IOGear GME224M32 User manual

Read this guide thoroughly and follow the installation and operation procedures
carefully to prevent any damage to the unit and/or any devices it connects to:
This package contains:
• 1 USB Memory Mini Mouse 800
• 1 Carrying Case
• 1 User Manual
• 1 Warranty/Registration Card
© 2004 IOGEAR®. All Rights Reserved.
All brand names and trademarks are the registered
property of their respective owners.
PKG-M0072V1/W1
1. Welcome 2. Features
Congratulations on your new IOGEAR®purchase!
With the advent of optical technology in computer mice, the days of ball-mice
are a thing of the past. Users of ball-mice, or mice that use a rolling ball to
navigate, all share the common frustrations of dirty rollers. When the rollers
become dirty, the mouse begins to skip and jump from location to location.
Since the USB Optical Mini Mouse has no moving parts, dirty rollers are no
longer an issue. The flash drive allows you to take your files on the go without
another disk to carry around.
This mouse is very small and portable; it is designed for the mobile
professionals. It can save you precious space in your mobile work area. The
ergonomic contour design offers comfortable use on most surfaces. This unit
is USB ready, Plug-n-Play and hot pluggable.
Once again, IOGEAR®lays the standard for connectivity!
For general troubleshooting information, FAQ, and other related documents in
our T.I.L. (Technical Information Library), we encourage you to check out our
web site -- http://www.iogear.com
Contact Information:
23 Hubble Drive Irvine, CA 92618
(P) 949.453.8782 (F) 949.453.8785
www.iogear.com
• Comes with built-in flash drive to store PowerPoint presentations, MP3s,
photos, files and more
• Take your files on the go without another disk to carry around
• Much sturdier than a CD-Rom or floppy disk, don’t worry about losing your
data due to a disk braking or getting scratched in your bag or pocket
• 800 dpi resolution for precision cursor movement and sensitivity
• Self-retracting cable reduces clutter and makes it easy to store and transport
• Light and very portable, suitable for mobile professionals
• Operates on virtually every surface
• Ergonomically contoured design for comfortable use
• USB ready
• Plug-n-Play and hot pluggable
• 3 Year Limited Warranty
• Carrying case included
4. Other IOGEAR®Products
4-D Web Cruiser™ (GME421)
Phaser-RF Wireless Mouse (GME322R)
Hi-Speed USB 2.0 A to B Cable (G2LUAB06)
Hi-Speed USB 2.0 PCI Card (GIC220U)
Hi-Speed USB 2.0 PCMCIA CardBus Card (GPU202)
USB KVMP Switch (GCS1732/GCS1734)
5. Pictorial Introduction
1. Scroll Wheel
2. Left Click Button
3. Right Click Button
4. Optical Sensor
4
3
1
2
6. Installation Instruction
Note:
To properly retract the mouse cable, carefully pull both ends of the cable.
Windows®
1. Turn on your computer, and let it boot all the way into your Operating
System.
2. Insert the USB Optical Mini Mouse's USB connector into your computer's
USB port. You will see a dialog box, showing the computer has detected a
new device.
3. After a few moments, the light in your mouse will begin to flicker. This
is completely normal, and should only last a few seconds.
4. Then, your mouse will begin to function as a normal mouse. This may take
longer, depending on your computer's speed, amount of memory, and
operating system.
Mac
This mouse is Plug-n-Play for Macs. Just plug it in, you will be able to use it
immediately.
For Windows®98/98SE, you will need to download the driver from the IOGEAR®
web site. After you install the driver, you will be able to see the Removable drive
from My Computer screen.
Windows®
For any special needs on mouse set up, go to My Computer/Control Panel
and select mouse.
Button Configuration
Here you may set the mouse to your hand's preference. If you are left-handed or
right-handed, you can set the mouse to accommodate your clicking preference.
Ex. A left-handed mouse commonly has the right-mouse-button as the primary
button and the left-mouse-button is commonly the option button.
Pointers Tab
This tab is an extension of your Microsoft®Windows®Desktop schemes.You
may choose different schemes for your mouse icons here.
Pointer Shadow will leave a dark shadow over the desktop, to dramatize the
presence of the mouse pointer.
The flash drive is Plug-N-Play for Mac OS X. After you install the mouse, you will
be able to see the flash drive immediately.
Mac
Mouse system Preferences
In the mouse preferences you can adjust the tracking, scrolling and double
click speed.
8. Specifications
Function
Specification
Connectors USB Type A
Dimensions
1.5"
Power Source
USB Specification
Weight
3.5"
1.75"
USB Bus powered
USB 1.1
0.1 Lb
Specification
Height
Length
Width
Housing Case Plastic
Unit Wt.
GME224M32W1 User Manual
3. Requirements
• Windows98®*, 98SE*, 2000, ME, XP
• Mac OS X or later
(For Mac 9.x or earlier, it works only as a one button mouse)
• Available USB port
*For Windows®98/98SE, please download the driver from IOGEAR®
website: http://www.iogear.com
7. Operation
Flash Drive
For Windows®ME/2000/XP, it is Plug-n-Play for the flash drive. After you install the
mouse, go to My Computer, you will be able to see the drive immediately:
Windows®
9. Radio & TV Interference Statement 10. Limited Warranty
IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK
OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT.
The direct vendor makes no warranty or representation, expressed, implied, or
statutory with respect to the contents or use of this documentation, and
especially disclaims its quality, performance, merchantability, or fitness for any
particular purpose.
The direct vendor also reserves the right to, but not limited to, revise or update
the device or documentation without obligation to notify any individual or entity of
such revisions, or updates. For further inquires please contact your direct vendor.
WARNING!!! This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual,
may cause interference to radio communications. This equipment has been
tested and found to comply within the limits for a class B device, pursuant to
Subpart J of Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a commercial environment.
Operation of this equipment is a residential area is likely to cause interference, in
which case the user at his own expense will be required to take whatever
measures may be required to correct the interference. There is no guarantee that
radio frequency interference will not be created in particular locations.
IOGEAR®is not responsible for any radio or television interference caused by
unauthorized modification of your mechanism or cables.
