IOGear GWMHDRX User manual

Expandable Wireless TV
Connection Receiver
Quick Start Guide
GWMHDRX
PART NO. Q1558
www.iogear.com

1
Package Contents
System Requirements
1 x HDMI Extender Receiver
1 x 3 ft. HDMI cable
1 x IR Extender Cable
1 x 5 VDC/2A Switching Power Supply
1 x Quick Start Guide
1 x Warranty Card
• 1 HDMI display device (SDTV, HDTV, projector with HDMI port, etc.)
• IOGEAR Expandable Wireless TV Connection Kit GWMHDKIT22
or GWMRHDKIT

2
Overview
D. Power input
E. Data transmission indicator
F. Wireless connection indicator
G. HDMI output connector
H. IR receiver extender cable connector
I. Antenna connector
A. Input Channel indicator
B. Channel selector button
C. IR remote control window
Receiver Back
Receiver Front
D
G
H
EF
I
AB
C

3
Hardware Installation
Please read safety instructions carefully before installation and operation:
1. Please pay attention to all the warnings and hints for this device.
2. Do not expose this unit to rain, moisture or liquid.
3. Do not insert any foreign object into the device.
4. Opening the enclosure will void the warranty.
5. Place the device in a well ventilated area.
6. Use DC5V/2A power adapter only. Make sure the specification
matched if using 3rd party DC adapters.
Note:
1) Transmission distance will vary due to the environment.
2) Obstructions such as wall, brick or glass will shorten the signal
cover range or cause signal degradation.
3) It is recommended that the distance between each unit should
be more than 15 feet.
Connection Options
1 Transmitter 1 Receiver
1 Transmitter 2 Receivers
2 Transmitters 1 Receiver
2 Transmitters 2 Receivers

4
Hardware Installation
STEP 3
Connect one side of the HDMI cable to the receiver and the other
side to your HDMI display device
STEP 1
Install the antenna to the receiver
Receiver
STEP 2
Connect the IR receiver extender cable to the connector
STEP 4
Connect DC5V/2A power adapter to the Receiver power input port
1
2
3
4

5
Hardware Installation
STEP 1
Install the antenna to the receiver
Receiver
STEP 2
Connect the IR receiver extender cable to the connector
STEP 4
Connect DC5V/2A power adapter to the Receiver power input port
STEP 5
You can now connect to the transmitter by selecting the same
channel number as the transmitter from either of the receiver(s)
connected to your TV(s)
STEP 6
Wireless connection indicator of the transmitter and receiver will
light up when the transmitter and receiver connection is
established wirelessly
If your video source and your display is on, you should be able to
see the content of the source on your display
NOTE: When the wireless signal is transmitted through walls,
glass or other obstacles there could be signal degradation. It is
advisable to install this device in a clear environment with few or
no obstacles if possible
ReceiverTransmitter
CHANNEL CHANNEL
5

6
FAQ
QTransmitter and receiver will not connect wirelessly
A1. Please check if the wireless connection light is on and blinking
2. Restart both transmitter and receiver
3. Reconnect HDMI cables
QMy transmitter and receiver are not connecting
AMake sure the channel numbers are the same on the receiver to the
transmitter that you want to connect to
QThe wireless indicator is on but nothing on the display
APlease check and see if the video source is working correctly by
connecting the HDMI cable directly to the display and see if the
operation is now normal
QVideo is flickering or not stable
A1. Change the position of the transmitter and receiver and make
sure that they are within the specified operating distance
2. Restart the transmitter and receiver
3. Reconnect the HDMI cables
4. Check for any obstacles that may block the wireless signal from
the transmitter to the receiver

Compliance Information
Limited Warranty
Contact
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential setting. This product
generates, uses, and can radiate radio frequency energy and, if not installed and used as
directed, it may cause harmful interference to radio communications. Although this
product complies with the limits for a Class B digital device, there is no guarantee that
interference will not occur in a particular installation.
CE Statement
This device has been tested and found to comply with the following European Union
directives: Electromagnetic Capability (2004/108/EC), Low Voltage (2006/95/EC) and
R&TTED (1999/5/EC).
This product carries a 1 Year Limited Warranty. For the terms and conditions of this
warranty, please go to http://www.iogear.com/support/warranty
Register online at http://www.iogear.com/register
Important Product Information
Product Model
Serial Number
WE’RE HERE TO HELP YOU!
NEED ASSISTANCE SETTING UP THIS PRODUCT?
Make sure you:
1. Visit www.iogear.com for more product information
2. Visit www.iogear.com/support for live help and product support
