Invacare Formula Powered Seating Manual

Owner’s Operator and Maintenance Manual
DEALER: This manual MUST be given to
the user of the product.
USER: BEFORE using this product, read this
manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
Formula™
Powered Seating
Tilt
Recline
Elevate
Tilt/Recline
Tilt/Elevate
Tilt/Recline/Elevate
All manuals and user guides at all-guides.com
all-guides.com

REFERENCE DOCUMENTS
Formula™ Powered Seating 2Part No 1122170
 WARNING
A QUALIFIED TECHNICIAN MUST PERFORM THE INITIAL SET UP
OF THIS WHEELCHAIR. ALSO, A QUALIFIED TECHNICIAN MUST
PERFORM ALL PROCEDURES IN THE SERVICE MANUAL.
WHEELCHAIR USERS: DO NOT SERVICE OR OPERATE THIS
EQUIPMENT WITHOUT FIRST READING AND UNDERSTANDING
(1) THE OWNER’S OPERATOR AND MAINTENANCE MANUAL
AND (2) THE SEATING SYSTEM’S MANUAL (IF APPLICABLE). IF
YOU ARE UNABLE TO UNDERSTAND THE WARNINGS,
CAUTIONS, AND INSTRUCTIONS, CONTACT INVACARE
TECHNICAL SUPPORT BEFORE ATTEMPTING TO SERVICE OR
OPERATE THIS EQUIPMENT OTHERWISE INJURY OR DAMAGE
MAY RESULT.
DEALERS AND QUALIFIED TECHNICIANS: DO NOT SERVICE OR
OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND
UNDERSTANDING (1) THE OWNER’S OPERATOR AND
MAINTENANCE MANUAL, (2) THE SERVICE MANUAL (IF
APPLICABLE) AND (3) THE SEATING SYSTEM’S MANUAL (IF
APPLICABLE). IF YOU ARE UNABLE TO UNDERSTAND THE
WARNINGS, CAUTIONS AND INSTRUCTIONS, CONTACT
INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO
SERVICE OR OPERATE THIS EQUIPMENT OTHERWISE, INJURY
OR DAMAGE MAY RESULT.
REFERENCE DOCUMENTS
 WARNING
Refer to wheelchair base owner’s manual for additional safety and operation
information.
DOCUMENT PART NUMBER
MK6i™Electronics Field Service Guide 1141471
MK6i Electronics Service Manual 1143203
Formula TRE Service Manual 1123 20
NOTE: Updated versions of this manual are available on www.invacare.com.
All manuals and user guides at all-guides.com

TABLE OF CONTENTS
Part No 1122170 3Formula™ Powered Seating
TABLE OF CONTENTS
REFERENCE DOCUMENTS ................................................................. 2
REGISTER YOUR PRODUCT ............................................................... 4
SPECIAL NOTES ................................................................................ 5
LABEL LOCATIONS ........................................................................... 7
All Wheelchairs...........................................................................................................................................7
Wheelchairs with Elevate .........................................................................................................................8
Wheelchairs with entilator Trays ........................................................................................................8
TYPICAL PRODUCT PARAMETERS .................................................... 9
Formula Powered Seating Systems.........................................................................................................9
SECTION 1—GENERAL GUIDELINES ................................................. 11
Repair or Service Information ...............................................................................................................11
Operation Information............................................................................................................................11
Weight Training ........................................................................................................................................14
Weight Limitation.....................................................................................................................................14
SECTION 2—EMI INFORMATION ..................................................... 15
SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS ......................... 17
Pinch Points................................................................................................................................................17
SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING .................... 1
Safety Inspection Checklists...................................................................................................................18
Troubleshooting........................................................................................................................................20
SECTION 5—WHEELCHAIR OPERATION ........................................... 23
A Note About Drive Lock-Out ............................................................................................................23
Operating Powered Seating Systems ...................................................................................................24
MPJ+ Joystick Switches and Indicators ................................................................................................28
Preparing the Joystick for Use...............................................................................................................33
Repositioning the Joystick.......................................................................................................................34
SECTION 6—FRONT RIGGINGS ........................................................ 35
Installing/Removing Footrests................................................................................................................35
Footrest Height Adjustment..................................................................................................................36
Raising/Lowering Elevating Front Riggings ..........................................................................................38
Adjusting/Replacing Telescoping Front Rigging Support .................................................................38
Installing Adjustable Angle Flip-up Footplate Hinge .........................................................................40
Installing Adjustable Angle Flip-up Footplates....................................................................................40
Adjusting Adjustable Angle Flip-Up Footplates .................................................................................41
Composite/Articulating Footplate Heel Loop Replacement ..........................................................42
Installing/Removing Elevating Legrests.................................................................................................43
Raising/Lowering Elevating Legrests and/or Adjusting Calfpads ....................................................44
Removing/Installing the Center Mount Footrest ..............................................................................45
Adjusting the Height of the Center Mount Footrest.......................................................................47
Adjusting the Angle of the Manual Center Mount Footrest ..........................................................48
All manuals and user guides at all-guides.com

TABLE OF CONTENTS
Formula™ Powered Seating 4Part No 1122170
TABLE OF CONTENTS
Adjusting the Footplate Angle ...............................................................................................................48
Adjusting the Tension of the Flip Up Footplate ................................................................................49
Calf Pad Adjustment for Power Center Mount Footrests .............................................................50
Installing/Removing the Power Elevating Legrests ............................................................................51
SECTION 7—ARMS ......................................................................... 53
Installing/Removing Flip Back Armrests ..............................................................................................53
Adjusting Flip Back Armrests.................................................................................................................54
Removing/Installing Reclining Armrests ..............................................................................................55
Adjusting Reclining Armrest Height.....................................................................................................56
SECTION —SEAT ........................................................................... 5
Adjusting the Back Angle ........................................................................................................................58
Replacing Seat Positioning Strap ...........................................................................................................59
SECTION 9—HEADREST .................................................................. 60
Removing/Installing/Adjusting Headrest ..............................................................................................60
Replacing Headrest ..................................................................................................................................61
SECTION 10—ELEVATE BATTERIES ................................................. 62
Warnings for Handling and Replacing Batteries ................................................................................62
Using the Proper Batteries.....................................................................................................................63
Replacing Batteries ...................................................................................................................................63
Cleaning Battery Terminals....................................................................................................................66
Removing/Installing the Batteries From/Into the Wheelchair........................................................66
When to Charge Batteries.....................................................................................................................70
Charging Batteries ....................................................................................................................................70
SECTION 11—VENTILATOR TRAY ................................................... 73
Preparing the entilator Tray for Use.................................................................................................73
GLOBAL LIMITED WARRANTY (EXCLUDING CANADA) ................... 75
CANADA LIMITED WARRANTY ...................................................... 76
REGISTER YOUR PRODUCT
The benefits of registering include:
1. Safeguarding your investment.
2. Ensuring long-term maintenance and servicing of your product.
3. Receiving updates with product information, maintenance tips and industry news.
Register ONLINE at warranty.invacare.com
Please have your model number and purchase date available to complete your registration.
Any registration information you submit will only be used by Invacare Corporation and
protected as required by applicable laws and regulations.
All manuals and user guides at all-guides.com

SPECIAL NOTES
Part No 1122170 5Formula™ Powered Seating
SPECIAL NOTES
Signal words are used in this manual and apply to hazards or unsafe practices which
could result in personal injury or property damage. Refer to the table below for
definitions of the signal words.
NOTICE
THE INFORM TION CONT INED IN THIS DOCUMENT IS SUBJECT TO
CH NGE WITHOUT NOTICE.
WHEELCH IR USER
s a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of
wheelchairs to meet many needs of the end user. However, final selection of the
type of wheelchair to be used by an individual rests solely with the user and his/her
healthcare professional capable of making such a selection. Invacare highly
recommends working with a certified rehab technology supplier and/or a member
of NRRTS or RESN .
WHEELCH IR TIE-DOWN RESTR INTS ND SE T RESTR INTS (TRBKTS)
TRBKTS includes four factory-installed wheelchair transport brackets. TRBKTS has
not been crash-tested in accordance with WC 19. Use these transport brackets only
to secure an unoccupied wheelchair during transport.
s of this date, the Department of Transportation has not approved any tie-down
systems for transportation of a user while in a wheelchair, in a moving vehicle of any
type. It is Invacare’s position that users of wheelchairs should be transferred into
appropriate seating in vehicles for transportation and use be made of the restraints
made available by the auto industry. Invacare cannot and does not recommend any
wheelchair transportation systems.
 TRBKTS WARNINGS
Only use the transport brackets included with TRBKTS for the purposes described
in this manual.
SIGNAL WORD MEANING
DANGER
Danger indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
Warning indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
Caution indicates a potentially hazardous situation which, if not avoided,
may result in property damage.
All manuals and user guides at all-guides.com

SPECIAL NOTES
Formula™ Powered Seating 6Part No 1122170
 WARNING
Invacare products are specifically designed and manufactured for use in conjunction
with Invacare accessories. ccessories designed by other manufacturers have not
been tested by Invacare and are not recommended for use with Invacare products.
The seat positioning strap is a positioning belt only. It is not designed for use as a
safety device withstanding high stress loads such as auto or aircraft safety belts. If
signs of wear appear, belt MUST be replaced immediately.
To determine and establish your particular safety limits, practice use of this product
on various sloping surfaces in the presence of a qualified healthcare provider before
attempting active use of this wheelchair. Other general warnings listed within this
document also apply.
Wheelchairs should be examined during maintenance for signs of corrosion (water
exposure, incontinence, etc.). Electrical components damaged by corrosion should
be replaced IMMEDI TELY.
Wheelchairs that are used by incontinent users and/or are frequently exposed to
water may require replacement of electrical components more frequently.
Refer to wheelchair base owner’s manual for additional safety and operation
information.
 POWERED SEATING SYSTEM WARNINGS
This seating system has been custom designed and will be assembled to the wheel-
chair base before delivery to the user. The information contained in this manual is
for maintaining and adjusting the seating system. There are very few adjustments
that can safely be made by the user. If there is a procedure or adjustment that
needs to be performed on the seating system that is not in this manual, DO NOT
perform that procedure. Have the seating system serviced by a qualified technician.
All manuals and user guides at all-guides.com
all-guides.com

LABEL LOCATIONS
Part No 1122170 7Formula™ Powered Seating
LABEL LOCATIONS
NOTE: Refer to Owner’s Manual shipped with wheelchair base for additional labels located on
wheelchair base.
All Wheelchairs
Refer to Service Manual to
reposition the seat - otherwise serious personal injury
and damage will result.
WARNING
P/N 1114823 Rev B - 5/10/06
Weight Capacity Label
located here
Serial Number
Located HERE
NOTE: Auto st le seat
positioning strap shown. This
label is also on the airline st le
seat positioning strap.
All manuals and user guides at all-guides.com

LABEL LOCATIONS
Formula™ Powered Seating 8Part No 1122170
Wheelchairs with Elevate
Wheelchairs with Ventilator Trays
All manuals and user guides at all-guides.com

TYPICAL PRODUCT PARAMETERS
Part No 1122170 9Formula™ Powered Seating
TYPICAL PRODUCT PARAMETERS
Formula Powered Seating Systems
CONTOURA BACKS CON ENTIONAL
BACKS
SEAT WIDTH RANGE: 16 - 24 inches in 2-inch
increments
16 - 24 inches in 1-inch
increments
SEAT DEPTH RANGE
SMALL FRAME:
LARGE FRAME:
EXTRA LARGE FRAME:
Adjustable in 1-inch
increments
16 - 1 inches
19 - 21 inches
22 inches
Adjustable in 1-inch
increments
16 - 19 inches
20 - 22 inches
N/A
BACK HEIGHT RANGE
ALL SYSTEMS EXCEPT ELEVATE ONLY:
ELEVATE ONLY:
Not Adjustable
25 inches and 29.5 inches
N/A
Not Adjustable
20 - 26 inches
16 - 24 inches
BACK ANGLE RANGE
TILT ONLY, TILT/ELEVATE AND ELEVATE
ONLY: 5° - 105° in 5° increments
TILT RANGE
TILT, TILT/RECLINE OR TILT/RECLINE/ELEVATE
0° Seat Angle:
5° Seat Angle:
0° - 55° ± 3°
5° - 60° ± 3°
RECLINE RANGE (MEASURED RELATIVE
TO THE GROUND)
RECLINE ONLY, TILT/RECLINE AND TILT/
RECLINE/ELEVATE
0° Seat Angle:
5° Seat Angle:
90° - 170° ± 3°
95° - 170° ± 3°
SEAT-TO-FLOOR
0° SEAT ANGLE:
5° SEAT ANGLE:
1 inches ± .25 inches
19. inches ± .25 inches
ELEVATE RANGE: 7.0 inches
*OVERALL WIDTH WITH MODEL RA19
ARMS
WITH 4-WAY SWITCH:
OVER ARMPADS:
30.70 inches
2 .75 inches
*OVERALL HEIGHT (CONVENTIONAL
BACK WITHOUT HEADREST): 41.5 inches
NOTE: All dimensions are ± .50 inches unless otherwise indicated.
*NOTE: 20-inch deep x 20-inch wide with 24-inch high back.
**NOTE: Weight limitation is total weight (user weight plus an additional items that the user
ma require [back pack, etc.]). Example: If weight limitation of the wheelchair is 300 lbs and
additional items equal 25 lbs, subtract 25 lbs from 300 lbs. This means the maximum weight
limitation of the user is 275 lbs.
All manuals and user guides at all-guides.com

TYPICAL PRODUCT PARAMETERS
Formula™ Powered Seating 0 Part No 1122170
 WARNING
If the seating system is mounted onto a power wheelchair that has a weight
limitation greater than that of the seating system, the weight limitation is
maintained at the seating system’s limitation. Example: If a seating system with a
weight limitation of 300 lbs is mounted onto a power wheelchair with a weight
limitation of 400 lbs, then the power wheelchair is restricted to a 300 lb weight
limitation.
*OVERALL LENGTH
WITH MANUAL CENTER MOUNT FOOTREST
AT 90°:
WITHOUT FRONT RIGGINGS, FULL LENGTH
ARM, MPJ™JOYSTICK:
41.5 inches
37.3 inches
ARMRESTS
TILT ONLY, TILT/ELEVATE AND ELEVATE
ONLY:
RECLINE ONLY, TILT/RECLINE AND TILT/
RECLINE/ELEVATE:
Flip Back, Adjustable Height (9 - 13 inches) - Desk or Full
Length
Adjustable Height (11 - 16 inches) - Desk or Full Length
LEGRESTS: Swingaway Footrests, Power or Manual Center Mount
Footrests, Manual or Power Elevating Legrests
HEADRESTS: Curved, Contoured, Small or Large
WEIGHT LIMITATION:
ALL SEATING SYSTEMS WITH ELEVATE:
ALL SEATING SYSTEMS WITHOUT HEAVY
DUTY OPTION:
TILT ONLY, RECLINE ONLY OR TILT/RECLINE
SYSTEMS WITH HEAVY DUTY OPTION:
ALL SEATING SYSTEMS WITH VENT TRAY:
300 lbs
300 lbs
400 lbs
Subtract 50 lbs from the seating system weight limitations
(250 and 350 lbs respectively)
CONTOURA BACKS CON ENTIONAL
BACKS
NOTE: All dimensions are ± .50 inches unless otherwise indicated.
*NOTE: 20-inch deep x 20-inch wide with 24-inch high back.
**NOTE: Weight limitation is total weight (user weight plus an additional items that the user
ma require [back pack, etc.]). Example: If weight limitation of the wheelchair is 300 lbs and
additional items equal 25 lbs, subtract 25 lbs from 300 lbs. This means the maximum weight
limitation of the user is 275 lbs.
All manuals and user guides at all-guides.com

SECTION 1—GENERAL GUIDELINES
Part No 1122170 Formula™ Powered Seating
SECTION 1—GENERAL GUIDELINES
 WARNING
SECTION 1 - GENER L GUIDELINES contains important information for the safe
operation and use of this product. DO NOT use this product or any available
optional equipment without first completely reading and understanding these
instructions and any additional instructional material such as Owner’s Manuals,
Service Manuals or Instruction Sheets supplied with this product or optional
equipment. If you are unable to understand the Warnings, Cautions or Instructions,
contact a healthcare professional, dealer or technical personnel before attempting
to use this equipment - otherwise, injury or damage may occur.
epair or Service Information
Except for programming, DO OT service or adjust the wheelchair while occupied,
unless otherwise noted.
A pinch point exists between walking beam/head tube cap and telescoping tube when at
the lowest seat to floor height.
Pinch point may occur when returning the tilted seat to the full upright position or when
lowering the elevating seat. Make sure the hands and body of the occupant, attendants
and bystanders are clear of all pinch points before returning the tilted seat to the full
upright position or lowering the elevating seat.
Before adjusting, repairing or servicing the wheelchair, ALWAYS turn the wheelchair
power Off, otherwise, injury or damage may occur.
Invacare products are specifically designed and manufactured for use in conjunction with
Invacare accessories. Accessories designed by other manufacturers have not been tested
by Invacare and are not recommended for use with Invacare products.
Transport ready packages are not retrofittable to existing models and are not field
serviceable.
Wheelchairs should be examined during maintenance for signs of corrosion (water
exposure, incontinence, etc.). Electrical components damaged by corrosion should be
replaced IMMEDIATELY.
Wheelchairs that are used by incontinent users and/or are frequently exposed to water
may require replacement of electrical components more frequently.
Operation Information
Performance adjustments should only be made by professionals of the healthcare field or
persons fully conversant with this process and the driver's capabilities. Incorrect settings
could cause injury to the driver, bystanders, damage to the wheelchair and to
surrounding property.
All manuals and user guides at all-guides.com
all-guides.com

SECTION 1—GENERAL GUIDELINES
Formula™ Powered Seating 2 Part No 1122170
After the wheelchair has been set-up/adjusted, check to make sure that the wheelchair
performs to the specifications entered during the set-up procedure. If the wheelchair does
OT perform to specifications, turn the wheelchair Off immediately and reenter set-up
specifications. Repeat this section until the wheelchair performs to specifications.
DO OT leave the power button On when entering or exiting your wheelchair.
DO OT operate on roads, streets or highways.
DO OT climb, go up or down ramps or traverse slopes greater than 9°.
DO OT attempt to move up or down an incline with water, ice or oil film.
DO OT stand on the frame of the wheelchair.
DO determine and establish your particular safety limits by practicing bending, reaching
and transferring activities in the presence of a qualified healthcare professional before
attempting active use of the wheelchair.
DO OT attempt to reach objects if you have to move forward in your seat.
DO OT attempt to reach objects if you have to pick them up from the floor by reaching
between your knees.
DO OT lean over the top of the back upholstery to reach objects behind you, as this may
cause the wheelchair to tip over.
ALWAYS shift your weight in the direction you are turning. DO OT shift your weight
in the opposite direction of the turn. Shifting your weight in the opposite direction of the
turn may cause the inside drive wheel to lose traction and the wheelchair to tip over.
DO OT shift your weight or sitting position toward the direction you are reaching as the
wheelchair and/or seating system (if any) may tip over.
DO OT use an escalator to move a wheelchair between floors. Serious bodily injury may
occur.
DO OT use the footplates as a platform. When getting in or out of the wheelchair, make
sure that the footplates are in the upward position or swing footrests towards the outside
of the wheelchair.
EVER leave an unoccupied wheelchair unattended on an incline.
DO OT attempt to lift the wheelchair by any removable (detachable) parts. Lifting by
means of any removable (detachable) parts of the wheelchair may result in injury to the
user or damage to the wheelchair.
DO OT overtighten hardware attaching to the frame. This could cause damage to the
frame tubing.
ALWAYS keep hands and fingers clear of moving parts to avoid injury.
ALWAYS wear your seat positioning strap. The seat positioning strap is a positioning belt
O LY. It is not designed for use as a safety device withstanding high stress loads such as
auto or aircraft safety belts. If signs of wear appear, belt MUST be replaced immediately.
All manuals and user guides at all-guides.com

SECTION 1—GENERAL GUIDELINES
Part No 1122170 3 Formula™ Powered Seating
ALWAYS turn the wheelchair power Off and engage the motor locks/clutches to prevent
the wheels from moving before attempting to transfer in or out of the wheelchair. Also
make sure every precaution is taken to reduce the gap distance. Align both casters parallel
with the object you are transferring onto.
DO OT use with a broken or missing joystick knob.
DO OT use if joystick does not spring back to the neutral position or becomes sticky or
sluggish.
DO OT use if joystick boot is torn or damaged.
ALWAYS check foam grips for looseness before using the wheelchair. If loose, contact a
qualified technician for instructions.
ALWAYS engage both wheel locks and reduce the gap distance before transferring to and
from the wheelchair. Turn all casters parallel to the object you are transferring onto.
Avoid storing or using the wheelchair near open flame or combustible products. Serious
injury or damage to property may result.
Use caution when driving in a tilted, elevated or reclined position.
DO OT operate the seating system while on an incline.
DO OT operate the seating system while the wheelchair is moving.
EVER operate the wheelchair or elevate/lower the seat while in any tilted/reclined/back
angle position over 20° relative to the vertical position. If the drive lock-out does not stop
the wheelchair from operating or the seat from elevating/lowering in a tilt position over
20° relative to vertical, DO OT operate the wheelchair or elevate/lower the seat. DO
OT attempt to adjust the drive lock-out. Have the wheelchair serviced by a qualified
technician.
Use only the controls listed in Operating Powered Seating Systems on page 24 to activate
the powered seating functions*. DO OT USE any other actuator controls. Such devices
may result in excess heating and cause damage to the actuator and associated wiring and
could cause a fire, death, physical injury or property damage. If such devices are used,
Invacare shall not be liable and the limited warranty is void.
*NOTE: Specific actuator controls are noted for each function or combination throughout this
manual.
DO OT operate tilt seat around children.
ALWAYS keep hands and feet out from underneath tilt seat - otherwise serious injury
may result.
DO OT tip the seating system/wheelchair without assistance.
DO OT store items under seat.
Cables must be routed and secured properly to ensure that cables DO OT become
entangled and damaged during normal operation of seating system.
Systems equipped with power legrests only - EVER allow items to become trapped
between the legrest assemblies. Otherwise, damage to the power legrest could occur.
All manuals and user guides at all-guides.com

SECTION 1—GENERAL GUIDELINES
Formula™ Powered Seating 4 Part No 1122170
Weight Training
Invacare DOES OT recommend the use of its wheelchairs as a weight training
apparatus. Invacare wheelchairs have OT been designed or tested as a seat for any kind
of weight training. If occupant uses said wheelchair as a weight training apparatus,
Invacare shall not be liable for bodily injury and the warranty is void.
Weight Limitation
Refer to Typical Product Parameters in this manual and the Typical Product Parameters
in the owner’s manual shipped with the wheelchair base to determine the weight limit
(total combined weight of user and any attachments) of your wheelchair model. DO OT
exceed the limit - otherwise, injury or damage may result.
All manuals and user guides at all-guides.com

SECTION 2—EMI INFORMATION
Part No 1122170 5 Formula™ Powered Seating
SECTION 2—EMI INFORMATION
 WARNING
C UTION: IT IS VERY IMPORT NT TH T YOU RE D THIS INFORM TION
REG RDING THE POSSIBLE EFFECTS OF ELECTROM GNETIC
INTERFERENCE ON YOUR POWERED WHEELCH IR.
Electromagnetic Interference (EMI) From Radio Wave Sources
Powered wheelchairs and motorized scooters (in this text, both will be referred to
as powered wheelchairs) may be susceptible to electromagnetic interference (EMI),
which is interfering electromagnetic energy (EM) emitted from sources such as
radio stations, TV stations, amateur radio (H M) transmitters, two way radios, and
cellular phones. The interference (from radio wave sources) can cause the powered
wheelchair to release its brakes, move by itself, or move in unintended directions. It
can also permanently damage the powered wheelchair's control system. The
intensity of the interfering EM energy can be measured in volts per metre (V/m).
Each powered wheelchair can resist EMI up to a certain intensity. This is called its
"immunity level." The higher the immunity level, the greater the protection. t this
time, current technology is capable of achieving at least a 20 V/m immunity level,
which would provide useful protection from the more common sources of radiated
EMI.
There are a number of sources of relatively intense electromagnetic fields in the
everyday environment. Some of these sources are obvious and easy to avoid.
Others are not apparent and exposure is unavoidable. However, we believe that by
following the warnings listed below, your risk to EMI will be minimized.
The sources of radiated EMI can be broadly classified into three types:
1) Hand-held Portable transceivers (transmitters-receivers with the antenna
mounted directly on the transmitting unit. Examples include: citizens band (CB)
radios, "walkie talkie", security, fire and police transceivers, cellular telephones,
and other personal communication devices).
NOTE: Some cellular telephones and similar devices transmit signals while they are ON,
even when not being used.
2) Medium-range mobile transceivers, such as those used in police cars, fire trucks,
ambulances and taxis. These usually have the antenna mounted on the outside of
the vehicle; and
3) Long-range transmitters and transceivers, such as commercial broadcast
transmitters (radio and TV broadcast antenna towers) and amateur (H M)
radios.
NOTE: Other types of hand-held devices, such as cordless phones, laptop computers,
M/FM radios, TV sets, CD players, cassette players, and small appliances, such as elec-
tric shavers and hair dryers, so far as we know, are not likely to cause EMI problems to
your powered wheelchair.
All manuals and user guides at all-guides.com

SECTION 2—EMI INFORMATION
Formula™ Powered Seating 6 Part No 1122170
 WARNING
Powered Wheelchair Electromagnetic Interference (EMI)
Because EM energy rapidly becomes more intense as one moves closer to the
transmitting antenna (source), the EM fields from hand-held radio wave sources
(transceivers) are of special concern. It is possible to unintentionally bring high
levels of EM energy very close to the powered wheelchair's control system while
using these devices. This can affect powered wheelchair movement and braking.
Therefore, the warnings listed below are recommended to prevent possible
interference with the control system of the powered wheelchair.
Electromagnetic interference (EMI) from sources such as radio and TV stations,
amateur radio (H M) transmitters, two-way radios, and cellular phones can affect
powered wheelchairs and motorized scooters. lso, the electronics used in our
powered wheelchair can generate a low level of electromagnetic interference,
which however will remain within the tolerances permitted by law.
FOLLOWING THE W RNINGS LISTED BELOW SHOULD REDUCE THE
CH NCE OF UNINTENDED BR KE RELE SE OR POWERED WHEELCH IR
MOVEMENT WHICH COULD RESULT IN SERIOUS INJURY.
1) Do not operate hand-held transceivers (transmitters receivers), such as citizens
band (CB) radios, or turn ON personal communication devices, such as cellular
phones, while the powered wheelchair is turned ON;
2) Be aware of nearby transmitters, such as radio or TV stations, and try to avoid
coming close to them;
3) If unintended movement or brake release occurs, turn the powered wheelchair
OFF as soon as it is safe;
4) Be aware that adding accessories or components, or modifying the powered
wheelchair, may make it more susceptible to EMI (NOTE: There is no easy way
to evaluate their effect on the overall immunity of the powered wheelchair); and
5) Report all incidents of unintended movement or brake release to the powered
wheelchair manufacturer, and note whether there is a source of EMI nearby.
Important Information
1) 20 volts per meter (V/m) is a generally achievable and useful immunity level
against EMI (as of May 1994) (the higher the level, the greater the protection);
2) This device has been tested to a radiated immunity level of 20 volts per meter.
3) The immunity level of the product is unknown.
Modification of any kind to the electronics of this wheelchair as manufactured by
Invacare may adversely affect the EMI immunity levels.
All manuals and user guides at all-guides.com
all-guides.com

SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS
Part No 1122170 7 Formula™ Powered Seating
SECTION 3—SAFETY/HANDLING OF
WHEELCHAIRS
NOTE: For more information about safet /handling of the wheelchair, refer to the owner’s manual
that shipped with the wheelchair base.
Pinch Points
 WARNING
pinch point exists between head tube cap and walking beam.
pinch point exists between walking beam/head tube cap and telescoping tube
when the seat is in the lowest seat to floor height.
Pinch point may occur when returning the tilted seat to the full upright position or
lowering the elevated seat. Make sure the hands and body of the occupant, atten-
dants and bystanders are clear of all pinch points before lowering seat or returning
the tilted seat to the full upright position.
NOTE: For this procedure, refer to FIGURE 3.1.
FIGURE 3.1 Pinch Points
Pinch Point
Headtube Cap
Front
Caster
Telescoping Tube
Walking
eam
Walking eam
Headtube Cap
(Not Shown)
Front Caster
Pinch
Point
Pinch
Points
All manuals and user guides at all-guides.com

SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING
Formula™ Powered Seating 8 Part No 1122170
SECTION 4—SAFETY INSPECTION/
TROUBLESHOOTING
NOTE: Ever six months take our wheelchair to a qualified technician for a thorough inspection
and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation
of our wheelchair. To operate properl and safel , our wheelchair must be cared for just like an
other vehicle. Routine maintenance will extend the life and efficienc of our wheelchair.
NOTE: Refer to wheelchair base owner’s manual for additional safet inspection and
troubleshooting information.
Initial adjustments should be made to suit your personal body structure needs and
preference. Thereafter follow these maintenance procedures and those in the owner’s
manual shipped with the wheelchair base:
Safety Inspection Checklists
Inspect/Adjust Initially
CAUTION
s with any vehicle, the wheels and tires should be checked periodically for cracks
and wear, and should be replaced.
❑Inspect all fasteners.
❑Inspect TRBKTS fasteners and hardware.
❑Ensure clothing guards are secure.
❑Arms are secure but easy to release and adjustment levers engage properly.
❑Adjustable height arms operate and lock securely.
❑Upholstery has no rips.
❑Armrest pad sits flush against arm tube.
❑Check that all labels are present and legible. Replace if necessary.
❑Make sure all electrical connections are secure.
❑Check that cables are routed and secured properly to ensure that cables DO OT
become entangled and damaged during normal operation of seating system.
❑Check limit switch position for recline.
❑Make sure drive lock-out operates properly.
❑Make sure tilt operates smoothly and properly.
❑Make sure recline operates smoothly and properly.
❑Make sure elevate operates smoothly and properly.
All manuals and user guides at all-guides.com

SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING
Part No 1122170 9 Formula™ Powered Seating
❑Make sure seating systems with the recline function have the retaining pin in place at
the top of each back cane.
❑Make sure all systems, except Elevate Only, have the retaining pin in place at the back
of each seat rail.
❑Make sure elevate systems drive with reduced speed when seat is in elevated position.
❑Check that spreader bar mounting fasteners are tight.
❑Check that back cane mounting fasteners and back mounting fasteners are tight.
Inspect/Adjust Weekly
❑Inspect all fasteners.
❑Inspect TRBKTS fasteners and hardware.
❑Make sure all electrical connections are secure.
❑Check that cables are routed and secured properly to ensure that cables DO OT
become entangled and damaged during normal operation of seating system.
Inspect/Adjust Monthly
❑Clean upholstery and armrests.
❑Clean dirt and lint from axles.
❑Clean dirt and lint from bearings.
❑Inspect seat positioning strap for any signs of wear. Ensure buckle latches. Verify
hardware that attaches strap to frame is secure and undamaged. Replace if necessary.
❑Make sure drive lock-out operates properly.
❑Make sure tilt operates smoothly and properly.
❑Make sure recline operates smoothly and properly.
❑Make sure elevate operates smoothly and properly.
❑Make sure elevate systems drive with reduced speed when seat is in elevated position.
❑Check that spreader bar mounting fasteners are tight.
❑Check that back cane mounting fasteners and back mounting fasteners are tight.
Inspect/Adjust Periodically
❑Inspect all fasteners.
❑Inspect TRBKTS fasteners and hardware.
❑Ensure clothing guards are secure.
❑Arms are secure but easy to release and adjustment levers engage properly.
❑Adjustable height arms operate and lock securely.
All manuals and user guides at all-guides.com

SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING
Formula™ Powered Seating 20 Part No 1122170
❑Upholstery has no rips.
❑Armrest pad sits flush against arm tube.
❑Inspect foam handgrips for damage. If damaged, have them replaced by a qualified
technician.
❑Check that all labels are present and legible. Replace if necessary.
❑Inspect electrical components for signs of corrosion. Replace if corroded or damaged.
❑Check limit switch position for recline.
❑Make sure seating systems with the recline function have the retaining pin in place at
the top of each back cane.
❑Make sure all systems, except Elevate Only, have the retaining pin in place at the back
of each seat rail.
❑Check that spreader bar mounting fasteners are tight.
❑Check that back cane mounting fasteners and back mounting fasteners are tight.
Troubleshooting
NOTE: For additional troubleshooting information and explanation of error codes, refer to the
wheelchair base owner’s manual and the individual Electronics Manual supplied with each
wheelchair.
SYMPTOM PROBABLE CAUSE SOLUTIONS
Wheelchair Power On but does not
drive.
System tilted or reclined beyond
drive lock-out angle (20°).
Motor lock levers are
disengaged.
Return to neutral position (upright and
completely lowered). Refe to
Ope ating Powe ed Seating
Systems on page 24.
Contact Invacare/Dealer for service if
this does not solve the problem.
Engage motor lock levers. See
wheelchair base owner’s manual.
Seating system not functioning or
working intermittently.
Low batteries.
Faulty electrical connection.
Seat has been driven under a
heavy load for an extended
period of time.
Charge batteries.
Check all connections.
Allow time for the electronics to cool
down (Light Duty Use).
 SPM L Park Brake Fault or
 SPM R Park Brake Fault displays
and wheelchair does not drive.
Motor lock levers disengaged
(Error code E9 or E10).
Engage motor lock levers.
CHARGER PLUGGED IN displays. Battery charger connected
(Error code E2 ).
Unplug battery charger from the
wheelchair.
