InWin 915 User manual
Lighting Instruction Manual
Lighting Modes
The 915 will automatically display the lighting effects in the front panel for 10 seconds when
computer turns on, then will lead users into two lighting modes. (The lighting modes depend
on the features of the motherboard.) This allows users to switch between:
1.InWin LED (Default Mode)
The InWin LED mode comes with 13 distinct lighting effects. If your motherboard doesn’t feature
addressable headers, the lighting will be placed on InWin LED mode. In this mode, you can still
switch to different colors such as: red, green, blue, white and multicolor to your personal preference,
and display 13 distinctive lighting effects with a variety of luminous styles.
Installation Guide
2.Addressable RGB
If your motherboard supports addressable RGB headers, please connect the 3-pin addressable cable
directly to the motherboard (refer to the following step), it allows you to sync the addressable lighting
effects with motherboard.
Addressable RGB Light Bar Operation Instructions
If your motherboard support the addressable RGB luminous eect, please follow the direction of sign and
insert addressable RGB-strip into the 3-pin addressable RGB-strip header directly on the motherboard.
Other Addressable Light
+5V
DATA
key
GND
+5V
DATA
key
GND
+5V
DATA
key
GND
+5V
DATA
key
GND
MotherBoard
Addressable
1.The lighting effects are controlled by pressing the Top Cover Ventilation & LED Lighting
Control button. To switch between InWin LED mode and Addressable RGB, just simply hold
the button for 2 seconds. (Note* The top cover ventilation control and system failure
indicator will be temporarily unavailable.)
2.When switching from Addressable RGB to the InWin LED mode, it also can shift to different
LED lighting effects by a quick press of the button, the button sequence is as follows:
Button Presses LED Modes Color
1
Breathing
Red
2 Green
3 Blue
4 White*
5
Double-Sided
Scrolling
Red
6Green
7 Blue
8 White*
9
Middle
Scrolling
Red
10 Green
11 Blue
12 White*
13 Multicolor Multicolor
To turn off the lights directly, just hold the button for 5 seconds.
* The white featured in the InWin LED mode will be displayed as RGB white instead of pure white.
3. The operation will be considered complete if there is no activity for 6.5 seconds.
4. Once the setup has completed, the features of top cover ventilation control and system
failure indicator will resume normal operation.
* The current settings of lighting effect will be saved if you turn off the computer in the proper way. You can have your
previous lighting settings automatically when reboot the computer. But it will return to factory settings if your computer
is in a power off condition such as: the electricity goes out suddenly, or turning off the power switch before the computer
shutting down.
Lighting Control
1. WhenthesystemfailureindicatorLEDisashingonbothsides,pleasecheckforany
of the following occurrences:
If an error occurred, please press the top cover ventilation switch to reopen the cover after
troubleshooting.
2.If the elevating ventilation cover isn’t lifting up/down automatically when computer turns on/
off, please refer to step 1 to check if there are any problems, then press the top cover ventilation
switch to control the lifting system manually. Please do not press or pull out the top cover by
force.
3.If the power goes off, the top cover will lift down after the power supply is restored. Please press
the top cover ventilation switch to reset the lifting system.
System Failure
Indicator Color Occurrence Description
Flashing on
Both Sides
Red
A Malfunction of the
Motor or the Top
Cover
The motor stops running, or the
top cover isn’t installed properly.
Green A Malfunction of the
Switch or the Wires
The limit switch or the internal
wires are broken or damaged.
Blue Stuck with a Foreign
Object
Insufcientspacefortopcover
lift, or the top cover is stuck due
to a foreign object.
White Overweight Do not stack anything on the top
cover to avoid any damages.
Troubleshooting
