InWin VE Series User manual

User Manual

Product Story
The VE Series is an 80 PLUS® Gold
certi󽗉ed power supply that meets
PCIe 5.0 requirement and feature a
smart temperature-controlled FDB fan
with a zero RPM mode. The VE Series
fully modular cables make this PSU
an optimal choice for PC builds with
desirably clean cable management.

1. Fully Meets the Newest Generation
(ATX3.0) of Intel’s PSDG
2. Includes PCI-E 5.0, 16 Pin Connector
with High Quality 16 AWG Cable
3. Fully Modular with High Quality Flat
Cables
4. Smart Temperature-Controlled FDB
Fan with Zero RPM Mode
5. Highly Reliable Japanese Aluminium
Electrolytic Capacitors
Features

Speci󽗉cations
* InWin products comply with RoHS regulations.
* Speci󽗉cations may vary based on di󽗈erent regions.
Model DC OUTPUT +12V +5V +3.3V -12V +5VSB Total Power
VE75
AC INPUT 100-240Vac, 10-5A, 50-60Hz
Max. Output Current 62.5A 20A 20A 0.3A 3A
750W
Max. Combined Power 750W 100W 3.6W 15W
VE85
AC INPUT 100-240Vac, 12-6A, 50-60Hz
Max. Output Current 70.8A 20A 20A 0.3A 3A
850W
Max. Combined Power 850W 100W 3.6W 15W
Model VE75 VE85
Model Number IW-PS-VE750W IW-PS-VE850
Total Power 750W 850W
Materials SECC
Type ATX12V V3.0
Cable Management Fully Modular
PFC Active PFC (> 0.95)
E󽗋ciency 80 PLUS® Gold (Up to 90%)
MTBF (Hours) > 100,000 hrs.
AC Input 100-240Vac, 10-5A, 50-60Hz 100-240Vac, 12-6A, 50-60Hz
Fan 135 mm FDB Fan
Typical Load Fan Noise (dBA)
(50% Loading) < 25 dB(A)
Operating Temperature Range (° C) 0 - 40° C
Full Protection OCP / OVP / UVP / SCP / OTP / OPP
Safety Certi󽗉cations CB / TUV / cTUVus / BSMI / RCM / CE / FCC / UKCA
Product Dimensions (L x W x H) 160 x 150 x 86 mm
Package Dimensions (L x W x H) 355 x 210 x 105 mm
Net Weight 1.6 kg 2.8 kg
Gross Weight 1.7 kg 2.9 kg
Warranty
5 Years
Connectors
24 Pin Motherboard 1
8 (4+4) Pin CPU 2
8 (6+2) Pin PCI-E 4
12VHPWR 1
4 Pin Peripheral 3
SATA (90 Degree) 9
Floppy
1

Package Contents
VE Series Power Supply Unit x1
(VE75 / VE85)
Modular Cables box

Power Cord Mounting Screws Cable Ties
24 Pin Motherboard
12VHPWR
8 (4+4) Pin CPU
SATA (90 Degree)
8 (6+2) Pin PCI-E
4 Pin Peripheral & Floppy
VE75X1
VE85X1
VE75X1
VE85X1
VE75X1
VE85X1
VE75X3
VE85X3
VE75X2
VE85X2
VE75X1
VE85X1
X1 X4 X8
Modularized Cables Box

DC Output Cable Model VE75 VE85
24 Pin Motherboard 1 1
8 (4+4) Pin CPU 1 1
8 (6+2) Pin PCI-E 2 2
12VHPWR 1 1
SATA (90 Degree) 3 3
4 Pin Peripheral
1 1
Floppy
Cable Information
600mm
650mm
150mm
500mm
150mm
600mm
150mm 150mm 500mm
150mm
150mm
150mm
500mm

1. Make sure the power supply’s AC
power cable is not connected before
installation.
2. Place the power supply unit into the
space provided in the case and secure
the power supply unit with the
screws.
3. Connect 24 Pin power to the 24 Pin
socket on the motherboard.
4. Connect the 8 (4+4) Pin CPU cable to
the motherboard.
A. If your motherboard has an 8 (4+4)
Pin CPU socket, connect the 8
(4+4) Pin CPU cable directly to your
motherboard.
B. If your motherboard has a 4 Pin
CPU socket, connect the 4 Pin CPU
cable directly to your motherboard.
Installation

5. Connect the PCI-E cable to the
graphics card.
A. Each 6+2 Pin PCI-E cable can
provide up to 150W, and the
MB PCI-E connector will supply an
additional 75W to the graphics
card.
B. If your graphics card supports
PCI-E 5.0 12VHPWR cable, please
connect the PCI-E 5.0 12VHPWR
cable direct to the socket.
While your GPU exceeds 225W，please
connect the 6+2 Pin PCI-E cables as
diagram.
Please use an additional 6+2 Pin PCI-E cable if
your GPU exceeds 225W (150+75).
Installation

6. Connect the peripheral cables, and
the SATA cables to the appropriate
socket.
7. Make sure all the cables are tightly
connected and save any unused
modular cables for future usage.
8. Connect the AC power cord to
the power supply and turn it on by
switching the power button to the
"I"position.
Installation

These troubleshooting points will help
you diagnose and solve problems with
your power supply if the unit fails to
operate properly:
1. Please make sure the power supply
and power cord are connected
properly.
2. Please make sure the power cord is
plugged into the power socket.
3. Please make sure the power supply
I/O button is switched to the
"I" position.
4. Please check if all the connectors
(motherboard and peripheral) are
connected properly.
5. Please allow a 5-second interval before
turning the power on again when
power supply is switched off manually.
6. If you are still experiencing difficulties,
please contact your local distributor
for RMA support.
Troubleshooting

■ Notices
1. Please use the anti-static precautions
while installing the components to
prevent damage and injury.
2. Install in accordance with the user
manual’s instructions and safety
warnings.
3. High voltages are present in the
power supply. Do not open the power
supply case. Any modifications may
damage the product and may place
the user at risk.
4. Do not use the power supply if it has
been wet or damaged to avoid electric
shock or injury.
5. Do not install the power supply near
any heat sources such as: radiators,
heat registers, or other apparatus
that produces heat.
Notices and Warranty

6. Do not insert any objects into the
open ventilation or fan grill area.
7. Please use only this product's
exclusively supplied cables. Other
cables may not be compatible and
could cause serious damage to your
system and power supply.
8. Do not modify the cables and/or
connectors included with the power
supply.
Notices and Warranty

■ Warranty
1. InWin provides a 5-year warranty
toward the product. The warranty
covers malfunctions or flaws before
customer use. The warranty starts
from your initial purchase (according
to the date on your receipt). Please
note that we do not honor the
warranty for the product if it is not
purchased personally or if it is
purchased through an unauthorized
distribution channel.
2. This limited warranty shall not apply
if the defect was caused through any
of the following:
1) Abuse and misuse,
2) Operation outside of product
specification,
3) Unauthorized service or
modification,
4) Any and all alteration of the
product.
Notices and Warranty

■ Warranty
3. For more detailed warranty
information, please visit the InWin
retail website at https://www.in-win.
com/en/warranty
4. The actual product is subject to
change without prior notice.
In Win Development Inc. reserves the
right to make final modifications.
Notices and Warranty

Copyright © 2023 In Win Development Inc. All Rights Reserved.
