inVENTer ZR10-D User manual

ZR10-D Controller
Installation and Operating Instructions 10/2013

ZR10-D Controller • Installation and Operating Instructions 10/2013
02
LEGAL NOTICES
WARNING SIGNS
These instructions contain information for your personal safety and to prevent material damage. Information for your
personal safety is denoted by a warning triangle. Information pertaining to material damage only has no warning
triangle. The warnings are grouped according to these levels of risk:
DANGER indicates that death or serious injury will result if proper precautions are not taken.
WARNING indicates that death or serious injury can result if proper precautions are not taken.
CAUTION with warning triangle indicates that minor injury can result
if proper precautions are not taken.
CAUTION without warning triangle indicates that material damage can result
if proper precautions are not taken.
BEWARE denotes that an undesirable event or state can result
if the relevant advisory is not heeded.
Should there be more than one level of risk, the warning for the highest level of risk is always used. A warning about
personal injury with a warning triangle may also include a warning about material damage.
NOTE denotes further, useful information.
QUALIFIED PERSONNEL
The unit/system may only be installed and operated in conjunction with this documentation. Installation, electrical
connection and initial startup of the unit/system may only be performed by qualified personnel. Qualified personnel
within the context of safety-related information in this documentation are those authorized to install, start up and
identify equipment, systems and electrical circuits in accordance with safety engineering standards.
INTENDED USE > WARNING
When installing the equipment/system, observe the applicable building codes, fire protection
regulations and accident prevention regulations of the Employer's Liability Insurance Association. Only
use the equipment/system as intended for the applications described in this documentation and only
in conjunction with the components recommended, approved and specified in this documentation
by Öko-Haustechnik inVENTer GmbH. Changes and modifications to the equipment/system are not
permitted. Trouble free and safe operation of the equipment/ system requires proper transportation,
proper storage and assembly, as well as careful operation and maintenance. This documentation is
part of the equipment/system and must be accessible at all times. Observe all safety regulations in
this documentation.
TRADEMARKS
inVENTer® is a registered trademark of ÖkoHaustechnik inVENTer GmbH. Other names used in this documentation
may be trademarks whose use by third parties may infringe upon the rights of the owner.
EXEMPTION FROM LIABILITY
The content of this documentation has been reviewed for compliance with the hardware and software described.
However, discrepancies cannot be ruled out and so liability cannot be assumed for full compliance. This
documentation is updated regularly. Necessary corrections and appropriate additions are always included in
subsequent versions.
As of: 10/2013

10/2013 ZR10-D Controller • Installation and Operating Instructions 10/2013 03
TABLE OF CONTENTS
1 Description of ZR10-D controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Overview .................................................................................................................5
1.2 Modes.....................................................................................................................7
1.3 Synchronization of multiple controllers...................................................................7
2 Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.1 Junction box ...........................................................................................................8
4.2 Surface mount and and control cabinet...............................................................10
5 Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.1 Junction box .........................................................................................................13
5.2 Surface mount and control cabinet......................................................................14
6 Startup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.1 Junction box .........................................................................................................16
6.2 Surface mount and control cabinet......................................................................17
7 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8 Technical details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
8.1 ZR10-D-Standard / ZR10-D-Flat ..........................................................................20
8.2 Transformer...........................................................................................................20
9 Deliverables and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
10 Maintenance and repair. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11 Troubleshooting and disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11.1 Troubleshooting ....................................................................................................21
11.2 Disposal................................................................................................................21
12 Warranty and service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
12.1 Terms of warranty .................................................................................................22
12.2 Service .................................................................................................................22
Legal notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

04 ZR10-D Controller • Installation and Operating Instructions 10/2013
Service information for iV14R, iV14R-Corner, iV14R-Sylt, iV14V, iV14V-Top, iV14V-Ohio, iV-Twin, iV25
CAUTION
These installation and operating instructions are valid only in conjunction with those for the iV14R, iV14R-
Corner, iV14R-Sylt, iV14V, iV14V-Top, iV14V-Ohio, iV25 and iV-Twin ventilation systems, and the USTS
overcurrent system, and complement them. All legal notices in the installation and operating instructions
are also applicable for this document without restriction. This pertains to the warning signs convention,
qualified personnel, intended use, trademarks and exemption from liability.

05
10/2013 ZR10-D Controller • Installation and Operating Instructions 10/2013
DESCRIPTION
1 DESCRIPTION
1.1 Overview
The ZR10-D controller is an electronic operating unit for controlling up to
• 4 iV14 ventilation systems or
• 2 iV25 ventilation systems or
• 2 iV-Twin ventilation systems
It features easy installation and straightforward operation. The ZR10-D controller allows the control of the iV14
ventilation system in two modes:
• Heat recovery (HR)
• Ventilation (V)
Dual frame
Cover with ventilation slots
Control knob
Blanking cover with ventilation slots
Figure 1: Front view of ZR10-D controller
1
2
4
3
1 2
4
3

06 ZR10-D Controller • Installation and Operating Instructions 10/2013
DESCRIPTION
Variants
The ZR10-D controller is available as two variants:
• ZR10-D-Standard
• ZR10-D-Flat
The ZR10-D-Standard and ZR10-D-Flat differ in the airflows in power stage 0. Use of the ZR10-D-Flat is rec-
ommended in rooms having the requirement that the ventilation system must remain ON to maintain ventilation
for moisture protection.
AIRFLOW (%) as a function of power stage
ZR10-D-Standard ZR10-D-Flat
Power stage 0 OFF 17%
Power stage 1 25%
Power stage 2 40%
Power stage 3 60%
Power stage 4 100%
Maximum *) 115%
*) Only permitted when the airflow requirement is increased for a short time (maximum 30 minutes)
The power stages of the fan can be adjusted in both modes.
Features
• Control of the ventilation system in 2 modes
• Continuous setting of the airflow with control knob
• Airflow indicators for 4 power stages
• LED display dependent on mode selected
• Synchronization of multiple controllers to each other
• Integrated thermostatic switch
Validity
This service information applies for these components:
COMPONENT ORDER NO.
ZR10-D-Standard controller 1003-0070
ZR10-D-Flat controller 1003-0071
Control knob actuator, 2-part 1003-0060
ZR10-D/31 electronic junction box 1003-0027
Control knob surface mount junction box 1003-0061
ZR10-D/31 control cabinet junction box 1003-0073

07
10/2013 ZR10-D Controller • Installation and Operating Instructions 10/2013
DESCRIPTION / CONTROLS AND INDICATORS
1.2 Modes
Heat recovery (HR)
The fan operates in line with the principle of regenerative heat exchange, and switches between Supply and
Extract mode at intervals of 70 seconds. When air is flowing out, the thermal accumulator charges itself from
the thermal energy of the ambient air. When the fan switches direction, it releases the thermal energy stored to
the fresh air supplied.This mode is the standard application during the heating season. It is also recommended
in the summer because the heat supply is reduced significantly when venting.
Ventilation (V)
The fan operates with no change of direction. The ventilation system must be set to Supply mode.
This mode is recommended for cooling rooms during summer nights.
1.3 Synchronization of multiple controllers
The ZR10-D controller allows multiple controllers to be synchronized to each other. It automatically rates the
line frequency via the upstream transformer and generates from it the interval switching of the fans.The follow-
ing requirements must be met for this:
• Each controller is connected to the power supply via its own transformer
• The transformers of all controllers to work synchronously are connected to the same power phase
(all to P1, P2 or P3) or all controller power supply lines are routed to a
common automatic circuit breaker in the meter cabinet
• An interference-free power signal must be available
2. CONTROLS AND INDICATORS
LED (orange) *)
LED (blue) *)
Control knob with finger guide
Power stage indicators (1 ... 4)
*) The LED is off when power stage 0 is set
Figure 2: ZR10-D controls and indicators
1
1
2
2
4
4
33

08 ZR10-D Controller • Installation and Operating Instructions 10/2013
INTERFACES / INSTALLATION
3. INTERFACES
The figure shows the layout of the interfaces on the ZR10-D controller board.
2-pin transformer connector
Jumper *)
3-pin fan connector
*) For service settings only
Figure 3: ZR10-D board interfaces
4. INSTALLATION
Danger - Before starting any work on electrical systems, disconnect all relevant equipment
from the power supply. When wiring the power supply, observe the requirements of Safety
Class II.
4.1 Junction box
Wall opening / wiring
1. Make a hole for the junction box in a vertical wall in the drywall or masonry of the interior area with these
dimensions:
• Depth: 76mm
• Height: 139mm
• Diameter: 68mm
2. Lay the round or ribbon cable in the wiring duct for the wall mounting box so that the ends protrude ap-
prox. 150 mm from the hole. This ensures that the controller can be connected.
Masonry / drywall
Fan bus connecting lead
Junction box
Transformer connecting lead (AC 230V, 50 Hz)
Figure 4: Fitting the wall mounting box
1
1
1
1
2
2
2
2
4
4
3
3
3
3

09
10/2013 ZR10-D Controller • Installation and Operating Instructions 10/2013
INSTALLATION
Installation in the wall
Fixing screws (assembly panel) Controller board mounting holes
Cavities Fan bus connecting lead
Cavity separator Mounting holes, support ring, blanking cover (x 2)
Terminal block power connector (AC 230V, 50 Hz)
Transformer connecting lead (AC 230V, 50 Hz)
Fan bus connector
Figure 5: Installing the junction box
1. Make two holes on the junction box - these must be in different cavities (top and bottom).
2. Guide the power and fan cables separately through one hole each.
3. Insert the junction box into the wall.
4. Use the 4 fixing screws (1) to secure the junction box to the wall.
5. Attach the 3-wire round cable or 6-wire ribbon cable to the connector (6).
6. Note the color sequence (Section Electrical connection > Connection example).
7. If ribbon cable is used, connect two leads in one conductor sleeve.
8. Connect the transformer connecting lead (5) to the terminal block (4)
Dimensional drawing
Figure 6: Dimensional drawing for junction box
1
1
1
1
2
2
2
4
4
2
3
3
3
3
5
5
75
142
60
71
Ø 69
6
6

10 ZR10-D Controller • Installation and Operating Instructions 10/2013
INSTALLATION
4.2 Surface mount and control cabinet
The ZR10-D controller is intended for installation into a surface mount junction box and for installation in a
control cabinet.
SURFACE MOUNT CONTROL CABINET
Figure 7: Front view
Wiring
SURFACE MOUNT CONTROL CABINET
Cable feedthrough (x 2, pre-stamped) Cable feedthroughs (x 12, pre-stamped)
Hole for fixing screw Fixing screws (x 2)
(2 x top / 2 x bottom)
Fan bus connecting lead with connector Fan connecting lead with connector
Power cable (AC 230V, 50 Hz) Power cable (AC 230V, 50 Hz)
Figure 8: Wiring
11
1
1
1
2 2
2 2
2
4 4
44
4
3 3
33
3
ACE MOUNT CONTROL CABINET
ACE MOUNT CONTROL CABINET
Cable feedthrough (x 2, pre-stamped) Cable feedthroughs (x 12, pre-stamped)
Hole for fixing screw
Fan bus connecting lead with connector Fan connecting lead with connector
Power cable (AC 230V, 50 Hz) Power cable (AC 230V, 50 Hz)

11
10/2013 ZR10-D Controller • Installation and Operating Instructions 10/2013
INSTALLATION
SURFACE MOUNT
1. In the surface mount junction box, break
out the two pre-stamped holes for the cable
feedthrough (1).
2. Bring the two cables (fan connector (3) and
power (4)) through separate holes.
3. Use at least two fixing screws at the top and
bottom to secure the surface mount box to
the mounting wall.
4. Attach the connector to the 3-wire round or 6-wire ribbon cable. If ribbon cable is used, connect two
leads in one conductor sleeve.
Note the color sequence (Section: Electrical connection > Connection example).
*) Pre-stamped holes for the cable feedthroughs are on the base plate and
also on the sides of the control cabinet junction box. This makes it possible to
tailor the wiring to your own practical requirements.
CONTROL CABINET
1. Break out the two pre-stamped holes (left and
right) in the control cabinet junction box, for the
cable feedthrough (1). *)
2. Bring the two cables (fan connector (3) and
power (4)) through separate holes.
3. Use the two fixing screws (2) on the left and
right to attach the control cabinet box on the
top hat rail so that the cavity with the notch is
on the right-hand side. Ensure that the two at-
tachment clamps on the underside of the base
plate fit into place accurately on the top hat rail.

12 ZR10-D Controller • Installation and Operating Instructions 10/2013
ELECTRICAL CONNECTION
1)
7)
6)
5)
4)
3)
2)
3)
1)
2)
3)
1)
2)
3)
1)
2)
3
5
6
2
9
7
8
10
8
4
1
5. ELECTRICAL CONNECTION
Danger- Before starting any work on electrical systems, disconnect all relevant equipment
from the power supply. Ensure that power leads and controller leads are routed separately.
CONNECTION EXAMPLE
CAUTION
Use only
these cable cross
sections for
the electrical
connection:
Fan bus:
0.5 - 0.75 mm2
Transformer:
0.5 - 1.5 mm2
Fuse Ribbon cable Round cable
Main switch 1) White/Brown White
Terminal 2) Yellow/Green Green
Transformer 3) Gray/Pink Brown
Power supply (230V AC, 50 Hz), 2-pin
Transformer connector (AC 20V, 1.5A), 2-pin Power lines
ZR10-D controller 4) Blue (neutral) *)
Grid voltage
Fan bus (socket contact turnable) 5) Brown (phase) *)
Distributor box 6) Black
Operating voltage
Fan 1 ... 4 7) Red Controller
*) Other controllers connectable.
Figure 9: ZR10-D controller connection example
1
2
4
3
6
7
8
9
10
Fuse
Main switch 1) White/Brown White
Terminal 2) Yellow/Green Green
Transformer 3) Gray/Pink Brown
Power supply (230V AC, 50 Hz), 2-pin
Transformer connector (AC 20V, 1.5A), 2-pin
ZR10-D controller 4) Blue (neutral) *
Grid voltage
Fan bus (socket contact turnable) 5) Brown (phase) *
Distributor box 6) Black
Operating voltage
Fan 1 ... 4 7) Red Controller
*) Other contr
Fuse
Main switch 1) White/Brown White
Terminal 2) Yellow/Green Green
Transformer 3) Gray/Pink Brown
Transformer connector (AC 20V, 1.5A), 2-pin
ZR10-D controller 4) Blue (neutral) *
Grid voltage
Fan bus (socket contact turnable) 5) Brown (phase) *
Distributor box 6) Black
Operating voltage
Fan 1 ... 4 7) Red Controller
Operating voltage
Fan 1 ... 4 7) Red Controller
Distributor box 6) Black
Operating voltage
Grid voltage
Fan bus (socket contact turnable) 5) Brown (phase) *
ZR10-D controller 4) Blue (neutral) *
Grid voltage
Transformer connector (AC 20V, 1.5A), 2-pin
Transformer 3) Gray/Pink Brown
Terminal 2) Yellow/Green Green
Main switch 1) White/Brown White
Fuse
Grid voltage
Grid voltage
Grid voltage
Grid voltage
Grid voltage
Grid voltage
Operating voltage
Operating voltage
Operating voltage
Operating voltage
Operating voltage
Operating voltage
5
Transformer 3) Gray/Pink Brown
Terminal 2) Yellow/Green Green
Main switch 1) White/Brown White
Ribbon cable Round cable
Operating voltage
Fan 1 ... 4 7) Red Controller
Operating voltage
Grid voltage
Grid voltage
Grid voltage
Operating voltage

13
10/2013 ZR10-D Controller • Installation and Operating Instructions 10/2013
ELECTRICAL CONNECTION
5.1 Junction box
Fan bus connecting lead
Controller connecting lead
Dividing plate hole
Terminal block power connection (AC 230V, 50 Hz)
Transformer connecting lead (AC 230V, 50 Hz)
Transformer
Figure 10: ZR10-D transformer electrical connection
1. Use the terminal block (4) to connect the connecting lead (5) of the transformer to the power supply
(230V, 50 Hz).
2. Insert the transformer into the junction box.
3. Insert the dividing plate such that the connecting lead to the controller (2) leads upwards through the
hole (3).
Fan bus connecting lead
Controller connecting lead
Support ring for blanking cover
Support ring fixing screw (x 2)
Detents upward
Figure 11: Support ring attachment
1. Use both fixing screws (4) to secure the support ring (3) to the junction box. Ensure that the two
detents (5) are at the top and bottom and are facing out of the junction box.
Junction box
Fan bus connecting lead
Controller connecting lead
Figure 12: Board connection
1. Attach the fan connector (2) to the socket contact on the controller board.
2. Attach the transformer connector (3) to the socket contact on the controller board.
1
1
1
1
2
2
22
4
4
4
4
3
3
33
6
6
5
5
55
1
1
2
2
3
3

14 ZR10-D Controller • Installation and Operating Instructions 10/2013
ELECTRICAL CONNECTION
5.2 Surface mount and control cabinet
SURFACE MOUNT CONTROL CABINET
Controller connecting lead with connector Controller connecting lead with connector
Fan bus connecting lead with connector Fan bus connecting lead with connector
Dividing plate with opening for cable feedthrough
Dividing plate with opening for cable feedthrough
Transformer Transformer
Transformer connecting lead (AC 230V, 50 Hz) Transformer connecting lead (AC 230V, 50 Hz)
Terminal block power connector (AC 230V, 50 Hz)
Terminal block power connector (AC 230V, 50 Hz)
Notch on housing
Figure 13:Transformer connection
SURFACE MOUNT CONTROL CABINET
1. Insert the transformer into the lower 1. Insert the transformer into the right-hand
cavity. cavity (with notch on housing (7)).
2.
Use the terminal block (6) to connect the connecting lead (5) of the transformer to the power supply .
3. Route the controller connecting lead (1) into the top/left-hand cavity.
4. Push the dividing plate aside. Ensure that the controller connecting lead (1)
is positioned accurately in the hole. This will mean the cable is not squashed.
*) Always ensure that the short fixing screws are fitted on the right-hand side
1
1
1 1
2
2
2 2
4
4
4 4
3
3
3 3
6
6
6 6
7
7
ACE MOUNT CONTROL CABINET
Controller connecting lead with connector
Fan bus connecting lead with connector Fan bus connecting lead with connector
ough
Transformer Transformer
Terminal block power connector (AC 230V, 50 Hz)
Notch on housing
ACE MOUNT CONTROL CABINET
ormer into the lower 1. Insert the transformer into the right-hand
cavity (with notch on housing (7)).
5
5
5 5

15
10/2013 ZR10-D Controller • Installation and Operating Instructions 10/2013
ELECTRICAL CONNECTION
SURFACE MOUNT CONTROL CABINET
Fan bus connecting lead Fan bus connecting lead
Controller connecting lead Controller connecting lead
Controller board Controller board
Support ring for blanking cover Support ring for blanking cover
Detents (x 2) Detents
Support ring fixing screw (x 2) Support ring fixing screw
Figure 14: Controller connection
1. Use the two fixing screws (6) to attach the support ring (4) to the junction box. Ensure that the two de-
tents (5) are at the top and bottom and face out of the junction box. The detents are used for accurate
attachment of the blanking cover.
2. Connect the fan connecting lead plug (1) to the 3-pin interface of the controller board (3) and the con-
troller connecting lead plug (2) to the 2-pin interface.
1
1
1
2
2
2
4
4
4
3
3
3
6
6
6
ACE MOUNT CONTROL CABINET
Fan bus connecting lead Fan bus connecting lead
Controller connecting lead
d Controller board
ver Support ring for blanking cover
Detents
ew (x 2) Support ring fixing screw
5
5
5
1
243
6
5
1

16 ZR10-D Controller • Installation and Operating Instructions 10/2013
STARTUP
6 STARTUP
6.1 Junction box
Caution
- Make sure that all renovation work inside the building has been completed. This
ensures that the ZR10-D controller does not come into contact with wall paint, wallpaper glue
and plaster, so that its functionality is maintained.
Board fixing screw (x 2)
Control knob slot (seat for control knob)
*)
*) Horizontal alignment
Figure 15: Installing the board
1.
Turn the controller board such that all cables are pointing backwards and the "CE" mark in the top left
is visible.
2.
Use two fixing screws (1) on the left and right to mount the board on the junction box.
3.
Check that the control knob slot (2) is aligned horizontally. Correct the position using a screwdriver if
required. Horizontal alignment is necessary for accurate fitting of the control knob (Section Fitting the
control knob and blanking cover (Figure 17) and Section Fitting the control knob (Figure 21)).
Frame
Cover with ventilation slots
Cover fixing screw
Figure 16: Fitting the frame and cover
1.
Put the frame (1) on
2.
Put the cover (2) on. Make sure that the hole for the fixing screw is at the bottom.
3.
Use the screw (3) to attach the cover.
1
1
1
1
2
2
3
3
2
2

17
10/2013 ZR10-D Controller • Installation and Operating Instructions 10/2013
STARTUP
Power stage 0
Marker line for switch position
Finger guide
Blanking cover with ventilation slots
Blanking cover snap-fits
Figure 17: Fitting the control knob and blanking cover
1. Fit the control knob. Ensure that the marker (2) is in the power stage 0 (1) position using the finger guide (3).
Only in this position does the control knob lock into place correctly in the controller board.The prerequisite
is horizontal seating of the control knob slot on the board (see also Figure 15: Fitting the board).
2. Put the blanking cover (4) on and allow the snap-fits (5) to lock into place. Ensure that the ventilation slots
face upwards and downwards.
6.2 Surface mount and control cabinet
SURFACE MOUNT CONTROL CABINET
Fixing screw (x 2)
Figure 18: Fitting the ZR10-D controller
1. Fold the controller board upwards
2. Use the two fixing screws (1) to attach the controller board
1
1
1
1
1
2
2
4
4
3
3
ACE MOUNT CONTROL CABINET
5
5
1
4
3
5

18 ZR10-D Controller • Installation and Operating Instructions 10/2013
STARTUP
SURFACE MOUNT / CONTROL CABINET
Dual frame
Blanking cover with ventilation slots
Figure 19: Fitting the frame and blanking cover
1. Put on the frame (1)
2. Position the blanking cover (2) and allow its snap-fits to lock into place. Ensure that the ventilation slots
are aligned up and down.
SURFACE MOUNT / CONTROL CABINET
Cover with ventilation slots
Fixing screw
Figure 20: Fitting the control cover
1. Put the cover (1) on
2. Make sure that the hole for the fixing screw is at the bottom. Use the screw (2) to attach the cover.
1
2
2
1
2
1
1
2
2
1
2
1

19
10/2013 ZR10-D Controller • Installation and Operating Instructions 10/2013
STARTUP
Finger guide
Marker line for switch position
Power stage 0
Figure 21: Fitting the control knob
1. Put on the control knob. Ensure that the marker (2) is in the power stage 0 (3) position using the finger
guide (1). Only in this position does the control knob lock into place correctly in the controller board.The
prerequisite is horizontal seating of the control knob slot on the board
(see also Figure 15: Fitting the board).
7 OPERATION
The position of the knob enables you to control:
• Switching between modes
• The intensity of the airflow (power stages)
POWER STAGE 0 POWER STAGE 1 ... 4
Mode - *)Heat recovery Ventilation
Knob Off Left Right
LED (orange) **)Off Steady light Off
LED (blue) **)Off Steady light Off
*) The ZR10-D-Flat controller does not switch off but operates in HR or V mode
**) The luminosity of the LED increases or decreases depending on the power stage set On the ZR10-D-Flat
controller, the LED of the mode set last remains active
Figure 22: Operation of the ZR10-D-Standard
1. Turn the marker line on the knob to the power stage indicator you wish to set. Information on the power
stages of the fan is available in Section Description > Overview.
1
1
1
2
2
3
POWER STAGE 0 POWER STAGE 1 ... 4
Heat recovery Ventilation
Off Left Right
Off Steady light Off
Off Steady light Off
Heat recovery Ventilation
Off Left Right
Off Steady light Off
Off Steady light Off
POWER STAGE 0 POWER STAGE 1 ... 4
- *
Off Left Right
Off Steady light Off
Off Steady light Off
1
2
3
2

20 ZR10-D Controller • Installation and Operating Instructions 10/2013
TECHNICAL DETAILS
8. TECHNICAL DETAILS
8.1 ZR10-D-Standard / ZR10-D-Flat
VOLTAGE SUPPLY
Power supply AC 230V, 50 Hz
Transformer AC 18V (extra-low safety voltage)
Fan DC 6 ... 16V
POWER CONSUMPTION
Total 15W (max.)
Total switched current Max. 0.4 A (transient: 1 A)
Dimensions (mm) Height x width: 80 x 80 Depth: 22
Weight (g) 28
Operation at °C 0 ... 60°C
8.2Transformer
Protection type to EN 61558 IP20
Protection class II
Voltage supply AC 230V, 50-60 Hz
Power consumption 0.5 W (standby)
Total switched current Max. 2 A
Inputs Terminal block (2-pin, brown/blue): AC 230V, 50 Hz
Outputs Connector (2-pin, black/red): AC 19-21V, 50 Hz
Dimensions (mm) Diameter: 58 Depth: 36
Weight (g) 336
Operation at °C 0 ... 60°C
Thermostatic switch 100°C
9. DELIVERABLES AND ACCESSORIES
Deliverables
• ZR10-D controller (controller with transformer)
• Control unit
• Junction box appropriate for the installation (wall, surface mount or control cabinet)
Weight (g) 28
Weight (g) 28
0 ... 60°C
Weight (g) 28
Height x width: 80 x 80 Depth: 22
Total switched current Max. 0.4 A (transient: 1 A)
Fan DC 6 ... 16V
Total 15W (max.)
Transformer AC 18V (extra-low safety voltage)
Power supply AC 230V, 50 Hz
Weight (g) 28
100°C
0 ... 60°C
Weight (g) 336
Diameter: 58 Depth: 36
Connector (2-pin, black/red): AC 19-21V, 50 Hz
Terminal block (2-pin, brown/blue): AC 230V, 50 Hz
Total switched current Max. 2 A
Power consumption 0.5 W (standby)
Voltage supply AC 230V, 50-60 Hz
Protection class II
Protection type to EN 61558 IP20
