inveo Nano Relay Output PoE User manual

User manual
The Relay Output Module
Nano Relay Output PoE
Nano Relay Output
Soft >= 1.21
INVEO s.c.
ul. Rzemieślnicza 21
43-340 Kozy
tel: [phone]
www.inveo.com.pl
[email protected]

Dear Customer!
Thank you very much for choosing our product. Before its use, please read these
instructions carefully. Here you find the most appropriate ways of dealing with this
device, the basic principles of safety and maintenance. Please, also keep the user manual
so that you can read it during later use.
Attent on!
The manufacturer s not l able for any damage caused by mproper use of
the dev ce wh ch d ffer from ts ntended purpose, or mproper handl ng, as well
as a fault of dr ver result ng from mproper use.
User manual Nano Relay Output PoE / Nano Relay Output Page 2 of 29
[B02a]

Contents:
1 PRELIMINARY INFORMATION...................................................................................................................4
2 APPLICATION OF THE DEVICE..................................................................................................................5
3 WARRANTY AND LIABILITY OF THE MANUFACTURER...................................................................5
4 SAFETY GUIDELINES.....................................................................................................................................6
4.1 STORAGE, WORK AND TRANSPORT CONDITIONS.........................................................................................................6
4.2 INSTALLATION AND USE OF THE DEVICE..................................................................................................................6
4.3 DECOMMISSIONING OF THE DEVICE.........................................................................................................................6
5 CONSTRUCTION OF THE DEVICE..............................................................................................................7
5.1 NANO RELAY OUTPUT POE.................................................................................................................................7
5.2 NANO RELAY OUTPUT........................................................................................................................................
6 CONFIGURATION OF THE DEVICE.........................................................................................................11
6.1 CHANGING THE DEVICE'S IP ADDRESS BY DISCOVERER APPLICATION.........................................................................11
6.2 CHANGING THE PC'S SUBNET ADDRESS, FOR THE DEVICE CONFIGURATION..................................................................12
6.3 SECURITY SETTINGS AND ADMINISTRATION............................................................................................................14
7 THE DEVICE FUNCTIONS...........................................................................................................................15
7.1 OUTPUT CONTROL.............................................................................................................................................15
7.2 CONFIGURATION OF THE OUTPUT CHANNEL............................................................................................................15
7.3 DESTINATION CLIENT (M2M)...........................................................................................................................17
7.4 SNMP CONFIGURATION....................................................................................................................................21
7.5 WINDOWS COMMAND LINE SOFTWARE..................................................................................................................22
7.6 LINUX CONTROL PROGRAM.................................................................................................................................22
7.7 MODBUS TCP.................................................................................................................................................23
7.8 COMMUNICATION VIA THE MQTT INVEO PROTOCOL.............................................................................................24
7. CONTROL VIA HTTP PROTOCOL.........................................................................................................................25
7.10 DESCRIPTION OF THE COMMUNICATION TCP/UDP PROTOCOL...............................................................................27
8 COMMUNICATION WITH THE MODULE FROM THE E TERNAL NETWORK...........................28
9 CHECKING THE IP ADDRESS.....................................................................................................................28
10 DHCP................................................................................................................................................................28
11 RESTORING FACTORY DEFAULTS........................................................................................................29
12 FIRMWARE UPDATE..................................................................................................................................29
User manual Nano Relay Output PoE / Nano Relay Output Page 3 of 29
[B02a]

1 Prel m nary nformat on
Before start ng work w th the dev ce, read The User manual and follow the
nstruct ons conta ned there n!
Description of visual symbols used in this user manual:
This symbol is responsible for reviewing the appropriate place in the
user instructions, warnings and important information. Failure to
follow warnings could cause injury or damage to the device
Important information and guidelines
Following this guidelines makes the use of the device easier
Attent on: The screenshots in this manual can be dissimilar from actual images at
the time of the device purchase. Due to continuous development of the devices software,
some of the functions may differ from these in the manual. The manufacturer claims no
responsibility for any undesirable effects (misunderstanding) caused by changes of
the software.
User manual Nano Relay Output PoE / Nano Relay Output Page 4 of 29
[B02a]

2 Appl cat on of the dev ce
The Nano Relay Output device is used to control one electrical circuit using relay.
The relay can be controlled using www website, network protocols (HTTP GET,
Modbus TCP, SNMP, MQTT) TCP frame or software supplied by manufacturer.
3 Warranty and l ab l ty of the manufacturer
The manufacturer provides a 2-year warranty on the device. The manufacturer also
provides post-warranty service for 10 years from the date of the introducing the device
on the market. The warranty covers all defects in material and workmanship.
The manufacturer undertakes to comply with the contract of guarantee, if the following
conditions are met:
all repairs, alterations, extensions and device calibrations are performed by the
manufacturer or authorized service,
supply network installation meets applicable standards in this regard,
the device is operated in accordance with the recommendations outlined in this
manual,
the device is used as intended.
The manufacturer assumes no responsibility for consequences resulting from improper
installation, improper use of the device, not following this manual and the repairs of the
device by individuals without permission.
Th s dev ce doesn’t conta n serv ceable parts.
User manual Nano Relay Output PoE / Nano Relay Output Page 5 of 29
[B02a]

4 Safety gu del nes
The device has been designed and built using modern electronic components, according
to the latest trends in the global electronics. In particular, much emphasis was placed on
ensuring optimum safety and reliability of control. The device has a housing with a high-
quality plastic.
4.1 Storage, work and transport conditions
The device has to be stored in enclosed rooms which are free of caustic vapors and
substances and also meet the requirements:
surrounding temperature from -30°C to +60°C,
humidity from 2 to 90%,
atmospheric pressure from 700 to 1060hPa.
The device working conditions:
surrounding temperature from -10°C to + °C,
relative humidity from 30% to 7 %,
atmospheric pressure from 700 to 1060hPa.
Recommended transport conditions:
surrounding temperature from -40°C to +8 °C,
relative humidity from % to 9 %,
atmospheric pressure from 700 to 1060hPa.
4.2 Installation and use of the device
The dev ce should be used follow ng the gu del nes shown n next part of the
user manual.
4.3 Decommissioning of the device
When it becomes necessary to recycle the device (for instance, to decommission the
device from service), please contact the manufacturer or its representative, who are
obliged to respond, appropriately, i.e. collecting the device from the user. You can also
ask the companies involved in recycling of electrical or computer equipment. Under no
circumstances should you place the device along with other waste material.
User manual Nano Relay Output PoE / Nano Relay Output Page 6 of 29
[B02a]

5 Construct on of the dev ce
5.1 ano Relay Output PoE
Techn cal data:
Power supply::
PoE: 33- 7V POE IEEE 802.3af
DC: 10-24VDC (screw terminals 3, mm)
Power consumption: max 1, W
Outputs:
1 output: Output type: relay NO
Max current: 1A @ 30VDC
Engage time: 10ms,
Disengage time: ms,
Communication:
1 port Ethernet: 10Mbps
PoE IEEE 802.3af
Housing:
IP Code: 30
Dimensions:
User manual Nano Relay Output PoE / Nano Relay Output Page 7 of 29
[B02a]

General features:
The device has a 7-segment display signaling the current input status (ON or OFF).
There are several ways to communicate with the module:
•using built in WWW server via any web browser,
•Windows / Linux command line programs,
•MODBUS TCP protocol,
•SNMP protocol,
•HTTP protocol,
•MQTT Inveo protocol,
•User application – TCP protocol available for user.
Descr pt on of the module connectors:
•LAN – LAN connection and PoE IEEE 802.3af power supply,
•RESET – switch used to enabling DHCP service, checking the current IP address
and restoring the module to the factory settings.
•OUTPUT – relay connector NO,
•POWER – power connector. An additional power connector used in the event of
a PoE power failure. Supply voltage 10-24VDC.
User manual Nano Relay Output PoE / Nano Relay Output Page 8 of 29
[B02a]

5.2 ano Relay Output
Techn cal data:
Power supply:
The module is adapted to 12-24VDC power supply.
Power is supplied through the PoE adapter.
Outputs:
1 output: Output type: relay NO
Max current: 1A @ 30VDC
Engage time: 10ms,
Disengage time: ms,
Communication:
1 port Ethernet: 10Mbps
passive PoE 12-24VDC power supply
Housing:
IP Code: 30
Dimensions:
User manual Nano Relay Output PoE / Nano Relay Output Page 9 of 29
[B02a]

General features:
The device has two LEDs. LEDs indicate power supply and input status.
There are several ways to communicate with the module:
•using built in WWW server via any web browser,
•Windows / Linux command line programs,
•MODBUS TCP protocol,
•SNMP protocol,
•HTTP protocol,
•MQTT Inveo protocol,
•User application – TCP protocol available for user.
Descr pt on of the module connectors:
•LAN – LAN network and Passive PoE power supply,
•RESET – switch used to enabling DHCP service and restoring the module to the
factory settings,
•OUTPUT – relay connector NO.
User manual Nano Relay Output PoE / Nano Relay Output Page 10 of 29
[B02a]

6 Conf gurat on of the dev ce
The device when used for first time needs to be configured.
There are two methods to do so. The network configuration can be easily changed by
Inveo “Discoverer” (https://inveo.com.pl/software/) software:
6.1 Changing the device's IP address by Discoverer application.
When the “Discoverer” is opened and the relevant device is found, choose Interface list
box and click on Change IP button.
In a new opened dialog box, settings such
as IP address, MASK, GATEWAY, DNS1/DNS2
and the Host name can be changed.
Please save correct settings by choosing
Change button.
If Remote Conf g is disabled (enabled by default), it is necessary to configure
the device by changing the computer's subnet (chapter 6.2).
To enable the remote configuration it is necessary to enter Adm n strat on tab
and mark Enable Remote Network Conf g.
Save the setup by selecting Save Conf g button.
User manual Nano Relay Output PoE / Nano Relay Output Page 11 of 29
[B02a]

6.2 Changing the PC's subnet address, for the device configuration
After the device is connected to a network, a subnet address of a PC which is connected
to the same network has to be changed.
To do so, go to the PC's MS Windows network configuration: Start->Control panel
->Network and Sharing Center->Network and Internet->Network Connections, choose
the related controller and right click on „Properties”.
After selecting this option configuration window will show up:
Next choose "Internet Protocol (TCP/IP)", double click on it and enter following settings:
After saving changes by clicking OK, open an Internet browser and enter in the browser's
address line: 192.168.111.15.
Default user name/password: admin/admin00
User manual Nano Relay Output PoE / Nano Relay Output Page 12 of 29
[B02a]
Chang ng network sett ngs n MS WINDOWS
Illustrat ve TCP/IP protocol sett ngs

In the etwork tab it is possible to change LAN parameters.
To change the network settings, use the following fields:
•Host ame – NETBIOS name,
•DHCP – checking this box forces use of the address assigned by the DHCP server,
•IP Address – the IP address of the reader,
•Gateway – network gateway,
•Subnet Mask – IP subnet mask,
•D S1, D S2 – DNS servers addresses.
•Dest nat on IP – the IP address of the server or of the external device
in the M2M connection (chapter 7.3),
•Dest nat on Port – the listening port of the server or of the external device
in the M2M connection.
After all changes, select Save Conf g.
User manual Nano Relay Output PoE / Nano Relay Output Page 13 of 29
[B02a]

6.3 Security settings and administration
The Administration settings allow for changing access password and to enable/disable
particular services in the device.
Password change
To change password, in the Current Password field write a current password. Next,
in the New Password field write your new password and confirm it at Re-type
Password field.
Serv ce sett ngs
The device allows to choose which services are to be available. Selecting the check box
next to the service name activates the selected service.
Enable Program Access – a service of access by a computer program (Windows, Linux)
and TCP / IP protocol operating on port 9761,
Enable MODBUS TCP Protocol – enables Modbus TCP server,
Enable SNMP – enables SNMP protocol supporting,
Enable Dest nat on Cl ent – connecting to a remote host service (chapter 7.2),
Enable MQTT Inveo – a service that sends data to the INVEO MQTT cloud,
Enable Remote Network Conf g – remote configuration (via the Discoverer
application),
Enable TFTP Bootloader – enables a bootloader.
Attent on:
TFTP Bootloader and Remote Network Conf g ought to be disabled during normal
work operation. It should be enabled for a firmware update only.
User manual Nano Relay Output PoE / Nano Relay Output Page 14 of 29
[B02a]

7 The dev ce funct ons
7.1 Output control
The basic function of the Nano Relay Output module is to control the relay output.
The Home tab shows the current state of the output channel and the current status of
the relay.
Current status of the output channel. The output is switched on or off by
clicking on the icon.
Current state of the relay output.
7.2 Configuration of the output channel
The user can configure the output channel settings of the device. Settings can be
customized in the Channel tab.
Power on state determines the output status after switching on the power supply.
•ON – after powering the device, the output channel is active,
•OFF – after powering the device, the output channel is inactive,
•LAST – after powering the device, the output channel takes the last state before
turning off the power.
Invert field activates the inversion of the relay contact.
User manual Nano Relay Output PoE / Nano Relay Output Page 15 of 29
[B02a]

Output mode
The relay built into the device can work in 3 modes:
B stable mode – a relay has one determined status (is engaged or disengaged),
Astable mode – if the channel will be enabled, the relay is engage and disengage
cyclically. Time of engage and disengage relay:
- T me On – time when a relay is engaged,
- T me Off – time when a relay is disengaged.
T meBased mode – one pulse mode.
oIn T meBased mode, if ton>0 and toff>0, after triggering the output,
the relay will stay disengaged for toff and then it will engage for ton.
oIn T meBased mode, if ton >0 and toff=0, after triggering the output,
the relay will engage for ton and after that it will disengage.
oIn T meBased mode, if ton=0 and toff>0, after triggering the output,
the relay will stay disengaged for toff and then it will engage.
User manual Nano Relay Output PoE / Nano Relay Output Page 16 of 29
[B02a]
t
off
t
on
t
on
t
on
t
off
t
on
t
off
t
on
t
off
t
on
t
off

7.3 Destination Client (M2M)
Inveo dev ces as LanTick, Nano Temperature Sensor, Nano Digital Input, Nano Relay
Output or others are able to send nformat on data to the server or to another
module w th outputs using the TCP or UDP protocol. It means that this another module
can react to activation of channel or when alarm occurs (Nano Sensors).
The message is sent each time state is changed and additionally every seconds.
Conf gurat on of dev ces rece v ng messages (external dev ces)
To enable the service, enter the Administration tab and select Enable Program
Access and confirm with the Save Conf g button.
Conf gurat on of dev ces send ng alarm status messages
To enable the service, enter the Administration tab and select Enable Dest nat on
Cl ent and confirm with the Save Conf g button.
In the etwork tab, fill in the Dest nat on IP and Dest nat on Port fields.
The Dest nat on IP field is an IP address of the external device or server.
The Dest nat on Port field is a port number of the external device (9731 by default).
User manual Nano Relay Output PoE / Nano Relay Output Page 17 of 29
[B02a]

Then, in the Channel tab select the appropriate output which will be enabled in the
external device or – select type of the message.
The user can choose the following fields:
•TCP Ch:x – the function uses the connect on protocol i.e. the TCP protocol.
Number Ch:x is selected output channel in an external device, e.g. LanTick, which
will be enabled when the channel state of the local device changes. The TCP frame
sends in the format #1,
•UDP Ch:x – the function uses the connect onless protocol i.e. the UDP
protocol. Number Ch:x is selected output channel in an external device, e.g.
LanTick, which will be enabled when the channel state of the local device changes.
The UDP frame sends in the format #1,
•Status – sends the device channel status, TCP frame sent in the format #2,
•MAC+Status – sends the MAC address of the device and current channel status,
TCP frame sent in the format #3,
•HTTP GET – sends the MAC address of the device and current channel status,
frame sent in the format #4.
User manual Nano Relay Output PoE / Nano Relay Output Page 18 of 29
[B02a]

Frame formats:
Format #1
The frame in the #1 is sent in binary form.
Active outputput and set Ch:5
SOF CMD CH F_ID OUT !OUT R1 R2 R3 R4 CRC
0x0F 0x01 0x04 0xFF 0x01 0xFE 0x00 0x00 0x00 0x00 0x7F
Inactive output and set Ch:5
SOF CMD CH F_ID OUT !OUT R1 R2 R3 R4 CRC
0x0F 0x01 0x04 0xFF 0x00 0xFF 0x00 0x00 0x00 0x00 0x7F
CRC:
CRC = (SOF+CMD+CH+F_ID+OUT+!OUT+R1+R2+R3+R4) MOD 2 6
Format #2
The frame in the #2 format is sent as a string.
<Output state>
•Output state – value 1 means active output, 0 means inactive output
HEX value STRING
30 0
Format #3
The frame in the #3 format is sent as a string.
<MAC>[SPACJA]<Output state>
•MAC – MAC address
•Output state – value 1 means active output, 0 means inactive output
HEX value STRING
3 34 31 30 4 43 36 3 3 30 32 31 20 30 410EC6 021 0
User manual Nano Relay Output PoE / Nano Relay Output Page 19 of 29
[B02a]

Format #4
Setting Client Mode to HTTP GET causes that the device sends data to the server in the
form:
nano.php?mac=<MAC>&io=<Output state>
•MAC – MAC address
•Output state – value 1 means active output, 0 means inactive output
An example of a frame received by the server:
GET /nano.php?mac=123456789012&io=1
address MAC = 1234 6789012,
io=1, the output is enabled
The TCP frame can be handled w th your own software.
An example of using the netcat command for Linux:
Format #1
Format #2
Format #3
User manual Nano Relay Output PoE / Nano Relay Output Page 20 of 29
[B02a]
