Invacare P9000 XDT Manual

Owner’s Operator and Maintenance Manual
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
P9000™ XDT

REFERENCE DOCUMENTS
P9000
™
XDT 2Part No. 1118386
 WARNING
A QUALIFIED TECHNICIAN MUST PERFORM THE INITIAL SET UP
OF THIS WHEELCHAIR. ALSO, A QUALIFIED TECHNICIAN MUST
PERFORM ALL PROCEDURES IN THE SERVICE MANUAL.
WHEELCHAIR USERS: DO NOT SERVICE OR OPERATE THIS
EQUIPMENT WITHOUT FIRST READING AND UNDERSTANDING
(1) THE OWNER’S OPERATOR AND MAINTENANCE MANUAL
AND (2) THE SEATING SYSTEM’S MANUAL (IF APPLICABLE). IF
YOU ARE UNABLE TO UNDERSTAND THE WARNINGS,
CAUTIONS, AND INSTRUCTIONS, CONTACT INVACARE
TECHNICAL SUPPORT BEFORE ATTEMPTING TO SERVICE OR
OPERATE THIS EQUIPMENT OTHERWISE INJURY OR DAMAGE
MAY RESULT.
DEALERS AND QUALIFIED TECHNICIANS: DO NOT SERVICE OR
OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND
UNDERSTANDING (1) THE OWNER’S OPERATOR AND
MAINTENANCE MANUAL, (2) THE SERVICE MANUAL (IF
APPLICABLE) AND (3) THE SEATING SYSTEM’S MANUAL (IF
APPLICABLE). IF YOU ARE UNABLE TO UNDERSTAND THE
WARNINGS, CAUTIONS AND INSTRUCTIONS, CONTACT
INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO
SERVICE OR OPERATE THIS EQUIPMENT OTHERWISE, INJURY
OR DAMAGE MAY RESULT.
REFERENCE DOCUMENTS
DOCUMENT PART NUMBER
MK5™NX™Electronics Manual 1110532
NOTE: Updated versions of this manual are available on www.invacare.com.

TABLE OF CONTENTS
Part No. 1118386 3P9000
™
XDT
TABLE OF CONTENTS
REFERENCE DOCUMENTS ................................................................. 2
REGISTER YOUR PRODUCT ............................................................... 6
SPECIAL NOTES ................................................................................ 7
TYPICAL PRODUCT PARAMETERS .................................................... 8
LABEL LOCATIONS ........................................................................... 9
SECTION 1—GENERAL GUIDELINES ................................................. 10
Controller Settings/Repair or Service ................................................................................................. 0
Operating Information............................................................................................................................. 0
Tire Pressure ............................................................................................................................................. 2
Electrical Accessories .............................................................................................................................. 2
Batteries...................................................................................................................................................... 2
Charging Batteries ............................................................................................................................... 3
Grounding Instructions ........................................................................................................................... 4
Rain Test..................................................................................................................................................... 4
Weight Training ........................................................................................................................................ 4
Weight Limitation..................................................................................................................................... 5
SECTION 2—EMI INFORMATION ..................................................... 16
SECTION 3—SAFETY/HANDLING OF HEELCHAIRS ......................... 18
Stability and Balance................................................................................................................................. 8
Coping With Everyday Obstacles......................................................................................................... 9
A Note to Wheelchair Assistants ........................................................................................................ 9
Tipping.........................................................................................................................................................20
Tipping - Curbs.....................................................................................................................................20
Lifting/Stairways ........................................................................................................................................2
Transferring to and From Other Seats ...............................................................................................22
Reaching, Leaning and Bending - Forward ..........................................................................................22
Reaching and Bending - Backward ........................................................................................................23

TABLE OF CONTENTS
P9000
™
XDT 4Part No. 1118386
TABLE OF CONTENTS
SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING .................... 24
Safety Inspection Checklists...................................................................................................................24
Inspect/Adjust Initially .........................................................................................................................24
Inspect/Adjust Weekly........................................................................................................................25
Inspect/Adjust Monthly.......................................................................................................................25
Inspect/Adjust Periodically.................................................................................................................25
Troubleshooting - Mechanical ...............................................................................................................26
Troubleshooting Guide ...........................................................................................................................26
Checking Battery Charge Level.............................................................................................................27
SECTION 5— HEELCHAIR OPERATION ........................................... 28
SPJ™Joystick Switches and Indicators .................................................................................................28
Multi Function Charger Port .............................................................................................................28
On/Off Toggle Switch .........................................................................................................................28
Speed Control switch .........................................................................................................................28
Joystick....................................................................................................................................................28
Information Gauge Display ................................................................................................................29
Operating the Wheelchair......................................................................................................................3
Turning the Power On/Off................................................................................................................3
Using the Horn.....................................................................................................................................3
Using the Joystick to Drive the Chair .............................................................................................3
SECTION 6—FRONT RIGGINGS ........................................................ 33
Installing/Removing/Using the Footrest/Legrest................................................................................33
Installing..................................................................................................................................................33
Removing ...............................................................................................................................................33
Using .......................................................................................................................................................33
Adjusting the Footrest Height...............................................................................................................34
Replacing the Heel Loop.........................................................................................................................35
Raising/Lowering the Legrest Assembly ..............................................................................................35
SECTION 7—ARMS ......................................................................... 37
Adjusting Armrest Height.......................................................................................................................37
Swing-Back Arms ......................................................................................................................................38
Replacing Armrest Pad ............................................................................................................................38
SECTION 8—SEAT AND BACK ......................................................... 39
Replacing the Seat Upholstery...............................................................................................................39
Replacing the Back Upholstery..............................................................................................................40
Adjusting the Back Height ......................................................................................................................4
Replacing Seat Positioning Strap ...........................................................................................................42

TABLE OF CONTENTS
Part No. 1118386 5P9000
™
XDT
TABLE OF CONTENTS
SECTION 9—JOYSTICK .................................................................... 43
Preparing the Joystick for Use...............................................................................................................43
Repositioning the Joystick.......................................................................................................................44
SECTION 10—CASTER .................................................................... 45
Adjusting Forks .........................................................................................................................................45
SECTION 11—BATTERIES ................................................................ 46
When to Charge Batteries.....................................................................................................................46
Charging Batteries ....................................................................................................................................47
Description and Use of Battery Chargers......................................................................................47
Connecting the Battery Charger......................................................................................................48
Replacing the Batteries............................................................................................................................48
Recommended Battery Types...........................................................................................................48
Cleaning Battery Terminals ...............................................................................................................49
Removing/Installing the Battery Boxes ................................................................................................49
Installing/Removing Battery Tray......................................................................................................50
Installing/Removing Batteries Into/From Battery Boxes .............................................................5
Connecting Battery Cables ....................................................................................................................52
Direct Mount Method.........................................................................................................................53
Battery Clamp Method .......................................................................................................................56
Replacing Battery Box Retaining Strap............................................................................................59
SECTION 12—CLUTCH/MOTOR LOCK ............................................... 60
Engaging/Disengaging the Clutches.......................................................................................................60
SECTION 13— HEEL LOCKS ............................................................ 61
Installing/Adjusting/Using the Wheel Locks .......................................................................................6
Installing/Adjusting ...............................................................................................................................6
Using .......................................................................................................................................................62
SECTION 14—ANTI-TIPPERS ........................................................... 63
Installing/Removing/Adjusting Anti-Tippers........................................................................................63
Installing..................................................................................................................................................63
Removing ...............................................................................................................................................63
Adjusting Height...................................................................................................................................63
SECTION 15—TRANSPORTING ........................................................ 65
Transporting the P9000 XDT................................................................................................................65
Unfolding/Folding the Wheelchair ...................................................................................................65
Unfolding ..........................................................................................................................................65
Folding ...............................................................................................................................................65
LIMITED ARRANTY ..................................................................... 68

REGISTER YOUR PRODUCT
P9000
™
XDT 6Part No. 1118386
REGISTER YOUR PRODUCT
The benefits of registering include:
. Safeguarding your investment.
2. Ensuring long-term maintenance and servicing of your product.
3. Receiving updates with product information, maintenance tips and industry news.
Register ONLINE at warranty.invacare.com
Please have your model number and purchase date available to complete your registration.
Any registration information you submit will only be used by Invacare Corporation and protected
as required by applicable laws and regulations.

SPECIAL NOTES
Part No. 1118386 7P9000
™
XDT
SPECIAL NOTES
Signal words are used in this manual and apply to hazards or unsafe practices which
could result in personal injury or property damage. Refer to the table below for
definitions of the signal words.
NOTICE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO
CHANGE WITHOUT NOTICE.
WHEELCHAIR USER
As a manufacturer f wheelchairs, Invacare endeav rs t supply a wide variety f
wheelchairs t meet many needs f the end user. H wever, final selecti n f the
type f wheelchair t be used by an individual rests s lely with the user and his/her
healthcare pr fessi nal capable f making such a selecti n.
WHEELCHAIR TIE-DOWN RESTRAINTS AND SEAT RESTRAINTS
Wheelchair users sh uld NOT be transp rted in vehicles f any kind while in
wheelchairs. As f this date, the Department f Transp rtati n has n t appr ved
any tie-d wn systems f r transp rtati n f a user while in a wheelchair, in a m ving
vehicle f any type.
It is Invacare’s p siti n that users f wheelchairs sh uld be transferred int
appr priate seating in vehicles f r transp rtati n and use be made f the restraints
made available by the aut industry. Invacare cann t and d es n t rec mmend any
wheelchair transp rtati n systems.
 WARNING
Invacare pr ducts are specifically designed and manufactured f r use in c njuncti n
with Invacare access ries. Access ries designed by ther manufacturers have n t
been tested by Invacare and are n t rec mmended f r use with Invacare pr ducts.
The seat p siti ning strap is a p siti ning belt nly. It is n t designed f r use as a
safety device withstanding high stress l ads such as aut r aircraft safety belts. If
signs f wear appear, belt MUST be replaced immediately.
Wheelchairs sh uld be examined during maintenance f r signs f c rr si n (water
exp sure, inc ntinence, etc.). Electrical c mp nents damaged by c rr si n sh uld
be replaced immediately.
Wheelchairs that are used by inc ntinent users and/ r are frequently exp sed t
water may require replacement f electrical c mp nents m re frequently.
SIGNAL WORD MEANING
DANGER Danger indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARN NG Warning indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUT ON Caution indicates a potentially hazardous situation which, if not avoided, may result in
property damage.

TYPICAL PRODUCT PARAMETERS
P9000
™
XDT 8Part No. 1118386
TYPICAL PRODUCT PARAMETERS
*NOTE: Values for range are calculated for maximum chair weight rating using largest batteries
applicable U1), per test procedures described in ANSI/RESNA WC/VOL2-1998 Section 4 and
meet federal reimbursement requirements for this product. While considered typical, they are
derived based on certain ideal conditions. Variances in battery condition, user weight, usage
pattern or overall terrain conditions will result in actual values for range that differ from these
stated values. Users should become accustomed to how their unique conditions impact their
individual results. Users should become familiar with the battery discharge indicator on the
joystick to determine the range of their wheelchair. Refer to When to Charge Batteries on page 66
for more information about the battery discharge indicator.
**NOTE: Includes seating system and accessories.
P9000 XDT
SEAT WIDTH 18 inches
SEAT DEPTH 16 or 18-inches (by extension
BACK HEIGHT 17, 18, or 19 inches
SEAT-TO-FLOOR 19½ inches
OVERALL WIDTH
(EXCLUDING JOYSTICK
Unfolded - 24½ inches
Folded - 13 inches
OVERALL HEIGHT 38 inches (with 17 inch back
OVERALL LENGTH 28 inches (base only to 47 inches (with riggings and anti-tippers
WEIGHT
W/O BATTERIES AND FRONT RIGGINGS
WITH UI BATTERIES
SHIPPING
82 lbs
142 lbs
100 lbs
DRIVE WHEELS/TIRES (FLAT FREE) 12½ inches x 2¼ inches
CASTERS W/PRECISION SEALED
BEARINGS 8 x 1¾ inches semi-pneumatic
ANTI-TIPPERS Removable
FOOTRESTS/
LEGRESTS Swingaway, Removable
ARMRESTS Adjustable Height - Desk
UPHOLSTERY Black Nylon
BATTERIES
BATTERY/SIZE (NOT SUPPLIED
TWO REQUIRED U1
SPEED (M.P.H.) 0 to 4
TURNING RADIUS
CHAIR ONLY
CHAIR WITH FOOTREST
CHAIR WITH ANTI-TIPPERS
Front - 26 inches; Rear - 13 inches
36 inches
16 inches
*RANGE (VARIABLE) 12-14 miles with U1 batteries
**WEIGHT LIMITATION 250 lbs

LABEL LOCATIONS
Part No. 1118386 9P9000
™
XDT
LABEL LOCATIONS
Crossmember
Lower Frame
Tube
WARNING
DO NOT OPERATE WITHOUT
THE ANTI-TIP TUBES
INSTALLED.
REV. 5/98 P/N 60106X144
Refer to Owner's Manual
for proper anti-tipper
setting. 1085379
WARNING
IMPORTANT NOTICE
The wheel locks on this wheelchair have been
pre-set at the factory to comply with the
Veterans Administration functional Standard
8320 01 of the Federal Register, paragraph
3 2 4 5 3 If these wheel locks do not meet
your needs, follow instructions below
! CAUTION
Any wheel lock adjustments should embed
wheel lock shoe at least 1/8" into tire when
locked (3/16" on pneumatic tires)
INSTRUCTIONS FOR WHEEL
LOCK ADJUSTMENTS
1 Loosen wheel lock mounting fastener,
which runs through mounting bracket and
frame
2 Slide clamp toward rear wheel until wheel
lock shoe is embedded into tire material at
least 1/8" when handle is engaged to the
lock position (3/16" for pneumatic tires)
3 Tighten mounting fastener to secure
mounting bracket in desired location and
recheck lock shoe embedding
4 Inspect for correct locking action BEFORE
actual use
00078X021-0394
Serial Number Label
Location

SECTION —GENERAL GUIDELINES
P9000
™
XDT 0 Part No. 1118386
SECTION 1—GENERAL GUIDELINES
 WARNING
This secti n c ntains imp rtant inf rmati n f r the safe perati n and use f this
pr duct. DO NOT use this pr duct r any available pti nal equipment with ut
first c mpletely reading and understanding these instructi ns and any additi nal
instructi nal material such as Owner’s Manuals, Service Manuals r Instructi n
Sheets supplied with this pr duct r pti nal equipment. If y u are unable t under-
stand the Warnings, Cauti ns r Instructi ns, c ntact a healthcare pr fessi nal,
dealer r technical pers nnel bef re attempting t use this equipment - therwise,
injury r damage may ccur.
Controller Settings/Repair or Service
Set-up of the Electronic Control Unit is to be performed only by a qualified technician.
he final adjustments of the controller may affect other activities of the wheelchair.
Damage to the equipment could occur if improperly set-up or adjusted.
Wheelchairs should be examined during maintenance for signs of corrosion (water
exposure, incontinence, etc.). Electrical components damaged by corrosion should be
replaced IMMEDIA ELY.
Wheelchairs that are used by incontinent users and/or are frequently exposed to water
may require replacement of electrical components more frequently.
Operating Information
Performance adjustments should only be made by professionals of the healthcare field or
persons fully conversant with this process and the driver's capabilities. Incorrect settings
could cause injury to the driver, bystanders, damage to the chair and to surrounding
property.
After the wheelchair has been set-up, check to make sure that the wheelchair performs to
the specifications entered during the set-up procedure. If the wheelchair does not
perform to specifications, turn the wheelchair off immediately and reenter set-up
specifications. Repeat this procedure until the wheelchair performs to specifications.
ALWAYS shift your weight in the direction you are turning. DO NO shift your weight in
the opposite direction of the turn. Shifting your weight in the opposite direction of the
turn may cause the inside drive wheel to lose traction and the wheelchair to tip over.
DO NO shift your weight or sitting position toward the direction you are reaching as the
wheelchair may tip over.
DO determine and establish your particular safety limits by practicing bending, reaching
and transferring activities in the presence of a qualified healthcare professional before
attempting active use of the wheelchair.
