IPGARD SA-DMN-DP-P User manual

4 Port DP secure KVM switch
1 2 3 4ST1 ST2 Full PIP QuadT QuadQ
SA-DMN-DP-P
CONSOLE
12VDC2.0A AUDIO
K/M
AUDIO AUDIO AUDIO AUDIO
K/M K/M K/M K/M
CAC
CAC CAC CAC CAC
IN-1IN-2IN-3IN-4
DP Preview DP OUT DP IN4 DP IN3 DP IN2 DP IN1
TECHNICAL SPECIFICATIONS
SA-DMN-DP-P
Advanced 4-Port Secure
Single-head DisplayPort KVM
Switch with Audio, CAC Support
and Preview Screen
Quick Start Guide
VIDEO
Host Interface (4) DisplayPort
User Console
Interface (2) DisplayPort
Max Resolution 3840 x 2160 @ 30Hz
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
USB
Signal Type
USB 1.1 and 1.0 Keyboard and
Mouse only.
USB 2.0 for CAC connection.
USB Connectors (8) USB Type B
User Console Interface
(2) USB Type A for keyboard/mouse
connections;
(1) USB Type A for CAC
AUDIO
Input (4) Connector stereo 3.5 mm
female
Output (1) Connector stereo 3.5 mm
female
POWER
Power Requirements 12V DC, 3A power adapter with
center-pin positive polarity
ENVIRONMENT
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
CERTIFICATIONS
Security
Accreditation
Common Criteria Validated To
NIAP, Protection Prole PSS Ver.
4.0
OTHER
Emulation Keyboard, mouse, and video
User Controls Front-panel buttons
WHAT’S IN THE BOX
PART NO. QTY DESCRIPTION
SA-DMN-DP-P 1
4-Port SH Secure DisplayPort KVM
with Audio, CAC Support and
Preview Screen
PS12VDC2A 112-VDC, 2-A power adapter with
center-pin positive polarity.
1Quick Start Guide
A full manual can be downloaded from
www.ipgard.com/documentation/
DESIGNED
AND MADE
IN THE USA
NOTICE
The information contained in this document
is subject to change without notice. iPGARD
makes no warranty of any kind with regard
to this material, including but not limited to,
implied warranties of merchantability and
tness for a particular purpose. iPGARD
will not be liable for errors contained
herein, or for incidental or consequential
damages in connection with the furnishing,
performance, or use of this material. No
part of this document may be photocopied,
reproduced, or translated into another
language without the prior written consent
from iPGARD, Inc.
20170518
Toll Free: (888)-994-7427
Phone: [phone]
Fax: [phone]
WWW.iPGARD.COM

EDID LEARN HARDWARE INSTALLATION
1. Ensure that power is turned off or disconnected from the unit and the computers.
2. Use DisplayPort cables to connect the DisplayPort output ports from each computer to the
corresponding DP IN ports of the unit.
3. Use a USB cable (Type-A to Type-B) to connect a USB port on each computer to the
respective USB ports of the unit.
4. Optionally, for CAC models, connect a CAC (Common Access Card, Smart Card Reader) to the
CAC port in the user console interface.
5. Optionally, connect a stereo audio cable (3.5 mm to 3.5 mm) to connect the audio output of
the computer(s) to the audio in ports of the unit.
6. Connect monitor(s) to the DP OUT console port of the unit using DisplayPort cable(s).
7. Connect a USB keyboard and mouse in the two USB console ports.
8. Optionally, connect stereo speakers to the audio out port of the unit.
9. Finally, power on the secure KVM switch by connecting a 12-VDC power supply to the power
connector, and then turn on all the computers.
Note: You can connect one monitor to the single-head KVM switch. The computer connected
to port 1 will always be selected by default after power up.
Note: You can connect up to 4 computer to the 4 port KVM.
DESIGNED
AND MADE
IN THE USA
The KVM is designed to learn a connected
monitor’s EDID upon power up. In the event
of connecting a new monitor to the KVM, a
power recycle is required.
The KVM will indicate the unit’s EDID learn
process is active by ashing the front panel’s
LEDs. In sequential order. Starting with the
LED above button “1” on the front panel,
each LED will ash green for approximately
10 seconds upon beginning the EDID learn.
Once all the LEDs stop ashing, the LEDs will
cycle and the EDID learn will be complete.
A monitor must be connected to the video
output port located in the console space at
the back of the KVM during the EDID learn
process.
If the read EDID from the connected monitor
is identical to the current stored EDID in the
KVM then the EDID learn function will be
skipped.
AUDIO IN
CAC IN
DP IN
USB IN
Input Connectivity Output Connectivity
AUDIO OUT
CAC OUT
DP OUT
USB OUT
1 2
3 4
SA-DMN-DP-P
1 2 3 4ST1 ST2 Full PIP QuadT QuadQ
SA-DMN-DP-P
A full Manual can be downloaded from
www.ipgard.com/documentation/
