Invacare TRACER EX Installation instructions

TRACER EX
TRACER IV
HEAVY DUTY/EXTRAWIDE
TRACER TRANSPORT
INVACARE MG
R
R
R
R
Owner's Operator And Maintenance Manual
DEALER: THIS MANUAL MUST BE GIVEN TO THE USER
OF THE WHEELCHAIR.
USER: BEFORE USING THIS WHEELCHAIR, READ THIS
MANUAL AND SAVE FOR FUTURE REFERENCE.

2
W
A
R
N
I
N
G
WARNING
SAVE THESE INSTRUCTIONS
WARNING
DO NOT OPERATE THIS EQUIPMENT WITHOUT FIRST
READING AND UNDERSTANDING THIS MANUAL. IF YOU ARE
UNABLE TO UNDERSTAND THE WARNINGS, CAUTIONS, AND
INSTRUCTIONS,CONTACTAHEALTHCARE PROFESSIONAL,
DEALER OR TECHNICAL PERSONNEL IF APPLICABLE BEFORE
ATTEMPTING TO USE THIS EQUIPMENT - OTHERWISE INJURY OR
DAMAGEMAYRESULT.

3
TABLE OF CONTENTS
T
A
B
L
E
O
F
C
O
N
T
E
N
T
S
NOTE: The information in this owner's manual applies to the TRACER EX, TRACER IV, TRACER TRANSPORT
and the INVACARE MG wheelchairs except where specified.
TABLE OF CONTENTS
SPECIAL NOTES ................................................ 4
SAFETY SUMMARY ........................................... 5
SAFETY/HANDLING OF WHEELCHAIRS ............ 7
SPECIFICATIONS ............................................. 12
SAFETY INSPECTION CHECKLIST ................. 13
TROUBLESHOOTING ..................................... 14
MAINTENANCE ................................................ 14
PROCEDURE 1 - FRONT RIGGINGS ............... 15
SWINGAWAYFOOTRESTASSEMBLY
INSTALLATION................................................. 15
SWINGAWAYFOOTRESTHEIGHT
ADJUSTMENT ................................................. 15
HEEL LOOP REPLACEMENT ............................ 15
ELEVATINGLEGRESTASSEMBLY
INSTALLATION................................................. 16
ADJUSTINGTHEELEVATINGLEGREST
ASSEMBLY..................................................... 16
PROCEDURE 2 - ARMS.................................... 17
REMOVINGORREPLACINGSTANDARD
ARMREST....................................................... 17
ADJUSTINGARMRESTHEIGHT-ADJUSTABLE
HEIGHTARMSONLY ....................................... 17
USINGORREPLACINGFLIP-BACKARMREST .. 17
PROCEDURE 3 - SEAT AND BACK .................. 18
FOLD DOWN BACK - TRACER TRANSPORT
ONLY .............................................................. 18
REPLACINGBACKUPHOLSTERY..................... 18
REPLACINGTHESEATUPHOLSTERY .............. 18
ADJUSTINGSEATWIDTH .................................. 18
PROCEDURE 4 - REAR WHEELS..................... 20
REMOVING/INSTALLINGTHEREARWHEELS.... 20
REPLACINGREARWHEELHANDRIM ............... 20
REPLACING/REPAIRINGREARWHEEL
TIRE/TUBE...................................................... 20
PROCEDURE 5 - FRONT CASTERS ................ 21
INSTALLING/REPLACINGSIXOREIGHT-INCH
FRONT CASTERS AND FORKS...................... 21
ADJUSTINGFRONTCASTERS ......................... 21
REPLACING/REPAIRINGFRONTCASTER
TIRE/TUBE...................................................... 21
REPLACINGFRONTCASTERS ......................... 21
PROCEDURE 6 - SEAT-TO-FLOOR HEIGHTS . 22
CHANGINGSEAT-TO-FLOORHEIGHT-
TRACER EX ONLY .......................................... 22
PROCEDURE 7 - ANTI-TIPPERS/WHEEL LOCKS
23
INSTALLINGANTI-TIPPERS ................................ 23
WHEELLOCKADJUSTMENT ............................ 24
PROCEDURE 8 - OPTIONS.............................. 25
INSTALLINGAMPUTEEATTACHMENT ................ 25
INSTALLINGFIXEDHEIGHTI.V.ROD .................. 25
INSTALLINGTHECARRYINGPOCKET............... 25
INSTALLINGTHESEATPOSITIONINGSTRAP .... 26
INSTALLING/ADJUSTINGTHEFRONT
ANTI-TIPPERS................................................ 26
INSTALLINGTHETELESCOPINGI.V.ROD ......... 28
WARRANTY ...................................................... 31

4
SPECIAL NOTES
S
P
E
C
I
A
L
N
O
T
E
S
WARNING/CAUTION notices as used in this manual apply to hazards or unsafe practices which could
result in personal injury or property damage.
NOTICE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEELCAIR USER
As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to
meet many needs of the end user. However, final selection of the type of wheelchair to be used by an
individual rests solely with the user and his/her healthcare professional capable of making such a
selection.
WHEELCHAIR TIE-DOWN RESTRAINTS AND SEAT POSITIONING STRAPS
InvacarerecommendsthatwheelchairusersNOTbetransportedinvehiclesofanykindwhileinwheel-
chairs. As of this date, the Department of Transportation has not approved any tie-down systems for
transportation of a user while in a wheelchair, in a moving vehicle of any type.
It is Invacare’s position that users of wheelchairs should be transferred into appropriate seating in ve-
hicles for transportation and use be made of the restraints made available by the auto industry. Invac-
are cannot and does not recommend any wheelchair transportation systems.
ASREGARDSRESTRAINTS -SEATPOSITIONING STRAPS- IT ISTHE OBLIGATION OF THE DME DEALER, THERA-
PISTSANDOTHERHEALTHCAREPROFESSIONALSTODETERMINEIFASEATPOSITIONINGSTRAPISREQUIRED
TO ENSURE THE SAFE OPERATION OF THIS EQUIPMENT BY THE USER. SERIOUS INJURY CAN OCCUR IN THE
EVENT OF A FALL FROM A WHEELCHAIR.
SPECIAL NOTES

5
OPERATING INFORMATION WARNING
To determine and establish your particular safety limits, practice bending, reaching and transfer-
ring activities in several combinations in the presence of a qualified health professional BEFORE
attempting active use of the wheelchair.
DO NOT attempt to reach objects if you have to move forward in the seat.
DO NOT attempt to reach objects if you have to pick them up from the floor by reaching down
between your knees.
DO NOT lean over the top of the back upholstery to reach objects from behind as this may cause
the wheelchair to tip over.
DO NOT shift your weight or sitting position toward the direction you are reaching as the wheel-
chair may tip over.
DO NOT tilt the wheelchair without assistance.
DO NOT use an escalator to move a wheelchair between floors. Serious bodily injury may occur.
DO NOT attempt to stop a moving wheelchair with the wheel locks. WHEEL LOCKS ARE NOT
BRAKES.
Before attempting to transfer in or out of the wheelchair, every precaution should be taken to
reduce the gap distance. Turn both casters toward the object you are transferring onto. When
transferring to and from the wheelchair, ALWAYS ENGAGE BOTH WHEEL LOCKS.
DO NOT operate on roads, streets or highways.
DO NOT climb, go up or down ramps or traverse slopes greater than 9o.
DO NOT attempt to move up or down an incline with a water, ice or oil film.
DO NOT attempt to ride over curbs or obstacles. Doing so may cause your wheelchair to tip over
and cause bodily harm or damage to the wheelchair.
DO NOT use accessories, or adapters other than those authorized by Invacare.
DO NOT overtighten hardware attaching to the frame. This could cause damage to the frame tubing.
Keep hands and fingers clear of moving parts to avoid injury.
DO NOT attempt to lift the wheelchair by any removable (detachable) parts. Lifting by means of
any removable (detachable) parts of a wheelchair may result in injury to the user or damage to
the wheelchair.
DO NOT stand on the frame of the wheelchair.
Anti-tippers MUST BE attached at all times. Inasmuch as the anti-tippers are an option on this
wheelchair (You may order with or without the anti-tippers), Invacare strongly recommends or-
dering the anti-tippers as an additional safeguard for the wheelchair user.
When changing the seat-to-floor height you must adjust the anti-tippers accordingly.
DO NOT use the footplate as a platform when getting in or out of the wheelchair.
ALWAYS wear your SEAT POSITIONING STRAP. Inasmuch as the SEAT POSITIONING STRAP is an option on
thiswheelchair (Youmay order with or without the SEAT POSITIONING STRAP), Invacare stronglyrecom-
mends ordering the SEAT POSITIONING STRAP as an additional safeguard for the wheelchair user.
SAFETY SUMMARY
SAFETY SUMMARY
S
A
F
E
T
Y
S
U
M
M
A
R
Y

6
SAFETY SUMMARY
SAFETY SUMMARY
S
A
F
E
T
Y
S
U
M
M
A
R
Y
WARNING
TIRE PRESSURE
DO NOT use your wheelchair unless it has the proper tire pressure (p.s.i.). DO NOT overinflate the
tires. Failure to follow these suggestions may cause the tire to explode and cause bodily harm.
Replacement of a pneumatic tire or tube MUST be performed by an authorized Invacare Dealer
or Qualified Technician.
WEIGHT TRAINING
Invacare DOES NOT recommend the use of its wheelchairs as a weight training apparatus. In-
vacare wheelchairs have NOT been designed or tested as a seat for any kind of weight training.
If occupant uses said wheelchair as a weight training apparatus, INVACARE SHALL NOT BE LIABLE
FOR BODILY INJURY AND THE WARRANTY WILL BE VOID.
WEIGHT LIMITATION
The TRACER EX, TRACER TRANSPORT and INVACARE MG wheelchairs have a weight limitation of
250 lbs. The TRACER IV EXTRA WIDE wheelchair has a weight limitation of 350 lbs. The TRACER IV
HEAVY DUTY has a weight limitation of 450 lbs. with the heavy duty option.

7
S
A
F
E
T
Y
&
H
A
N
D
L
I
N
G
SAFETY/HANDLING
SAFETY/HANDLING OF WHEELCHAIRS
“Safety and Handling” of the wheelchair requires the close
attentionofthewheelchairuseraswellastheassistant.This
manualpointsoutthemostcommonprocedures and tech-
niques involved in the safe operation and maintenance of
the wheelchair. It is important to practice and master these
safe techniques until you are comfortable in maneuvering
around the frequently encountered architectural barriers.
Usethisinformationonlyasa“basic”guide.Thetechniques
that are discussed on the following pages have been used
successfully by many.
Individual wheelchair users often develop skills to deal with
daily living activities that may differ from those described in
thismanual. Invacare recognizesand encourages eachin-
dividual to try what works best for him/her in overcoming
architectural obstacles that they may encounter, however
ALL WARNINGS and CAUTIONS given in this manual
MUSTbefollowed.Techniquesinthismanualareastarting
pointforthenewwheelchairuserandassistantwith“safety”
as the most important consideration for all.
STABILITY AND BALANCE
WARNING
ALWAYSwearyourseatpositioningstrap.Inasmuch
astheSEATPOSITIONINGSTRAPisanoptiononthis
wheelchair(YoumayorderwithorwithouttheSeat
PositioningStrap),Invacarestronglyrecommends
orderingtheSeatPositioningStrapasanadditional
safeguard for the wheelchair user.
Toassurestabilityandproperoperationofyourwheelchair,
youmustatalltimesmaintainproperbalance.Yourwheel-
chairhas beendesignedtoremainupright andstabledur-
ing normal daily activities as long as you do not move be-
yond the center of gravity.
Virtuallyallactivitieswhichinvolvemovementinthewheel-
chair have an effect on the center of gravity. Invacare rec-
ommendsusingseat/chestpositioningstrapsforadditional
safety while involved in activities that shift your weight.
DO NOT lean forward out of the wheelchair any further
thanthe length of the armrests. Make sure thecastersare
pointingintheforwardpositionwheneveryouleanforward.
This can be achieved by advancing the wheelchair and
then reversing it in a straight line.
COPING WITH EVERYDAY
OBSTACLES
Coping with the irritation of everyday obstacles can be
alleviated somewhat by learning how to manage your
wheelchair. Keep in mind your center of gravity to main-
tain stability and balance.
A NOTE TO WHEELCHAIR
ASSISTANTS
When assistance to the wheelchair user is required, re-
member to use good body mechanics. Keep your back
straightandbendyourkneeswhenevertippingthewheel-
chair or traversing curbs, or other impediments.
WARNING
DO NOT attempt to lift the wheelchair by any re-
movable (detachable) parts. Lifting by means of
anyremovable(detachable)partsofawheelchair
may result in injury to the user or damage to the
wheelchair.
Also, be aware of detachable parts such as armrests or
legrests. These must NEVER be used for hand-held or
lifting supports, as they may be inadvertently released,
resultinginpossibleinjuryto the user and/or assistant(s).
When learning a new assistance technique, have an ex-
perienced assistant help you before attempting it alone.
PERCENTAGE OF WEIGHT
DISTRIBUTION
WARNING
DO NOT attempt to reach objects if you have to
move forward in the seat or pick them up from
thefloorbyreachingdownbetweenyourknees.
Many activities require the wheelchair owner to reach,
bend and transfer in and out of the wheelchair. These
movements will cause a change to the normal balance,
the center of gravity, and the weight distribution of the
wheelchair. To determine and establish your particular
safety limits, practice bending, reaching and transferring
activities in several combinations in the presence of a
qualified healthcare professional BEFORE attempting
active use of the wheelchair.
Proper positioning is essential for your safety. When
reaching, leaning, or bending forward, it is important
to use the front casters as a tool to maintain stability
and balance.

8
S
A
F
E
T
Y
&
H
A
N
D
L
I
N
G
SAFETY/HANDLING
CENTER OF
GRAVITY
Example 46% 54% 103 lbs. 130 lbs.
UNOCCUPIED OCCUPIED
FUNCTIONAL REACH FROM A
WHEELCHAIR
The approximate reach-limit values shown in the ac-
companying graph were derived on the basis of a
sample of 91 male and 36 female wheelchair users.
Note the difference between the maximum and the
comfortable reach limits, a subjective but important
consideration in design.
REACHING, LEANING AND
BENDING - FORWARD
Positionthe front casters so that they are extended as
far forward as possible and engage wheel locks. DO
NOTATTEMPTTOREACHOBJECTSIFYOUHAVE
TOMOVE FORWARDINTHESEATOR PICKTHEM
UP FROM THE FLOOR BY REACHING DOWN
BETWEEN YOUR KNEES.
FORWARD REACH
(ADULT)
COMFORTABLE MAXIMUM
INCHES
INCHES
REACHING, LEANING - BACKWARDS
WARNING
DO NOT lean over the top of the back uphol-
stery. This will change your center of gravity
and may cause you to tip over.
Position wheelchair as close as possible to the de-
sired object. Point front casters forward to create the
longest possible wheelbase. Reach back only as far
as your arm will extend without changing your sitting
position.

9
S
A
F
E
T
Y
&
H
A
N
D
L
I
N
G
SAFETY/HANDLING
TIPPING
WARNING
DONOT tip the wheelchair withoutassistance.
Whentippingthewheelchair,anassistantshouldgrasp
the back of the wheelchair on a non-removable (non-
detachable) part. Inform the wheelchair occupant be-
fore tipping the wheelchair and remind him/her to lean
back. Be sure the occupant’s feet and hands are clear
of all wheels.
After mastering the techniques of tipping the wheel-
chair, use one (1) of the following methods to tackle
curbs, short stairs, etc.
Tipping - Curbs: Method 1 - Wheelchair With
Step Tubes
Apply a continuous downward motion until the bal-
ance point is achieved and the front casters clear the
curb.Atthis point, the assistant willfeel a differencein
the weight distribution.
WARNING
When lowering the front casters of the wheel-
chair, DO NOT let the wheelchair drop the last
few inches to the ground. This could result in in-
jury to the occupant and/or damage to the
wheelchair.
Step Tube
Tipping - Curbs: Method 1 - Wheelchair
Without Step Tubes
This method requires two (2) assistants. The second
assistantshouldbepositionedatthefrontofthewheel-
chair lifting upward on a non-removable (non-detach-
able) part of the wheelchair frame when lifting the
wheelchair and stabilizing the wheelchair when the
wheelchair is being lowered to the ground.
The first assistant should stand on the sidewalk and
turnthewheelchairsothattherearwheelsareagainst
the curb. Turn the anti-tippers so the anti-tip wheels
are pointing up, The wheelchair should be tilted back
to the balance point and, in one continuous upward
movement, the rear wheels should be pulled up and
over the curb. DO NOT return the front casters to the
grounduntilthewheelchairhasbeenpulledbackward
far enough for the front casters to clear the edge of
the curb.
WARNING
When lowering the front casters of the wheel-
chair, DO NOT let the wheelchair drop the last
few inches to the ground. This could result in in-
jury to the occupant and/or damage to the
wheelchair.
RollthewheelchairbackwardandSLOWLY lowerthe
wheelchair in onecontinuous movement. DO NOT let
the wheelchair drop the last few inches to the ground.
This could result in injury to the occupant.
METHOD 2 - WHEELCHAIR WITHOUT STEP TUBE
Roll the wheelchair forward and slowly lower the front
of the wheelchair in one continuous movement onto
the sidewalk. Do not let the wheelchair drop the last
few inches to the ground. This could result in injury to
the occupant. Push the wheelchair forward until the
rear wheels roll up and over the curb.
METHOD 1 - WHEELCHAIR WITH STEP TUBE

10
S
A
F
E
T
Y
&
H
A
N
D
L
I
N
G
SAFETY/HANDLING
Positionthewheelchairascloseaspossiblealongside
the seat to which you are transferring, with the front
casters pointing toward it. Engage wheel locks. Shift
body weight into seat with transfer.
During independent transfer, little or no seat platform will
be beneath you. Use a transfer board if at all possible.
TRANSFERRING TO AND FROM
OTHER SEATS
WARNING
BEFORE attempting to transfer in or out of the
wheelchair,everyprecaution should betaken
to reduce the gap distance. Turn both casters
toward the object you are transferring onto.
Also be certain the wheel locks are engaged
to help prevent the wheels from moving.
CAUTION
Whentransferring, positionyourself as far back
as possible in the seat. This will help prevent
broken screws, damaged upholstery and the
possibility of the wheelchair tipping forward.
NOTE: This activity may be performed independently
provided you have adequate mobility and upper body
strength.
STAIRWAYS
WARNING
ALWAYSwearyourseatpositioningstrap.Inasmuch
astheSEATPOSITIONINGSTRAPisanoptiononthis
wheelchair(YoumayorderwithorwithouttheSeat
PositioningStrap),Invacarestronglyrecommends
orderingtheSeatPositioningStrapasanadditional
safeguard for the wheelchair user.
Do not attempt to lift a wheelchair by lifting
on any removable (detachable) parts. Lifting
by means of any removable (detachable)
parts of a wheelchair may result in injury tothe
user or damage to the wheelchair.
Extreme caution is advised when it is neces-
sary to move an occupied wheelchair up or
down the stairs. Invacare recommends using
two(2)assistants andmakingthorough prepa-
rations. Make sure to use ONLY secure, non-
detachable parts for hand-held supports.
Follow this procedure for moving the wheelchair be-
tween floors when an elevator is NOT available:
1. After the wheelchair has been tilted back to the
balance point, one assistant (in the rear) backs
the wheelchair up against the first step, while se-
curely grasping a non-removable (non-detach-
able) part of the wheelchair for leverage.
2. The second assistant, with a firm hold on a non-
detachable part of the framework, lifts the wheel-
chairupandoverthestairandsteadiesthewheel-
chair as the first assistant places one (1) foot on
the next stair and repeats STEP 1.
3. The wheelchair should not be lowered until the last
stair has been negotiated and the wheelchair has
been rolled away from the stairway.
ESCALATORS? SORRY!
DO NOT use an escalator to move a wheel-
chair between floors. Serious bodily injury may
occur.

11
S
A
F
E
T
Y
&
H
A
N
D
L
I
N
G
SAFETY/HANDLING
FOLDING AND UNFOLDING THE
WHEELCHAIR
WARNING
Keep hands and fingers clear of moving parts
to avoid injury.
Opening
1. Open the wheelchair by grasping the push handle
of the wheelchair closest to you.
2. Tilt the wheelchair towards you (raising the
opposite wheel and caster off the ground/floor).
3. Push downward on the TOP of the seat rail closest
to you where the seat upholstery is attached until
the wheelchair is fully open.
4. Engage both wheel locks, open the footrest/legrest
for clearance and transfer into the wheelchair. Refer
to TRANSFERRING TO AND FROM OTHER
SEATS in this section of the manual.
"HAMMOCK OR SLING SEAT" MODELS
Closing
1. Swing footrest/legrest in locked position to the front
of the wheelchair.
2. Pivot footplates upward to vertical position.
3. With both hands,grasp the middleof the seatuphol-
stery at the front and back edge and lift up.
NOTE: If wheelchair is equipped with carry straps, the
wheelchair may be closed by pulling up on the straps.
"HAMMOCK OR SLING SEAT" MODELS

12
S
P
E
C
I
F
I
C
A
T
I
O
N
S
SPECIFICATIONS
*Weights based on 18-inch wide chair without front rigging. All weights are approximate and will vary depending on
how wheelchair is equipped.
SPECIFICATIONS
Seat Width:
Seat Depth:
Overall Width:
Permanent Arm:
Removable Arm:
Overall Depth
(w/o riggings):
Seat-to-Floor:
Back Style:
Back Height:
ArmStyles:
Front Riggings:
Rear Axle:
Rear Wheels:
Handrims:
Wheel Locks:
Caster Size:
Upholstery:
Weight (approx)*:
Permanent Arm:
Removable Arm:
Shipping Weight
(approx.)*:
Permanent Arm:
Removable Arm:
TRACER IV
20, 22 and 24-inches
18-inches
N/A
27-1/2 to 31-1/2-inches
32-inches
21-inches
Fixed
16-inches
Fixed-Desk/Full Length
Adjustable Height -
Desk/Full Length
Swingaway Footrest/El-
evatingLegrest,Articulat-
ing Elevating Legrest
Permanent
24-inch Composite; DTM,
Pneumatic-Flat Free Insert
-(24-inch Composite
DTM Standard)
Chrome
Push to Lock
8 x 1-inch Solid Rubber
(Standard),8x1-3/4-inch
Semi-Pneumatic
Vinyl - dark blue (stan-
dard), Marina Blue,
Space Blue, Dove Grey,
Ruby, and Camel
N/A
52 lbs. (22" Wide)
N/A
62 lbs.
TRACERTRANSPORT
14,16,18 and 20-inches
16-inches
18-1/2 to 22-1/2-inches
19 to 25 inches
27-inches
21-inches
Fixed and Fold Down
16-inches
Permanent,
Fixed-Desk/Full Length
Swingaway Footrest,
Elevating Legrest
Permanent
8x1-inch Solid Rubber
(Standard),8x1-1/4-inch
Composite Urethane
N/A
Push to Lock
8 x 1-inch Solid Rubber
(Standard)8x1-1/4-inch
Composite Urethane
Vinyl - Lightweight Black
(Standard), Navy Blue,
Blue Topaz or Claret
Naughahyde and Navy
Textilene
26 lbs.
31 lbs.
30 lbs.
35 lbs.
INVACARE MG
16-1/2 and 18-inches
16-inches
23-1/4 and 24-3/4 inches
24-1/2 and 26-inches
32-1/2-inches
21-inches
Fixed
16-inches
Permanent or Remov-
able Fixed Height Desk/
Full Length
Hook On Elevating
Legrest,SwingawayFoot-
restandElevatingLegrest
Permanent
24-inchComposite-Ure-
thane Tire
Composite
Push to Lock
8 x 1-inch Solid Rubber -
Dark Grey
Silver Blue Vinyl
35lbs.(36-1/2lbs.forFixed
Front End)
38 lbs.
44-1/2 lbs. (46 lbs. for
Fixed Front End)
47-1/2 lbs.
TRACER EX
16-1/2,18and 20-inches
16-inches
23-1/4 and 24-3/4-inches
24-1/2,26,and28-inches
32-1/2-inches
21-inches
Fixed
16-inches
Permanent, Fixed-Desk/
Full Length
Swingaway Footrest,
Elevating Legrest,
PaddedElevatingLegrest
Permanent
20, 22, 24-inch Compos-
ite;Urethane,Pneumatic,or
Pneumatic Flat Free In-
sert- (24-inch Composite
Urethane Standard)
Composite (Standard),
Chrome, or Aluminum
Push to Lock
8 x1-inch Solid Rubber -
Dark Grey (Standard)
8 x1-inch Solid Rubber
-Light Grey,8 x1-1/4inch
Pneumatic or Pneumatic
Flat Free, 8x1-3/4-inch
Semi Pneumatic, 8x2-
inch Pnumatic, 6x1-inch
Urethane - Light Grey, or
Dark Grey
Midnight Blue (Stan-
dard), Ruby
35 lbs.
38 lbs.
44 1/2 lbs.
47 1/2 lbs.

13
SAFETY INSPECTION CHECK LIST
S
A
F
E
T
Y
I
N
S
P
E
C
T
I
O
N
ITEM
GENERAL
●Wheelchairrollsstraight(noexcessivedragorpulltooneside).
SEAT AND BACK (PROCEDURE 3)
●Inspectforripsorsagging.
●Inspectforlooseorbrokenhardware.
REAR WHEELS (PROCEDURE 4)
●Noexcessivesidemovementorbindingwhenliftedandspun.
HANDRIMS(PROCEDURE4)
●Inspectforsignsofroughedgesorpeeling.
SPOKES
●Inspectforbrokenspokes.
FRONT CASTER (PROCEDURE 5)
●Inspect wheel/fork assembly for proper tension by spinning caster;
castershouldcometoagradualstop.
●Loosen/tightenlocknutifwheelwobblesnoticeablyorbindstoastop.
●Wheel bearings are clean and free of moisture.
CAUTION:As withanyvehicle, thewheelsandtiresshould be
checkedperiodicallyforcracksandwear,andshouldbereplaced.
TIRES
●Inspect for flat spots and wear.
●Ifpneumatictires,check forproperinflation.
CAUTION: As with any vehicle, the wheels and tires should be
checkedperiodicallyforcracksandwear,andshouldbereplaced.
WHEELLOCKS(PROCEDURE7)
●Donotinterferewithtireswhenrolling.
●Pivotpointsfreeofwearandlooseness.
●Wheellocks easy to engage.
CLEANING
●Cleanupholsteryandarmrests.
SAFETY INSPECTION CHECKLIST
NOTE: Every six (6) months take your wheelchair to a qualified dealer for a thorough inspection and servicing. Regular cleaning
will reveal loose or worn parts and enhance the smooth operation of your wheelchair. To operate properly and safely, your
wheelchairmust becared forjust likeany othervehicle. Routinemaintenance willextend thelife and efficiency of your wheelchair.
Initialadjustmentsshouldbemadetosuitpersonalbodystructure/preference.Thereafterfollowthesemaintenanceprocedures:
INITIALLY
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
INSPECT/
ADJUST
WEEKLY
X
X
X
X
X
INSPECT/
ADJUST
MONTHLY
X
X
X
X
INSPECT/
ADJUST
PERIODICALLY
X
X
X
X
X
X
X

14
TROUBLESHOOTING/MAINTENANCE
T
R
O
U
B
L
E
S
H
O
O
T
I
N
G
M
A
I
N
T
E
N
A
N
C
E
MAINTENANCE SAFETY
PRECAUTIONS
WARNING
After ANY adjustments, repair or service
and BEFORE use, make sure all attach-
ing hardware is tightened securely - oth-
erwise injury or damage may result.
CAUTION
DO NOT overtighten hardware attaching
to the frame. This could cause damage
to the frame tubing.
SUGGESTED MAINTENANCE
PROCEDURES
1. BeforeusingyourTracerSerieswheelchair,makesure
allnutsandboltsaretight.Checkallpartsfordamageor
wearandreplace.Checkallpartsforproperadjustment.
WARNING
DO NOT use the wheelchair unless it has
the proper tire pressure (p.s.i.). DO NOT
overinflate the tires. Failure to follow these
suggestions may cause the tire to explode
and cause bodily harm.
2. If tires are pneumatic, recommended tire pressure is
listedonthesidewall of the tire.
3. Thewheelsandtires should be checked periodically
for cracks and wear, and should be replaced when
necessarybyyourauthorizeddealerorbyaqualified
technician.
4. Periodically check handrims to ensure they are se-
curelyattachedtotherearwheels.RefertoREPLAC-
ING REAR WHEEL HANDRIM in PROCEDURE 4
of this manual.
5. Periodically adjust wheel locks in correlation to tire
wear. Refer to WHEEL LOCK ADJUSTMENT in
PROCEDURE 7 of this manual.
6. Periodically check front caster and rear wheel hubs
to make sure they are clean.
7. Check Upholstery for sagging, rips or tears.
MAINTENANCE
TROUBLESHOOTING
SOLUTIONS
If pneumatic, check tires for cor-
rect and equal pressure.
Checkforloosestemnuts/bolts.
Check that both casters contact
ground at the same time.
CHAIR 3
WHEELS
X
LOOSENESS
IN CHAIR
X
SQUEAKS AND
RATTLES
X
CASTERS
FLUTTER
X
X
X
SLUGGISH TURN/
PERFORMANCE
X
X
CHAIR VEERS
LEFT/RIGHT
X
X
X

15
This Procedure includes the following:
Swingaway Footrest Assembly Installation
Swingaway Footrest Height Adjustment
Heel Loop Replacement
Elevating Legrest Assembly Installation
Adjusting the Elevating Legrest Assembly
SWINGAWAY FOOTREST HEIGHT
ADJUSTMENT (FIGURE 2)
NOTE: Release the footrest locking mechanism and lift
the footrest off of the hinge pins. Lay the assembly on a
flat surface to simplify this procedure.
1. Removeimpactguardsand/orcalfstrap,ifnecessary.
2. Loosen, but do not remove the bolt and locknut that
securethelowerfootrestassemblyto theupperfoot-
rest support.
3. Repositionthelowerfootrestassemblytothedesired
height.
4. Securely tighten the bolt and locknut.
5. Repeatthisprocedurefortheotherfootrest,ifneces-
sary.
6. Replaceimpact guardsand/orcalfstrap, ifnecessary.
WARNING
After ANY adjustments, repair or service and
BEFOREuse,makesure all attaching hardware
is tightened securely - otherwise injury or dam-
age may result.
SWINGAWAY FOOTREST ASSEMBLY
INSTALLATION (FIGURE 1)
1. Turn the footrest to the side (open footplate is per-
pendicular to wheelchair).
2. Install the hinge plates on the footrest onto the hinge
pins on the wheelchair frame.
3. Push the footrest towards the inside of the wheel-
chair until it locks into place.
NOTE: The footplate will be on the inside of the wheel-
chair when locked in place.
4. Repeatthisprocedurefortheotherfootrestassembly.
5. To release the footrest, push the footrest release le-
ver inward, rotate footrest outward.
Swingaway
Footrest
Assembly
Hinge
Plate
FIGURE 1 - SWINGAWAY FOOTREST
ASSEMBLY INSTALLATION
Footrest
Release
Lever
Hinge Plate
Hinge Pins
FIGURE 2 - SWINGAWAY FOOTREST HEIGHT
ADJUSTMENT
Upper
Footrest
Support
Bolt and
Locknut Lower
Footrest
Assembly
HEEL LOOP REPLACEMENT
(FIGURE 3)
NOTE: Heel loops are not available on Invacare MG
wheelchairs.
1. Loosen, but do not remove the bolt and locknut that
securethelowerhalfofthefootresttotheswingaway
footrest assembly.
2. Remove the lower footrest assembly.
3. Remove the phillips screw and locknut that secure
the heel loop to the footrest.
4. Slide heel loop over cane of the footrest assembly.
5. Replace heel loop.
6. Reverse STEPS 1-5 to reassemble.
NOTE: When securing the heel loop to the footrest as-
sembly, tighten the phillips screw and locknut until the
spacer is secure.
F
R
O
N
T
R
I
G
G
I
N
G
S
PROCEDURE 1
FRONT RIGGINGS

16
F
R
O
N
T
R
I
G
G
I
N
G
S
PROCEDURE 1 FRONT RIGGINGS
ELEVATING LEGREST ASSEMBLY
INSTALLATION (FIGURE 4)
6. To release the legrest, push the legrest release
handle toward the inside of the wheelchair
(facing the front of the wheelchair) and swing the
legrest assembly to the outside of the wheelchair.
ADJUSTING THE ELEVATING
LEGREST ASSEMBLY (FIGURE 5)
NOTE: Adjustments to Articulating Legrests and Fixed
Front End Legrests are performed in the same fasion as
the elevating legrest.
1. To adjust the elevating legrest, raise legs until the
desired height is obtained.
2. To reposition legrest to normal position, support leg
with one (1) hand and push release lever downward
with other hand.
3. Toadjustthecalfpad,turnpadtowardstheoutsideof
the wheelchair.
4. Slidethecalfpadupordownuntilthedesiredposition
is obtained.
5. To secure the calfpad, turn the calfpad towards the
inside of the wheelchair.
Phillips Screw
Spacer
Locknut
Bolt and Locknut
Heel Loop
FIGURE 3 - HEEL LOOP REPLACEMENT
1. Place legrest assembly on the outside of the wheel-
chair and install the hinge plates onto the hinge pins
on wheelchair frame (FIGURE 4).
2. Rotate legrest assembly toward the inside of the
wheelchair until it locks in place (FIGURE 4).
NOTE: The footplate will be on the inside of the wheel-
chair when locked in place.
3. Repeat this procedure for other legrest assembly.
4. After seated in wheelchair, adjust footrest to cor-
rect height by loosening the locknut and
sliding the lower footrest assembly tube up or
down until desired height is achieved.
5. Tighten locknut securely.
Slide Tube
Footplate
Release Lever
FIGURE 5 - ADJUSTING THE ELEVATING LEGREST
ASSEMBLY
Calfpad
Calfpad Rotated for
Height Adjustment
FIGURE 4 - ELEVATING LEGREST INSTALLATION
Calfpad
Assembly
Lower
Footrest
Assembly
Bolt and
Locknut
Hinge
Plates Footplate
Legrest Release Handle
Hinge Pins

17
This Procedure Includes the Following:
Removing or Replacing Standard Armrest
Adjusting Armrest Height - Adjustable
Height Arms Only
Using or Replacing Flip-Back Armrest
ARMS PROCEDURE 2
A
R
M
S
WARNING
After ANY adjustments, repair or service and BE-
FORE use, make sure all attaching hardware is
tightened securely - otherwise injury or damage
may result.
Makesure the armrest issecurely locked into the
arm socket BEFORE using the wheelchair.
FIGURE 3 - USING OR REPLACING FLIP-BACK
ARMREST
USING OR REPLACING FLIP-BACK
ARMREST (FIGURE 3)
WARNING
DO NOT operate or replace flip-back armrest
when wheelchair is folded.
Using
1. Press in armrest release button located on armrest
front tube.
2. Rotate front of armrest UP and BACK and out of
arm socket.
3. Reverse STEP 2 toreplace armrest to DOWN position.
4. Position the front of the armrest into the arm socket.
5. Ensure armrest is securely locked into arm socket
and snap button locks into place BEFORE using.
Replacing
1. Perform STEPS 1-2 above to flip the armrest back.
2. Remove bolt, washer, spacer and locknut securing
armrest to wheelchair frame.
3. Remove armrest from frame.
4. Position newinsertintonew rear armresttube,align-
ing the mounting holes.
Arm Socket
Armrest Release Button
Armrest Front
Tube
Washer Spacer
Armrest
Rear Tube
Nut
FIGURE 1 - REMOVING OR REPLACING
STANDARDARMREST
REMOVING OR REPLACING
STANDARD ARMREST (FIGURE 1)
1. Press in armrest release button located on armrest.
2. Pull straight up to remove armrest from arm sockets.
3. Replace armrest by reversing STEPS 1-2.
Arm Socket
Arm Socket
Armrest Release
Button
ADJUSTING ARMREST HEIGHT -
ADJUSTABLE HEIGHT ARMS ONLY
(FIGURE 2)
1. Unlock the armrest by flipping the height adjustment
leveron thetopfrontofthe armresttotheUP(HORI-
ZONTAL) position.
2. Adjust armrest to desired height.
NOTE:HeightadjustmentleverMUSTbeintheunlocked
position when placing armrest into the arm assembly.
3. Lock the armrest by pressing the height adjustment
leverintotheDOWN(VERTICAL)positionwhenthe
desired armrest height is achieved.
FIGURE 2 - ADJUSTING ARMREST HEIGHT -
ADJUSTABLE HEIGHT ARMS ONLY
Unlocked (Horizontal)
Height Adjustment Lever
Locked (Vertical)
5. Insert the new bolt through the armrest mounting
bracket, new washer, new spacer and new armrest
rear tube, as shown in FIGURE 3.
NOTE: Ensure the spacer sits flush against the armrest.
6. Install nut onto bolt. Torque to 55-60in./lbs.
Armrest
Mounting
Bracket
Bolt Armrest Rear
Tube
Insert
Mounting
Holes

18
REPLACING THE BACK
UPHOLSTERY (FIGURE 2)
1. Remove the screws and washers that secure the
existing back upholstery to the back canes.
2. Position new back upholstery on back canes as
shown in FIGURE 2.
REPLACING THE SEAT
UPHOLSTERY (FIGURE 3)
1. Remove the eight (8) screws that secure the exist-
ing seat upholstery to the crossbraces.
2. Remove the existing seat upholstery from the
crossbraces.
3. Install the new seatupholsterybyreversingSTEPS1-2.
FIGURE 3- REPLACING THE SEAT UPHOLSTERY
Screws
ADJUSTING SEAT WIDTH
WARNING
Adjusting the seat width of the wheelchair MUST
beperformedayanauthorizedInvacaredealer
or qualified technician.
Removing Lower Mounting Hardware
(FIGURE 4)
1. Remove the existing back and seat upholstery from
the wheelchair. Refer to REPLACING THE BACK
UPHOLSTERY and REPLACING THE SEAT UP-
HOLSTERY in this section of the manual.
NOTE: If adjusting the seat width of the wheelchair, back and
seatupholsteryaswellasthecrossbracesMUSTbereplaced.
2. Remove the four (4) screws and locknuts that se-
cure the insert tube to the lower wheelchair frame.
FIGURE 2 - REPLACING BACK UPHOLSTERY
Seat Upholstery
This Procedure Includes the Following:
Fold Down Back - Tracer Transport Only
Replacing Back Upholstery
Replacing the Seat Upholstery
Adjusting Seat Width
WARNING
AfterANYadjustments,repairorserviceandBEFORE
use,makesureallattachinghardwareistightened
securely - otherwise injury or damage may result.
FOLD DOWN BACK - TRACER
TRANSPORT ONLY (FIGURE 1)
Folding
1. Liftuponthetwo(2)releaseleversonthebackcanes.
2. Pull back on the handles to the desired position.
Unfolding
WARNING
Make sure the release levers are securely
locked in place BEFORE using the wheelchair.
1. Pull up on the two (2) back canes until the release
levers lock in place.
NOTE: There will be an audible click.
2. Pull on the handles to make sure the back is locked
in place.
FIGURE 1 - FOLD DOWN BACK - TRACER
TRANSPORTONLY
PROCEDURE 3 SEAT AND BACK
S
E
A
T
A
N
D
B
A
C
K
Release Lever
Back Cane
Handle
Washers
Washers
Back Upholstery
Screws
3. Securely tighten the new back upholstery to the back
canes with the screws and washers.

19
PROCEDURE 3SEAT AND BACK
S
E
A
T
A
N
D
B
A
C
K
Rear Seat Guide
Front Seat Guide
FIGURE 5 - ALL PERMANENT ARM
WHEELCHAIRS
Crossbrace
Hex Screw
Locknut
Wheelchair
Frame
Screw
Crossbrace
Insert
Tube
FIGURE 4 - REMOVING LOWER MOUNTING
HARDWARE
Removing Upper Mounting Hardware
1. Perform one (1) of the following:
ALLPERMANENTARMWHEELCHAIRS(FIGURE5).
a. While pushing down on the rear seat guide, pull
up the front seat guide until the front seat guide
releases from the wheelchair frame.
b. Pullthecrossbraceawayfromtherearseatguide.
c. Repeat STEPS a-b for opposite crossbrace.
d. Reverse STEPS a-c to assemble the upper
mounting hardware.
e. Reverse STEPS 1-5 in REMOVING LOWER
MOUNTING HARDWARE in this section of the
manual to reassemble the wheelchair.
c. Pullthecrossbraceawayfromtherearseatguide.
NOTE: Seat guide will remain attached to back tube.
d. Repeat STEPS a-c for opposite crossbrace.
e. Reverse STEPS a-d to assemble the upper
mounting hardware.
f. Reverse STEPS 1-5 in REMOVING LOWER
MOUNTING HARDWARE in this section of the
manual to reassemble the wheelchair.
Spacer
Crossbrace
FIGURE 6 - ALL REMOVABLE ARM
WHEELCHAIRS - EXCEPT TRACER IV
Front Seat Guide
Rear Seat Guide
3. Remove the inserts from the rear of the wheelchair.
4. Remove the hex screw and locknut that secure the
two (2) existing crossbraces together.
ALLREMOVABLE ARM WHEELCHAIRS -
EXPECT TRACER IV (FIGURE 6).
a. Pulluponthecrossbraceuntilthefrontseatguide
is removed from the wheelchair.
b. Removethetwo(2)spacersandfrontseatguide
from the crossbrace.
TRACER IV (FIGURE 7).
a. Pull up on the crossbrace until the front and rear
seat guides are removed from the wheelchair.
b. Remove the end cap, two (2) seat guides and
spacer from the crossbrace.
c. Repeat STEPS a-b for opposite crossbrace.
d. Reverse STEPS a-c to assemble the upper
mounting hardware.
e. Reverse STEPS 1-5 in REMOVING LOWER
MOUNTING HARDWARE in this section of
the manual to reassemble the wheelchair.
End Cap
Rear Seat Guide
Spacer
Crossbrace
Front Seat Guide
FIGURE 7 - TRACER IV

20
REMOVING/INSTALLING THE REAR
WHEELS (FIGURE 1)
1. Remove the dust cap, hex screw and locknut that
secure the rear wheel and axle spacer to the wheel-
chair.
2. Repeat STEP 1 for the opposite rear wheel.
3. To reinstall the rear wheel onto the wheelchair,
reverse STEPS 1-2.
NOTE: Make sure axle spacer is between rear wheel
and wheelchair frame.
REPLACING REAR WHEEL
HANDRIM (FIGURE 2)
1. Remove the rear wheel from the wheelchair.
2. Remove the button screws and washers that se-
cure the handrim to the rear wheel.
3. Remove the existing handrim.
4. Install the new handrim by reversing STEP 1-3.
5. Repeat the procedure for the opposite rear wheel if
necessary.
FIGURE 1 - REMOVING/INSTALLING THE REAR
WHEELS
Locknut
Axle Spacer
Hex Screw
Dust Cap
Rear Wheel
TRANSPORT
Axle Mounting Hole
Handrim
FIGURE 2 - REPLACING REAR WHEEL HANDRIM
Button
Screw
REPLACING/REPAIRING REAR
WHEEL TIRE/TUBE
WARNING
Replacement of rear wheel tire or tube MUST
be performed by an authorized Invacare
dealer or qualified technician.
CAUTION
Aswithanyvehicle,the wheels andtiresshould
be checked periodically for cracks and wear,
and should be replaced.
Axle Spacer
Axle Mounting
Hole
Locknut
Rear Wheel
Hex Screw
This Procedure Includes the Following:
Removing/Installing the Rear Wheels
Replacing Rear Wheel Handrim
Replacing/Repairing Rear Wheel Tire/Tube
WARNING
After ANY adjustments, repair or service and
BEFOREuse,makesure all attaching hardware
is tightened securely - otherwise injury or dam-
age may result.
R
E
A
R
W
H
E
E
L
S
PROCEDURE 4 REAR WHEELS
