Contents
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsaved
forfuturereference.
1General.........................................4
1.1Introduction..................................4
1.2SymbolsinthisDocument........................4
1.3WarrantyInformation...........................4
1.4Compliance...................................5
1.4.1Product-specicStandards.....................5
1.5ServiceLife...................................5
2Safety..........................................6
2.1SafetyInformation..............................6
2.2Labelsandsymbolsontheproduct.................7
3ProductOverview.................................9
3.1Intendeduse..................................9
3.2ProductDescription.............................9
3.3Overview....................................9
4Setup...........................................12
4.1SafetyInformation..............................12
4.2Assemblingtheshowerandtoiletchair..............12
4.2.1Installingtheseatframetubeforheight
adjustment................................12
4.2.2Installingthebackrest........................14
4.2.3InstallingandRemovingtheSeatPlate............15
4.2.4Adjustingtheheightofthearmrests.............15
4.2.5Installingthefootrests........................16
4.2.6Installing/Removingself-propellingwheels
(optional).................................17
5Accessory(optional)................................18
5.1Fitting/removingthetoiletpanholderandtoiletpan....18
6Usage..........................................20
6.1Safetyinformation..............................20
6.2SwivellingtheArmrests..........................21
6.3Swivellingthefootrests..........................21
6.4Engaging/DisengagingtheCastorLocks..............22
6.5Engaging/disengagingtheparkingbrakes.............22
7Transport........................................24
7.1Safetyinformation..............................24
8Maintenance.....................................25
8.1MaintenanceandInspection......................25
8.2CleaningandDisinfection........................25
8.2.1GeneralSafetyInformation.....................25
8.2.2CleaningIntervals............................26
8.2.3CleaningInstructions.........................26
8.2.4DisinfectionInstructions.......................27
9AfterUse........................................28
9.1Storage......................................28
9.2Reconditioning................................28
9.3Disposal.....................................28
10Troubleshooting..................................29
10.1Identifyingandrepairingfaults...................29
11TechnicalData...................................30
11.1Dimensionsandweight.........................30
11.2Materials....................................32
11.3Environmentalparameters.......................32

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
1General
1.1Introduction
Thisusermanualcontainsimportantinformationaboutthe
handlingoftheproduct.Toensuresafetywhenusingthe
product,readtheusermanualcarefullyandfollowthe
safetyinstructions.
Notethattheremaybesectionsinthisdocument,whichare
notrelevanttoyourproduct,sincethisdocumentapplies
toallavailablemodels(onthedateofprinting).Ifnot
otherwisestated,eachsectioninthisdocumentreferstoall
modelsoftheproduct.
Themodelsandcongurationsavailableinyourcountrycan
befoundinthecountry-specicsalesdocuments.
Invacarereservestherighttoalterproductspecications
withoutfurthernotice.
Beforereadingthisdocument,makesureyouhavethe
latestversion.YoundthelatestversionasaPDFonthe
Invacarewebsite.
Ifyoundthatthefontsizeintheprinteddocumentis
difculttoread,youcandownloadthePDFversionfromthe
website.ThePDFcanthenbescaledonscreentoafont
sizethatismorecomfortableforyou.
Formoreinformationabouttheproduct,forexample
productsafetynoticesandproductrecalls,contactyour
Invacaredistributor.Seeaddressesattheendofthis
document.
Incaseofaseriousincidentwiththeproduct,youshould
informthemanufacturerandthecompetentauthorityin
yourcountry.
1.2SymbolsinthisDocument
Symbolsandsignalwordsareusedinthisdocumentand
applytohazardsorunsafepracticeswhichcouldresultin
personalinjuryorpropertydamage.Seetheinformation
belowfordenitionsofthesignalwords.
WARNING
Indicatesahazardoussituationthatcouldresult
inseriousinjuryordeathifitisnotavoided.
CAUTION
Indicatesahazardoussituationthatcouldresult
inminororslightinjuryifitisnotavoided.
IMPORTANT
Indicatesahazardoussituationthatcouldresult
indamagetopropertyifitisnotavoided.
TipsandRecommendations
Givesusefultips,recommendationsand
informationforefcient,trouble-freeuse.
1.3WarrantyInformation
Weprovideamanufacturer’swarrantyfortheproduct
inaccordancewithourGeneralTermsandConditionsof
Businessintherespectivecountries.
Warrantyclaimscanonlybemadethroughtheprovider
fromwhomtheproductwasobtained.
41639501-C

General
1.4Compliance
Qualityisfundamentaltothecompany’soperation,working
withinthedisciplinesofISO13485.
ThisproductfeaturestheCEmark,incompliancewiththe
MedicalDeviceRegulation2017/745ClassI.Thelaunchdate
ofthisproductisstatedintheCEdeclarationofconformity.
Wearecontinuouslyworkingtowardsensuringthatthe
company’simpactontheenvironment,locallyandglobally,
isreducedtoaminimum.
WeonlyuseREACHcompliantmaterialsandcomponents.
1.4.1Product-specicStandards
Theproducthasbeentestedandconformstothestandard
ISO17966(Assistiveproductsforpersonalhygienethat
supportusers)andrelatedstandards.Thisincludestesting
concerningammability.Progressivesmoulderingignition
andamingignitiondonotoccur.
Forfurtherinformationaboutlocalstandardsand
regulations,contactyourlocalInvacarerepresentative.See
addressesattheendofthisdocument.
1.5ServiceLife
Theexpectedservicelifeofthisproductisveyearswhen
useddailyandinaccordancewiththesafetyinstructions,
maintenanceintervalsandcorrectuse,statedinthismanual.
Theeffectiveservicelifecanvaryaccordingtofrequency
andintensityofuse.
1639501-C5

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
2Safety
2.1SafetyInformation
WARNING!
RiskofSeriousInjuryorDamage
Improperuseofthisproductmaycauseinjury
ordamage.
–Ifyouareunabletounderstandthewarnings,
cautionsorinstructions,contactahealthcare
professionalorproviderbeforeattemptingto
usethisequipment.
–Donotusethisproductoranyavailable
optionalequipmentwithoutrstcompletely
readingandunderstandingtheseinstructions
andanyadditionalinstructionalmaterialsuch
asusermanual,servicemanualorinstruction
sheetsuppliedwiththisproductoroptional
equipment.
WARNING!
RiskofInjury
–Donotstandontheproduct.
–Donotuseasaclimbingaid.
–Donotuseoutdoors.
WARNING!
RiskofInjury
–Donotuseifdefective.
–Intheeventofamalfunction,contactyour
providerimmediately.
–Donotmakeanyunauthorizedchangesor
alterationstotheproduct.
–Onlyuseaccessoriesintendedforthisproduct.
WARNING!
RiskofInjury
–Neverusetheproductasanaidforgettinginto
oroutofabathtub,forclimbingordescending,
asasupportorforsimilarpurposes.
WARNING!
–Beforerstuse,cleantheproductthoroughly.
–Beforeeveryuse,checktheproductfordamage
andensurethatitissecurelyassembled.
CAUTION!
RiskofInjury
Non-originalorwrongpartsmayaffectthe
functionandsafetyoftheproduct.
–Onlyuseoriginalpartsfortheproductinuse.
–Duetoregionaldifferences,refertoyour
localInvacarecatalogorwebsiteforavailable
optionsorcontactyourInvacaredistributor.
Seeaddressesattheendofthisdocument.
61639501-C

Safety
IMPORTANT!
Whencombiningthisproductwithanother
product,therestrictionsofbothproductsapply
forthecombination.E.g.themaximumuser
weightofoneproductinthecombinationmay
belower.
–OnlyusecombinationsallowedbyInvacare.
ContactyourInvacaredistributorfor
information.
–Beforeuse,readtheusermanualofeach
productandchecktherestrictions.
2.2Labelsandsymbolsontheproduct
IdenticationLabel
Theidenticationlabelcontainsimportantinformation:
A
B
CDEF
G
H
I
J
AManufactureraddress
BEuropeanConformity
CReadusermanual
DForuseonlevelgroundonly
EMaximumuserweight
FDateofmanufacture
GMedicaldevice
HSerialnumber
IReferencenumber
JProductdesignation
Theidenticationlabelisattachedtotheinsideof
theleftsidepart.
1639501-C7

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
Labelsontheproduct
Thefollowinglabelisattachedtothehandleofthe
backrest:
LabelDescription
WARNING!
Riskoftippingover
–Donotsteponthefootrest
whengettingintooroutofthe
showerandtoiletchair.
–Pushthefootreststothesides
orfoldupthefootplatesbefore
gettingintooroutoftheshower
andtoiletchair.
–Beforesittingdownorstanding
up,turnthecastorssothatthe
lockispointingforwards.
–Donotleantoofarforwards
whensittingintheshowerand
toiletchair.
81639501-C

ProductOverview
3ProductOverview
3.1Intendeduse
Theshowerandtoiletchairisdesignedexclusivelyasan
aidforshoweringorbathing,goingtothetoilet,foruse
duringpersonalhygiene(e.g.infrontofthebasin)orfor
transferringpatientswhileindoors.Itisintendedtobeused
byyouthandadultpatientswithorwithoutcaregiverˈs
assistance,whohave:
•aphysicalsizetoormorethan146cm,aweightequal
toormorethan40kgandabodymassindex(BMI)
equaltoormorethan16
•Difcultystandingorkeepingtheirbalance
•Weaklegsorlowerlimbdisability
•Medicalconditionsthatimpairtheirbalance
Theproductisintendedforinstitutionalandprivatehouse
holduse.Anyotheruseisprohibited.
Asatoiletchair,theproductcanbeusedoverastandard
toiletorindependentlywiththetoiletpan(optional).
Theshowerandtoiletchairmayonlybeusedasabathing
chairinapool,ifthepooldoesnotcontainsaltwaterand
anattendantispresentatalltimes.
Temperatureforuse:10-65°C
3.2ProductDescription
AquatecOceanErgoandAquatecOceanErgoXLare
mobileshower-andtoiletchairswithstainlesssteelframe,
individuallyadjustableseatheight,tensionadjustable
backrest,ipuparmrestsandfoldableangle-adjustable
texturedfootplates,designedforpeoplewithdisabilities
thatrestrictshowering/toiletuse.Theproductisavailablein
twomodels:Amodelwhichcanbepushedusingthepush
handlesanda24"wheels-modelforself-propelling.
3.3Overview
Thefollowingcomponentsareincludedwithinthescope
ofdelivery:
ASidepartwithcastors(leftandright)
BBackrestwithbackrestcoverandarmrests
CSeatframe
1639501-C9

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
DSeat
EFootrestwithheelstrap(leftandright)
FClips(2x)forfootrest(inserted)
GClips(4x)forseatframe
HScrewsandwashers(4x)
IBasestabilisationtubewithscrews(4x),washers
(8x)andnuts(4x)-OceanXLonly
JPushbar
KUsermanual
LAllenkeyAF4
Thefollowingpartsareincludedwithinthescopeofdelivery
oftheself-propellingwheelswithparkingbrake:
D
ASelf-propellingwheels(2x)
BParkingbrakes(2x)withscrews(4x),washers(4x)
andnuts(4x)
CHubsinc.axlesandwashersandnuts(2x)
DAssemblyinstruction
Notethechangeindimensionswhenthe
self-propellingwheelsaretted.Fordetailssee
chapterTechnicalData.
101639501-C

ProductOverview
Accessory—Toiletpanholderwithtoiletpan
AToiletpanholder
BToiletpan
CLid
1639501-C11

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
4Setup
4.1SafetyInformation
WARNING!
–Checkthepartsfortransportdamagebefore
commissioningandcontactyourproviderif
required.
–Ensureduringassemblythatthepartsare
positionedcorrectlywithrespecttoone
another.
–Self-lockingscrews/nutsorthread-locking
adhesiveareusedforseveralconnections.If
theseareloosened,theymustbereplacedby
newself-lockingscrews/nutsortheymustbe
securedusingnewthread-lockingadhesive.
CAUTION!
RiskofPinching
–Takecareduringassembly.
4.2Assemblingtheshowerandtoiletchair
Thissectiondescribestheassembly.Disassemblytakesplace
inthereverseorder.
Thearmrestheight,footrestheight,footrestangle,
heelstrap,tensionofbackrestcoverandaccessories
mustbeadjustedtooptimallyttheuser.
4.2.1Installingtheseatframetubeforheightadjustment
1.RemovetheenclosedclipsFfromthebag.
2.Placetheseatframeonitsside.
Pushthesidepartevenlyontotheframeanddo
nottwist.
IMPORTANT
–Securethesidepartatthesameheight,front
andrear.
3.PushthesidepartAwiththeguidesforthefootrests
DforwardsontheseatframeB.
Makesurethattheidenticationlabelisattachedto
theinsideoftheleftsidepart.
Makesurethattheorientationoftheseatframeis
correct(seegraphicinchapter3.1).
121639501-C

Setup
4.BringtheclipmountsConthefrontandbackofthe
sidepartinlinewithaholeintheseatframeE.
5.InserttheclipsFfromtheoutsideintothesidepart,
untiltheclipedgesGenclosetheseatframetubeB.
IMPORTANT
–Makesurethatallfourclipsaresecurely
fastened.
–Makesurethattheleftandtherightsideparts
areadjustedtothesameheight.
6.Turntheseatframeandrepeattheprocedureonthe
secondsidepart.
7.Settheseatframewiththettedsidepartsonits
wheels.
Adjustingtheseatheight
WARNING!
–Makesurethatallfourclipsaresecurely
fastened.
–Makesurethattheseatisadjustedtothe
sameheightonbothsides.
–Donotadjusttheseatheightwhensomeoneis
sittingontheshowerandtoiletchair.
1.Raisetheshowerandtoiletchairslightlyononeside
bytheseatframeB.
2.RemovebothclipsFonthisside.
3.PulltheseatframeoutofthesidepartAorpushit
intothesideparttoadjusttheseatheight.
4.Pushbothclipsbackincompletely.
5.Repeatstep1-4ontheotherside.
Theseatheightcanbeadjustedtoaccommodate
differentsituationsofusee.g.transferfromabed
orawheelchairoruseaboveatoiletetc.
Installingthebasestabilizationtube(OceanErgoXLonly)
1.InstallthebasestabilizationtubeAbetweentheside
partsCusingthescrewsandnutsBsupplied.Make
surethestabilizationtubeisfacingupwards.
2.Tightenthescrewswithatorqueof5Nm.
1639501-C13

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
4.2.2Installingthebackrest
1.Pushdownallfourfootpedalsofthecastorstolock
them.
2.PushthebackrestDfromtherearsideontotheseat
frameE,untilthecollarCtouchestheseatframe
tubeF.
3.PositionawasherBoneachscrewAandsecurethe
backrestoneachsidewithatorqueof5Nmusingthe
Allenkeysupplied.
IMPORTANT!
–Checkthescrewsregularlytoensuretheyare
fastenedsecurely.
Adjustingthebackrestcover
Thetensionofthebackrestcovercanbeadjustedasneeded.
WARNING!
–Makesurethatatleastthreebeltsarealways
passedaroundthebackrestframe(onthe
outside)andtheirbeltbucklesarefastened.
Tightening:
1.PullthebeltsAofthebackrestcovertighter.
Loosening:
1.OpenthebucklesBbysqueezingtheretaininglugs
together(arrows).
2.Pushthebeltsbackalittlethroughthebuckle.
3.Fastenthebeltbuckles.
4.Retightenthebeltsgently.
141639501-C

Setup
WARNING!
Riskofinjuryduetodamagedbackrestbuckles!
Checkforsecurefasteningofthebackrest
buckleseachtimetheproductismaintainedor
reconditioned.
–Checkallbucklesforsecurefasteningbyclosing
thebucklesandpullingonbothends.
–Replacethebackrest/backrestbucklesifa
buckleopensundertheappliedforce.
4.2.3InstallingandRemovingtheSeatPlate
Installing
1.Placetheseatplateontheseatframewiththecutout
tothefront.
2.Presstheseatplatedownwiththeathandatthe
sidesandthenatthefrontandbackuntiltheseatplate
snapsontotheseatframe.
Removing
1.Pulltheseatplateupwardsattherear.
4.2.4Adjustingtheheightofthearmrests
1.Onthebackrestcover,openthethirdbuckleofthebelt
andloosentheotherbelts.
Thenutsareinsertedlooselyinthesecuringclamp
andcanfallout.
2.UnscrewthescrewsBofthearmrestbracketAusing
theAllenkeysupplied.
3.RemovethesecuringclampDwiththenutsfromthe
insideofthebackrestframe.
4.RemovethebackrestbracketAwiththearmrestand
moveitupwards.
Thesmallerholeservestoxthesecuringclamp.
5.Insertthescrewsinthearmrestbracketandguidethem
throughtheholesinthebackrestframe.
6.Ifrequired,putthenutsbackintothesecuringclamp.
7.Placethesecuringclamponthebackrestframeinserting
thexationpinintothesmallerhole.
8.Insertthescrewsintothenutsandtighten.
1639501-C15

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
9.Movethebackrestcoversothatthethirdbeltruns
eitheraboveorbelowthearmrest.
10.Passthethirdbeltofthebackrestcoverontheoutside
ofthebackrestframe,closeandtightenallbelts.
11.Theheightadjustmentprocedureisthesameforthe
rightandleftarmrest
Toinstallaccessories,thethirdbeltfromthetopcan
beopenedandthebackrestcovercanbepassedby
thebackrestframeontheinside.
4.2.5Installingthefootrests
1.InsertthepinoftheclipGfromtheoutsideintothe
requiredholeonthefootrestB.Makesuretheclip
engagesaroundthetube.
2.PushthefootrestintotheguideHatthefrontofthe
sidepartuntilthepinofclipGengagesinthegroove
A.Thefootrestcannolongerbeturnedtotheside.
Theassemblyprocedureisthesamefortheright
andtheleftfootrest.
Adjustingtheheightofthefootrests
Thefootrestscanbeshortenedifrequired(referto
theservicemanual).Shorteningthefootrestsmust
beperformedbyaqualiedtechnician.
1.SlightlypullupthefootrestB.
2.PulltheclipGoutoftheholeinthefootrestand
re-insertitintotherequiredhole.Pulloutthefootrest
slightlyfurtherifnecessary.
3.PushdownthefootrestuntilthepinofclipGengages
inthegrooveA.
4.Settheotherfootresttotherequiredheightas
described.
Adjustingtheinclinationofthefootplates
Theinclinationofthefootplatescanbeadjusted
innitelyvariably.
1.LoosentheAllenscrewConthefootplateusingasize
4Allenkey.
2.TurnthefootplateDtotherequiredposition.
3.Re-tightentheAllenscrew.
161639501-C

Setup
4.2.6Installing/Removingself-propellingwheels(optional)
IMPORTANT!
–Whentheself-propellingwheelsaretted,the
rearcastorsmustremainlocked.
–Thehubsandtheparkingbrakesforthe
self-propellingwheelsmustbettedbya
qualiedtechnician.Assemblyisdescribedin
theassemblyinstructions“Aquatec®Ocean
Accessory–24"wheels/Parkingbrake“.
1.Alignallfourcastorsinthedrivingdirection.
2.Lockallcastors.
3.PushtheaxleDontheself-propellingwheelinwards.
(Thehandrimsprojectoutwards.)
4.PressandholdthebuttonFontheoutsideoftheaxle.
ThisreleasestheretainingballsCattheendoftheaxle.
5.Raisetheshowerandtoiletchairslightly.
6.InserttheaxleintothehubBandpushinthe
self-propellingwheelontotheaxleuntiltheendstopE.
7.ReleasethebuttonF.
8.CheckthattheretainingballsarebehindthehexnutA.
9.Theassemblyisthesamefortherightandleft
self-propellingwheel.
Toremovethewheels,carryoutthesameprocedurein
thereverseorder.
1639501-C17

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
5Accessory(optional)
WARNING!
Riskofinjury
–Theassemblyofaccessories(optional)must
becarriedoutaccordingtothecorresponding
instructions.
5.1Fitting/removingthetoiletpanholderand
toiletpan
ThetoiletpanFcanbeinserted/removedwithor
withoutthelidG.
1.RemovetheseatBfromtheframeA.
2.PositiontheendsofthetoiletpanholderCintothe
holesoftherearcrosstubeE.
3.Engagethefrontpartofthetoiletpanholderwiththe
frontcrosstubeD.
4.Re-ttheseattotheframe.
5.Placethelidonorremoveitfromthetoiletpan.
6.HoldthetoiletpanbyitshandleHandinsertfromthe
rearsidebetweenthetoiletpanholderandtheseat.
Slightlypushdownthetoiletpanwheninsertingor
removing.
Thelidcanbehungontheplastichookatthe
undersideofthetoiletpanhandle.
Thereisalllevelindicatorontheinnerwallof
thetoiletpan.
181639501-C

Accessory(optional)
1639501-C19

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
6Usage
6.1Safetyinformation
WARNING!
–Onlyusetheshowerandtoiletchaironaat
surfaceandindoors.
–Observethespecicationsontheidentication
label.Donotoverloadtheshowerandtoilet
chair.
–Observethesafetylabelonthehandleof
thebackrest,2.2Labelsandsymbolsonthe
product,page7
–Alwaysperformavisualinspectionofthe
productforexternaldamagebeforeeachuse.
–Regularlycheckthefunctionoftheparking
brake(self-propellingwheelsoptiononly).
WARNING!
Riskofslippingandrolling
–Beforeuse,makesurethattheseatissecurely
fastenedtotheseatframe.
–Lockallcastorswithleversusingthefootlevers
beforesittingdownontheshowerandtoilet
chairorstandingupfromit,aswellasinthe
parkingposition.
–Applytheparkingbrakewhentheself-propelling
wheelsaretted(optional).
WARNING!
Riskoftipping
–Swivelthefootreststothesideorfoldupthe
footplatesbeforesittingdownorstandingup.
–Beforesittingdownorstandingup,turnthe
frontcastorssothatthelockispointing
forwards.
–Neverstandonthefootrests.
–Donotleanexcessivelyforwards.
WARNING!
Riskoftipping
–Theshowerandtoiletchairmustonlybemoved
byusingthepushbarortheself-propelled
wheels(optional).
CAUTION!
Riskofburningyourskin
Theproductcomponentscanheatupwhen
exposedtoexternalsourcesofheat.
–Considerheatedupsurfaceswhenusingthe
showerandtoiletchairinthesaunaorwhenit
isexposedtohotwater.
–Donotexposetheproducttodirectsunlight
beforeuse.
201639501-C
