InWin B1 User manual

User Manual

Product Story
The B1’s extremely small footprint is perfect for
small form factor builds such as HTPCs, light
gaming PCs or even a LAN rig. The integrated
ventilation in the exquisite streamline design
provides a better thermal solution, and you
can set up your PC vertically or horizontally!
The B1 comes with prebuilt InWin 200W, 80 PLUS
Gold PSU, InWin 80mm fan and an anti-dust filter.
Use the B1 to match your lifestyle!

Specifications
Model Number
Colors
Case Type
Case Materials
M/B Compatibility
Expansion Slots
Maximum Compatibility
Front Ports
Internal Drive Bays
Thermal Solution
Compatibility
Power Supply
Compatibility
AC Input/Efficient
Product Dimensions
(H x W x D)
Package Dimensions
(H x W x D)
Net Weight
Gross Weight
IW-CS-B1BLK-PS200W
Black
Mini ITX Tower
Tempered Glass, ABS
Mini-ITX
N/A
CPU Heatsink Height: 60mm (Max)
1 x USB 3.0
HD Audio (CTIA ‒ SPK/Mic)
2 x 2.5"
1 x 80mm Side Fan ( Included)
InWin 200W PSU Included
AC Input: 100 - 240V / 80 PLUS Gold
108 x 302 x 238mm
4.3" x 11.9" x 9.4"
141 x 336 x 287 mm
5.6" x 13.2" x 11.3"
1.9 KG/ 4.2 lb
2.2 KG/ 4.9 lb
Model B1
■ InWin products comply with RoHS regulations.
■Specifications may vary based on different regions.

Specifications
InWin 200W 80PLUS GOLD PSU
Total Power
Material
Type
PFC
Efficiency
MTBF (Hours)
AC Input
Operating Temperature
Range(°C)
Full Protection
Safety Certifications
Dimensions
(L x W x H)
Warranty
Connectors
200W
SECC
ITX
Active PFC
80 PLUS Gold
> 100,000
100 ‒ 240Vac. 50-60Hz
0~40°C
OVP/UVP/SCP/OPP
TUV/cTUVus/BSMI/CB/CE/FCC/
EAC/RCM/CCC
52 x 40 x 170 mm
2.05" x 1.6" x 6.7"
3 Years
Motherboard 24-pin
CPU 4+4-pin
PCIE 6+2-pin
Peripherals
SATA
Floppy Power
Model IP-AD200C7-2
■ InWin products comply with RoHS regulations.
■ Specifications may vary based on different regions.
1
1
0
0
1
0

Specifications
InWin 80mm Side Fans
Fan Size
Materials
Rated Voltage
Rated Power
Rated Current
Speed Mode
Air Flow
Air Pressure
Connector
Noise Level
Bearing Type
Life Expectancy
80 x 80 x 15mm
PBT
DC 12V
2.16W
0.18A
PWM 600-2500 RPM
24.09 CFM
1.08mm/ H2O
4-Pin
23.55dB(A)
Long Lifespan Sleeve Bearing
>30,000 hrs.
Model DF0801512SELN
■ InWin products comply with RoHS regulations.
■Specifications may vary based on different regions.

Package Contents
1.B1 Chassis
2.InWin 200W
80 PLUS Gold PSU
3.InWin 80mm Side fan x 1
4.QR Code Card
5.Accessories Bag
1
2
3
4
5

Accessories Bag
b. 2.5” HDD Screws X 10
a. Hexagon Head Screws X 8
c. Cable Ties X 5
d. Foot-Stand Stickers X 4
a
c
d
b

Case Structure
1. Tempered Glass
2. Logo
3. Power Button
4. HDD/Power LED indicator
5. USB 3.0 Ports
6. HD Audio Port (CTIA ‒ SPK/Mic)
7. Removable Foot-stand
8. Release Panel
1
2
3
4
5
6
78

Case Structure
1. 2.5” Drive Bay
2. InWin 80mm Side Fan
3. Motherboard Mounting Area
4. InWin 200W 80 PLUS Gold PSU
5. Fan Dust Filter
1
2
3
4
5

Installation Guide
(Please follow the related chapters to assemble)
Opening the Chassis
Please release the two screws and
lift up the top cover.
01
Motherboard
Installation
Parts Required: Hexagon Head
Screws.
02

Switch/LED Connector
Black(P_LED) 1
Black(P_LED) 3
Black(P_SW) 5
Black(P_SW) 7
Key 9
2 Black (HDD)
4 Black (HDD)
6 NC
8 NC
10 NC
I/O Wires Installation
03

2.5” Drive Bays Installation
04
Parts Required: 2.5” HDD Screws
i.Release the two screws
and remove the bottom
cover.
ii.Install the 2.5’’ HDD screws
on your SSD screw holes.
iii.Attach the SDD in the
designated area and push
towards the SATA direction.

2.5” Drive Bays Installation
04
How to Uninstall the 2.5” Drive Bays
ii.Pull towards the direction
to release it.
i.Push the panel

Foot-Stand Stickers Installation (Optional)
05
Note: After installed, the stickers will be hard to remove. Please
use wisely, we suggest using the chassis on vertical position for
a better look.
Parts Required: Foot-stand Stickers
i.Release the two screws
and remove the bottom cover.
ii.Release the screws of the
foot-stand and detach the
foot-stand.
iii.Place the stickers on each
designated area.

Completing Installation
06
Parts Required: Cable Ties
*For more installation instructions, please scan the QR Code
or watch the video in the website link
https://youtu.be/cHm2nA2liQY

■ Notices
1. Please follow the user manual for installation guidelines.
2. When installing the computer components, please use
antistatic precautions to prevent ESD (electrostatic discharge)
damage. Failure to take the necessary precautions may result
in injury to the installer and/or damage to the machine.
Incorrect installation may burnout the motherboard and other
system components.
3. To avoid any damages, please do not use this product for any
other purpose than its intended use.
4. Any modifications may damage the product.
5. Please handle with care when moving the case.
6. When storing the case, please keep this product away from
high temperatures. Keep away from machines such as heaters
that might cause high temperatures.
7. Please do not put anything in the impeller.
8. Please do not touch the fan blades when the fan is in operation.
Please only use your fan in the computer case..
■ Warranty
* For more detailed warranty information, please visit the
InWin retail website at www.in-win.com.
* The actual product is subject to change without prior
notice. InWin Development Inc. reserves the right to
make final modifications.
Notices and Warranty

Copyright © 2020 InWin Development Inc. All Rights Reserved.
