InWin P Series User manual

User Manual

Product Story
The P Series is an 80 PLUS® Gold
certified power supply that focuses
its features on efficiency, reliability
and overall PC building experience.
The P Series’ low noise output makes
this PSU the optimal choice for most
PC builds.

1. 80 PLUS® Gold Certified for High
Efficiency
2. Ultra Quiet Zero RPM Fan Mode
3. 5V and 3.3V DC to DC Design
4. Highly Reliable Japanese
Aluminum Electrolytic Capacitors
5. Multi-Protection Safeguards (OCP,
OVP, UVP, SCP, OTP, OPP)
6. Fully Modular Cables for Quick and
Easy Installation
7. 5-Year Warranty
Features

Specications
* InWin products comply with RoHS regulations.
* Speci󽗉cations may vary based on di󽗈erent regions.
Model AC INPUT 100-240Vac.,10A, 50-60Hz
DC OUTPUT +12V +5V +3.3V -12V +5VSB Total Power
P65 Max. Output Current 54.2A 22A 22A 0.3A 3A 650W
Max. Combined Power 650W 120W 3.6W 15W
P75 Max. Output Current 62.5A 22A 22A 0.3A 3A 750W
Max. Combined Power 750W 120W 3.6W 15W
P85 Max. Output Current 70.9A 22A 22A 0.3A 3A 850W
Max. Combined Power 850W 120W 3.6W 15W
Model P65 P75 P85
Model Number IW-PS-P650W IW-PS-P750W IW-PS-P850W
Total Power 650W 750W 850W
Material SECC
Type ATX12V V2.4 / EPS12V V2.92
Cable Management Fully Modular
PFC Active PFC (> 0.95)
Eciency 80 PLUS®Gold (Up to 90%)
MTBF (Hours) > 100,000 hrs.
AC Input 100-240Vac.,10A, 50-60Hz
Fan 135mm FDB Fan
Typical Load Fan Noise(dBA)
(50% Loading) < 25dBA
Operating Temperature Range (°C) 0~40 °C
Full Protection OCP/ OVP/ UVP/ SCP/ OTP/ OPP
Safety Certications cTUVus/ TUV/ CB/ BSMI/ CE/ FCC/ EAC/ CCC/ RCM
Dimensions (L x W x H) 160 x 150 x 86mm
Package Dimensions
(L x W x H) 210 x 325 x 100mm
Net Weight 2.35kg 2.46kg 2.64kg
Gross Weight 2.81kg 2.92kg 3.12kg
Warranty 5 Years
Connector
20+4 Pin Motherboard 1 1 1
8 (4+4) Pin CPU 122
8 (6+2) Pin PCI-E 446
4 Pin Peripheral 444
SATA (90 Degree) 9 12 12
Floppy
111

Package Contents
QR Code Card x1
Modular Cables Box x1
P Series Power Supply Unit x1
(P65/ P75/ P85)

Modularized
Cables Box
X8
Cable TiesPower Cord Mounting Screws
X4
X1
SATA (90 Degree)
Connector
Floppy Connector
8 (6+2) Pin PCI-E
Connector
4 Pin Peripheral
Connector
20+4 Pin Motherboard
Connector
8 (4+4) Pin CPU
Connector
X1
P85X3
P75X2
P65X2
X1
X1
X1
X3 X3
P65
P85 P75
P85 P75
P65X1

Cable Information
650mm
600mm
100mm
550mm
100mm100mm100mm
550mm
100mm100mm
550mm
100mm
150mm
650mm
100mm
650mm
8 (4+4) Pin CPU P65
20+4 Pin Motherboard
8 (4+4) Pin CPU P75/P85
SATA (90 Degree) P75/P85
8 (6+2) Pin PCI-E
4 Pin Peripheral
SATA (90 Degree) P65
Floppy

1.Make sure the power supply's AC
power cable is not connected
before installation.
2.Place the power supply unit into
the space provided in the case and
secure the power supply unit with
the screws.
3.Connect 24-pin power to the 24-pin
socket on the motherboard.
4.Connect the 8-pin +12V cable to
the motherboard.
A.If your motherboard has an
8-pin + 12V socket, connect
the 8-pin cable directly to your
motherboard.
B.If your motherboard has a 4-pin
socket, detach the 4-pin from the
8-pin cable, and plug the 4-pin
cable directly to your
motherboard.
Installation

5.Connect the peripheral cables, PCI-
Express cables, and the SATA
cables to the appropriate socket.
6.Make sure all the cables are tightly
connected and save any unused
modular cables for future usage.
7.Connect the AC power cord to
the power supply and turn it on by
switching the power button to the
"I" position.
Installation

These troubleshooting points will help
you diagnose and solve problems
with your power supply if the unit fails
to operate properly:
1.Please make sure the power supply
and power cord are connected
properly.
2.Please make sure the power cord is
plugged into the power socket.
3.Please make sure the power supply
I/O button is switched to the "I"
position.
4.Please check if all the connectors
(motherboard and peripheral) are
connected properly.
5.Please allow a 5-second interval
before turning the power on again
when power supply is switched off
manually.
6.If you are still experiencing
difficulties, please contact your
local distributor for RMA support.
Troubleshooting

■ Notices
1.Please use the anti-static precautions
while installing the components to
prevent damage and injury.
2.Install in accordance with the user
manual’s instructions and safety
warnings.
3.High voltages are present in the
power supply. Do not open the
power supply case. Any modifications
may damage the product and may
place the user at risk.
4.Do not use the power supply if it has
been wet or damaged to avoid
electric shock or injury.
5.Do not install the power supply near
any heat sources such as: radiators,
heat registers, or other apparatus
that produces heat.
Notices and
Warranty

6.Do not insert any objects into the
open ventilation or fan grill area.
supply.
7.Please use only this product's
exclusively supplied cables. Other
cables may not be compatible and
could cause serious damage to your
system and power supply.
8.Do not modify the cables and/or
connectors included with the power
supply.
Notices and
Warranty

■ Warranty
1.InWin provides a 5-year warranty
toward the product. The warranty
covers malfunctions or flaws before
customer use. The warranty starts
from your initial purchase
(according to the date on your
receipt). Please note that we do not
honor the warranty for the product
if it is not purchased personally
or if it is purchased through an
unauthorized distribution channel.
2.This limited warranty shall not apply
if the defect was caused through
any of the following:
1) Abuse and misuse,
2) Operation outside of product
specification,
3) Unauthorized service or
modification,
4) Any and all alteration of the
product.
Notices and
Warranty

■ Warranty
3.For more detailed warranty
information, please visit the InWin
retail website at www.in-win.com.
4.The actual product is subject to
change without prior notice. In Win
Development Inc. reserves the right
to make final modifications.
Notices and
Warranty
