888101691818" 88810523078881052300888101957720"
Note: When ordering, please specify U05 Black for Lightweight/Vinyl and U240 Black for Nylon Upholstery.
Nylon Seat Upholstery
R32 and R51 (After 11/14/02)
Chair Width 16" Depth 17" Depth 18" Depth
88810572138881057206888105719914" 88810572158881057208888105724116" 88810572178881057210888105724218" 88810572188881057211888105720420"
Note: When ordering, please specify U05 Black for Lightweight/Vinyl and U240 Black for Nylon Upholstery.
18
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220

Seat Upholstery
Nylon Seat Upholstery
R32LX/R50LX/R51LX/R51LXP
Chair Width 16" Depth 17" Depth 18" Depth
10163171016316101631514" 10163231016322101632116" 10163291016328101632718" 10176491017646101764320"
Note: When ordering, please specify U05 Black for Lightweight/Vinyl and U240 Black for Nylon Upholstery.
Hardware for Seat Upholstery
Part Number Description 16" Depth
Quantity Required 17"-18" Depth Quantity Required
108
Single Pack Screw with
Washer (#10 x 7/8")
1076284
N/A1 Pkg of 8
Multi Pack Screws with
Washers (#10 x 7/8"")
1057950
1 Pkg of 10N/A
Multi Pack Screws with
Washers (#10 x 7/8")
1050393-NLA
19
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-220
