IOGear GWHDRX01 User manual

Quick Start Guide
GWHDRX01
PART NO. Q1286-a
www.iogear.com
Long Range Wireless 5x2 HDMI
Matrix PRO Receiver

1
Package Contents
System Requirements
1 x Long Range Wireless 5x2 HDMI Matrix PRO Receiver
1 x Remote Control
1 x HDMI Cable
1 x IR Extension Cable
1 x Power Adapter
2 x AAA Batteries
1 x Quick Start Guide
1 x Warranty Card
Long Range Wireless 5x2 HDMI Matrix PRO (Part# GWHDMS52MB)
Display:
• HDTV
Media Source:
• HDMI Output

2
Overview
Front View
1. Power Button with LED Indicator
Press to turn the receiver
ON / OFF. The LED indicator
lights green when powered
on and lights red when in
Standby Mode.
2. Source Button
Press for Source device
input selection.
3. Video status LED
For video input status
indication.
4. Wireless Signal status LED
For wireless link status
indication.
Back View
1. Power Adapter DC IN
Connect to receiver’s power
adapter.
2. HDMI OUT
Connects the Receiver to an
HDTV via an HDMI cable.
3. IR IN
Available to connect IR sensor
extender cable.
1
2
3
4
1 2 3

3
Hardware Installation
Step 1: Setup the Receiver
1. Connect the Receiver Power Adapter into the Mini USB power jack.
2. Connect an HDMI cable to the HDMI OUT port on the Receiver to an
HDMI IN port on the HDTV or HD Projector.
3. Connect the IR Sensor Extender cable to the IR IN port on the back
of the Receiver.
1
2
3
HD Projector or HDTV

4
Step 2: Setup the IR sensor extender cable
The IR relays infrared commands from your remote control to your
device. Users can control their A/V devices by pointing their remote
control to the receiver or IR sensor extender cable. (IR distance from
remote to receiver / IR sensor cable is 30 feet line of sight.)
1. Place the wireless receiver out of sight and use the IR sensor
extender to control your devices with the remote control.
2. Plug the IR sensor extender cable into the IR IN jack on the receiver
and place the sensor on the front of the TV for convenient operation.
HDMI

5
Step 3: Mounting the Receiver to a Wall (Optional)
1. Refer to the drawing at the right that
has a relative position of the main
holes that will be needed to be drilled
into the wall.
2. Drill two 1/4” pilot holes.
3. Insert the supplied two Anchors
into the wall. If necessary, use
a small hammer to lightly tap
the anchors flush to the wall.
4. Insert two screws into the
anchors. Leave 1/4” length for
mounting the Transmitter, 5/8”
for the Receiver.
5. Place receiver main holes over
the protruding screws and slide
down into position.
1.8”

6
Advanced Operation
Pairing an additional receiver to the existing Transmitter
Enter Pairing Mode for the Transmitter:
1. Unplug the power adapter from the Transmitter.
2. Press and hold down the Power button on the Transmitter.
3. Plug the power adapter back into the Transmitter.
4. Keep pressing down on the Power
button until the LED indicator begin
flashing orange, indicating that the
Transmitter has entered into
Pairing Mode.
2
3
4

7
Enter Pairing Mode for the Receiver:
1. Unplug the power adapter from the Receiver.
2. Press and hold down the Power button on the Receiver.
3. Plug the power adapter back into the Receiver.
4. Keep pressing down on the Power button until the LED indicator
begins flashing orange, indicating that the Receiver has entered
into Pairing Mode.
5. Once the Receiver enters pairing mode, the On Screen Display
will show:
6. The Transmitter and Receiver will pair automatically. Once the
pairing process is completed, the Transmitter and Receiver will
reboot and link to each other automatically.
Note: This process MUST be repeated for every addtional receiver. A
total of THREE (3) additional receivers can be paired to the Transmitter.
Searching...
Adding GWHDMS52MB
2
3
4
